Shading the World of Anthem

[Music] i'm just super thrilled to give this talk today uh shading the world of anthem and i need to give you a little bit of backstory to help you understand why for the last three years i've been giving talks about writing shaders at the tech artist boot camp and each talk i would give examples of shaders that you could write and show and kind of break them down and show how they worked but i wasn't able to show anything uh from the game that i was working on because anthem hadn't shipped yet but now that it has shipped i can actually show an audience like you guys um some shader examples from our actual game and that just feels super cool to me uh before we begin something that's really important for me to to point out about this talk is that i'm the one here

giving the talk but i actually represent hundreds of really talented developers back home in both bioware austin and bioware edmonton who worked really hard to make this game so while i'm going to show a lot of the work that i helped to create i don't want to take credit for any of it because it was a massive collaboration from the whole team and i especially want to call out uh the contributions of my colleague nick sadler who was a fantastic shader artist on the project as well and with that let's jump right in uh just as a brief introduction i'm ben cloward and i've been a technical artist and animator in the video game industry for 20 years now these are some of the projects that i've worked on i also helped to create some software that's part of uh max and maya now called shader effects i don't know how many of you are familiar with with shader effects in max or maya so i

i helped to work on that project as well as shipping these games and now of course uh for the last three and a half years i've been working on a little project called anthem can i see how many of you have played anthem all right fantastic maybe a third of you uh for those of you that aren't familiar with it i want to play a trailer so we'll just take a minute to watch that you are the chosen few protectors of our world this is your time fire out there you will fight the unimaginable feel the power of your javelin it's

precision [Music] rely on each other unleash your power [Applause] [Applause] you are freelancers [Applause] thank you so the first time i saw this trailer was at a company meeting on a screen maybe three times this size and when it was done i was just like yeah i'm fired up wanna go blow some things up um anyway um so as you can see from the trailer anthem is uh the most recent uh adventure game

from from bioware you're in a squad of up to four players you put on javelin armor and you go out into the wild to to have amazing adventures with your friends so um we ran into a lot of challenges in the process of developing this game and when i originally gave this talk uh to the tech artist at bioware um i had this slide here and it just had bullet points with with three of the challenges we ran into and they were like no no bullet points in a list do not do these challenges justice we want you to separate them out and put them in like a triangle shape and just really emphasize uh how hard these things were because they're not just individual items they actually multiply on each other so the first challenge was that we had a lot of diverse environments so we had swamps and jungles and weird alien

interiors and i'll show you some examples in a minute so we had a really large library of assets to support all these different environments on top of that we have a dynamic weather system in the game so any time while you're playing the clouds can roll in and it can start raining softly and then rain harder so all of the assets in all of our diverse environments also have to being support the ability to to look wet and rained on at any given time and being a dynamic open world we also have our day and night system so all of our assets also have to look good under any lighting conditions so these aren't just like three individual challenges but they kind of compound on one another so each of for each of these i have a little demo video that i want to show you and this first one is an illustration of some of the diverse environments that we have

so you can see we have like rocky terrain and really weird looking alien interiors and jungles and the list just goes on [Music] so you can imagine building lots of different types of environments require creating a very large asset library to be able to support this kind of variety [Music] [Applause] it's really neat experience to be able to go go to work every day and look at

artwork like that and feel like oh i get to participate in this i get to help our our environment artists build this amazing work next i want to show you a video that shows uh what our dynamic weather system looks like um while you're watching this i want to just kind of tell you that uh shader artists are weird and and the reason for that is you know this is a game about getting in and javelin and going out and destroying things and fighting monsters and having a great time and here we are as game developers and what are we doing we're staring at the cement um a few years ago i took my kids to the zoo and i had my camera with me and my kids were all excited about looking at the animals you know oh giraffes lions tigers and because i had my camera i was looking around and i was like oh there's really neat material reference here and so i had my

camera pointed at the brick wall and a guy came up and tapped me on these on the shoulder and he's like buddy the monkeys are over there so anyway you can see in this video we have we have the dynamic weather the clouds roll in you can see the little raindrops on the cement i have it sped up a little bit but the puddles will grow dynamically over time and then you can see the rain ripples in the puddles and then the storm stops and the crowds dissipate and you can still see the rain ripples but then they go away and then the puddles start to shrink uh and have its i haven't sped up because i didn't think you wanted to sit here for 10 minutes just watching puddles dry but yeah that's how our dynamic weather system works and i'll get into that a little bit more later in the talk and then we also have our day night cycles and our day and night lasts about an hour of real time in the game and so i have this sped up 60 times so you only have to watch it for a minute but you can see that the sun moves

across the sky and the shadows change and this was especially a challenge for lighting artists who had to be sure that the lighting looked correct uh at all times of the day they had to create nice looking cloudy sky but then also a sky at night and when the sun goes down here in a minute you'll see that that the stars will come out you can see the moons go by and it's just it's really beautiful to look at one of the things that i did to contribute to this is i wrote this shader that has the bioluminescent bacteria in the water that you can only see at nighttime so yeah those are some pretty big challenges and i know these aren't necessarily things that are new in games but they are really neat to be able to work on and i was excited to be able to participate in a project with time of day and dynamic weather and all kinds of fun challenges like that

it makes it exciting to go to work when you have hard problems to to bite off and chew so here are a couple of techniques that we used or that i used when faced with any particular challenge so i'd have an environment artist or the art director come to me and he would say or she would say i need a shader that does this and so i would go down these steps in order to create that first of all i would go out and collect reference either photos that i took for myself or images that i found with google image search and i would bring them all together into a big reference library and then i would work together with the person that asked for that particular asset to identify some key elements that represented the essence of what that effect was and just as important as identifying what we wanted to go into the effect was identifying what we wanted to leave out because if you go out and look at reality it's infinitely

detailed and we just can't push that kind of detail and so you have to kind of draw the line somewhere and say well we can do this and we can do this but we can't do these other 300 things that we see you really have to identify what you're not going to do in addition to what you will do and then i would go about creating a shader step by step trying to mimic each of these key elements that we had identified in from our reference material so what i'm going to do for the rest of the talk is i'm going to walk you through three example shaders that were created for anthem and i'm going to show you how those steps applied of collecting reference material identifying key elements and then building the shader step by step to replicate the elements that we saw in the reference so let's start out with lava

so as i said first of all we collect reference and here are some images of lava that we were able to to find and bring together we used a lot more of this a lot more images than this but these are just a few examples so what we needed to do then once we had our reference images collected is identify some key characteristics that make lava what it is so let's take a look first of all lava has these really interesting folds and wrinkles when it kind of piles up on itself and it hardens into these really unique shapes secondly you can see from the images that there's a really nice contrast between the areas of really molten lava where it's really hot and areas where it's cooled and then finally there's this there's this really beautiful gradient between like bright yellow and orange and red representing the different temperatures of the lava and not displayed in these images obviously but

we also collected a reference video of lava moving and it has this really irregular way of oozing that we're going to try to to replicate so it also in addition to being able to collect reference it's also very beneficial if you can send some people to actually take photos of the real thing so we had some of our environment artists go on a photogrammetry trip to hawaii lucky them so they spent 10 days uh capturing images of all kinds of things and you can see here they're they're taking pictures of the lava flows now they didn't actually go to any real flowing lava and so they kind of left that part up to me we weren't going to put our artists on top of active flowing lava but from what they create or what they captured with the photo photogrammetry and the images that we created we were able to put that

together and create something convincing so from the photogrammetry i was able to derive some really nice source textures so you can see here we have our base color our height normal ambient occlusion and smoothness and these all came from the photogrammetry assets that the environment artists created from their trip to hawaii all right so let's dive right in and create a shader now in the previous years when i've given these talks i've been using the unreal engine but at bioware we use the frostbite game engine and i love working in frostbite because it it enables us to create some really amazing looking effects pretty much anything that we can think of that we get from the reference images i'm able to to replicate in frostbite's shader editor so here you can see i have my two base textures this texture at the top is a packing of the base color and the height and then the second texture is the

normal the ambient occlusion and the smoothness and i'm just passing all that data into my lit root node and so let's take a look at what that looks like so this is the the lava that we're looking right at right here in the middle um the rest of the environment here is just so that you can kind of take a look at it in context but this thing that's going diagonally down the middle is what we're going to be looking at for this example you can see that it's just this static lava that they captured from the lava fields and there's a lot more work that we need to do on this effect to make it what we want to what we want to see so the first thing that i want to do is figure out where uh in the in the lava i want to put the molten parts and so to do that i'm going to start out by uh sampling the height mask so here i've got the height mask which was in the alpha channel alpha channel of my my base color and i have this node down here called linstep

and this is very similar to smooth step but it's linear and so it's a little bit more optimized and what that note does is it remaps the range between two values that i specify and then i'm going to invert it this complement node is like a one minus it flips it and the reason i want to do that is because the height map is bright where it's high and i actually want it to be bright where it's low because i want the lava to be in the cracks so after applying the height now you can see i plugged my height map here into reflectance and the reason for that is i'm going to use the reflectance channel temporarily just to to get a debug view of what that mask looks like so here is our reflectance view and you can see i'm starting to create the mask that will determine where the molten parts of the lava are going to go and just using the height map it's kind of blurry looking and there's not enough detail there i want to add some more details and make it look cooler

so i'm going to go back to my shader and what i can do is i had a lot of detail in the ambient occlusion and smoothness maps so those are coming from right here so what i'm going to do is take those maps and adjust them a little bit i'll adjust brightness and contrast invert them you know multiply a little bit to to brighten it up and then i'm going to add those masks together with the mask that i already created for my height map and that's going to look like this so you can see using the smoothness and ambient occlusion detail i'm able to to pull in some more detail and make it look a little bit more interesting the next thing i need to do is take that mask and map it to my color gradient so this is a gradient that i created based on the reference images i'm just kind of color picking kind of a darker red orange leading up to a yellow and then

almost white at the hottest part of the gradient all right so i'm going to take my mask here and use that as my coordinate to look up into my small gradient texture i'm able to store this uh in the previous slide this gradient looks really big but i'm able to store it in an image that's only like 32 by 4 pixels because i don't need a ton of detail because it's a nice smooth gradient all right so then i plug that color detail into my base color and also my emissive color and i end up with something that looks much more like lava but we're not quite there yet there's a couple of things still missing first of all i want to mask out the lava so that it's not as bright on the edges to kind of mimic the fact that it's going to be cool on the edges but more more hot in the center and so it created another gradient image that just goes from black to white to black again and then i multiply from from one side to the other it's going black to white

to black again and then i multiply my mask by that and i'm able to get an effect that looks like this so here's what it used to look like and then when we apply that mask kind of masks out the edges so that you know over here i'm not getting hot lava but i'm mostly isolating that to the center of the flow all right now there's one more thing that i need and it's probably obvious like you've been staring at this lava and you're like why isn't it moving it's supposed to be flowing right lava flows so that's what we're going to add next and we're going to do it with a flow map and i'm not going to spend a lot of time going into what a flow map is because at last year's gdc abel spent his entire talk talking about what a flow map is but just really briefly what you do with a flow map is you stretch the uvs of a texture along a specific direction and that direction is defined in the flow map

and then as the uvs become too stretched you cross fade to another texture which is also stretching and you kind of ping pong back and forth so one texture is stretching out and then you fade to the other one and it's moving and this one while you're seeing this one this one pops back but because you're fading back and forth you hide the pop so that's what flow maps are and in this case i'm going to use the flow maps to make the lava flow faster in the center and slower on the edges i could just scroll the uvs so that it all move would move uniform but i don't think that would look as nice and so we're going to use the flow map instead and so here's my graph that sets up the uv coordinates to sample my my two textures so i have my uv-1 and my uv2 and then i also have this this logic here that's going to set up the math to blend back and forth between the two textures so here's my graph as it was and now it

becomes a little more complicated because i'm having to sample uh two textures both of the base color and of the utilities and so this node right here is what i showed on the previous slide of of the the logic that i was using to set up the uvs for the flow map and then for my flow i'm using this same gradient down here that i was using to to multiply the brightness so the black to white to black and that's going to make it flow faster in the middle and slower on the edges so then we end up with something that looks like this so you can see that over here on the edge of the effect it's hardly moving at all but then the lava in the middle is flowing faster all right and that is the lava effect and i have a little video here that kind of shows uh this example plus a couple a couple of other ones so that you can see in context uh what

this effect looked like i also i didn't show this in the shader itself but i also added some controls that would allow the environment artist to control the temperature of the lava in various places along the flow so in the in one of the shots you could see that it was really red looking and then in other places it looks really warm and that's because they were able to control at each point along this flow how hot and how cold it was all right let's move on to the next example so now we're going to talk about the dynamic weather in the game and so uh as with the lava we needed to go out and capture reference uh and this is yet again more evidence of how weird uh shader artists are here i am with my camera standing in the rain uh taking pictures of things with with raindrops on them so you can see that uh from the reference

images uh um hard surfaces have rain that hits them and it kind of rolls off and runs down the side porous surfaces the rain soaks into them after it's been raining for a while puddles form and the puddles have ripples and so these are all the kinds of things that we want to try to imitate as we create the weather for our game so as i said we the next thing that we do is is identify these key steps so we're going to talk about creating wetness creating rain drops on the horizontal surfaces rain drips on vertical surfaces and also puddles so let's jump right into it first we're going to talk about wetness so when surfaces get wet what happens if the surface is porous the liquid is going to soak into them and it's going to make the surface look more saturated and darker and if the

surface is impermeable the water is going to pool on the surface and make it more smooth so this shader function is doing just that i have a mask down here that's determining how wet the surface is going to be and it's also using this term called impermeability to figure out what should happen and i also have this this term here the drop and puddle mask because we know that it's going to be a hundred percent wet if it's puddle or if it's a raindrop so then i use that value to determine the final base color the smoothness and reflectance smoothness and reflectance are fairly straightforward i can just blend between the current smoothness and the smoothness of water based on the mask that i created and the same with reflectance blend between the current reflectance and reflectance of water based on the mass that i created the base color is just a little bit more involved here i'm blending between the base color

and my adjusted wet color based on the mask that i created and in order to create the adjusted wet color i use this desaturate node with a negative value which actually makes the color more saturated i know it's called desaturate but if you pass a negative value into it it actually saturates and then i have this multiplier here which is darkening the color so this is the wet color and the dry color and i get my final color based on where the where the wetness shows up all right next i want to show raindrops and there's a really important principle that i want to talk about with this slide and that is it's really important to do as few texture samples as possible in your shaders the more times you sample a texture the more expensive it is and so here i have four different maps that i need in order to create my raindrop effect

but i want to figure out a way that i can pack them all together into a single texture so that i can just do one texture lookup for the entire raindrop effect so my normal map has three channels and i know that i can derive the z component of the normal in the shader and so i really just need two channels for my normal map then my second map here is temporal offset map and every drop here i don't know if you can see on the slide there but every drop is a different shade of gray and i'm going to combine that with time i'm actually going to subtract it from my time value so that when the drops are animated they happen all at different times instead of all at once in sync and then i have two masks here one mask is for my animated drops and my other mask is for my static drops and if i put my normal map in my red and my green channel and my temporal offset mask in my blue channel

that leaves me one channel left and two masks but in this case the really nice thing about these masks is that they're that they do the data doesn't overlap so the animated drops fit in between the static drops and so what i can do is adjust my animated drop mask so that it goes from point five to one and my static drop mask so that it goes from point five to zero does that make sense so i'm packing the two the two textures together into one single channel so when i'm able to do that then i can create take all this data and put it into one texture and then just use one texture sample to create my effect and so here's what my shader graph looks like for creating the raindrops this up here is multiplying by two and subtracting one which is a standard operation that you have to do

for a normal map to switch it from your texture you're storing your data from zero to one but in a normal map it needs to be negative one to one and so i expand that by multiplying by two and subtracting one and that gives me my normal multiplied by my mask and there's the the normal that i need for the drops so let's talk about how the mask is created here's the blue channel which is my temporal offset mask and as i said i subtract that from time and then i take the fractional value of what's left and what that does is it gives me time that proceeds from zero to one and then jumps back to zero to one and then it continue it's like making it into a loop and with that temporal offset mask it makes every drop loop at a different uh a different time now there's something really interesting going on here and that is these two nodes that i'm using to expand my normal map that's exactly what i need to expand and

separate out the two uh the two masks that i packed together in the same channel so i had one that go that went from point five to one and the other one that went from point five to zero and with this times two minus one now i have one map that goes from zero to one and the other map that goes from zero to negative one and so it's really easy to just add a single saturate node to get the one mask because then i throw out the data that's less than zero and i just have the mask left over that's from zero to one and then for my static drops i multiply it by a negative one because that data is from zero to negative one so if i multiply by negative one i flip it over and then i saturate that and i have my animated drop mask so i'm able to share these two nodes that unpack my normal map in order to also unpack my animated and static drop mask so then i combine those two

masks and i multiply them by this other mask down here now this is my world space normal with my y component facing up and also a factor that i pass into this to determine like is it raining or not and so then i'm able to multiply my map by that and i get my drop mask out and my normal map out and my result looks something like this you can see on the top of the surface here i've got drops some of them are static some of them are animated and i don't get any drops here on this side of the object all right let's take a look at puddles now i know that puddles have been a kind of a controversial topic lately but we're going to talk about them anyway so we wanted puddles to form uh all over the map and we're able to procedurally decide where

to put them based on a noise texture and this is this particular shader that i'm showing here is for our props but on terrain we actually used uh two of them that were scaled differently and combined with each other so that the tiling was much less apparent but i wanted to show kind of a simple example so that it was obvious what was going on but basically this is projected from world space y down here for puddle size one of the neat things about the frostbite engine is that i'm able to really easily pass in parameters from outside the shader that the engine is controlling externally so in this case this wetness parameters red channel contains a value from the environment system that is the accumulation of water and what this does is the game is keeping track of how long it's been raining and the longer it rains the higher this value gets so it's basically controlling how big the puddles can be and then i remap these two values and

pass them into my lens step which again is is remapping my texture color so the puddles start out really small in the areas that are black and they grow over time as my wetness red channel value gets higher then i also have another y up value here that's masking so the puddles only appear on up facing surfaces and i have some logic up here in the shader that's controlling what the normals look like in the puddles i have one node that does the wind ripples and another node that does the rain ripples so then i add those together and i blend between the current normal and the puddle normal and here i pass out my puddle mask and my normal mask for the puddles now if you've attended my talk two years ago i actually went into a whole lot of detail about how these drop ripples were

created and in that particular talk i was using the unreal engine so you can see this this node graph looks a little bit different than the other ones that i've been showing that's because i i built this example in unreal but it's basically the exact same thing in frostbite because i talked about it back then i'm not going to go into a whole lot of detail about the how these ripples are created now but please check out the talk that i gave two years ago on the vault to to go into more detail about how these rebels were created so i take this ripple logic and then i duplicate it four times you can see how that's happening here and the reason it's duplicated four times is if you're just doing it like this there's no possible chance that any of these ripples can overlap each other and that's really what we wanted to do and so i needed to do this effect multiple times with different time offsets different speeds different positions and scale offsets as well

so when all of those are combined together you get an effect that's much more convincing so here i have my four ripple nodes and i combine those normals together and then i pass them out now if you really want to get a lot of detail on creating weather effects and rain and puddles and ripples i recommend you take a look at sebastian lagarde's blog online it's absolutely amazing he goes into all kinds of scientific detail about what surfaces look like when they're wet how they change and he's got all kinds of references and it's just a really really useful material so here's what our puddles look like and in this particular video i didn't actually capture it long enough to see the puddles grow but you can see that they do have the the wind ripples and the rain ripples and we get puddles on the up facing surfaces of terrain and objects that are flat

all right so i talked about how to create raindrops and i talked about how to create puddles and we talked about wetness so what this graph is doing is it's combining all of those effects together so this node here represents the drops graph that i had previously this node here represents the puddles graph that i had and then down here what i'm doing is um i'm making the world kind of wet overall um so this multiply here is is like a value of 0.6 and so everything in general gets about 0.6 wet after it's been raining for a little while so i know that my drops are 100 wet my puddles are 100 wet and then everything else is about sixty percent wet and i combine those together and then i

run that through my wetness uh so that we can create wetness where where there's a puddle where there's a raindrop or just in general uh for for sixty percent of everything and so that's how our our weather effects are created now this is a really simple example we actually made the liquid look different on different surfaces so it works differently on rocks and it works differently on hard surface objects and it works differently on terrain but this is a fairly straightforward way of illustrating some of the things that it does all right and here's kind of a montage video showing what it looks like on different surfaces so here are some ruined walls you can see the water kind of flowing down the sides the puddles with the wind ripples and rain ripples also water flowing down the sides of rocks and you can see droplets on hard surface objects

and this was so much fun to do i just absolutely loved figuring out how to do all these things all right let's move on to water surfaces um we had tons of water in our game i think our environment artists decided early on that they really liked the way that water looked and so they're just going to put it everywhere so we ended up with all kinds of water but i'm going to go over kind of the basics of creating a water shader and then we'll show some examples of of the variety of water that we had so here are some some images that we correct collected kind of as reference to figure out you know what water looks like and these are some of the key elements we

identified so water has ripples on the surface it changes color as you go from shallow water to deep color it also changes opacity it's really transparent when it's shallow and it gets less transparent the deeper that you go then it has really nice looking reflections and it also has a refraction so this is what we start out with we start out with just a completely blank slate you know we have a flat plane here just a solid gray color and we need to create a shader that makes this look like water so i'm going to start off with the surface ripples and you can see here i have a normal map that looks like rippling water and i'm using three of these and basically these are different sizes and i'm scrolling them at different rates across each other and combining those together now i need to step back and tell a story here um i gave my talk for my wife maybe two weeks ago and when we

got to this slide she said wait a minute she said a couple of weeks ago you and i were on a date and we were taking a walk down by the river this is the riverwalk in san antonio for those of you that are familiar with it and you pointed out the water to me and you said isn't that beautiful water it has small ripples it has medium ripples it has large ripples and i thought you were being romantic she said you were doing research weren't you it's really easy to get into trouble uh with your wife uh when you're excited about things and you're out uh on a walk so be careful anyway so what this network is doing is it's combining three different sizes of ripples together and uh we also have this control here that blends between this this blue color here represents a flat normal and we're able to use ripple one suppression these are values that i can pass into the function ripple 1 suppression and ripple 3 suppression to control how much of each of those i'm

blending together so that i can get more big waves or more small waves and so here's uh the very simple start of my shader uh the the ripple normals are in this node then i use this node to transform them into world space because that's what frostbite wants and then i just pass that into my root and i get something that looks like this so it's not water yet but you can see that the ripples are sort of trying to approximate something that might become water if we do a little bit more with it all right so the next thing that we want to do is uh use some depth so i add this depth node and what this does is uh surfaces below my water that are really far away and i can specify a value for how deep the maximum is those that will appear white and anything that's really shallow or right next to the surface of my water will appear black so in this case i'm just

going to start out by passing that into my base color and i get something like this so you can see that it's sort of white down here where it's deep and black up here where it's shallow so that creates a mask for me and then i'm able to use that mask to do some interesting things so the first thing that i'm going to do with it is blend between two different colors i kind of have this light green color where it's shallow and then this sort of darker blue color where it's deep and that gives me something like this so i have my darker blue color here and my lighter green color here but i can also use this mask for opacity and so in this this case i'm just going to take my depth opacity here and i'm going to pass it into the opacity on my root node now i'm adding a value of 0.2 because i don't ever want the water to become completely transparent even at the edges i want it to have a little bit of opacity so i add a value of 0.2 there and so where i started out with this when i use my depth for opacity i end up with

something that looks like this now there's nothing amazing or fancy in my shader that's creating those uh caustic patterns dynamically so don't kind of get that idea that i'm doing something amazing there the the caustics are a completely separate effect that we project using an environment decal but they are there to illustrate the fact that you can see through the water and it's more opaque or it's more transparent where it's shallow and then as it gets deeper it's less transparent all right so there's still a little bit more that we need to do and the next step that we're going to do is add in some reflections so this node takes my world space normal and it generates reflectance and smoothness values now the smoothness values are pretty much constant i think i just passed in like a value of 0.95 or something like that but for reflectance what i want is to use a fresnel term so the water is more reflectance more reflectant at a glancing angle and then if i'm

looking straight down into it uh it's less reflectant so that's what that's giving me there and so this is what it looked like without the reflectance and then it's i add in the reflections you can see that i get really nice reflections out here where my water is at a glancing angle but as i'm looking down directly into it i get less all right now there's one one last thing that's missing and that is the refraction on the water so i'm going to add in one more node here which does refraction it takes my tangent space normals and does a screen space distortion effect and this also has a fresnel term in it so that i'm only getting refraction when i'm looking down at the water and not when i'm looking across it i want to get reflections looking across it and refractions when i'm looking down and so this is what it looks like without the distortion or without the refractions and then when i add that in i get something that looks pretty nice now we got some water got reflections

refractions uh depth-based opacity and depth-based color and then some nice ripples on the surface and these are all of the elements that we put together to create uh basic water now we did all kinds of water for this game like i said so i would start out with this and then the environment artist would come to me and they would say can you make it look muddy can you make it look like it somebody poured antifreeze into it can you make it uh really swampy looking and so we created tons of different kinds of water and i put together this video montage to give you some ideas of some of the different looking water effects that we're able to achieve in the game [Music]

[Music] wow all right we're almost done uh so let's just go over a couple of takeaways the first one is that collecting good references critical and if you can sneak in a trip to hawaii that's good too next it's important that when you create or when you collect your reference that you identify the elements that make this thing what is it you boil it down to its essence and figure out what is it that i'm going to try to

imitate in my shaders based on the reference and like i said before it's almost as important to identify the things that you're not going to do as to identify the things that you are going to do and you need to figure out uh things that you can leave out uh to save on performance because you can't do absolutely everything early on in the production of our game we had a lot more complicated looking weather for example and we found that we just couldn't run it and we had to simplify things a lot so the examples that i showed you were the the more simplified versions of of what we started out with so it would have been a lot better to do that up front but that's not how things turned out if i've done my job today in my talk hopefully all of you are thinking man shader work is super cool how can i get into this like if you don't write shaders how can i start learning this and here are a few things that you can

do to get started first of all take a look at other games when i was in the process of working on this i loved playing games like horizon zero dawn and spider-man just just by show of hands how many of you been have been to 10 or more talks about spider-man at gdc okay yeah but anyway i loved looking at other games and figuring out what they were doing you can do google and youtube searches for tutorials on writing shaders you can download unreal for free for example and and get into shader writing that way or use shader effects in max or maya and most importantly just do it identify something that you want to try to imitate and just give it your best shot and i talked about finding a book to read these are some of the books that i learned how to write shaders with and this was maybe 10 or 15 years ago but this knowledge is all still very relevant to to writing shaders now so if you want to

get started it's really great to divine to grab a book a lot of these books are available for free online now and so that's my talk i have my email address here and my twitter handle if you want to give me some direct feedback and i really appreciate all of you for for coming and listening to what i have to say today so thanks a lot it looks like we have about five or ten minutes for questions so if you'd like to ask a question feel free to step up to the mic and i'll do what i can to answer go ahead hi hello i'm sorry i may be missing some information so just want to confirm that for your ring jobs maps they are like normal map and the temporal offset mask and three masks then then you said you package them to the one map so as i know like like the rgb channel

only three channels so how could you package all three or all maps in the one map and like when you withdraw the normal map you make sure it's the correct normal map sure so a a texture can have three channels or it can have four channels you can have red green blue and alpha yeah and so the the static map and the animated drop map were both packed into the alpha channel together okay so a screen or overlay together in the alpha channel right okay and then your second the second part of your question was about the normal yes so if you put the red in or if you put the x component and the y component of your normal map into the red channel on the green channel then in the shader you can reconstruct your normal now in this particular example i just kind of didn't do that to make it cheaper but if you want it to be technically correct you can do the math

to derive the z chant the z component from the x and the y because the normal is supposed to be normalized okay that math has a square root in it which is kind of expensive and so i just skipped it in this effect because i didn't think it was necessary i just assumed a value of one for the for the z component instead of calculating it okay okay so actually you use the like blue channel to package one map and then the alpha channel packages the rest too right that's cool okay thank you very much you're welcome over here hi uh you mentioned your first pass on the weather stuff wasn't performant enough to ship and you had to optimize it a bit sort of along those lines do you have like shader lods or like per skew shader control high medium low yeah yeah absolutely and those are the kinds of things that i took out of these examples just so my graph didn't look like a pile of spaghetti for the shots of my graphs that i was showing here they're really simplified down but we

have a node that controls quality where you can it has a low medium high and ultra pin and whatever you pass into each of those pins is what gets compiled as the shader for those quality settings how often do you have to use that like what percentage of the materials in the game need a cheaper version um that's a that's a hard question i use it as often as i can um because you know you want the game to be much more performant on each of those levels of quality if there are things that can that can be left out without absolutely killing the the image then we want to do that on the the lower quality levels for sure so you like do it ahead of time instead of waiting for engineering to come to your desk and i've never had engineering do that to me um i usually do it myself um because we we work in kind of two passes so we'll we'll do a look dev development pass and get things looking

the way that we want them to and then we'll go back and perform a performance pass and really that just involves you know using uh razer on ps4 or pix and just kind of seeing how much things cost and well does it fit in my time and if not you know how can i make it faster cool thank you you're welcome hello hey um my question is more on like the organizational bookkeeping as you're putting together these growing libraries of shaders so you mentioned you have environments come to you and ask you for like a new effect or uh you have like this extensive different types of water and i struggle personally it's where i'll go down the path of wanting to create more and more like master materials so do you have any certain cutoffs that you try to keep to to determine whether you want to combine two setters together or keep steph more separate that's a really good question in the case of water um we don't have the ability to

pass um external parameters in to adjust it and so every time the artist wants something new i need to to create a new shader and that's one of the reasons why all of those water nodes were created kind of modularly i had one for reflect reflection one for refraction because i could just take those and put them together to create a new one fairly quickly yeah for some of the other assets like vegetation or rocks or that sort of thing we had one really large shader but then you could tick boxes to turn it on and off the features that you needed so that the the shaders didn't get out of hand in terms of how many of them there were the artists could just pick i want the rock shader and then they could check the boxes for the wrong uh the features that they needed even with the master series like the rocks is there a certain cut off to where like you don't want to have 20 plus exposed parameters for them to go through for each yeah yeah absolutely uh i don't have a silver bullet for you

on how to right how to decide how to do that um but definitely something to consider yeah yeah absolutely thank you i'm interested to hear more about the optimization pass uh did you optimize it yourself or did you ever hand it over to like a graphics programmer to kind of hand optimize it uh no none of our shaders were touched by graphics programmers sometimes that they sometimes they would say hey in general this view is too expensive go and figure it out but optimization of the art assets is generally the domain of the tech artists at our studios and so you know the graphics engineers would say hey tech artists figured this out but they wouldn't actually get in and and tell us how to do it it was just a matter of of isolating a specific view or direction that we are looking in the game and you know if it's not running at 30 frames a second here or actually faster because we had to account for characters and vfx and all kinds of other things i think our target was like 25 or 28

milliseconds if it was over that then we would just run that specific frame through pixar razor and identify targets of opportunity to to reduce all right thank you i've already tried to packing extra information to a normal map channel but with the x5 compression i cannot avoid compression artifact on normal trading so could you tell me what kind of comprehension setting do did you use yeah so in the case of this rain texture it's a 512 by 512 and because it's used on every asset in the game we did not compress it so this texture is stored uncompressed oh i see okay thank you oh hello nice talk uh i'm interested in the doing the refraction uh did you do it in this screen space and did you use the death

map to assist the pickup of how to uh resolve the uh resulting uh like angle of the light vector right so one of the things that's interesting about our engine is that yeah it it does it does this distortion in screen space and what i really would like to have is something where the surface of the water is not distorted and it only distorts what's underneath it but unfortunately because this is a screen space effect that gets applied to everything and so that's why it was really important to do the the fall off or the fresnel so that it only showed up when you're looking directly down what was the second half of your question i was just wondering if you used the desk map to assist in that pickup so i use the depth map to determine how much distortion to apply so the deeper the water it is the more i would distort is that what you were talking about okay so you it is an approximate term then yeah very nice thank you all right last question uh i was actually

wondering about that depth map myself is that a screen space depth map for your water depth or is it actual like from the top how deep is the water down ah so yes it is a screen space effect um did you run into any uh issues with the fact that you know different angles would produce a different depth yeah and for that i had to multiply it by a fresnel term to to isolate it so that you'd only get it when you're looking down it had to be adjusted yeah gotcha thank you good question all right thanks a lot for coming everybody
