3D Toon Rendering in 'Hi-Fi RUSH'

[Music] hi everyone uh thanks for attending our session it's pretty late in the day but thanks for making it out to hear our talk uh this is tune rendering in Hi-Fi rush and before we start uh GDC told us to remind you to make sure your cell phones don't make noise and uh fill up the survey after the art talk okay we'd like to start off the talk with brief speaker introductions hi I'm Kos I've been working as a graphics programmer at Tango Gameworks since 2011 for high-fi rush I worked as lead Graphics programmer working on our core tune rendering I went from from bloody VFX for zombie head shot and Moody survival horror lighting to tune

hi I takash I am a I am a graphics and physics programmer I've been working as a programmer at Tang game marks since 2016 on highi lash I was Graphics physics and animation programmer here's the agenda for today's talk I'll cover the core tune rendering topics in the blue frame and kada San will present our tace shadow implementation in the green frame okay I'm going to start off with a brief introduction of our game so before I start uh how many people here have played our game can you raise your hand oh wow that's that's a

lot thank you okay yeah okay okay great okay but some people didn't raise their hands so not all of you have played our game so I'd like to introduce our presentation popup characters first the character on the left kale is one of the enemy characters in the game since he's an evil guy he'll mostly be making difficult demands for the graphics team the character the character in the middle chai is the main protagonist of the game since he's our friendly hero he'll mostly be making enthusiastic comments and finally the robot on the John right is John despite not having a catchy food name John made a strong creative push for our TB visuals had a conveniently available texture and is high-fi Russ's creative director so I've included his

comments okay it's the main topic of our talk today but high-fi Rush is a game utilizing tune rendering a lot of games use tune rendering for characters but not the environment in our game everything is rendered in a tune style a big challenge for the graphics team was how to utilize Unreal Engine fors modern Graphics Pipeline and make it work for a 2d tune look another defining characteristic of our game is that we're a rhythm matching game that requires a rock solid 60fps in order to minimize input latency and provide the best gameplay feel programmers and artists were told from the very start of development FPS is top priority but at the same time we were going to support the New Gen n hardware and the team wanted to pursue great

graphics that would do justice to the hardware with goals of great graphics the keyword that are art director defined for the team were sharp clean and colorful I'll go over the technical makeup of our attempt at great graphics in more detail but notice that two of our key words were sharp and clean image quality was very important to us and in addition to high frame frame rate one of the key technical features of our game is its high resolution we aim for Native resolutions on our console targets for Sharp clean artifact free image quality we're aware of super resolution Tech and we support super resolution plugins for PC and they're great because our resolution is high to begin with they allowed us to push the limits of our PC lowend specs even further

because we prioritize performance and image quality a nagging fear during development was that people would be disappointed by our technology in the end it was a great win for us that the game's Visual Arts was well received and we got great technical reviews balancing performance resolution and rendering features is hard as Graphics programmers were excited by new rendering Tech and want great graphics but our game emphasized performance and image quality and the rendering features we chose for the game were carefully considered so we could hit our goals if a graphics programmer were to introduce our game that would be it I'll now discuss our tune rendering starting off with an explanation of the cortech our deferred tune renderer Hi-Fi Rush uses Unreal Engine for which out of the box it is a photo

realistic deferred renderer and not a tune renderer the lighting is forced but this is what high-fi rush looks like when tune rendering features are disabled from the game the main pain point of the image is that if we were to use the default ue4 lighting there would be gradation everywhere and the image ends up looking too much like it's rendered using a 3D engine this is the same scene rendered with tune rendering features re-enabled this is what we were going for as a tune look Shadow gradation is replaced with sharper shadows and our comic Shader has been applied to the various 3D render passes adding a 2d touch to the image this is what sharp clean and colorful looks like for us compared to past games with strictly Soul shaded environments we Inc incorporate a lot of 3D lighting

rendering features into the game we added rendering passes like static Shadow maps and decal tune lights but we also stylized and extended the excellent based UE for graphics features such as ssao and SSR and made them work for cell shading it's possible to write a tune renderer without engine modification in ue4 in the simplest case of using U four post-process materials the TB postprocess is applied after the scene lighting is finished and most of the rendering is complete it's the simplest approach and we want it to do better since we planned on supporting many lighting features we wanted to be able to apply tune stylization to each lighting layer with their own stylization parameters another thing we wanted to improve on is that you for post-process

materials are applied per camera we felt that this was too restrictive and wanted to apply different tune colors and stylizations to different areas within the same camera to achieve our goal we customized Unreal Engine 4 and combined deferred lighting and TB post process into a single deferred tune rendering pass here's a quick review a regular deferred rendering material information are rendered into g-buffer render targets and the lighting PA is decoupled from the geometry pass Point lights are rendered with sphere geometry and spotlights are rendered with cone geometry in a pass independent from the geometry they are Lighting in a similar fashion we want to decouple tune rendering into a pass separate from the mesh's actual geometry rendering

our TB post-process volumes work like deferred lights except the Shader is a postprocess light deferred lights our artists can freely move around the toune postprocess volume to locally change the tune rendering in the slide video when I move the billboard mesh inside the smaller tune post process volume notice that its tune rendering changes at its core our t post-process volumes are using standard deferred rendering calculations we use the scene depth to recreate the world position and use g-buffer information to apply the volumes to postprocessing on not the volume box geometry but the underlying scene geometry our environment artists Place many Tom post process box volumes throughout our Levels by placing these volumes our artists adjust tune shading

locally per volume within each area of the level the above is a PIX for Windows capture of the timeline for our deferred tune rendering pipeline I'm showing you the render passes that are executed in an actual scene in preparation for the tomb postprocess pass the render pass of the Vox volumes in the previous slides quite a few render targets end up getting generated for the Tom post process past my earlier test map was very simple looking but there are quite a bit more lighting layers in an actual scene tune shaded environments tend to look simplified but there are a lot of layers to our Environmental Lighting because our deferred tune rendering is a combination of tune lighting and tune post process notice that the scene color is completely except for emiss before the tune

postprocess rendering is applied a regular deferred renderer has seene depth and G buffers for deferred tune rendering we have seen that g buffers plus the various individual lighting pass results all waiting to be applied the TST process has available to it all these render targets what do we do with them because we have all lighting results as input textures as was one of our initial goals we can apply comic stylization to each lighting layer with individual parameters because we apply all Shadow types to the scene inside the Tom post process pass we can easily control the visual look when different Shadow types overlap for example when the player Shadow is drawn inside our cascaded shadow Maps we can detect this overlap and adjust the player Shadow Darkness so

it doesn't appear too dark or light stylized shadows and side Shadows is a very cool tune thing and we want it to make it look good ue4 has a greatl looking deferred rendering implementation and it was a natural progression for us to extend it to a deferred tune renderer we tried to utilize U for strengths but at the same time didn't want to lose our own visual personality by using the engine to directly locally tun shading different areas by placing T postprocess volumes like deferred lights seemed like good usability for our artists deferring all lighting and T post processes into a single pass made sense because we wanted our artist to be able to control how different lighting layers combine and interact for tune okay that was an overview of our

deferred tune rendering next I'd like to highlight unique aspects of our tune lighting during deferred tune rendering I'll cover Shadow color 3D textures and ambient CU Maps the major requirement for our tune lighting was artists need to be able to add color and adjust brightness but it can't look to 3D to make the scene not look artificial for tune artist artists need to be a able to paint the colors themselves environment artists need a way to give color to each location our art director's keywords were sharp clean and colorful so it was important that artists be able to control the environment Shadows with the colors they wanted in the slide image the shadow color is a uniform black this is what the scene looks like with Shadow color volumes applied the black Shadows are now properly colored

with our artist authored shadow colors I'll explain in more detail in the following slides but Shadow color volumes work by mapping a 3D texture to a 3D World position here in the slide video I'm adding a new a new local Shadow color volume to the scene with a whiter grayer Shadow color 3D texture the rendering of the Shadow color volumes is like our T post process volume rendering the Shadows are not applied to the V volume box geometry but are projected onto the geometry enclosed by the box if we look carefully the shadow color volume colors gradually become darker with increasing height this positional color change happens because the enclosed surface W position is converted into the shadow color volume's normalized local 3D coordinates and this coinet is used to sample the 3D texture

the gradually changing colors inside the 3D textures are hand adjusted by artists to give the desired Shadow color Nuance our art director wants for the scene here's an interior scene and its corresponding Shadow color 3D texture for interior scenes our environment is initially unlit and in Shadow and we light by adding lighting layers to this state because the scene is initially in Shadows artists can use Shadow color volumes to adjust the overall base color makeup of the scene in addition to 3D textures for shadow colors we also use Cube maps for postprocess ambient brightness adjustments like with our shadow color volumes we apply ambient Q maps to the underlying geometry using a box

volume as mentioned earlier our interior scenes are initially unlit and to this state we add lighting layers one of which is ambient Cube Maps Cube Maps need a sampling Direction because we are a deferred tune renderer we can use a world normal stored in the G buffer for this purpose in the slide image the ambient Cube map volume is being toggled on and off notice that in the scene the underside of the surface is lit brighter than the top in the sides representing a difference in directional ambient brightness this this directional brightness comes from the Cub map texture which are environment artists create by hand okay I'd like in the next section I'd like to talk about our comic shaders it's a recognizable trait of our tune look but we implemented a comic

Shader for rendering half tone dots and hatching lines half tone dots are the round dots that we apply to the lip portions of our lighting hatching lines are the rotated lines we apply to the dark shadowed areas of lighting the goal of our tune renderer is to render a 3D world as 2D tune our comic Shader is a stylization but at the same time it's an important element in our deferred tune rendering for making the world look less 3D and more 2D tune here's what a scene from our game looks like with the comic Shader turned off ssao gii Bloom make the world look richer but since we're just applying 3D engine functionality the final image looks 3D also the performance oriented low sample count nature of some of our

rendering passes become especially noticeable on our clean tune textures here's what the scene looks like with the comic Shader enabled the scene is stylized but at the same time gradation is removed making everything look less 3D the dirty look of GI and ssao have been made sharper with lines and dots and the image looks much cleaner here's the comic Shader on off as an animation 2D sign distance functions are often used in procedural shaders for our comic shaders programmers use sdfs to create the comic Shader half tones and hatching lines procedurally inside our shaders we just B do basic stuff in terms of SDF but for clarity I'll go over an examp example half tone

Shader my example is a postprocess which uses screen space UVS the first step is to calculate the distance from the center of the screen if this distance is below the half tone radius we draw a white color if the distance is above the half tone radius we draw a black color we C we take into consideration the aspect ratio to go from a ellipse to a circle we want large we don't want large circular dots but want multiple smaller dots in a grid across the screen using the Frack instruction we scale and wrap the screen space UVS art wanted half tones rotated 45° for this we just rotate the grid UV because we are using a simple 01 step function for the distance function threshold aliasing can occur

by using smooth step instead of step and Alpha blending the boundary regions of the halone dots we can implement anti-aliasing the area inside the Yellow Frame is the width of the smooth step function where AA is applied since we want to apply anti-aliasing only on the threshold border pixel we use DDX ddy instructions to calculate the per pixel rate of change of the distance function and use this value as the basis for our width UE for's temporal AA blurs the half tones so the AA is only obviously noticeable on half tones applied after TAA such as our Bloom half tones the difference also becomes not very noticeable with camera movement so the benefits of AA is somewhat limited for us but we kept the calculations for the moments that the user might notice the difference

so that was an explanation of half tones are rendered using screen space UVS hatching lines are the same Shader code just with uvy fixed to zero for effects such as Bloom and volumetric fog we use screen space UV coordinates in actual scenes we don't do anything complicated an example Shader is close to how we render actual in-game screen space Hal tones screen space UVS work well for stuff without B such as Bloom and volumetric fog but on actual polygonal surfaces we want our half tones and lines to look as though they are printed on the surface and not attached to the front of the camera for these cases we use World space UVS to calculate the world space UV we use the G buffer World space normal to calculate the dominant axis of the surface and just project on to this axis's plane for example if the zv value

is largest in the is the largest direction of the world normal we want to project onto the XY plane and so we simply use a scaled World position XY as our UV coordinates for intersections of planes we don't use tripler mapping we experiment with it but blending artifacts were noticeable and we simply project onto a single plane I didn't get complaints about the half tones and lines cutting off at the plane intersections and the final implementation was kept simple one important one final important feature of our comic Shader because we prely generate our half tones in lines we can easily adjust their look based on the scene lighting conditions we use seene luminance to adjust half tone and hatching line sizes for the image in the slide the GI Hal tones become larger the closer to the

emissive light source and smaller the further away it's a simple technique that allows us to express the lighting's distance attenuation while avoiding gradation which makes our scene look more computer generated okay the next section I'd like to move on to our tune lights HiFi rushes tune shading uses a simple two-tone Lich shade tune shading model the tune shadings lit shade calculation is not performed in a deferred pass but is calculated by a global key light that is forward rendered in UE fors base pass we chose the Ford render our key lights because we could do so without ue4 engine modifications in later stages of development we began you utilizing ue4 render commands for data passing and render thread delegates for render pass callbacks that would allow us to

implement original render passes gam side we're now more experienced about how to approach u4 engine modifications but that realization came after our core Tech was implemented we eventually needed to support two key lights and it may have been more performant to associate the key light with a Tom post process volume and render it in the later deferred past our lighting's mix of deferred and board is probably something we can improve on besides key lights artists can use familiar light actors such as Point lights and spotlights to perform local Environmental Lighting for placable lights again we supported forward lights for the same reason as key lights a lot of smaller teams probably struggle with this but how much ue4 engine modification is safe is something we struggled with especially es in the earlier phases of

development we initially experimented with forward lights but decal lights which run in an original deferred paths were easier to optimize and eventually more useful for our artists my tlight explanation will focus on decal lights since they're more interesting usually with placeable light actors in a 3D engine light distance attenuation is ex is expressed with color gradation for Hi-Fi Rush this was a big no because using gradation led to the scene looking 3D in addition to half tones and hatching lines we use cutouts to 2D stylize our tune light distance attenuation the colors become darker the F further away from the light source in cutout steps the scene in the slide looks unlit add a decal light with cutout light

attenuation and the scene is lit by a 3D light without making the scene look 3D decal lights support arbitrary cutout textures our art director prepared seven cutout texture patterns to give variation to the decal lights used throughout our Maps decal lights are Hi-Fi Russia's deferred lights and so when a decal light is placed in the world they are deferred rendered with a sphere or cone geometry just like regular deferred lights decal lights namesake and what makes them special is that they can be assigned to a decal light decal volume to render as a decal environment artists can place lights as light sources in a traditional way but they can limit the projection volume of the light separately using decal volumes

one obvious benefit of projecting to a decal volume is a smaller area to render and better performance in addition to Performance decal lights provide finer artistic control over which parts of the environment the light affects for example we can add a separate decal light with its own projection texture specifically to light the wall the scene displays a star out projection for the ground but a tier cutout projection for the wall in The Evil Within too our PBR lights could use clip volumes to prevent spotlights from light leaking to the Next Room decal light decal volumes also function as clip volumes and can prevent light leaking some of you might be wondering doesn't decal volumes mean characters

are properly lit let's try lighting our game's hero chai with a decal light in Hi-Fi Rush character lighting is a separate system from Environmental Lighting forward lights and decal lights don't affect characters next I'd like to explain what we do for shadows in Hi-Fi Rush having proper Shadows for the environment and characters is extremely important for Quality even in tune rendering Shadows can be very performance in intensive if applied without a strategy in ue4 Shadows look good but can be costly to balance quality and performance we were very careful in how we chose to render our shadows we limit Shadow casting lights for performance t lights are unable to cast

Shadows for outdoor environmental Shadows we use ue4 standard cascaded Shadow Maps we have our own pre-bake static Shadow map system and use it for parts of directional Light Shadows for performance but for the most part we needed the extra quality that Dynamic shadow cascaded shadow Maps provide us with for dynamic Shadows other than cascaded Shadow Maps artists are required to use Shadow only Lights Shadow only lights are customized ue4 PBR lights specializing in only casting Dynamic Shadows because we were going for a 2d tune look having different lights for lighting and shadowing was not a problem an exclusive Shadow only light was assigned to the player character in outdoor areas the player Shadow is not drawn by by the cascaded shadow mod but by this separate player

exclusive Shadow only light giant bosses are allowed their own shadow only light because their Shadows can look very dramatic the character Shadow only light in the slide doesn't cast Shadows from the player or the environment and only cast Shadows from the giant boss player shadows and some of our static Shadow maps are drawn with stylization for the shadow to light transition the hatching lines become thinner the further away the shadow becomes from the shadow casting object representing a 2d tun style light Shadow to light transition non-player characters use the more coste effective capsule Shadows for their shadowing capsule Shadows are standard ue4 functionality artists prepare capsule shapes to approximate the character mes and these shapes are used to calculate

per pixel visibility towards a global Right light direction to approximate soft Shadows it wouldn't work for a photo realistic game but we can get away with the Blobby look of capsule Shadows because we are tuned because capsule Shadows don't require shadow shadow casting local lights we get coste effective character shadows Outdoors indoors regardless of lighting conditions capsule Shadows become too large and disperse for small characters that are floating in the air far away from the ground for these characters we implemented a simple AO volume decal system CPU raycasts are used to find the proper decal placement World position finally we also allow a single Shadow only Spotlight for the environment team and that's all they get it's

a they worked hard for the scene in the slide a shadow only light casts exclusively from the moving giant robot arms the only thing Shadow only lights can do is cast Shadows but just like for the character boss Shadows a well-placed shadow Spotlight can be very dramatic in a tune look I've mentioned we have a static Shadow map system I'd like to explain this system in more depth in this next section static Shadow maps are offline baked Shadow Maps they are important for us both in terms of performance and artist ease of use u4 has a static Shadow map system which is integrated into light Mass baking but we created it our own for better integration with our deferred tune rendering pipeline Shadow mapping is composed of two steps

the first step is light SP space depth map generation from the perspective of the Shadow casting light the second step is comparing the pixel's light space depth against the depth map to generate the actual Shadow map what we pre-bake in static Shadow Maps is the first step map capture step in the slide image I'm toggling on and off the static Shadow map display their environment team has strict limitations on Dynamic Shadow map usage and interior environmental shadows will typically Disappear Completely without static Shadow maps by placing static Shadow map actors in the environment environment artists can use static Shadow Maps the static Shadow map actor is composed of two components a scene capture camera for capturing the depth map and a deferred box volume for rendering The Shadow map when the static Shadow map actor is

selected the captured depth map is displayed in the lower right corner of the screen in the editor artists use the dep map preview in the lower right portion of the screen to manually maximize dep map coverage of Shadow casters to sha to improve Shadow map quality standard comparisons between the pixel's light space depth position and the depth map Maps light space depth position are performed to render a screen space Shadow map inside the static Shadow map decal volume without AA our screen space Shadow Maps look very jaggy we use 4x4 PCF for anti-aliasing our shadow Maps here's a gif animation of 4x4 PCF being toggled on and off as you can see the algorithm does a pretty good job of alleviating jaggies for

us here's a screenshot of static Shadow map camera placements in an actual scene many static Shadow map cameras with small coverage are placed throughout our levels each stat static Shadow map camera renders its own depth map and its Associated render volume owns that static Shadow Maps depth map texture data even the small handrail in the slide image has its own static Shadow map our artists use many static Shadow map cameras not just for artistic reasons but for texture streaming efficiency as well one of the first concerns we had when we considered using static Shadow Maps was memory usage and streaming hitches we managed static Shadow map texture streaming workloads by monit monitoring texture size and focusing on being being able to efficiently distribute streaming across

multiple frames for this reason we can't have individual static static Shadow map textures being too large our static Shadow maps are placed in their own streaming level and within the streaming level we distribute texture streaming across multiple frames by placing a per frame streaming memory limit the final topic I'd like to talk about is how we handle Global illumination Global illumination is being toggled on and off in the slide image we felt supporting standard 3D lighting features in our tune rendering was important for quality and this included GI we decided early on that we wanted to try to use ue4 light MK since we were satisfied with its quality and baked lighting is great in terms of performance at the same time we also thought thought a workflow using light Mass light Maps was too costly for our

artists due to needing to deal with light map UVS and possibly long GI bake times tune assets require artist handcrafting for quality and all artists including our environment team were super busy throughout the project we had noticed that light Mass volumetric light Maps could be used for the environment light Mass volumetric light map light probes bake faster and don't require light map UVS we decided we would customize the volumetric light map functionality with a focus on further improving bake iteration speed and usability a big factor that allowed this customization is the fact that our game has a tune art Direction and we can be artistically selective in which parts of the map we apply Global Illumination in the slide image only a small area around the window has Global illumination and

that can be okay for our look here the same level with the GI light probe debug display is enabled the environment artist has decided to bake probes around strong em missives but in areas without a strong light source no probes are baked ue4 has a functionality called light Mass importance volumes that limit light probe baking to the area within the volume we customize this functionality to implement our own Global illumination lighting volume actor in vanilla ue4 light probe data is stored per level we customize ue4 so that in our game light probe data can be stored per actor I should mention that we did optimize the ue4 volumetric light map data to save memory because we only need

directionless ambient Global illumination we cut down the light probe spherical harmonics 3D textures from 8 to1 and it's a huge memory saving since I emphasize bake iteration speed and usability as key points I'll give a quick overview of what our GI bake workflow looks like we start by enclosing the area we want to add Global illumination to with a GI writing volume after the volume is placed artists select from the menu build selected volumes a customized light Mass GI baking code is executed and the GI bake is limited to the area enclosed by the lighting volume bake times are dependent on light mass settings and PC specs but as a general idea for a standard de PC at our company a bake should finish in a minute or two since the bake is isolated to the selected actor artists can iterate

baking on specific areas quickly the GI lighting volume contains parameter for for both baking and rendering an often used parameter for baking is the detail cell size parameter which controls the distribution granularity of the generated light probes our environment artists use this parameter to balance bake quality and memory usage finally the GI lighting volume not only defines the GI bake accent but also serves as a rendering volume here I'm toggling on off the GI box rendering for a specific volume note how all the other volumes in the scene are unaffected by the toggling Deferred rendering a box volume is a local lighting technique that is used throughout our game and makes a final pres presentation appearance in this slide here are my main references now

I'm going to hand it off to kadan for a section on our Tech our tace shadow [Applause] Tech okay I'm going to explain the face shadow of highi rash in this section the self Shadows of the character in highi rash are in a s shaded style the shadowed and non-shadowed areas are clearly separated and the shadowed areas are given a specified Shadow color with shadows like this the quality

is all about the choice of the Shadow color and the shape of the Shadow Area highi art concept was sharp clean and colorful so the Shadows also needed to always have clean shapes whether pixels in the inner Shadow area is determined by whether the dot product of the pixels normals and the light Vector is less than the threshold this is a typical method for cell shading the btic normal is used for the normal however this method is not used on the face the face requires higher quality than other parts however there are problems in

achieving the desired quality with btic normal Shadows the first problem is that uh using btic normals makes it difficult to create a smooth curve as showing in the image on the right depending on of the direction of the light the shadow shapes can become quite messy it it is because there is a limmit to how much geometry can be divided and the shadow shape is affected by how it is divided the second problem is that the shape of the Shadow created by Vex MTH is easily broken by facial motion when the body bone orientation changes due to facial motion the Ori tion of the Vex normals also changes which unintentionally break the

shadow shape in this Chine where the facial expression is Extreme the shadow shape becomes considerably broken depending on the direction of the light the third problem is that it is difficult for artists to make adjustments artists can just geometry and vertic normals but it is very difficult for them to avoid problems one and two completely through manual adjustments it is difficult to intuitively understand the resulting shape of the Vex normal and geometry adjustments in all the various lighting directions even if you use a normal map in instead of B normals problem one may be solved but

problems two and three will not be solved to solve these Vex normal problems in highi rash we use the height map height map like texture internally we call this texture a thresold map I will explain how toite in later slides but we will first explain the calculations involved first calculate the angle between the horizontal component of the right direction and the forward direction of the head the horizontal component here refers to the horizontal component in the C C systems of the head bones the threshold value is in is the angle divided by pi and normalize to a

range of 0 to 1 then it is determined whether the area is Shadow area or not based on whether the sample value with the threshold map is greater than the threshold value since only the horizontal component is considered the shadow can only be moved in the horizontal Direction however this has enough for high highi rash in this video the light is shining on the right side of the face but when it is on the left side the texture is reversed horizontally how to use this threshold map is a reproduction of the method introduced in the session by mhoo at

Unity s 2018 I will now explain how to auor a threshold map first use a deat to bake the Shadows of the face into textures by moving a direction directional right at fixed angles 180 deg around the character as shown in the image we move the light every 5° so we B to 36 textures at this point Shadows Shadows are shaded using the vertic norals so the shape may not be smooth or Shadows may appear in unnecessary areas these textures are then rached to the artist

satisfaction this process create a clean shape so artist don't have to create perfect vertic normals as you can see retouching textures is much more intuitive to adjust than vertic normals artist can preview the final look of the Shadows in our DCC to finally using a dedicated inhouse tool all textures are interpreted like a distance or field interpetation and merged into a single texture the threshold map is now complete I now review how thresold map solved solved our original verx normal problems regarding problem one the shape does not

become a smooth cve with a B normal but with a thresher map it is always smooth as shown in the video this is thanks to the artist adjusting the shadow shape through retouching also since the texture the connect uh textures are connected smoothly using distance field like interpolation the shape changes smoothly when the direction of the light changes as aside aside thr map have similar characteristics to distance field textures and are less PR to artifacts even when the resolution is lowered however in order to maintain sharp shape even when zo camera camera zoomed in we use 2K textures problem two where the shape is broken

due to facial motion does not occur with a threshold map because in case of threshold map the shape is mapped with u v so it's not affected by bones as an example let's change the direction of the light and compare when shading with a threshold map Shadow shape are green in all right directions problem see is that shading using btic normals is difficult for artist to adjust again in the case of a threshold map artist can intuitively modify the shape by raching the B textures when shading using vertic nor the Vex norals were directly used for

shading when shading us a user using a thres map in between light light baking and texture marging there is a step where artist can make intuitively quality adjustments this concludes the explanation of our face shadows in our game thank you [Applause] okay that's it for the content of our presentation but I'd like to end our talk with some final concluding words so our game wanted to do a stylized cell-shaded look for both characters in the environment and this presented unique rendering challenges unique problems call for Unique Solutions and we developed an original deferred deferred post-process volume approach for our attempt at tune rendering we're using ue4 and we adapted

many 3D graphics features for tune rendering we use wellestablished Graphics techniques and build on the great works of others we talked about tech today but it's tune rendering and as you can imagine there was a lot of crafting and optimizations by our artists not covered today that ultimately determined the quality of the tune Graphics we had goals of Rock Solid 60 cfps high resolution and greatl looking tune and the tech we talked about today helped the Hi-Fi Rush team achieve these goals and we had more we had more Tech we wanted to share info about but uh probably be too much of us talking so we didn't do that and but we do have bonus slides at the end of the presentation so when the slides become available for download uh everyone can read them and our final page is a our special

thanks page we get to present this stuff but our tune rendering was made possible by the hard work of everyone on the high fir Rush team our final slide is a special thanks space to give a shout out to all the people who made today's talk possible okay that's it [Applause] so we have time for a little bit of time for Q&A so if people have questions please go to the Mike's hi uh I have a question um first of all fantastic talk uh second I um when you were talking about all the The More Physical 3D features um I couldn't help but notice that you didn't include um other PBR inputs like roughness um and metalness do you think was that a conscious decision to exclude those cuz

they didn't add anything or um what was the thought process and was am I right that your final uh only texture inputs to like the Deferred PBR workflow or deferred lighting workflow was just color Yes we just use color in in fact oh we we do use roughness because we have SSR so we use the standard UE for SSR at its uh low lowest setting that's about 1 millisecond but it's still u4 SSR is great at the low setting and it looks good and we apply uh a tun stylization to that SSR and use it so we do use roughness but metallic we don't need and uh yeah we don't do standard PBR I think it's mostly base color and roughness for us got it thank you and uh our bonus slides include a section on uh our G buffer stencils we actually use the the G buffer u4 GFF offer slots that we don't use for uh stencil bits that we

use in our tun rendering got it thank you y hi um how well did your artist receive this uh more unique lighting uh pipeline I'm I'm sorry I couldn't guess yeah how well did your artist receive this uh kind of unique lighting pipeline well we made the pipeline with artists so I worked with the environment lead environment artists to create the pipeline and like our ambient our shadow color volumes and our ambient CU maps that I wor part of that was suggested by them and they were they this is what they this was necessary for the look we were going for so they were all in thank you does that answer your questions sorry yeah yeah didn't answer the question okay hi I had a question about the threshold Maps so if I'm understanding correctly

are you creating a Sprite for merging all of them together and then are you doing any special processing for the base color textures to look sharp just show them up can can you ask can you come back with that question later okay sorry sorry uh hey I noticed that you guys use a lot of Shader code in uh like in your presentation here uh I wanted to ask if there was a an advantage over using a Shader code over like node-based uh Shader uh we use Shader code because our materials were all implemented by programmers so it's it's actually more confusing us for us to use Shader code and one of the benefits of using Shader code we we save all our Shader codes out into a text file and you know uh Le manage it through perforce and we can search what other programmers you know

Shader code easily so it's more it's easier for us to write and it's easier for for us to you know check up on what what Co what the code that we wrote cool thank you if there's no more questions thanks for attending our talk [Music]
