Modernizing Rendering at Supercell

[Music] welcome to this presentation my name isan and I'm going to be talking about modernizing rendering at supercell so first of all I want to remind everyone to please turn off their phones if they're potentially making any sounds and remember to fill in the review forms after the presentation so I'm going to start off the presentation with a short History tour on technology development at the company after that I'm going to be talking about the actual process of rewriting our core renderer and porting all of our games on top of the new system then I'm going to be talking about the new system itself going to give an overview of its architecture and talk a bit about the new the feature set

and finally I'm going to go through some of the learnings from along the way but first off a little bit of introductions so the name was already mentioned di MOA I've been a super cellan since March 2020 and ever since I've been focusing on building our shared rendering capabilities so my career actually started in the IT industry I did that for about five or so years but I always wanted to be in the game development industry so I decided to join bug bear entertainment and worked primarily on the game recfest after bug bear I join next games as the lead programmer on The Walking Dead no man's land before supercell I was at a small startup called reforge Studios so supercell was founded in 2010 we have about 420 or 430 people give or take globally and were best known for games such as Heyday clash of Clans Boom Beach Clash Royale and roll

Stars so now let's talk a bit about the history of Technology development here so we actually started developing our games in Flash our first game gunshine Donnet was made on flash for the Facebook platform and Facebook was the first component in our multiplatform strategy back then but we soon realized that gunshine Donnet was not going to be the huge success that we had hoped it to be so we decided to kill the game and pivoted to tablet oriented mobile which is really On The Rise back then so we needed something native to run on IOS and Android because Flash just wouldn't cut it and the options back then were quite a lot more limited than they are nowadays we also wanted to continue authoring in Flash because we had a lot of experience in the pipeline and we also had a lot of content coming up in

the pipeline as well so it made sense so this was the birth of what we call Titan so we developed this pipeline for converting flash content into our in-house format and a rendering system for rendering this content and we call this stage stage is closely modeled off of The Flash API stage is also part of Titan but Titan is quite a lot more than just rendering or stage in this case Titan is has a lot of components that are utilized by the game teams to develop uh to implement the game functionality components that they might not necessarily want to or it doesn't make sense for them to develop on their own historically Titan has been something of a toolbox of components from which game teams can pick and choose these components but it's becoming more and more of an actual engine Titan is also maintained by the

tools and Technology team so even though every game team does have the capacity and can commit directly into Titan the primary responsibility for maintaining the engine still falls on the tools and Technology team and I'm also personally part of that team so we've been seeing this growing need for 3D historically our early games have been isometric pre-rendered or hand painted 3D so if you look at at Heyday or Clash of Clans um it looks 3D is but it's actually not you know real time render 3D but games such as everdale which is one of our one of our beta games and ball Stars really highlighted the potential of 3D in our games and what how it could make for more Vivid environments uh it's worth mentioning here that even though uh everdale was killed it's found a new home under medicor so we're definitely looking forward to what they can come up with the idea with the

concept so then some new winds started blowing for 3D and one of the big things that happened was that Apple decided to drop a bomb when they deprecated openg GES this was a huge problem for us because we heavily relied on openg GES pretty much all of our rendering was built directly on top of it we had some lightweight layers on top of openg GES but a lot of the games were also directly called into into the underlying API so if we look at a bird ey view of our Legacy rendering architecture then at the bottom we have the openg and openg GES layer directly no abstractions on top of this we have this lightweight helper layer with Shader loading on a render class that helped with some vertx buffer binding things and stuff like that GL image for open GL texture creation and texture content

loading a very kind of simple and lightweight stuff on top of this we had 3D rendering uh functionality for meshes materials models scenes Etc and this layer also kind contains stage and this was using the underlying layer in addition to directly calling into openg G Es as well and then finally we have a game specific rendering layer which used all the layers under including directly calling into openg so we were heavily heavily ring on opengl so we wanted to Future proof our rendering we really saw this as an opportunity so we didn't want to just work around the issue of not having metal by just implementing a side bys side metal path for rendering we wanted to do this properly our Legacy rendering path was really holding us back so it's becoming more and more comp licated to create

anything more complex um 3D effects um so it was really holding us back and we had these situations where we had 2D rendering States leaking into 3D rendering States and it was really hard to maintain a separation between these systems so we needed a proper abstraction layer that would allow our game rendering Engineers to focus on the actual game visuals and not think too much about the underlying API so this could be considered a risky move to rewrite the render of billion doll games but we believe that changes like these are often necessary to keep us competitive so we keep moving our games to new Titan features because it helps us in many ways it helps us improve our existing games with every update so if we for instance develop a new content

delivery system then these games are able to deliver better and more content to our players it also keeps allows us to keep the tools and Technology team smaller because we can focus on these um single stack and we don't have multiple branches of our technology stack to maintain also it makes it a lot easier to share learnings and Technology between games because we have this common language that we're speaking common platform that we're using using so now it's time to introduce Thor or Titan Hardware oriented optimized renderer in fact this is actually just a name that I came up after watching a Marvel Thor movie but um the term was nice and it had a nice abbreviation so that's stuck so Thor is this abstraction layer currently it abstracts metal openg openg glees and Vulcan Vulcan is still an experimental support but we're pushing hard to get that into live as soon as

possible when I joined the company we had like a skeleton of what was to become Thor so it's very simple we had we had the basic architecture in place already uh and we had basic support for openg openg G es and metal won was still missing at this point and actually quite a lot of like core features you know we still missing and a lot of this has been Rewritten partially because of multi-threaded support added to openg but it was a good start so during the Spring of 2020 I worked on Thor pretty much in isolation so I didn't have any game project to actually work on I just had this separate test project for different rendering tests for creating textures creating uh compiling shaders and rendering Primitives but right before summer holidays which in Finland uh the game industry typically has

rough roughly around July so this was by the end of June or so I got Heyday running in a very limited manner so as you can see uh the screenshot is quite buggy uh but it is it is the first screenshot of the game actually running on Thor so it was a huge milestone because after this we could just start improving Thor making it better and making it production ready Heyday was chosen due to his limited rendering ing feature set it basically only relied on stage we didn't have to implement any of the 3D rendering functionality of course we had to prepare for the worst so we set up automated testing from the get-go even before we were considering merging anything in so we had these predefined scenarios for smoke testing tests that would scour through the game go through different menus press different buttons and basic basically kind of automatically play the

game we also have video recording for recording the PlayStation and storing that on disk for later analysis we had log capturing so that if we saw some issues in the videos we could go into the logs and see if there's any uh potential reasons for why that might be happening and we could execute these tests in Google Firebase so we can take hundreds of devices and combinations with different OS versions and try out the tests on there get really good coverage this helped us find multiple issues in rendering before a launch and towards the end of the presentation I have a couple of interesting uh examples of these and it allowed QA to focus on the more tricky issues so during the fall of 20120 I focused on improving Thor and stabilizing Thor so basically making a production ready fixing small issues

doing performance optimization and stuff like that working with the game team was super easy so whenever I had any questions about where certain things were implemented how it was how the rendering was done or how to make certain kinds of builds I could just directly go to the team and get answers really quickly and no one no one really questioned my ability work to work on this and I was able to do really big decisions uh autonomously so in the end the update of Heyday using Thor was released on the 23rd of November 2020 and this was the second huge milestone for Thor because after this point we had a game in the wild and we could start collecting performance metrics uh crash reports and overall player feedback luckily we didn't run into a lot of issues in the live so I was able to move to the next project which was that I was jumping from one game team to another porting the game rendering over

to Thor and improving Thor while doing so so the next game in the line was Clash of Clans and this was actually the first game um to be ported that had 3D elements in it so at this point I needed to Port meshes render cues materials all that stuff but it was a relatively straightforward process partially because stage was already ported and most of the rendering in Clash relied on stage with just a couple of 3D elements there this update went out pretty quickly after uh Heyday on the 12th of April in 2021 next up was Clash Royale and Clash Royale was actually started in parallel with Clash of Clans and there weren't a lot of huge surprises again here uh mainly mainly some Shader variant filtering systems that needed to be implemented but the biggest issue really

was matching the timelines of the project so their release schedule and it took quite a lot of time uh to bring this update out which came on out on the 25th of October in 2021 the fourth game out was brawl stars and brawl star was probably the most complicated most of the functionality itself was already there but because of the sheer amount of content that we had and the variations of the different um shaders that we had we ran into a number of like smaller issues that needed to be fixed also QA had their handsful on multiple releases of the game so it just took while to go through QA eventually this update went out on the 16th of December in 2021 the last game to be ported was Boom Beach and this took the longest um because again the release schedules of the game and boom has its own uh a bit

different way of doing 3D rendering so there was somewhat more work to be done there but the update eventually went out on the 2nd of November in 2022 so at this point all the live games had been ported and we could do a surgical operation to remove the old render path so this was the third major milestone for Thor development and we could consider the project done at this point you've probably noticed a pattern here uh with me mentioning that the biggest problem was really the timeline of the projects and that is true because it was complicated to match the work being done on Thor to the timelines of these individual projects because they still wanted to develop the games forward develop all the new feat cool features that they wanted for their players while I was still working on the core rendering so that was probably the Challen most challenging part on here but that was just the beginning so the develop of Thor has continued

nonstop we've now shifted Focus to building on top of Thor so now we're able to build new rendering techniques which we couldn't before it also has made sharing a lot easier it's easier to talk if you have a common codebase and common language to speak with and it has allowed us to build better tooling and use a lot of better tooling because of the PIP pipeline the new pipeline underneath so let's talk a bit about about Thor itself so we had three major design goals for Thor first of all it needed to support multiple rendering apis we wanted to add metal support but we had to also keep the openg and openg glees support so naturally we had at least two apis but we also wanted to add support for Vulcan because that's the direction that Android has been U pushing really hard we also wanted it to be powerful and

efficient but easy to use so we wanted to be able to create these modern impressive visuals with this system efficiently but we also wanted the game engineers and the game rendering Engineers to be able to do this uh without a lot of Hassle and we wanted to make this future proof so we didn't want to be rewriting this system anytime soon it was going to be our kind of rendering platform for the future future so Thor in a nutshell currently Thor supports these apis which I already mentioned earlier it is architectured around the concept of metal because we found that metal is probably the best compromise between performance and usability and also metal was kind of our primary target initially so it made sense to architecture things around it Thor is also multi-threaded so this was a really important point for us

because modern mobile devices tend to have a lot of cores and different types of cores also so we wanted to be able to utilize that to create multi-threaded rendering algorithms which we couldn't before so we had a number of design challenges also first of all it needed to support all the Legacy devices the render path also supported this partially comes from our mission which is to create game cre games that as many many people as possible play for years and that are remembered forever so we didn't want to be dropping these players that have been enjoying our our games for years just because we were rewriting this core rendering which was more or less future proofing our rendering but it wasn't immediately providing any huge benefits to our players it was going to provide those benefits in the future so the added abstractions should also be

very efficient we had a very efficient use of open G originally because we had built all of our rendering directly on top of openg GES and abstractions tend to add overhead so we wanted to keep this to the minimum this was probably our biggest challenges we we wanted to we wanted the new render path to coexist with the old render path so we didn't want to put all of our eggs in a single basket and we we wanted to update our games one after another to make sure that the game before worked before we moved to the next next game so let's look at a bird ey view of the core architecture of Thor so we have the bottom layer which is a platform specific layer and this is different for metal Vulcan um openg and

openg glees for openg and openg GES it shares quite a lot of code actually so technically it's kind of the same platform with some variations on top of this we have the actual abstraction layer which contains resources such as buffers textures different render states such as the render pipeline um depth stencil States Shader function definitions and all that and this is what we call Thor so it is the hardware or the underlying API abstraction layer on top of this we have the same layer that we had before for 3D rendering mainly also including stage and we didn't rearchitecturing layer which now depends only on Thor and

the scene layer here so as you can see it's no longer dependent on the platform API which was one of our biggest goals here so let's quickly look at the composition of a single frame here so we start off with command buffer encoding this is a concept that we took from metal so you create a command buffer and then you create a render encoder which is responsible for encoding these draw calls and state sets into the command this is emulated on opengl because opengl does not have an A an explicit concept of command buffers excuse me metal and Vulcan has this so for them it's basically just a native operation but for opengl we have a host memory buffer where we encode these um State sets and draw calls Etc this command buffer is then pushed into the command q and on metal and Vulcan this basically

goes through the driver and to GPU execution Etc but for opengl we actually have a dedicated working thread that unwraps the command buffer and executes the opengl commands so this has allowed us to create these command buffers on any threads uh but the actual amand uh opengl commands are executed on a single thread we can of course have multiple command buffers being encoded and an execution in parallel uh there is only a limit for how many command buffers can exist at any given time but if you encode these command buffers commit them and wait for some of them to be freed again you can encode any amount of command buffers during a single frame and this hard limit of command buffers executing actually comes from metal then of course the second command buffer here gets executed and finally

when we're complete with the frame we schedule a present that's that concludes the frame so let's talk a bit about shaders so we author our shaders in glsl this is then compiled into spury modules and we convert the spury module to the Target specific languages using spury cross for open GL is like different variations of GLS L and for metal that's MSL these are then loaded at runtime and uh converted into the runtime Concepts Shader functions or Shader link uh compiled and linked into Shader programs and on openg G we also have a Shader program cache that we can use to optimize the lad times significantly and of course on Vulcan we directly load the spury module but it's important to know that this spurv module might not be the same for every single

platform because we might be doing some optimizations for uh for them depending on the platform we have both a low time and a built time pipeline here so we can do the spury cross uh cross compilation either at low time or at build time the low time approach was something that we originally had where we shipped the spury modules and then at low time we did the cross comp to get the final target language which was then compiled but now we've since moved to a build time pipeline where we actually build the different variations of these shaders offline during the game built in addition to this we also have a variant system so every single Shader can define a set of variant flags and the pipeline then builds different variations of these but as we all know from a lot of other engines this can cost quite a lot of time to build all

these variations so we also support specialization constants so if you request a Shader function from Thor you can specify a set of specialization constants which will further Branch out the Shader implementation on metal this uses function constants and on Vulcan it's specialization constants and an openg G we actually utilize the way that spur cross kind of emulates the specialization constants and we're able to Def but we're able to Define these values at compilation time so naturally not all features of Thor are available on all platforms games can check for the availability of certain PL uh certain features using feature flag test but some of these features are also emulated and this allows for a uniform base implementation so the game

rendering Engineers can expect a certain uniform implementation or um base implementation to be there to build on top of and then they can Branch out for specific type of features that they might want to be using an example of these emulated features on openg ges2 backend is uniform buffers so in openg gle2 we don't have support for un native uniform buffers so we just have a host memory buffer where we store the uniform values based on the Shader uh uniform block layout and then when we want to actually render some Primitives we resolve these by reading from the memory buffer and using GL uniform calls to set the values of the uniforms so looking into the future Focus has now shifted to building on top of Thor as already mentioned I have a couple of examp examples here of things that uh we're currently working on so of

course we're adding features to Thor whenever we realize that there are some new feature in metal or Vulcan we consider adding that to the core of Thor if it is something that really benefits the game teams in addition to this we have a couple of uh new systems that I wanted to mention here that we're working on first of all a render graph implementation and something what we call Odin and this is not a coincidence that it's called loaded so now let's quickly talk about the render graph the render graph is basically a task render gra render task management system each task implements a piece of frame rendering and we have two types of tasks on here first of all we have generic tasks which do not output pixels and a good example of these is CPU skinning

and this uh task is basically responsible for taking the model transforms the untransformed verx data processing that and outputting that into a temporary verx buffer for rendering then we have render passes and render passes actually output pixels either offscreen or onscreen frame buffers these tasks are then queed for execution on worker cues we can have basically any number of worker cues depending on how many different cores the platform has it really makes sense to use different amount of cues synchronization is based on the inputs and outputs of these nodes so as you can see there is a dependency between model skinning and the different render passes here so the model skinning needs to complete before the render passes can start also there is a dependency between the shadow pass and the collar pass but

you can see there's quite a lot of overlap in the execution between these tasks this is because the colar pass only meets the frame buffer output of the Shadow pass but only on the GPU so we don't we can overlap most of the execution of these tasks because that execution is preparation of the command buffers so the only important thing is to make sure that the command buffer for the sh pass is committed before the color pass and this is something that the system also takes into account so I'm not going to go too much into Odin at this point but I wanted to mention that because this project with Thor did not really touch the middle layer that much but the project uh called Odin is this so the purpose is to modernize this middle layer so to be able to to be better equipped to fulfill

the needs of our new games and our current games uh to have different kinds of materials make that more uh datadriven and easier to use so now let's dig into some learnings from along the way the first thing that I wanted to talk about here is quality so our games are played on a wide range of devices we have about 250 million monthly average users who have quite a large variety of different kinds of devices so testing everything manually is just impossible and automated testing smoke testing really took the pressure off of QA and allow allowed us to have really good coverage here another very important topic at least for myself is proper self- review so making sure that the commit that you're making or the code that you're merging that you understand it and that

you know it is up to your own quality standards so this basically helps you feel sure that you've made the decis best decisions with the available time and information also it builds confidence in your co-workers that you are not making decisions at random and finally that you're also better equipped to fix any bugs that are surely going to pop up in your code in the future and finally respect your QA they really help me sleep my nights in relative Comfort something that's very important with mobile development overall is Energy Efficiency so batteries and heat dissipation tend to be very limiting factors of Mobile you don't see a lot of devices with active cooling like fans blowing and these devices are targeted towards not sustained performance but Peak

Performance so if you try to sustain the full 100% usage of the device then you're going to run through battery and it's going to be overheating and the device will be throttling rendering needs to pay extra attention to this because a lot of the rendering code tends to be on the hot path and this is really important to fulfill our mission because it allows us to you know we need to be efficient even on these lower-end devices and we need to allow our players to play our games as long as possible so taking into account the batteries and basically gaming comfort as well so a couple of examples of how to take into account Energy Efficiency first of all I would recommend to use cash efficient data layouts uh especially on hot memory I dug up some information in preparation to this presentation

indicating that the difference between a cash Miss and a cash hit is about 200 times so it's 200 times less efficient in terms of energy consumption if you get a cash Miss so you should definitely aim to design your data layouts in such a way that they are efficient for the for the cach also favor using multiple cores so if you're able to split your rendering algorithm into multiple threads then you're able to put less pressure on individual cores allowing them to run at a lower voltage saving a lot of energy also aim to use low power cores most modern devices nowadays have low power cores they might have mid power cores high power cores different sets of different kind of cores and using the low power course all the

mid power course uh really saves a lot of energy if we look at Clash of Clans for instance it mostly runs on the low power cores especially on the even slightly higher end devices and finally I would recommend everyone to write sensible code from the get-go because you will probably not have the time to fix your code if you have not allocated time to do that so make sure your cat the coat that you commit in is sensible enough it doesn't use a lot of brute forcing and it is just something that can go into production if you do not have the time to optimize it further also I wanted to put this picture here which showed the difference in energy consumption uh before and after moving to Thor so this was the um the comparison between using openg GES uh on the old the Legacy render

pipeline compared to the new render pipeline using uh metal of course sometimes devices don't work as expected so many Android devices especially ship with buggy drivers or Hardware the situation isn't as isn't as bad as we had expected it to be but it is still significant so I have a couple of examples here for the inquisitive mind uh of certain situations that we run into um in during this project so first of all there's this case of missing code blocks nested code blocks then we have using outputs as Temporaries and finally broken uniform structures so let's talk about the missing code blocks first so when we were analyzing the

recorded video from our test cases we noticed that on some devices the Hero characters were darker than on other devices digging into this I pinpointed the issue to um a function roughly like this so we were doing srgb decoding um if a constant was set to true and I thought that well maybe it's the constant that just has the wrong value so I'll just hack it in and just try you know checking if true is true but this did not fix the issue so at this point I was like well maybe it's actually a driver issue so I'll just remove the if and you know at least now it should execute that code turns out it didn't so the result was that the driver just didn't like code blocks within functions which was pretty ugly because we had to move this type of

code to the main function putting anything any code like this in a nested function or a function that was called for main just did not work and this was this was a relatively new opengl ES3 level device then we have this case of using fragment output as Temporaries this is actually something where we did wrong but the result was uh quite interesting I think so in the recording we saw that some on some devices the characters were drawn in grayscale and I pinpointed it to code like this so we were writing into the fragment output and then we were doing the linear to srgb encoding here um by reading from the output value and writing it back

doing it from the temporary value basically fixed the issue so we're not reading from Frack color anymore this is something that the opl specification actually stats should not be done so you should never read from the fragment output you should only write into that but nevertheless it was really interesting how you know how it worked on some devices and the compiler didn't really complain about it and uh the output was you know a very interesting case finally there's the case of broken uniform structures so on some devices we just had a black screen so this is like the worst nightmare of any rendering Engineers looking at a black screen you have no idea if it's rendering anything but look I opened the the build on the machine where device where it was broken and I was looking at it for quite a long time think thinking what could be wrong and then I noticed some small

flickering at the lower corner of the screen so I thought that well definitely it is rendering something but you know what's wrong with this so I looked at it using gpid which is an Android graphics debugging tool and it showed some inconsistencies between two two different views these view views displayed the uniform data uh of the Shader program so it was just showing different data there so this is how we had defined the uniform Block in the source Shader and this was converted um for the opengl2 backend which did not have uniform buffer support into code like this so it generated a structure with a couple of matrices and then a uniform based on that structure turns out the driver didn't like uniforms defined in the this way and when we were updating the uniform

values some of the columns in U view got values from you projection view so it was messing up the locations of the uniforms in some weird way the resolution to this issue was to use something uh in spury Cross that basically flattens out the uniform block into a v four array so we could just update this whole uniform using a single Un uniform GL uniform call the only problem was that this does not allow interleaving floating Point values with integer values in the uniform block but for the games that had this issue and needed to use the openg ges2 backend this was not really an issue so finally I wanted to talk about something very important um that's kind of been glanced over during this presentation but I want to highlight at this point which is the whole getting a

done mentality that we have at the company so our culture is really about empowering people to do their best work we have very little red tape so whenever you need to do something and you need to you know start off a project to improve a certain system you don't have to go through a lot of different kinds of um organizational Hoops don't have to go through different level levels of man management to get make designs and get approvals for them you can just kind of become your own project manager and start moving it Forward of course there are cases where this doesn't work for like big structural changes um uh some strategic strategically important things but for most of the like system development that we're doing it works really well people also tend to take responsibility and ownership of the code that they're developing and the systems that they're working on so I usually say

that it's not really a problem if you screw up that's totally okay that's that's human but it's really what happens after that what matters so if you really take U take up the responsibility and you help people fix your your issues or you fix them yourselves that is really the important thing and this whole mentality of autonomous um development basically being able to do that allowed me to work efficiently and move between different game teams and talk directly with the game teams and get things done really quickly and make big decisions uh without going through different levels of management of course it's not all roses like you know some people occasionally make decisions without making the uh the necessary prepar ations and talking to people who actually like know know about

the system that this person will be working on but overall the benefits really outweigh the downsides and it's been working really well so this actually brings me to my conclusions so first of all we build technology for a need so for Thor we really needed to add mental support so that was a given but we also wanted to make it possible for game rendering Engineers to build better visuals uh in the future so we were not just building some rebuilding something just because it was a fun thing to do we also had to proceed really carefully because we were rewriting the render of billion dollar games so we wanted to make sure that we're not um we're not putting all of our eggs in a single basket and then dropping it and finally Thor is our platform for the future for rendering so we were able

to build this common language that now all the different game teams use and we can rely on and now we can build on top of this and finally there is a very important thing that I wanted to mention here which is that we are hiring so if you want to know more about the company you can come talk to me or any one of the super sellion roaming around here of which there are quite many this year actually uh but apart from that I think it's time for questions now I thank you very [Applause] much uh so earlier you mentioned uh that you tried to uh put your game on the slower cores on mobile uh I'd like to know how you do that on iOS which doesn't provide an API uh for threat affinity Bas basically um really about like how

how much you actually push the CPUs so just try to like be as efficient as possible and it'll automatically move it there so in Clash's case it is relatively lightweight on the CPUs so it kind of naturally happens uh but yes it is true that there's like no way of defining that but then again if you do have that interface and then you force it onto the low power course and it's not enough then you're not going to have the frame rate that you want so the best way is to just like make sure that you has have as efficient Al use as efficient algorithms as possible to just naturally make it happen yeah we're we're running into that problem thank you okay yeah no problem thanks yeah I have mostly the same question but don't you run in the issue that when you run on the low power course that you're not getting your deadlines for example [Music] um it's pretty smart at actually scaling

like you know there there are cases where uh if you tried to do something really smart like automatically scale your like especially in metal if you try to scale your um your presentation times based on like the actual time that you're executing on the GPU then you get this kind of rubber band effect where it's like um spending more time and then you uh scale it down then spending less and you scale it up up um but yeah so it it can be you know it's it's a difficult problem in some cases to solve and it's really about like Tri and trial and error and looking at your metrics using the tools that you have and what you can do there all right thank you hi um how are you finding the driver stability um on like Android Vulcan drivers are you finding um bugs with all the drivers or are you having to limit your devices to like a known set of um

of devices uh yes so we've been like seeing uh multiple issues like some some very weird cases even unlike high-end uh devices things like the um uh like the pipeline cach is not working at all for like a large amount of specialization constants so it is it is a kind of a challenging world it's getting better the problem really is that you know you have the uh you have the Baseline profiles that you can rely on but that doesn't really tell anything about the quality of the driver so um it is just a thing that's improving over time and we just need to like maybe try it out on those devices and then Blacklist them if it just doesn't work there and move on there like incrementally but it yeah definitely we're running into into those issues okay thank you thanks hey thanks sok um when you selected SP Spire V did you

analyze other tools like bgfx or other kind of buttons like that uh excuse me selected what when you selected SP yeah did you analyze other tools like bgfx or others spury basically was like uh it was a pretty good natural selection in the sense that um it worked directly for Vulcan as well and there were pretty good tools for that like spury cross which we could use the for spury cross is not perfect and spurv itself is not perfect so we run into issues with for instance a floating Point 16 support which uh metal doesn't support the relaxed position attributes on there so it it gets a bit tricky to add like floating Point 16 support uh so definitely it's not perfect um but we didn't really really really I think we didn't really do really

in-depth analysis on that to be honest um but it was just a tool that looked to fit our requirements really well overall and the pipeline was there we could cover all of the different use cases like metal and open G and won for us with that uh but we have been thinking about potentially uh either switching a solution or potentially even building our own Pipeline on there because some of the issues that we're having with it but I hope that answers your question a bit thanks what tool were you using to measure wattage on the iPhone 7 uh this was like game bench I think yeah hi when you find problems with the drivers are you just doing workarounds uh and moving on or are you contacting the driver manufacturers and if so how long does it take till that gets resolved well both but the problem

really is that it's not a practical rout to expect the driver update because um many of the drivers actually never get updated and you might have like even slightly older devices which are updated like maybe for two years or so and then after that they never get any updates or like the drivers might even never be updated so we usually have to just work around the issue in some way and then um you know just hope that it's going to fix be fixed at some point thanks thanks so if there are no other question then I thank you very much [Applause] [Music]
