Content Fueled Gameplay Programming in Frostpunk

[Music] good afternoon ladies and gentlemen first things first i would like to remind you to turn off your cell phones and to fill out the session evaluation email and let's start my name is alexander kau i am lead gameplay programmer at 11 bit studios and today i would like to present you the architecture that we used in frostpunk a few words about me i've been gameplay programmer for about nine years now most of this time i spent at 11 bit studios and i programmed titles like anomaly anomaly 2 this war of mine and most recently i was the lead gameplay programmer of frostpunk that came out last year for for those of you who haven't played frostpunk it's a society silva survival

game so at its core it's a city builder but with strong emphasis on the survival aspect and harsh conditions in case of frostpunk the world is frozen and we are the leader of the last city on earth and the game is focused on society and how the harsh conditions can change the society itself what impact does it have on the society and on our decision decision making considering the society so it was made based on liquid engine our own homebrew technology that has been developed since nine years or so and it was programmed by five gameplay programmers and five engine programmers and everything that i will present you was made by those wonderful people me included so the idea of the game had

introduced us to many challenges first of all there was no solid reference for what we were trying to pull off because there was no city builder game that focused on the survival aspect aside from banished maybe but the thing that could stand out for our game was the focus on society that was never seen in a city builder game as far as we know so that meant for the programming team that we had to do a lot of research and r d and support our designers who did the same so fast prototyping fast iterations that was the main thing during the development and aside from that it was the biggest project for 11 bit studios this war of mine was made by 20 people frostpunk was made by 70 people so the scale went up pretty high

the solution we came up with was data-driven architecture that was based on entity component systems it proved to be a flexible easily expandable architecture that allowed the design and art teams to create content and with programmers only providing tools or new pieces of the puzzle and the architecture proved to be very good for iterations and experiments and i would say that without this approach without data-driven programming we wouldn't be able to create such a unique game as frostpunk i believe is and i will try to tell you why so when we started programming creating frost bank we had to start from somewhere the idea was that we start with something that we

all well know so the economy system the building systems and so on so the requests from our design teams were was where that they needed a system where they could define new entity types they could introduce for example new buildings new behaviors they should be able to quickly reconfigure them and they should be able to swap features between entity types so if we create a coal mine the fact of gathering coal should be we should be able to transfer it to another building as a feature and we all knew that it won't end on 20 entity types there would be more entity types so the system should be able to scale well enough so we started with data structure main piece of our data structure is something

we called rtti class it is a c plus class that can be serialized to xml and to binary and our rtti system recognize the type and loads the class from the definition we use the xml in our editor in our work place and the binary format is used in the final content we also introduced global unique identifier to identify rtti classes it of course has fixed size text form i think you will understand what it is and the last piece of a data structure puzzle is template template is a rtti class that define an in-game object type it is of course identified by unique id and it's widely supported by our editor

our tool so from from the template the instances of an object are created it's like a prefab in unity so the pipeline during the game load during the work goes like that we start with xml file then our rtti system creates template object in memory and then class factory creates its instances of in-game objects pretty straightforward template examples entity templates like buildings like citizen template and so on components in entity component systems were also implemented as templates mesh templates ui recipes basically everything you think was defined is defined in our architecture by a template class it's yes i think you all know what an

entity component system is so to briefly remind it is a system where entity is just a container for components the components there's carry that only and systems work only on components that are attached to them and the main advantage for us especially considering the number of entities in the city was that the update didn't go through entity by entity way but functionality by functionality so everybody in the city moved everybody in the city starved everybody in the city did their work and so on so on so state and data is kept in component all logic is implemented in systems but in our case systems can also keep global state it proved to be very useful for a game

like frostpunk because for example the economy system keeps the track of the resources the player has and it is global global value that can be taken from the system it proved useful for us so we we decided to let the system keep their state and we also needed to face the fact that our engine is older than entity component systems and not all parts of it were transferred to the new architecture so some features were outside of vcs that had an impact of on our code and for example that would be ui system input system rendering system and so on components and component templates as i mentioned earlier are rtti classes entity template

has a list of and of component templates that are inside this entity and component keeps reference to its template object so constant data is kept in the template object and the mutable data is kept within components of course via the serialization it can be saved as a safe game state we introduced two restrictions to the system we've decided that only one component of a type can occur inside one entity which helped us to keep the configuration clean and was less error prone than the approach where you can put many components of the same type on an entity so the designer would be warned or even would be forbidden to put one

to put more than one component of the same type on entity and another rule is one system per component type in our architecture one system is only taking care of and processes one component type this is single responsible responsibility principle and it proved to be very clean for us to navigate through the code so we had a lot of new people on board during the development of frostpunk and the clarity of the code was very important for us so it simplified the architecture and was easier to to understand when one component was handled by one system but that implied that there was no system or component classes inheritance so we technically couldn't

allow the inheritance and through that the only way the functionality of a component could be expanded was via adding a new component type so if there was a movement component type for example the running component type would be another component handled by another system or we add the functionality to already existing component this allowed us to head for the component to have a unique id so checking if the entity has a component of a type is just comparing bit masks so it worked but it introduced a new problem because of lack of inheritance some components were dependent on each other and for example

generator is a special building in frostpunk the main building in the center that provides heat for the for the city and it has of course generator component but it is also a building so it requires building component we solve that dependency by introducing attributes and attribute require component marks component type as prerequisite for another component type so when the generator component is added by the design team the default building component is also added on to an entity or the designer is prompt to define the building component if it's not able to be created by default and on the other hand there started to occur a problem with initialization order so we initialized components as they

were added by the designers but some component needed to be initialized after another components so we introduced attribute adapter component to mark that certain component type should be initialized before another component type and for example workplace component is a component that manages the efficiency of the workers inside a building and to properly be initialized it needs information about what what is the amount of people allowed in this building so it needs to be added after place for agent component as you can see in the example through the development of the game the design team pinpointed that a lot of entities are basically the same in some way so they have similar components attached

to them and they had to when creating a new building for example they had to copy the component definitions that were basically the same for every single building to solve that problem and to make the designer's life easier we introduced component sets component sets are batches of components that the designer can define it can be nested inside each other and it can be attached to entity so aside from the component list the entity also has pointers to component sets that are added when the entity is initialized so when the entity the building is a common building like any other the basic component set is sufficient for them but when something special should happen inside the building the designer always

can add the component set and not the component definition of which special configuration and the definition from an entity overloads the definition from a component set and here is an example of generator component it inherits from some base component type the component input class is an abstract class that basically combines the component template with components itself and allows the class factory to properly initialize the component then the capital lettered purple instructions are macros that allow the rtti system to work properly so it introduce introduces attributes as you can see two attributes require component and after add after component

which i spoke earlier and then we've got property declarations these are also macro definitions that adds the class fields to an rtti system and then of course our ordinary class members and for the convenience of usage we also befriend a generator system so that the system can access protected members of of of the component an overview over our architecture looks like that so the green part is what is defined by the design and art teams so we've got behavior trees for iai system that is used by ai components and ai systems but that's the topic for another talk then we've got templates configuration files which i'll cover in a moment and other things like user interface

like engine render and so on so the game state is held by entity component systems with some helper classes that manage configuration files and the rendering and user interface input is like a black box in the stock so we created a basic city builder with some basic economics but we didn't even start to create a society survival game so the design team wanted to start iterating on that and they wanted a system that would allow them to control the flow of the game control the narration control the special events that occur either from the story or from the game state itself so they needed a system that could allow them to write the story via

in-game events some of them scripted some of them emerging from the game state they also needed a way to easily check how the player is doing what is the state of the city and the state of the citizens and another requirement they wanted to define things once so if they define a building in some place of in the configuration then they shouldn't be shouldn't need to duplicate that definition so we needed a system that would allow us to point certain parts of configuration from another parts of configuration we introduced a concept of an entry to solve that last problem entry is an abstraction for a configuration part it is of course an rtti class with its own unique id but it has also a readable name and of course the data

it consists the idea is that a configuration file for example a building list provides entries then global entry manager reads these entries and the once more from another parts of configuration we are able to point on that entries inside entry manager via entry links so for example we've got config file i which consists a list of entries of type foo entry then we've got entry manager so after the game is loaded the the file is read the entry manager reads the entries and can provide a list of them and from another file we can put an entry link that points at a certain part of configuration

it was very useful because when entry link is a type of its own when a class an rtti class has a field of an entry type entry link type the designer when is configuring that part of that object that entity order is able to pick from the list of available entries it's all connected via general user ids unique ids so the configuration is always consistent because when an entry that is used somewhere else is deleted we can also always check if the entry link pinpoints on something and therefore we can inform the design team that the configuration is wrong is is error and as of the narration goes

we introduced game events system it is a basically a script system that is put in xml then it is loaded by the rtti system into c plus classes and held in memory that way so there is no scripts interpreted during run time and the idea was to create it for quick prototyping but with the cleanness and polish of final content so they could be valid in final content as well the main building part of game event systems is of course game event game event is a configuration entry that is built from three lists of elements triggers conditions and effects all of these elements are configurable by the design team the programming team

only provided different types of triggers or conditions or effects and with some additional features like local and global variables it became almost a programming language it has its pros and cons that we'll cover in a moment so triggers triggers are objects that register themselves for a specific incident in game so for example a specific time of day deaths of that citizen new child born whatever else you can imagine and when that specific incident happens the trigger is fired so here you've got uh an example from our editor a trigger that is named construction of building beacon finished its class is building work

the specific building is beacon and the event occurs when the construction is finished so the designer is able to configure the trigger a bit so to be specific when the trigger fires but main part of the configuration for conditions is done via condition system so conditions are basically boolean expressions that evaluate of course to true or false and they utilize some helper classes that provide information about the current game state all in all they take form of polish notation expression and in our editor it looks like a tree that is expanded and for example here we've got a comparison of integer comparison of one and amount of bodies the comparison is lesser than

and the left side is configured as constant integer with value of one and the right side is that helper class that i mentioned it is checking for a resource in this case bodies grim and last but not least we've got effects effects are simply put functors so c plus plus objects that are basically functions that can change game state uh when they when they fire when are executed so the flow the designer could create and could work on goes like this we've got ecs systems that provide game state when certain event in game occurs then the trigger is fired the conditions are checked if the conditions are evaluated to true the effects are executed and if the conditions are evaluated to false

nothing happens for example trigger citizen died from starvation condition more than 30 deaths from starvation effect the society should be manifesting or protesting that we need to solve the starvation problem another example new sikh citizen if there are more than 10 sick citizens without medical care start the quest to solve health care problem another example day 3 12 o'clock a bit late no hunter's huts no food create a hint for the player to build hunter's huts the last missing part of the event systems system was the context so when the event fires for example new child is born we want that child to be the context of the event so for example we want to give a name or whatever inside effects

and that is provide via context so every event when the trigger fires it assigns a context an entity to that event and it is valid through the conditions part the effects part and so on so we've got a entity that fired the trigger but sometimes we need to affect other entities connected somehow by the event so for example when a new child is born we want to name that child but we also want to raise happiness or hope for the family so inside the effects the designers can put selectors that filter entities through the city through the game state basically and execute effects with these selected entities as contexts so they are able to switch context during

the event execution and by the way default context for every event is a generator so when the event can't be really hung on anything it is hank on generator here is an example from our tool our editor of a game event it is a first death it triggers when a citizen dies and it basically creates a tough decision to build cemeteries or to just dispose the body in the snow we reused part parts of the system so the conditions were used in requirements for research the effects were used in technologies and in uh policies that the player could introduce to the city uh and the effects of course were used in hard decision choices so the price of this system

is were spread through a whole game the it proved to be a very useful tool tool for debugging for example an event could have a trigger that fires when certain console command is put into so it was easy for the design team to test certain story parts just by typing a command and the effects would be executed just like in the game it controls all of our flow in game the entry system and the fact that we could connect certain parts of configuration with certain events certain entries provided a tool to create libraries so in one scenario we've got certain events set and another scenario we could use another event set

it was very complicated to configure and got glad that we had designers that could cope with that because it required certain programming skills just to get into the system and without that we wouldn't be able to use that at all and of course we are aware that we need a better tool to simplify the configuration because right now it looks like this this is a list of directories of events then when we open one directory there is a list of events and when we get into an event this is a configuration for a single event the xml that defines that is huge and we need to find a way right now to to deal with that somehow okay so the designers were happy but the art team wasn't uh of course

they created art but they also needed a gameplay system they needed a system that would allow them to check the game state the conditions that are currently in the city and change the appearance of building of buildings based on that so they needed to define what visual parts would change and to define the conditions when they are they will be changing and they wanted to apply them at on every single building in the city so for example when the temperature is low is below zero degrees celsius the buildings should be covered in snow but when the temperature is higher the snow should disappear when the building is active there should be an animation that indicates the activity in that building

when it's not active maybe a prompt for a player to that the building is not working and he should do something about that and so on so on night the lights in the building should be on they they should be off so here's an example of a generator in different appearance states the first one is the basic state the second is when we introduce laws that basically change our city into a dictatorship state the third one is when we go too far with our religion to the point of fanaticism and the other three are different upgrade states for for the generator and the tricky part is that we needed a system that would allow us to combine the totalitarian generator with the third or second upgrade

to do that we introduced appearance state appearance state is basically a string label or a config entry that is defined by designers or artists and can be added or removed by game state mechanisms or by effects a building can have infinite amount of active appearance states for example active totalitarian building during night and so on and for the visuals some of these states should be able to be excluded so for example building during night and not under construction and the final visuals of the building depends on the combinations of these appearance states the appearance state can affect many many different things of course mesh elements props like like flags like the religious symbols and so on lights

textures outlines shaders animations ui icons sounds basically everything that surrounds the building and it has any impact visually or sound like sound wise on the player to aggregate the things that are changed by the appearance we created appearance overlay appearance overlay is a definition of what changes when this when this overlay is applied so for example visibility of certain props animation start stop and so on when the building is active the animation should start when the building is not active the animation should stop so this combined with appearance conditions creates a system that applies certain overlay

on appearance when the conditions are met so when the conditions are that the building should be active during night we should apply appearance overlay that puts on the lights and this is this is how we did it this is a simple sample configuration of appearance state this is an appearance for a building that is outside the required heat zone so the building needs to be heated and it isn't the conditions are the building is constructed the building requires heat zone the place is outside hit zone and the weather is different than storm because during the storm we provide the player with different prompts not that meaningful meaningless prompt that the building requires hits on and the overlay is only changing status indicator in this case it is an icon above the

building so when these conditions are met the building has these appearance states the icon appears and the players informed that the building requires heat zone and it isn't inside the heat zone so to sum up the data driven architecture as i have shown you in examples provided us with the ability to quickly iterate with minimum minimal involvement of the programming team it allowed us to create rapid prototypes and the programmers were only introducing new toys for designers to play with and artists of course and the ecs system that lies underneath it glued everything together and was was an efficient system that allowed once again rapid

prototyping and lots of r d that the game required that is all thank you very much if you have some questions i would gladly answer them [Applause] hi can you please explain this idea of template like probably provide some example what is what can be a template for a component what can be a template for what i'm smart component if you have some component you specify template for this component what is template template is just the definition of an object so for example the template defines what fields are in the object and what is configurable by the designer so the designer only sees the fields that are in the template okay so

component itself does not have fields configurable fields or no it does have but okay there is a configuration and there is one time so in the configuration part we've got templates only that define the that can be configured and create the component and when the component lives inside the runtime it can change the state and it only has states but the definition is remains the same okay it's the same concept as with the class definition and class instances okay thank you thank you so uh when the with the appearance system that you can have authoritarian not and night and everything that they can define a huge matrix of different visual configurations for a building for example uh did you do like a kind of uh one special mesh for each case which sounds like

that's a lot of meshes or some kind of combination system so that you overlay the and all the flags over their building and stuff like that so we use the simplest way the art team could cope with so they aren't our artists aren't really into configuration so we introdu we gave them a tool that uh basically uses the name of the mesh used in in the in the entity so that they can show every single mesh that has that name and therefore they do not need to look into the configuration they only need to look into the elements named in the editor so well so say um they have to decide for each case like i don't know how many cases but if it's fanatic and it's not night it could be a different like visual configuration that if it's okay

right yeah and they gave the designers and programmers requirements and we created the configuration for them only a few of them could make that configuration it there was a lot of cases but with the naming convention we could allow them just to you know they put an effect that has night inside it and it is already configured before so it would be applied in every building the the effect with knight is that okay thank you hi i was just wondering on how you actually managed to create a bridge between uh your your visual and your system because well the classic uh mvc you want to separate your view from you from your system but did you create specific system to create that bridge between your empty your building and

the visuals um well it is one-way communication so the flow is always like this uh it is it always starts with the game state and the visuals depend on the game state just like the view always reads the data yes the same concept okay and also i just wanted to did you inspire yourself by existing ecs system or is it was it a hundred percent custom made once more i'm sorry sorry did you did you inspire yourself by existing ecs system or did you build this from the ground up we when we started developing frost monk it was like four years ago or so and i don't recall any existing ecs system that was production ready but yeah the unity and unreal i think they already started developing and there were some papers that we based our system on so yeah it was it wasn't

from the ground our idea okay by no means but i kind of it was a long time ago i can't really remember what references did we use okay actually i was just curious thank you i have question about a system and component you mentioned that one system do is one component right yes so what if designer needs some function that you need to deal with the data from two components well the components are accessible via systems so one system can communicate with another system and get the data from certain components it's just the one system can change the components of one type and getting data from another system another component is like no no issue it's no problem so the what i mean by one system one

component type is that one system can change the data of one component type ah okay thanks i'm a little green with uh ecs systems in general but you mentioned that your old engine uh didn't support ecs for the visuals and the input yes is that an area that you would have liked to extend to ecs i've heard things in the past that usually the visuals are kept out of each ecs systems well i think that as far as i remember that our engine team is already porting certain parts of configuring of engine to the acs system but as i am stuck with frostpunk for now i'm not like updated what about the newest changes in the engine because it won't affect frostbite at all so but yeah they they try to move with to ecs even with the rendering

but if they pull that off i don't know yeah awesome well thank you very much thanks thank you hi uh you mentioned that input and ui were two of the things that had to live outside of the ecs control but you also mentioned that there were ui recipes could you briefly explain what the ui recipes were well the ets system and the templates and the rtti that i was talking about are separate things so the ui system uses ui recipes as templates to create user interface so once again we've got editors that create xml files that are read by rtdi and the final ui is created okay so it was it was just the data format that was being shared there but yes then completely outside of ecs yes gotcha okay thank you all right no more questions so thank you very much
