Take 'Control' of Animation

[Music] hello and welcome to our presentation my name is vila rustia i'm a principal animation programmer here with me presenting is il principal gameplay animator we both are from company called remedy we are quite small studio in finland famous from our story driven action games such as max payne alan wake quantum break and our latest control in this talk we will go through how we build our own animation technology how we took the responsiveness to the next level how we started using this quite new deck called motion matching how we created animation friendly tools and how of course how we survived through all the craziness that was happening around us with the project but before we start here's a video of control

[Music]

[Music] in quite early in the project we sat down and started laying out our core game goals we wanted to make a fast action game this means much stronger focus on gameplay what the quantum break was this also means that the animations can't compromise controls it needs to be twice as responsive what the quantum break was we got a lot of feedback on that for action we of course need more enemies on the screen this includes supernatural abilities include flying and throwing objects so how to make game responsive this for us this means code driven movement it needs to work without any animations and it needs to be easy enough that even

the designers can iterate for animation part this is quite tricky so i started evaluating like different options and i found out motion matching it seems quite good candidate so what is motion matching it's a tech originally presented by ubisoft in 2015 nuclear ai and then brought to the bigger audience in 2016 gdc it's a database of animations we predict the path based on the player's input and then the ai path we search through this big database to find the frame which best matches the character's current pose and the path we generated this search is then repeated every frame so in action we have a character and we have a path we have a bunch of points in a path some in the future some in the past then we have a points in the character such as angle positions velocities hip direction

and then the head height then we have generate offline the same information for animations we run through this search through this database and compute cost for each frame then in the end we pick the one with the closest in this case it picked really well so i started making prototype at that point we were using more theme as a middleware so i added a custom node to it and then simple path prediction for animations we use the ubisoft dance card as a reference i added the motion shader which defines how exactly the posing trajectories compared we chose to use the data driven approach to allow quick iteration what features we need

so i exposed potion position velocity and direction for trajectory channels i added support for specifying the time so those points those channels could be in the future or in the past for bones the information is only relative to current frame in order to control this we i added a bunch of markup i split the locomotion state in the idle start stop and move then we went through all the animations that were in the database and tagged those based on these and this is how it looked so we have our test character walking around with generated pad the path is the one that is in the ground and the character is following quite nicely and all this data is just the raw data

we didn't do much of editing with this and it seems to work surprisingly well with this so we were happy with this prototype we were also happy with the runtime characteristics of it the motion matching only needs some small internal state like animation index and time it's so small that we could easily like use that even in the multiplayer game the memory usage is also good it's small and consistent and it it's same in each frame but then surprise happened morphine goes out of market so i had to stop doing this prototype now we need to now we need to have a light options we checked the havoc behavior granny animation studio and some others but there's not really anything similar available we would also have to build quite a lot

of tech on top of those middlewares but those mirrors also share the risk of going out of market seems that for us the best option is to build our own tech and for that we need a plan with past experience we wanted to focus on performance runtime performance and the fast iteration we wanted to simplify the graphs so we wanted more powerful nodes doing complex operations such as motion matching which we chose as to be the core feature the old playercraft was close to 10 000 nodes the top picture you can see it's just a small fraction of complexity that we had we chose then that we want to use the expressions instead of math nodes all those gray boxes that you can see in the top picture are actually mad nodes then we picked the best features from

the old middlewares and no state machines i will cover that in a later slide so we started with co-driven moment only single plane three input and internal variables and expressions and this is how it looks so we have a motion matching that will cover the core locomotion then we have an animation clip to handle mantling the select will pick uh either one depending on the player's action then we have a more traditional notes such as feather blend and blend n the blend n covers the a matrix and the fader blend then applies it only to upper body the two bone ik fixes the aiming hand in right place for expression i created own expression language quite similar to shader languages i hooked that one into graph

which runs before the graph is evaluated this allows us to compute internal variables so the input variables are the ones that come from the game the graph variables are the ones that are computed the graph itself can use both of these in addition to that i write expression node it's a node in a graph it can be placed in any point there and it only runs when the node is active it can modify bones or compute variables for next node it's really good for prototyping features such as different ik setups but then second surprise e3 demo so we just got this deck running and now we have six months to ship hands-off demo it needs to have a functional mission multiple player abilities four enemy archetypes and everything needs to run on new tech

we need survival plan for locomotion we chose to use motion matching fall we don't have time to do anything else in order to allow multiple animators to work with this we need to split crafts into layers luckily we have the expressions to make up all the missing features that we have and luckily we also have time to work with the tech so we added animation mixer it defines the graph order so you can choose if a graph is running in the prefix or postphysics after dialogue lines are at the time timelines each of these graphs here are on files they can define their own set of phones and they can be shared quite easily because their own files so you can use it with different characters in order to handle the layering i added

the input post it allows craft to read bones from the previous layer mix it and then if that node is not active in the layer it can skip the previous ones as optimization so what it means that no state machines it means no animist animation specific state machine the main idea was that we combine it with the gameplay and ai this would then reduce the possibility that these state machines would be mismatching it was quite big issue in a quantum break for example quantum break is quite famous with the infinite fallback i i spent like one at least one month trying to fix that one and there's still some cases in a shipped game so how we do this then we have a higher level actions in a pla

in a blend tree we have a select node which chooses which action is active each of these actions then have a transition node using the motion matching it speaks the best transition to come into this then there's the main sequence which handles the switching then to the main loop this could be a simple case like the idle loop in here or it more complex like motion matching running or traditional blend tree but actually these features are coming soon we are not done so we have to cover this somehow luckily we have this expression language we can use it to build temporary state machine to handle the handle all these transitions and then use timers to time when the transition is ending this is not the nicest way but at least we all we managed to continue the work

so meanwhile we started working with this match node it's same kind of database of animations as motion matching in addition it has target position and rotation coming from the code it picks the best animation a starting frame using the same also matching search to actually reach target it has built-in motion warping support and it also allows to do the animation driven movement so to control this we added some markup the the match range defines like where the animation can be started this allows to use like different distances for where to start the animation the warping is also controllable by this markup so the position and rotation can be choose that happens in certain frames

so in action we have a character that is running at this point it decides that it wants to go in the cover so code generates the target the motion matching picks the the result at this case it picks something in further in the animation so the positional warping is 73 percent this point we scale this to actually handle the blending nicely and to see this in in full action just a clip i like and as you can see the result is 100 percent so it's perfectly matching the target at this point i will switch to iloca it will cover the more animation-specific things

hello i'm mika kozela principal gameplay animator at remedy and i was working on control as the animation lead and one of our first challenges for the e3 demo was how to make locomotion work with motion matching our motion matching was pretty much in a state where wheeler left it when starting to work on the new technology and we were hitting the infamous 80 quality we had all the normal motion matching issues start animations didn't always work stops almost never worked there was some sliding even more when converted to cultural motion sometimes the character would just get stuck in a single pose and often it just looked like the character was running weirdly and then when you debug it turns out he's looping some single cycle from a random animation and since all the coders were working on getting the technology ready for e3 there was no time to improve upon

motion matching itself so we needed to shift the demo with what we had and the way i started to approach approach morse and matching was that i need to learn how to think like the algorithm once i understand how it works then i can start to provide it with animations that work with it and if something isn't working i can deduce why that's happening and often it's pretty simple if you provide motion matching with the kind of animations it's looking for it's gonna work well so we needed to create animations that match the kind of paths what the game was requesting so we created this kind of animations that had accurate speed and correct acceleration curves and that of course eliminates sliding and also improves the way motion matching works here's a workflow example

so we have a script in motionbuilder and you could specify the movement parameters so you would put the same values what the game was using here and then we can define what is the direction we are coming from and where do we want to continue after this animation and at what speeds and then when you run the script it will generate movement for the trajectory for example here i generated 180 degree turn we would bring in motion capture typically it's quite far from the movement what we need for the game because the game tries to be so responsive but then with some editing we could make it much better with the game movement now of course since we are doing this much editing on every animation we couldn't pull off a large database of animations like i suggested in the earlier motion matching talks

so instead we chose to create a pretty traditional set of animations with start stops turns and so on and turns out that this kind of data set works just fine with motion matching end result is more or less similar to putting the same animations into a state machine and doing this kind of animations got us to a point where start animations were working stops were working there was less lighting thanks to matching the movement between animation and code we still had the problem that sometimes the character would get stuck in a single pose it looks like this and this started happening when we started adding turn animations to our database and specifically it happens when the player is trying to walk an arc like in this video and the reason this happens is that in order to walk a pattern like this the player has to be continuously changing

the input in order to keep turning but the prediction always assumes that we will keep the current input so in practice it's looking for the kind of data that begins with the turn but then continues to move straight and it starts finding this kind of animation in the end of the turning animations and if the player keeps turning it might find the same frame over and over again and this could be a really hard problem to solve but luckily when you think about it we don't actually want motion matching to ever jump to these frames directly they only make sense as part of the turn animation so we added a very simple feature where we could target parts of the animation to be ignored by the search for example in this turn animation we would leave maybe 10 frames near the beginning of the turn for motion matching to pick and anything after that would be ignored from the search

these frames are still accessible for continuous flavor so if this animation starts playing it can play all the way through and this turned out to be a pretty powerful tool for controlling motion matching one use case was fixing this problem where you get stuck in a pose you could also use it a bit more for stylistic reasons for example if you want to play your stop animation so that player always plants at least one foot in a stop then you can ignore the part where both feet are already planted to make sure we get enough of the stopping and in a similar way maybe you want your start animations to always start from the beginning so you can ignore all the other frames to pause it to play this animation from the first frame another good thing to ignore is tails after transitions when building a locomotion set typically what you get is lots of transitions or changes of directions that all lead into the same loops

so in practice you'll have these pieces of the loop scattered all the way across your animation database and this is actually why motion matching might start looping a small piece of animation because instead of your main loop it can find one of these loops after a transition and start looping a small part there but by ignoring those frames and only letting them play when the transition is playing help us get rid of the problem of getting stuck in a loop also anything near the end of the animation it doesn't really make sense to jump to the end of the animation because the animation is just gonna end and you have to jump somewhere else so we were able to reduce some glitchiness by just ignoring the ends of animations and of course since what the ignore tag is doing it's basically limiting the search space it also works as an optimization in control we were able to cut our search space down to 20 of the original

so after adding the ignore tags to the animations we got to a point where the most outstanding issues were fixed when it comes to combining abilities with locomotion we went for a pretty old cool approach of blending upper body animations on top of locomotion since locomotion was always facing the direction where you are going every animation needed to support all the possible directions so we built a matrices out of our animations and in some places where it had most impact we added full body animations and with that we got the retreat on modern we had a playable mission and we were able to deliver all the intended gameplay features we had a couple of set-piece animations and indian cinematics and our first building shift which is the transforming building and all of this was running on a new

technology here's a little glimpse into our e3 demo rituals you can keep traveling deeper [Music] [Music] [Music] okay

so when building this demo we were able to get a lot of important ground work done first of all for by defining what kind of a game we are making but also laying foundations for our animation technology and we were on track with the main goals we had the game was responsive we had good runtime performance and iterating on animation systems was fast because any change you made could be hot loaded to the game almost instantly and as a standard feature the match node was a great success it proved to be a pretty versatile tool and became our go-to option whenever we needed to do some one-off animations using motion matching was still quite difficult for us we spent a lot of time debugging it and trying to figure out why something wasn't working and overall didn't really yet have the level of control we needed over it and we also have some visualizers

most notably we couldn't do straight locomotion without sliding yet to debug motion matching we already had some information available so we could see what animation was playing which frame and what is the cause of this frame and also if the animation was changed we could see that what would have been the cost of continuing the previous animation but that didn't really answer all of the questions we were having such as why was one my animation interrupted or why isn't my animation getting picked and to answer these questions villa created a new animation debugger on the left it shows all the animations in the database and on the right it shows a real-time visualization of the course of the different frames in that animation so every little bar on the right corresponds to one frame in the animation and the height of the bar tells that how much cost that frame is getting

it was also possible to hover mouse on top of the frames to get more information about that frame such as how is this frame tagged what is its cost and how do the different channels contribute to the cost you could also tune the motion shader at the different cost of different channel live and see how the pearl frame costs react to this so this way you can try to tune your shader so that motion matching starts picking your your animation and then you can unpause the game and keep playing and see how the game feels after the modifications you did finally it was possible to draw some debug visualization like the path points and the skeleton of the character and then you could scrub backwards through a recording of the game

find the frame maybe where a glitch happened and then you can investigate for example that which animation did it choose and why did it not choose the animation i wanted it to choose to get even more control over motion matching we added a new kind of data driven category tagging system so it was possible to add custom category events on the animations and then we could request motion matching to play animations from that category and this was a soft category system in a sense that we could assign penalty for picking animations from a wrong category so if you want to ensure that it's always playing animations from a specific category we can give a really high category penalty in which case it forces it to pick those animations but it's also possible to give a lower penalty in which case it

will prioritize the animations in the correct category but if there are no good matches there it can then default to the other categories the reason our stray flop emotion was sliding was that when strafing you have to be able to move to every possible direction but since we can only have a discrete number of directions in the animation database then we get situations like the top picture here where the orange line is showing where the code wants the character to go and the yellow line is the best matching animation for that and if you play that animation but at the same time move along the orange path the feet will start sliding so to fix this we made it so that the character gets rotated so that the animated path is aligned with the path the code is requesting and then we apply a correction on the upper body to counter for this correction so in practice we are rotating the lower body of the character

to align with the path on the animation side work was proceeding well a lot of things that were causing friction early on like missing features were being fixed and animators were getting experience on the technology and one one nice bonus we get from motion matching was that now that we had best practices how to create the animations every animator on the gameplay idea was able to create their own locomotion sets on the players side we still needed a lot of improvement and the main problem was that when players were playing the game and running around and combining abilities and shooting at the same time things started getting messy we get this awkward process of trying to sort behind your back uh switching between the different abilities didn't look smooth and some important animations got lost in the overall business of the animation

so what we wanted to do was reduce any kind of issues caused by changing input and make the main actions what the player is performing stand out we started from our worst offender hip firing we wanted to get rid of the stiff feeling we get when combining upper body and lower body animations and instead create a full body locomotion set for hip firing and we also want if now that we could make nice straight locomotion we wanted to make a strafing set so that the character wouldn't have to turn around while moving this would perform better under changing input and also we didn't have to worry about scene handling so this is what we were able to create and indeed it worked a lot better than our previous version when transitioning between normal

locomotion and hip firing we did it so that we added the transitions to the motion databases so every transition into some hip fire animation would go into the hip fire database and transitions back to normal locomotion would go to the normal locomotion database and to make sure every time we go into hip firing we play some transition we use the category dax to force transitions for coming back to normal locomotion we didn't need to add them motion matching was speaking the right transitions automatically and every transition was timed so that in two frames you get from your pose to being ready to shoot to give this feeling that as soon as you hit the fire button the player starts powering the gun and while the hand is pointing to the right direction we let the rest of the body turn a bit slower just to make it feel a bit more natural

next offender was launching objects through the air it had similar resources as as the hip fire and this strafe locomotion worked for hifi we also wanted to try that for launching we were also getting feedback that launch needs to feel stronger and we need to have a better connection between the object and the character and i figured that by using straight locomotion we can also get a much more controlled composition of the character and the object on the screen so this way we can plan for a better connection between them as well only problem was that we didn't really have time to build another locomotion set so what we did instead was we took the hip fire locomotion and for every animation we would turn the character 90 degrees switch the pause and this gave us the launch locomotion some animations went through a bit more polish but the bulk of the work was done

like this and as a result we got launching that feels a lot stronger works better on the chasing input and we were also able to improve the connection between the object and the character for the animations where you launched the object we had some full body animations such as this one where you run forward and launch the object for other directions we would use the same animation but blend it with locomotion like this and we chose to use hip fire locomotion as a base for this drawing because that way we could get some body rotation into the animation as well and nicely it also allowed us to make use of the transitions we added for the hip fire

we were also able to blend seamlessly from full body animation to other body animation like here where the animation starts as full body but when the player changes its direction it seamlessly blends into upper body animation and what we got with all of these improvements was a character that can seamlessly switch between launching and hip firing while running around without creating animation issues and yeah in the end we made it we were able to sit the game in three years including pre-production time plugging at 10 to 20 hours of gameplay this was the biggest tournament again yet we had 11 different enemies some fights against big bosses which was a remedy first

25 minutes of cinematics and two and a half hours of conversations and as you can see from the timeline below since shipping the e3 demo we had one year to complete the full game and most importantly now we have control over our animation technology and we are in a good place to start building on top of this all right now it's been some time already since shipping control so we also wanted to give a quick look at where we are going with our motion matching since then in control we prove that we can make a game feel responsive and since then the progress has been more on improving animation quality and making our workflows less tedious and big part of this has been adding support for animation driven motion matching this is to give the characters a more grounded organic feel and we have this available for the

player on npcs for player of course only using when it makes sense we generally still like to use code driven for the most part but if there are ever cases where we want to prioritize animation quality over controls we can always switch to animation driven for npcs we are animation driven by default but still allowing designers to switch to culture and movement if they want to try different speeds for the enemies for example the way we do animation driven is that the characters are still moving along the exact path that is given this is to avoid any kind of pathfinding issues but the speed at which you move along this path comes from animation and adding animation driven locomotion here has changed our workflow a bit so instead of first generating movement for the trajectory and then animating on top of that we are now animating first and plotting the trajectory based on the

animations when using animation driven movement we can choose either to use both rotation and position or keep positional movement call driven but rotation animation driven and this is good for a playable character way we can still get the benefits of code driven movement but we can reduce issues that come from code driven rotation and the animated rotation being of sync and uh we are able to specify with animation tags on which frames do we want to be animation driven so for example if you want to make 180 degree turn feel more grounded we can make part of that turn animation driven to make it grounded and have a bit of control over the timing in the animation but leave the rest of it still code driven

now being animation driven only goes so far because even though the animation technically can now control the speed motion matching still prioritizes animations that are matching the speed what it's requesting and the qualcomm is uh we added the option to use distance instead of time to sample the animations so for example instead of asking where am i gonna be one second from now you can ask where am i gonna be after moving along the path for one meter and this makes motion matching completely independent of the movement speed so now we don't have to use speed as a factor in it if we want we can do that so one thing that works for example is that we can check against current speed and the speed after moving two meters but still leave the

how the acceleration happens between this totally up for animation or we can completely leave speed out of the matching and use a category instead for picking animations in sets that match the speed we want and this allows motionbutton to work on animations as whether speed is organically varying between animations there was also one one more motion channel we had to add to make animation driven movement work the problem was that when characteristics were strafing now that the chord was no longer rotating the character to face the right direction it was failing to find the correct animations so we added this channel called trajectory direction relative to velocity it basically tells you what is my rotation relative to movement direction and this helped it picked correct strafe directions under animation driven movement

and that is all we have thank you for listening i hope you enjoyed this if you like how we work go check out jobs at the renview website and don't hesitate to get in touch if you want to discuss more thank you [Music]
