Replicating Chaos: Vehicle Replication in Watch Dogs 2

my name is Matt del Bosque I'm a team lead programmer to be soft Toronto and today I'm going to talk to you about some of the stuff we did for vehicle replication in watchdogs - the best place to start is for me to explain the chaos part of the talk so let me show you chaos here we go so watchdogs two's bounty mode is a multiplayer game mode where three human players team up together to take down a fourth player and they do that alongside a whole bunch of ai-controlled cops and basically everyone gets into these cars you get these crazy high speed chases everyone's crashing into each other it's an insane lot of fun to play but getting all of that to replicate nicely was a bit of a challenge so I'm going to talk to you about some of the solutions we came up with today so first of all a little bit about our network

architecture so it's only four players completely peer-to-peer so there's no server in the middle that's kind of the master of everything and although we're only supporting four players there's actually a lot of entities to replicate so all of those cops driving alongside you pedestrians on foot all these things do add up to a lot of entities and those entities their authority is completely distributed so all those police they're actually earned by different players which adds some extra complication so when I first started working on this I'd done a lot of character replication in my background so and I figured all the techniques that I knew and loved that just apply them to vehicles and it was going to be super easy well it didn't quite turn out to be the case so what's harder about vehicles first of all vehicles drive fast so even if you have a little bit of lag say 100 milliseconds that's 2 to 3 metres

difference in their position which is like half a car length to a full car length and say you're working on a race well that's the difference between winning and losing now we don't have races in watchdogs - but the same principles apply and I'm going to talk about some of that later on the other things that cars do that people don't is they collide with each other so there's a lot of rigid body physics that come into play that cause them to interfere and react with each other and on top of that we're not just dealing with players and versus players colliding but there's a lot of traffic in the in the open world in watchdogs too so there's actually a lot of things that you're going to be crashing with and the other interesting thing I discovered while working on this is that when you're looking at vehicles driving around the human eye is really really sensitive to irregular velocities so if you're dead reckoning algorithm has got a few little inconsistencies and even a car going in the straight line and it's not perfect going perfectly at

the same velocity it's actually really noticeable for the player and that adds more more complications so what I'm going to talk about today first of all how we go about debugging trajectories I'll talk about the technique that we use for dead reckoning which is called projective velocity blending with a little bit of a twist for vehicles I'll talk about how we use snapshot buffers to interpolate and extrapolate our positions I'll talk about how we deal with collisions and finally I'll cover some of our and solve problems and future research directions so the most important thing you can do when working on dead reckoning is debugging your trajectories so this is the color scheme I'm gonna be using for the rest of the talk and I'll explain it quickly the red dots are the authoritative snapshots that you've received from the master the kind of blue dotted lines they're the extrapolations from those dots so it's a prediction of where we think the master is going to go and finally the green

path is the actual path that you've calculated from your dead reckoning then that the car has taken and really the goal is to get the Green Line matching up to the red dots as closely as possible because then you've replicated exactly what happened on the other end the algorithm that we use for dead reckoning is called projective velocity blending it's very well known I've used it a lot for care dead reckoning in the past and he still works pretty well for vehicles I want to explain the math the maths but I will explain sort of how it works basically let's say we have a replica at this position p0 going with a certain velocity and we receive a snapshot from the master the blue one that says hey actually you meant to be over here traveling with this velocity so what we have to do is correct for that and what we do is we interpolate from the current local velocity to the predicted master

velocity over a short period of time which gives us this this blended orange trajectory and then we interpolate between the two over that same period of time so that the final trajectory that you take is that light green path which basically takes you to from where you were to where you should have been and it's pretty smooth and pretty nice I'll show you a video of what this looks like so this is a car driving round in circles I've reduced the snapshots and right here for FX so you can sort of see the artifacts a bit better and you'll notice that circle but it's taking it's not very smooth right and one of the reasons for that if you look at the blue lines the extrapolated predictions well it's always in a straight line right it doesn't know that this car is actually driving around the corner so you're dead reckoning is trying to match to this very irregular polygon and you get this little jerky results so what can we do to improve that well ideally we don't

use a straight line for a prediction we predict that our car is turning around the circle that's going to be the best way to to get a better result now interestingly how do we how do we work that out so we already transmit the steering angle of the cars wheels which in theory should be enough but actually it's not and the reason is that a very cool simulation is actually really complex so in real life and enough in a simulation if you have the turning angle of the cars wheels to actually predict where it's going to go it's a factor of a whole lot of things the vehicles current velocity the tire temperature the friction with the road surface you actually have to take all of that into account to work it out properly and so this was a bit too much and it was it would have been a challenge with our engine to do that having said that what we the other information we have we have the position

the velocity the angular velocity that we already transmitted anyway and what we ended up using is just the your component of the angular velocity which work it we can then use that to do a very simple kind of 2d integration to predict whether cars going to go now you might notice there's something wrong with that because if your car's kind of turning in a nice circle then that's really easy but if you're sliding and turning then your prediction it would be wrong but for our game actually this wasn't an issue because the cars in watchdogs - they're not tuned to drip not a game about drifting so for all of us for our game this simple solution was actually the best and then the result looks something like this so what you can see now our extrapolation the blue lines they going nicely around the corner and dead wreckin trajectory well it's not now it's a perfect circle so

that's super nice and we can move on to the next technique so the next technique we used is it's called snapshot buffers the theory there is that instead of just extrapolating from the snapshots that we've received we wait a little while we buffer the snapshots that we've received and we interpolate between the last two so what's good about that is that by interpolating between two nine snapshots we representing a much more accurate trajectory so we're actually representing something that really genuinely happened because we have all the information what's bad about that is that we're now rendering something further back in time and I'm going to talk about why that's an issue first an example so we have a car driving in a straight line sends a snapshot to another machine it takes a

while to arrive we keep driving we keep driving we finally send another snapshot and now we have enough information to start our interpolation so in this example our replica is five frames behind the master now why is that an issue I'll give you an example this is a picture of taken on two machines there's two car driving at high speed through an intersection at 90 degrees to each other and the so the same picture the exact same moment in time and what you're going to notice is on the left-hand side they've crashed into each other and on the right-hand side well they know we're near each other and if we superimpose the two you kind of see this effect that I was talking about with the half to a full car and differences in this case it's actually a bit a big difference because one player thought he crashed into the other guy and the other player didn't see anything at all so that's the

sort of problems that we get when we interpolating too much having said that just because we're buffering all these snapshots well we don't have to interpolate between them there's nothing stopping us from actually extrapolating from the last received one and what this gives us is we introduced this really simple concept which is basically a time offset and what that really means it's really easy to understand it's how far back in time do we want to render this car and then we so if we take the time offset you know subtract it from the current time if that lands between to receive snapshots then we can use the calculator trajectory if that time offset is ahead of the last receive snapshot then we go back to extrapolation I'll look and for us this is really easy because we time-stamping our snapshots anyway so we can do those calculations pretty easily I'll show you an example so again we

have a car traveling at a bit of an angle now it's sent to send a snapshot to the other peer and now we've decided to extrapolate now because we don't have as much information we're kind of extrapolating the wrong way in this example now we've received another snapshot that's basically ahead of us in time and we can switch back to an interpolator trajectory and so the end result in this case is that replica is only five three frames behind the master which is a little bit closer and reduces those effects of mist collisions that I was talking about obviously that you can see the trajectory right it's not perfect it's a mix of interpolation and extrapolation but it's still a better result because we kind of getting the the best of both worlds to some extent the challenge here really is tuning the time offset and there's no real magic formula here we spend a lot of time

playing the game under different scenarios adjusting until we got something we were happy with and it's really a balancing act between too much interpolation and you're going to miss collisions and too much extrapolations which is going to cause more discontinuous trajectories potential D sinks and that sort of stuff the formula we ended up coming up with in watchdogs to is basically this it's kind of a factor of the measured lag to that period plus a bit of a constant value and we calculate that every frame but it's highly damp we clamp it to something sane and although I said constant value the constant value is actually variable because it's proportional to the speed of the vehicle and basically if you're traveling slowly then miss collisions unless is less of an issue so you can interpolate a bit more which means we reduce no we increase the time offset so you can go a bit further back in time and it's still gonna work pretty well now with all that

in place we were pretty happy with that dead reckoning cars driving around we're looking very good but then our testers started to try and break the game and they were crashing cars into each other and starting to report issues they were saying hey that collisions they don't really play out the same in multiplayer as they do singleplayer let me show you a video you have to pay attention because you it's it's a bit subtle the first time so this is two cars two players crashing into each other a master versus a replica I'm going to show you this again okay so something's not quite right about that if you play the game in single-player and you have two cars crashing into each other with the collision they kind of stop right or they might push each other out of the way a little bit but what you're seeing here in multiplayer is that they crash and then go shooting out far away from each other at high speed

that's not right this is not what we want so what happened how do we figure that out so as we know there should not be this shouldn't be happening there should be kind of stopping the way we ended up tracking this down is we we have a tool on the engine that lets us record the states of every entity and kind of play it back and look at everything frame by frame and kind of really analyze it and figure out what's going on so I'm now going to show you a frame by frame analysis so what we have is two cars about to crash into each other there's the replica on the left the master on the right so far so good again so far so good now they've collided into each other that's still fine now this is where it gets interesting what you can see there the replica is still continuing in a straight line you can see the extrapolation there which is

basically it's based on the snapshot that's before the collision so the extrapolation is basically saying well keep driving I don't know that you've crashed into anything so the only thing I can predict is that you're going to keep driving straight and again we continue we continue and finally we receive a snapshot from the master that says hey you crashed into something you meant to be further back from where you currently are so then our dead reckoning corrects for that then starts pulling the car backwards but basically while this is going on what's really happened is you kind of have these bunch of frames where the replica is pushing pushing pushing and that rigid body is imparting a huge velocity to that car and that's what's sending him shooting backwards and basically the other things happening on the other machine where this cars getting pushed and he goes flying backwards and the end result what everybody sees is this kind of massive high-speed ejection so we don't want

that how do we go about solving this well like I said we not receive the packet that tells us about the collision so we don't have that information on the on the replica side and really this is an unsolvable problem in our case because we fully peer-to-peer no one has authority about the collision there's no one true picture of what that collision should actually look like and this is when I really wish I had a server because the server could be authoritative and make all those decisions for us but we don't so we have to live with that so what can we do we know that the collision is going to happen right those rigid bodies they're going to be crashing into each other they're going to be applying forces to each other whether we like it or not so why don't we try and live with it instead and basically what we really want to do is give the local physics a chance to simulate the collision and basically after a short period of time

we then blend back into the correct dead reckoned trajectory and really what we ended up putting together was a tunable a blend factor that blends between two velocities so one is the velocity that's imparted by the rigidbody simulation and the other is the velocity that takes you to the dead reckoned position and we basically have to blend between those two and decide what we want and the goal is really to let something believable happen locally and then give time for a snapshot to arrive that takes the collision into account and then we can blend back into it what's hard there is tuning the blend factor again there's no real magic formula we played the game a lot we spent a long time crashing cars into each other under different scenarios and came up with stuff that looked good and really there's two parts that you need to tune

one is while there is a collision whilst your blend factor how much of the local physics velocity you take Bursar's the dead breakin velocity and when the collision finishes how quickly do you go back to full dead reckoning and what we ended up shipping with is a graph that looks a bit something like something like this so before you have a collision you're fully in dead reckoning as soon as you collide with something we there's a short period of time when we switch to full local physics so that recommended is ignored completely and we just simulate the the rigid bodies locally and then we kind of go to this halfway stage where we're taking a little bit of the dead reckoned trajectory but still mostly local physics and then when we come out of the collision we ran back up to full dead reckoning the other interesting thing here is that we ramp back up a lot quicker for bikes versus cars this is because bikes they're smaller they're lightweight so

they kind of go in and out of collisions a lot quicker so we want to go back to dead reckoning a lot quicker and this is a video of what you might get afterwards so I mean it's still not perfect and it's really hard to show this in a video but what you notice there is the car didn't go shooting all the way down the street he kind of got pushed out of the way a little bit but that was it so this was a much better result now one interesting side effect that arises is because we now we have now a short period where we fully in local physics we have no guarantees that for that period of time the collisions going to play out the same on both tiers for example if your two cars crash into each other and on one machine it's kind of pushed this way and on the other machine it's pushed that way then when you blend back to dead reckoning you cannot have

this weeds you're gonna have this weird sliding kind of effect which is very jarring so we we want to avoid that and there's no there's no magic way of doing that there there's no silver bullet but what we can do to try and help this a little bit is before the collisions about to start if our vehicles were theoretically closer to their master positions then the collision is more likely to play out the same on both machines which should reduce those kinds of issues how can we do that what we ended up doing is putting in an algorithm that predicted that there was a collision that was imminent and increased the extrapolation in those cases the the theory behind that is if you're about to crash into something you're very unlikely to steer out of the way so for AI controlled vehicles we can guarantee that because we we have control over that but even for player vehicles there's only a short time

window so it's very unlikely that they're going to avoid the collision completely and so by extrapolating a bit more we bring things a little bit closer together and it makes the problems just a little bit less likely and every little bit helps and actually we already had an algorithm for predicting collisions from our AI systems so we basically hooked that up to the to the dead reckoning logic and it gave us it gave us a heuristic about how likely you are to collide with something and we use the to modify the time offset so basically if you're likely to crash into something we kind of reduced the time offset which basically causes the vehicle to be extrapolated more and what I've just described there this is more or less what we ship with wash dogs too but another story is a lot of many problems that are still outstanding I'm going to cover some of them today but there's many others I'll talk about collisions with static geometry differences in time offsets and what I'm dubbing the uncanny

valley so when you're if you have a car that's kind of crashed into something and you're actually meant to be over here it's not too bad because you can sort of push this car out of the way and get to it you meant to be but if you're colliding with static geometry like a brick wall well the brick wall is not going to give way so you're kind of stuck and worse than that is trees because trees in a game and not destructible and they're tall and skinny so it's actually easier to end up on the wrong side of the tree and then you get things that look like this so this is exactly rated for effect you're not actually going to see this in the game unless you're really really unlucky but it kind of gives you an idea of what happens when things go wrong and there are sort of ways to improve that one of the possibilities is to just stay out of the position maybe if you're on the wrong side of the tree maybe it's not so

bad you can get away with that in some cases the other one that we could try it's kind of soft body physics so maybe just disable the collision on the tree and slide your way through the tree or there for a little bit of penetration something like that and of course with the dead reckoning there's always the fallback scenario of just teleporting to where you're going to go that's all something that you have to do at some point but really the goal is to reduce the jittering effects because that's what the player is going to notice generally in watchdogs 2 what we ended up doing is more the first option kind of leaving cars a little bit out of position if we detect this you're colliding with too many things and you're not getting to where you're more beware would just let it sit there and kind of hope for the best the other interesting problem is that I've talked about what we do with time offsets for vehicles but that doesn't apply for pedestrians pedestrians much prefer to be interpolated and that's

because they don't have to worry about missed collisions or any of that they if you and they travel a lot slower so using interpolation gives you much better looking trajectories so pedestrians and generally it's not much of an issue because if your player is on foot you're interacting with other players characters on foot and your time offsets they're pretty similar and then if your players in the car you're interacting with other characters in cars and again your time offsets are pretty similar where all of these Falls falls apart is when the two intersect and then you get things like this where one the pedestrians just been missed and on the other machine he's been run over and he's flying through the air and rag dolling now this is important because keep in mind the goal of bouncy mode is to take down another player and running someone over with your car is a really good way of taking someone down and so then you get these cases where you know

I think I killed you know you didn't yes I did blah blah blah which is very frustrating and I think the way we can improve this is the same collision prediction algorithm that I talked about could be applied for armed cars versus pedestrians where if you're about to run over someone we extrapolate both a bit more and we we get a bit closer on each end the difference is that pedestrians are much more maneuverable so they could jump out of the way at the last minute so it doesn't fully help and the other thing is we do have a similar issue for breaker balls but there's no real gameplay impact if one player drives through a bus stop and destroys it but it didn't happen on the other machine it's not a big deal right it's just debris that doesn't really interfere with anything the other interesting thing I want to talk about is one of something that I've dubbed the uncanny valley so with everything we've done so far our dead reckon tragic they were looking very good right our

trajectories were matching up very closely to the master snapshots the percentage of error was very low but actually playing the game it still didn't feel quite right you could still sort of tell that you were looking at the replicated car rather than a master and there's lots of little things that really add up so for example minor weight shifts kind of get lost in replication the other one is that cars actually don't rotate around their center of mass so dead reckoning algorithms usually deal with just a point with angular velocity around it and we map that to the car center of mass but actually it's a lot more complex than that and then there's the other issue with that I mentioned earlier with the sensitivity to even slightly inconsistent velocities and that became noticeable as well one of the things we did do here was apply a bunch of post-process moving to our dead raconteur check Therese just to at least even out smooth out those inconsistent

velocities what's a bit awkward there is that post-process smoothing kinda has to coexist with projective velocity Blandings so that reckoning is meant to give you a nice smooth trajectory but in practice it didn't so we put this thing on top of it which kind of canceled out the results a little bit so felt awkward and dirty but hey the results look good so whatever moving on there's a few areas I'd like to research a lot more in the future number one I'm very interested in machine learning kind of things because I think that reckoning is very applicable to machine learning it's kind of this thing where we're gonna have an error we can compare the result of algorithm to where it should have been and make it adapt itself to reduce that percentage of error and basically the holy grail for me is all the stuff I talked about when I had to do this manual tuning of variables and really play the game a lot I don't want to do that I want a robot to do that for me

and the other one that interests me is smoothing algorithms what we did for the post-process smoothing was very simplistic I'm specifically interested in Kalman filters because I think they bring many others concepts together they're a lot harder to deal with and put in place and tune but I think there's something there I want to try and so finally if you remember anything from this talk number one if you're working on that reckoning debug your trajectories get your testers to record everything to turn on all of the debug rendering and all of your debugging first and when you get a bug about a desync you get everything that's led up to that distinct so you can try and figure it out and finally for me I found that even though we're dealing with very mathematical algorithms and all these equations there's still a lot of art to the science we still end up tuning variables to make something feel good which is completely opposite to to

all my scientific instincts anyway that's it for me I've got time for maybe one question or you can catch me in the wrap-up lunch afterwards and I'm talking at the Ubisoft lounge I've got a whole bunch of extra problems to talk about if you're interested in that that I didn't get a chance to cover today thanks everyone [Applause] one question guy yes so you guys were talking about how authorities distributed between different clients I imagine that as one client goes away you kind of have to transfer Authority and usually that introduces kind of like a time hop yeah or something where you guys able to do anything about that er we we did a bit yes we is a bit especially with cars travelling in a straight line when you switch over it's exactly that it's going backwards and basically what we did there was kind of slowed it down so we know we've transferred Authority we know it's driving in a straight line so

instead of going backwards we just slowed down a bit to kind of let it catch up again and do you guys clamp the extrapolation along a plane so that if some if car is like bouncing up and down you don't over extrapolate like up or yeah we we had do I mean yes that was an issue for sure some of that stuff part of the solution there is to let physics simulate the the z-axis basically so don't extrapolate upwards if you're kind of close to the ground you let physics kind of keep you close right but there's where this goes wrong if you're jumping over you know jumping over a hill or whatever which we do because there's a lot of hills in our game then you do let dead reckoning kind of kick in and predict the vertical part of it and that makes sense unless someone else has a different question I have one more so usually like vehicle replication in games like Halo and other places use the information about that hey this is a car so we know we can limit interactions in

a certain way but it seems like you guys were generally replicating as if it was a generic physics object so what do you think about using some of these methods on replicating generic physics objects and not specifically just cars and multiplayer scenarios yeah I mean you you're right a lot of it was treating it as a general physics object we did have a lot of sort of car specific awareness the example that I'm thinking of now is knowing that you're a bike versus a car for example where we we put different clamps on certain things and adjust the numbers differently is that makes sense does that answer your question yeah I figured you guys like the collision prediction also yeah all that stuff does change right although it's it is rigid bodies it they still a bit more than that but the general basics sounded like you could easily apply it just general physics for sure yes yes thank you thanks everyone
