Tree's Company: Systemic AI Design in Just Cause 3

[Music] all right without further Ado hello everybody I'm Robert Meyer I'm a game designer focusing on AI at Avalanche Studios welcome to Tre company systemic AI design in Just Cause 3 to just quickly introduce myself I attended NYU New York University where I studied film but also dabbled in what was then the infancy of the NYU game center after that I worked at a couple of smaller and indie game studios around New York for a while and for the last three or so years I've been an AI designer at Avalanche Studios and of course this talk will mostly focus on my time as an AI designer on Just Cause 3 so what is AI in Just Cause 3 well just cause 3 is a chaotic over-the-top open world action game where the player has incredibly powerful traversal and combat mechanics there are destructible environments loads of dynamic objects and tons of ways for the player to mess around with AI the player can hijack AI

Vehicles shoot AI out of their parachutes the player can use their grappling hook to tether a character to their Jet and then fly them halfway across the world basically there are an extremely high amount of unpredictable things that can happen to or near the AI at any given time so how did AI process everything around them all this information and make any sort of decisions well we use Behavior trees which of course is not that uncommon in AI Design This is what our beh paper trees looked like for our combatants in Just Cause 3 each agent runs one of these trees sort of as their brain for now just think of the leafes at the bottom as basically sub trees different states that the AI can be in that sort of exist in a dynamic prioritized list inside each of these sub trees if you were to expand it you know double click it go into it it would reveal much much more Behavior tree script that controls all the actual decision making and processes that this state performs but for now we're just going to look at

this higher level abstracted view now in addition to behavior trees agents in Just Cause 3 also utilize various utility functions for the purpose of computing things like ideal positions to move to or which which eligible targets to focus on a utility function is a function that ranks a bunch of different options according to their utility to an individual so here this agent is ranking each position you see a sphere at based on a variety of things like proximity to the Target line of sight to the Target distance from other allies Etc The Greener positions are the ones with a higher utility score and so those are the positions that the enemy character you see is going to prefer to stay around note that this utility function evaluation does not actually take place inside the behavior tree itself but rather encode outside of it the behavior tree simply requests give me a good combat position to move to and then utility function does its thing and Returns the position to the AI so in a sense you can think of the AI in Just Cause 3 as being composed primarily of Behavior trees and these utility

functions now the problem I'm mostly going to talk about today stems from a few things firstly our Behavior trees are very bottom up each individual is making their own decisions we have very few coordinators or managers of any type it's a very individualistic system originally this was built for the robust and emergent systemic behaviors that would flourish in the open world but not for any sort of scripted content and the behavior trees are pretty complex they're complex enough that content designers are not going to be able to open them and look inside and modify them or understand what's going on but of course we're still an open world game with story missions set pieces occasionally we need the AI to do specific predetermined things like waiting for Rico the main character to use their grappling hook retract ability to open a gate in this scene Rico the player can be seen in a military station with his ally Mario right after our fight is finished this being a very early mission we re en Force the power of the

grappling hook by asking the player to use it to open a gate so a rescue vehicle can come in and pick up Mario of course Mario's Behavior here feels very scripted and instructed he's waiting for the gate to open playing a special animation that points at it and once the gate opens he then scrambles to get into the vehicle so the goal of then is of course to create a technical design for our AI an interface that allows the AI to still be built on these systemic Behavior trees and utility functions while also still empowering content designers to create whatever scripted content they desire when I talk about empowering content designers I'm specifically talking about Mission designers to create whatever objective sequences they can imagine World designers to create unique open moments and open World locations and encounter designers to create these sort of bite-sized narrative bits that we have procedurally generate in our world and I think to understand some of the solutions that I'm about to talk through it helps to understand the division of labor of designers at Avalanche Studios New York the AI designers like me we're the ones

that do all the scripting of the actual Behavior trees themselves we work with AI programmers who help us build all the lower level building blocks but we're the ones who actually put the behavior trees together we also tune all the utility functions we say it's really important to stand where you have line of sight to the Target in fact it's five times more important to stand there than it is to stand this amount of distance away from an ally for example we create a variety of AI templates and packages for other designers to use really anything technical design Rel to the AI we do whereas the content designers as we call it are people who might be level designers or Mission designers or World designers they're the ones actually placing the characters in the world and importantly they can fill out the exposed arguments and parameters on any of these character spawners another way to think about this might be by looking at the tools we use this is our proprietary Behavior tree scripting tool and so this is what me as an AI designer this is what I'm looking at most of my day now for now just note that if I select the root view the very top of

this Behavior tree that gives me the ability to expose certain parameters certain arguments variables that the content designer can then fill out when they're placing this AI using this Behavior tree in the world now the content designer they work in our level editor our engine and so here they've placed an enemy character using a character rule or which is a thing that just spawns a character and when they select that character rule they'll be able to see those same arguments those same parameters that I as an AI designer set to be exposed from the behavior tree so this is basically what we have to work with to solve this problem the AI designer can write the behavior tree set what arguments are exposed the content designer has access to those arguments or parameters whenever they spawn a character so the content designer can fill them out and then whatever they fill them out with that's data that can be read and used inside the behavior tree now the last thing I want to cover before I get into the core Solutions and methods is that I'd like to help you

form a mental model of how our Behavior trees actually work a lot of people do it a little bit differently so pictured here is how our Behavior tree flows on the first frame of a combatant's life basically this GIF is a debug view of me kind of just stepping over all these sub trees you can see that each node can return a success working or fail state every frame so that's what that check mark gear icon or X icon represents as you see me step over each sub tree so starting at the top right on spawn you see this yellow circle that's what we call a sequence it will run all the nodes under it from left to right so first it runs this init sub tree which just initializes a bunch of data like the AI looks at what weapon they're spawned with and so they kind of set up some things based on that but that only ever needs to run once then it moves over to this yellow Square called a parallel the parallel runs all nodes under it every frame so first it runs an update sub tree which looks at a bunch of different data in the world and sets up a bunch of internal data probably the most important thing that our update sub

tree does is it selects what combat Target this AI should focus on then the parallel moves over to this green circle called a selector now don't worry about remembering any of this vocabulary it's not that important just kind of trying try to grock the general flow of things so the selector first says do I have any special behavior to run on spawn an intro behavior in this case I don't so I'm going to move along to this green square at the bottom called the dynamic selector the dynamic selector checks every node under it all the way from left to right every frame it's sort of like a prioritized if else List It checks all these different sub trees to First find the one that's valid and once it finds a valid one it's happy and that's where it runs if we were look at the next frame in this combatant's life the second frame after they've spawned we see that they no longer need to check their init subtree or if they have a special ons spawn Behavior at this point they're just checking their update sub tree and the main Dynamic selector of possible behaviors below and if we look at a further frame where this AI is actually in combat we'll see once again they're only

checking their update sub tree and the dynamic selector but at this point the dynamic selector only needs to advance as far as the combat sub tree because the character is actively in combat this combat sub tree returns working and so the search and relax sub trees don't need to be checked at all at this point those trees are completely irrelevant because this AI is occupied in a higher priority Behavior so you can see in this way the dynamic selector kind of controls implicit conditions and transitions between these substates below so jumping back to our abstracted view looking at what we have how can we use this as AI designers to solve the problem we talked about earlier how can we keep things systemic while still allowing content designers to create their own custom content well the very first thing we tried were these built-in on spawn behaviors basically maybe you could give a character a point and if you gave them this point they would know they wanted to move there on spawn so you give them a point they run there on spawn you give them a path a spline they move along this path on spawn but as soon as we

baked in those options content designers just started asking for more right we immediately were faced with argument creep if it's a helicopter do we want them to land at the point or hover above it at what speed should they move along the path do I want them to stop at the point or move through it it's hard to really build in any of these custom ons spawn behaviors with only one or two simple arguments in fact this really didn't scale well at all pictured here is just an in development look at a portion of a subtree for a drive too style micro Behavior as well as a screenshot for all the exposed arguments different parameters a Content designer might want to set up for how a character could go about driving to a point we've got uh should drive around traffic in there should I reverse to the point should I wait at the point how fast do I drive to the point there's like literally 50 parameters about driving to a point in there and so obviously I couldn't bake this into the main Behavior tree because 99% of the time of course our characters are not driving to a point on spawn and content designers cannot just sort through all

this so obviously the natural intuition was that any sort of these micro on spawn behaviors they need to be split out of the main Behavior tree and made into these modular pieces somehow pieces that could be nicely compartmentalized this led us to the concept of external Behavior trees and this concept is twofold firstly content designers who are working in the level editor can add a new type of object called an external tree object and this object simply holds another self-contained Behavior tree so whereas this character rule object you see here spawns a character and provides it its default Behavior tree this external tree object doesn't do anything it just holds another external Behavior tree but the content designer can specify okay which behavior tree is this external tree object going to hold let's say for example the content designer selected a take cover in area micr Behavior to live on this tree well now as the AI designer I can set up the main Behavior tree to expect one of these external tree

objects as one of the arguments to be fed into it so now the content designer can pass in this external tree as a parameter to the main character's Behavior tree and then this external tree could basically be run inside that main Behavior tree as if it was another sub tree within it so this enabled content designers to basically feed in modular smaller micr Behavior trees as arguments into the main big Behavior tree so now we could have things like drive to point or take cover and area as compartmentalized objects that would live on their own and then be fed into the main character's Behavior tree and let me show you exactly what that looked like so here a Content designer has added an external tree Behavior tree object to their scene and the first thing they have to do with an external Behavior tree object is pick what Behavior tree it's going to use so down here they've selected a helicopter fly too micro Behavior as soon as they select the helicopter fly to point micro behavior that that's when this BTR args

Behavior tree arguments section fills out and so all these parameters are just about how a helicopter should fly to the point so this content design content designer has fed in the point they want the helicopter to fly to they've checked a box indicating they want the helicopter to land at the point and they filled out the speed they want the helicopter to fly they're at then they take that external Behavior tree object and feed it into the thing that actually spawns the helicopter pilot and the helicopter pilot can now run that helicopter fly to point Behavior with all those parameters baked into it and we didn't have to add all those helicopter fly to point arguments to the main Behavior tree arguments so now we have the concept of these external tree objects allowing us to create these modular micr behaviors and feed them into the main tree so while they're provided into the tree view via the main Behavior tree arguments the main tree itself still has to choose where and how to run these past in sub trees of course just doing things on spawn which is what we've talked about so far is the most obvious use case but this isn't enough for cont designers to do everything they want

sometimes you want an agent to be purely systemic on spawn but then use an external micro Behavior at some future time under uncertain conditions if these different places or conditions for triggering micro behaviors got too numerous though we'd once again end up with a mess of arguments and an unintuitive interface ultimately we realized we could do well with just three different points of ejection as I called them these external behaviors into the main tree could only be fed in at these three points but with with just these insertion points we found we could achieve almost every desired custom behavior in the game and we did it by only adding a very small amount of micro of arguments to the main Behavior tree here's a look at kind of where those three different insertion points actually fed in to the main Behavior tree so you can see we had the intro Behavior an interrupt behavior and an idol behavior and here is kind of how the content designer saw those arguments they had options for the idol Behavior interrupt behavior and in behavior and an object they could pass in for each of those

now I think it's worth taking the time to understand why these points of injection were chosen and what they're actually good for and then why we didn't add any ones Beyond these so let's take a look intro behaviors were the first and most classic use case of course on spawn do X very simple here I spawn a rebel and I give him an intro Behavior to just run to the right side of the screen doesn't need much further explanation than that now there is still a few things to note about this implementation note that the Run external tree node for intro Behavior still takes place after the init and update subt trees have had their chance to run this is because the init and update subt trees handle a lot of complex important tasks like Target selection and it's good for the micro behaviors that might be run in the intro Behavior to be able to rely on the fact that the main Behavior tree has already taken care of these things if it weren't for that we'd have to reinitialize a bunch of stuff in all the micro behaviors themselves and of course we want to keep these micr behaviors as lean and modular as possible so we run them after that main AI has

had the chance to update a bunch of internal facts about the world and themselves also note that the intro behavior is under this green circle which is a selector for now you can just know that all this does is ensure that the intro behavior only gets attempted to run once on spawn and then it never needs to get checked again after that now there was one extra parameter that came with intro behaviors which is a Bo or flag I simply called always finish intro behavior and this turned out to be incredibly useful basically each agent in their update has the ability to kick themselves out of their own intro Behavior based on various charistics that are running in parallel to determine if something more important has presented itself if you set this always finished intro Behavior flag to true then it basically turns those heuristics off so for example a world designer places an enemy helicopter on the other side of a mountain for some sort of Epic entrance she gives a helicopter pilot a special intro Behavior to fly a specific path around the mountain that she thinks will look really cool now our player has

a grappling hook and a wing suit so let's just say they get to the top of the mountain 1 second after the helicopter spawns and now that epic path that she outlined doesn't look that smart anymore because it takes the helicopter right past where the player is already standing well with the always finished intro Behavior flag unchecked the enemy Pilot's heuristics will detect hey my I know I'm supposed to fly this path but my target is right here in front of me so forget the path I'm just going to fight the target where I am whereas if you check the box if you don't check the box then the AI will uh yeah if you don't check the box they'll automatically exit or if you do check the box they'll be enforced to finish the whole path no matter what now you might think it's always smarter to not check the box let the AI systemically exit if they think something more important has happened but if you're creating a mission where this is an escape helicopter that's trying to escape with stolen data or pick up a critically wounded Ally then it would make perfect sense to check this box and make sure that this AI prioritizes completing its path the next up injection point I want to talk about is the interrupt Behavior which also came with a trigger event an

interrupt behavior is sort of like an intro Behavior except the AI doesn't attempt to run it on spawn but rather listens for an event in their update tree every frame and if this event is received that's when the AI will automatically make this interrupt Behavior their topmost priority so here we have a rebel that's fighting an enemy soldier and about a second or two into the fighting I send an event under the hood to the rebel telling them stop what you're doing get up and run to the square on the right side of the screen for whatever reason obviously this is a too micro and suboptimal use case for interrupt behaviors but it showcases what I mean that they can take over the AI at any point what's great about interrupt behaviors is that content designers Define the trigger event themselves and so it enables them to do it on a case-by Case basis and they can be fully responsible for it meaning if a Content designer has a timer that they want to wait 30 seconds before triggering an event or they have a counter that's counting a certain amount of things anything the content designer has that can send events they can use to trigger and interrupt Behavior as you'll see later this slot turns out

to be particularly useful for communicating with the mission objective system and of course when the interrupt behavior is done or if it's invalid or it can't run the AI resumes its main Dynamic selector and is as functional as any other character in the game lastly is the idle Behavior if provided this simply just runs with a higher priority than the systemic normal relax Behavior so a normal systemic relax Behavior might have a character roaming some sidewalks or just hanging out but you can author them a spefic specific Idol Behavior using this so here I have a rebel that's fighting an enemy soldier when they're done fighting the soldier instead of doing their normal relax Behavior I just sell I tell them to walk over to this arrow on the right side of the screen and stand guard there so I've just authored a manual idle behavior for this Rebel to do instead of their normal default systemic relax Behavior which would probably have them wander off screen somewhere as you might expect idle behaviors are great for staging patrolling characters around a military base or around a town and you might ask why is the idle behavior before the

relaxed behavior and not somehow overriding it well this is kind of an important theme imagine you have an enemy that's patrolling a military base in a Jeep and they have a special idol Behavior to drive a patrolling Jeep around a military base that's their external Idol Behavior now the player comes in they hijack the Jeep they throw the character out the player drives the Jeep away and then destroys the Jeep okay this character is going to go into combat for a while trying to shoot at the player while they drive away then they're going to go into search but after a while they're going to go back to their external Idol behavior and they're say okay time to drive my Jeep around the base again of course their Jeep no longer exists because the player blew it up but because we didn't override the default relax Behavior this character can now simply fall back to that normal relax behavior and be as functional as any other AI so they'll probably just find a good systemic spot to stand guard near the base and they'll look perfectly fine there so why didn't we just provide options to run these micro behaviors everywhere if iner stting things is so safe and the behavior tree is so robust

why didn't I just provide all the options to the content designers well this is in order to preserve the integrity and consistency of the AI the decision of whether to enter combat or search for example is very involved and meticulously crafted it's very important to keep transitions between combat and search consistent and clear so the player can learn them and begin to anticipate and predict them furthermore it's important that the content designer can't accidentally override places where the AI is about to play a special animation or a key reaction because if they could they would accidentally compromise the visual Integrity of the AI as well in many ways this is the same reason why we don't expose that much tuning data as Behavior tree arguments either this is all all the tuning data is mostly decided internally by the AI designers instead we only expose the few things you see on the right there for example one thing that content designers often requested was an overridden range they could give an enemy so let's say they wanted to put a sniper rifle on this enemy using enemy on the top of

this one Tower because the mission takes the player right by this Tower and it's going to be awesome if an enemy can use a sniper to shoot at them from the tower but a sniper's default range is 120 M and this Tower is 140 M High can't I just give them a you know ability to override it just this once well sadly I can't because I want every sniper enemy in the game to be perfectly consistent and have the same range so once again the player can learn this range and learn to anticipate it and play around it so yeah we designed these points of injection to maximize Simplicity flexible control robustness behavioral consistency and visual Integrity now part of the reason working with this micro behaviors were so easy and I could keep them so lean is because we used a header file system for our Behavior trees as well just like you might have a helper function in header file and code we had header files for our Behavior trees as well that could hold very frequently used AI sub trees so here we have a run and shoot sub tree which handles all the inner workings for

how a character fights as they run to a point and we put that in a header file we include that header file in our main Behavior tree so that in during standard systemic combat the character can use that function and run to a position determined by their utility function for a good place to stand in combat we can also include that header file in our micro behavior for running to an area aoo stands for area of operations the only difference here the same subtree gets used but the destination is an area provided by the content designer instead of one internally figured out by the AI of course the benefit of reusing these sub trees everywhere is that as I improve the sub tree Once all the behavior trees using it get that same Improvement now we had this General interface and I could focus on building this library of modular micr behaviors that felt the most useful or most often requested each of these micr behaviors could of course then have their own particular arguments which would be nicely compartmentalized and I could focus on making sure that these were dependable and reliable but the system still kind of had a pretty pretty big problem what if

a designer wanted to create a mission where Mario the character in Just Cause 3 the Ally character in the blue shirt has to First Take Cover then fight with the player for a while then wait for the player to kind of open the gate so they can escape and then get into the systemic vehicle that comes in and then fight from within the vehicle once it comes in right that's a pretty beefy micro behavior and this is again is not going to emerge naturally from our Behavior tree system at first I had no choice but to create these giant Mission specific intro behaviors and this would of course take a lot of my time to write and debug and it turned me into a bottleneck for the mission designers when they wanted to change how things in their mission worked obviously this was not a scalable solution there needed to be a way for Mission designers to craft their own sequences without ever needing to touch Behavior tree script well let's take a look at what the mission designer really needed to do here they roughly want Mario to perform this sequence of behaviors well if we abstract a away all the mission specific details at a glance

we have an intuition that we could maybe puzzle this out with the micro behaviors and the system we have now maybe take cover an area can be Mario's intro Behavior then we kind of release him into systemic combat for a while and then we trigger these other three sequence of micr behaviors as his interrupt behavior when it's time for Mario to wait for the gate to be opened but wait a minute I know what you're saying sequence of microbehaviors how do we do that we only have one slot for an interrupt behavior on our Behavior tree arguments well so we enter The Meta utility tree The Meta utility tree is basically just an intermediary tree that can package a bunch of smaller micro behaviors into a single Behavior tree that can then be fed into one of the main Behavior trees arguments these could be as simple as a sequence that just runs three other trees one after the other after the other so this is what it looked like to the content designer they had their character spawner for Mario and Mario had two things pass into him an interrupt Behavior which was a sequence

of micro behaviors and an intro Behavior which is just a take cover in area external tree the sequence of behaviors itself had three external tree arguments and those are where the three external tree objects are fed into that just quickly want to touch on these intermediary trees you don't need a lot of them we only needed three one which was just a sequence of trees as we've talked about so this was useful when you had a character that wanted to do something like enter a car then drive to a point then exit the car a selector of behaviors is more like or statements this is like try tree a and only if that fails try tree B this is pretty useful in a just cause game where you might want to have a character say try to drive this car to that point over there but if for some reason that car gets destroyed as you're moving to it or you're driving it then get out and run to the point instead lastly is an external Behavior with autocomplete we don't really need to dig into that one but basically it enabled us to autocomplete or Auto abort out of a bigger sequence or selector of behaviors whenever we needed to with just a single event designers could

stitch together or Nest these meta utility trees as much as they want you could have a sequence of sequences of behaviors you could have a selector of sequences with an autocomplete event you can infinitely Nest these as much as you want well probably not infinitely but pretty close um and the system was very intuitive and flexible enough for Content designers to use it scaled really well and we had basically a working way now where content designers could sort of script their own AI you'll notice that every layer at play here is a behavior tree the micro behaviors what they're organized into and the main tree that they're inserted into and this is actually beneficial for us for a few reasons the first is that the AI designers can do all of this we can quickly create different metat trees micr behaviors and work those into the main tree without requiring any AI programmer time since each layer is a behavior tree they all fit together seamlessly in runtime and that means that we can debug them with our Behavior tree debugger which is really good meaning that I could sit down with the mission designer and debug any layer of this whenever I wanted to lastly because these all use the same AI

header files we talked about earlier it was very easy to share subt trees and share Behavior tree script across these different layers and finally to quote Damian Isa from his famous Halo 2 AI uh presentation only by placing the stimulus Behavior into the tree itself can we be assured that all the higher level and higher priority behaviors have had their say before the stimulus Behavior can consider taking action by having this allb Behavior tree we were able to keep it very robust as well and yeah this three tree type interface this of course is the tit trees company that I know you've all been waiting for so there you go but speaking of trees we're not out of the woods yet we still had a pretty big problem with the mission system interface uh pictur the mission sequence from the Mario example earlier here's a mapping of the player objectives in the top row of the mission and Mario's behaviors on the bottom row imagine that each one of these player objectives on the top is sort of a checkpoint for that mission so if the player dies while

opening the gate somehow then they'll respawn at opening the gate they won't have to do the defeat enemies checkpoint again but what happens if the player fails during the escort objective Mario's AI has been fed a sequence of behaviors and will want to restart this sequence from the start but the mission will have checkpointed to the point where the gate is already opened and so now our Ai and our mission system would be out of sync initially Mission designers started to make alternate copies of spawners with different behaviors cut off and to accommodate every possible Mission checkpoint but this was of course Very unwieldy for Mission designers to handle especially as they iterated on their checkpoint system the solution of course was to assign trees to the mission objectives themselves not to the AI directly in these cases so for example we would assign each Mission objective object had what we called a character controller object for all the key characters so each Mission objective in this Mission has a Mario character controller we could feed the behavior treat that we wanted Mario to run during that objective to that objective's character

controller and that would automatically be passed to Mario as the mission progressed so if at objective three we know we want Mario to run a sequence where he animates at the gate and then enters the car we can pass that sequence just into objective three and whether you're respawning restarting the mission from objective three or you're starting it from objective one Mario will get this Behavior tree right on time and it'll work perfectly so by assigning the AI on a per character per Mission objective level rather than on the per character for the whole mission level we successfully synced this system with our mission system now all this functionality also benefited a lot of systems beyond the mission system as well in this random encounter you can see that the AI were staged into custom intro behaviors and animations setting up a firing squad type scenario but once Disturbed they all break out into their emergent systemic Behavior and the results are all the sort of emergent chaos You' you'd expect the rebels start investigating some enemy corpses other enemies happen to drive by and a fight

ensues and because we were able to have this sort of intro behavior that can release into normal systemic AI there was no stress that any of this was going to work fine the design also allowed world and location designers to set up custom Patrol paths here we see custom Idol behaviors at work with some patrolling enemies Rico and a rebel drive up they disturb the enemies out of their patrol they go into combat Ric runs away eventually those enemies go back to being relaxed and the uh enemies who are lucky enough to still be alive they resume their patrol as intended now is the time the presentation where I want to take a step away from talking about Behavior trees there were other ways that we went about creating systemic AI in our game and other ways where we needed to kind of control that AI but we used methods that had nothing to do with behavior trees the first thing I want to talk about is that often you need it to get a character on foot in combat from point A to point B but points and splines are fragile stuff that I want to get away from stuff in a just cause game moves

around a lot a lot of things get in the way paths that initially seemed Smart Start to look dumb I mean it's just caused the player can basically debug spawn a tank wherever they want so the better solution is to utilize our pre-existing concept of areas of operations or aoos an area essentially crops the positions that a character wants to consider moving to and so it confines the space where the next reposition here you can kind of see some of that repositioning in action this is a mission where the player is along with two friendly Ai anakah and Tio and throughout the mission we kind of Advance through this Warehouse together now rather than me telling anaka and Tio exactly where to move or how to move I simply update their area of operations in the back of their head the area of operations guides them to where they want to consider repositioning to the next time they want to reposition and anakah and Tio make all the decisions about exactly how to fight where to stand where to take cover themselves just within this bounded area that the content designer can provide them so here it was anak's decision to run up

to that cover and take cover there all they have to do is just stay in this general area here's kind of a debug screenshot of how an area of operations works it basically crops the utility map that they use for positioning we normally would make one this small in general again you want to have these areas be as big as possible because you never know what could be happening and the bigger you make it the more flexible and robust it is but of course the content needs will dictate the size and remember a normal utility map as we saw earlier is pretty huge a character considers about 150 square meter area of possible positions and so when you crop the AO you're cutting this down pretty drastically one important theme to this though is that we still let the AI make their own systemic decisions in this case about exactly where to stand or where to take cover we're just constraining their decision space but within as generous a bounds as possible and we'll see that come up again another subtler but really effective Improvement came when we stopped telling AI exactly when to do things for example exactly when to move

to the next area just because we assign them a new area doesn't mean we force them to move there right away instead we wait for the AI to tell us that they want to reposition characters in combat in Just Cause 3 want to reposition fairly often so it was good enough to update the area they want to be in and then let them finish what they were doing before they decide to reposition this helps avoid cutting off animations or firing patterns too awkwardly and it also gives a nice staggering effect you can notice here the anak decides to get up and start running but the other character Tio he's kind of already running by at this point so you can see that kind of Staggering effect in action again this happens because we just update information in the back of their head instead of telling them exactly what to do or exactly when to do it a different sort of example of affecting how AI act in a space while still leaving decisions up to the individual is this concept of restricted areas if a Content designer wants an area to be aggressively guarded by enemy AI where they will warn the player and eventually open fire if the player stays

there they can author one of these invisible restricted areas importantly the content designer does not need to assign certain characters to be the guards of this area all they have to do is place the restricted area why is this better that instead when the player enters a restricted area all near nearby AI get alerted to it well this is because we have no way of knowing exactly which enemies will be where at any given time in a just cause game in the first example in this uh video here of course these AI are expected to be in this restricted area and so they warn the player properly when he enters but in the next clip AI just kind of happened to be nearby this restricted area and it would look really silly if they also didn't respond to the player entering this area luckily because we don't need to Stage particular guard AI we just have the restricted area alert all AI nearby this kind of takes care of itself so maybe you're starting to sense a theme and that theme I want to try and illustrate through my own attempt at a grandiose uh GDC quote on AI design

which is the more chaotic and unpredictable your game the more of an intelligence Edge the runtime AI will have over the designers I'll take a break so you can all take photos of this and I know you want to let it soak in post it to Twitter # GDC Etc okay now seeing as Just Cause 3 ranks very highly on the chaotic and unpredictability scale which is part of what makes it great this of course is a very important thing to respect for us but fair warning your level designers will not necessarily appreciate you constantly telling them how much smarter your AI is than they are so uh choose your words carefully maybe just tell them the AI will have more upto-date information that seems to go over okay but anyways following this principle it becomes clear why this kind of annotation for the AI in a game like Just Cause 3 is so useful by annotation I'm referring to the way that content designers can mark up a space in order to influence AI to use it in a certain

way the restricted area we looked at before is actually one kind of annotation a more traditional kind of annotation is cover points all these little green spheres you see here these are debug drawings of particular places where an AI can consider taking cover in battle and again they use a utility function to rank all the covers based on things like angle to the Target distance from other allies distance to the Target Etc they score each cover and they pick the cover with the highest score when they decide that they do want to cover another annotation example that's not combatant focused at all is what we called systemic context actions these are essentially animated looping behaviors that can be reserved occupied and engaged with by an AI for a time for example a weit at the bus stop systemic context action could be placed on a bus stop any eligible roaming civilian walking by can reserve that CA move to it enter it and will now Loop the special waiting for the bus animation all sorts of places could be marked up with a variety of these that would

enable AI to contextually interact with their environment and express various themes of the world through their animations and this is much more Dynamic and lifelike than simply staging AI who are always static and in place it's much nicer to see AI coming and going from these different types of behaviors also once again this emphasizes directing the AI by authoring a space with optional or suggested behaviors that the AI can then in real time decide whether to utilize or not it's better to give the AI an option to wait at the bus stop rather than force them to because this way the AI can easily opt not to if say there's a tank at the bus stop or a crazy fight is going on or there's a bunch of stuff on fire nearby all stuff that's more likely than not to be honest now when you're working with annotations often it makes sense to build some of these annotation objects into the base templates of things themselves right the entities or the prefabs for example that wait for bus systemic context action maybe we want to build that directly into the bus stop

object so that wherever we place a bus stop it comes with one of these wait for bus stop context actions maybe we want to build cover points into a concrete barrier so wherever World designers place these concrete barriers AI can automatically take cover there when this is done these annotation objects would automatically of course accompany all instances of these entities in the world and there's a lot of benefits of doing this one of the benefits is of course it just saves a lot of authoring time these things don't need to be manually placed it usually makes sense and it's very easy to perform Mass edits on these things out in the world if they're all on the entity level and the best part is sometimes it creates emergent unexpected and awesome moments in this screenshot we had decided earlier to build in cover points to any car wreck some Vehicles get destroyed In the Heat of battle and now all of a sudden Rebels are taking cover behind a vehicle wreck as they fight this enemy in the distance and it's just a completely Emergen scene that happened just because we built covero entities into car WX now there are some drawbacks to doing this the biggest is that if you build

these annotations into entities things might start to feel too syy if every instance of an entity or a prefab generates the same annotations it can start to feel repetitive and gamey if you see the same animation of a guy or a girl waiting for the bus at every bus stop in the game it's going to start to feel a lot less lifelike and a lot less interesting generally we kind of just went for a hybrid approach where we built some stuff into entities we tried to build a variety of things into the entities that it might randomly choose from but more importantly we still did a lot of it by hand and we strongly believed that having this hand touched flavor especially to the more important locations in the game really helped a lot in summary to wrap up the talk we created an interface that empowered content creators to safely yet powerfully script their own AI without ever having to open a behavior tree while making sure the core of the systemic brain was preserved we did this using modular micro behaviors on external trees that could be packaged with meta utility trees and inserted into intro interrupt or idle points we

successfully synced this with the mission systems checkpointing by having mission objectives provide the behaviors to be run during them and we influenced AI using more bottomup systemic and annotation based tools that could guide the AI but would still let them decide things on their own terms and this of course is much more accommodating to ajust cause level of unpredictability so thank you all for attending and listening you can find some info on here and I want to make sure to give special thanks to the people you see there who help me with feedback or gathering assets for the presentation thanks uh I'm not sure what time it is but uh any questions feel free to ask and if there's no questions that anybody want to ask oh there is great hi hi great talk um I just wondered if if you had thought about and discarded

using a planner for something similar to this as as opposed to behavior trees yeah the question is if we considered using a planner more than just individual Behavior trees um we've definitely thought about that and on further projects we're exploring it it really depends on the type of game and the type of problem that you want the planner to solve in our case for a just cause game you probably don't need that much tactical maneuvering to happen for the AI because that's not really what the game is about and so almost is better suited to have a bunch of individuals running around like trying to manage the chaos the best they can but there are a lot of valid cases where it would be nice to have a planner for example deciding which characters should kind of enter combat with the player and which should kind of keep their position and hold off that's something that a planner could have helped us a lot with in Just Cause 3 and maybe we'll explore in future games yeah uh so you mentioned the utility functions a number of times where do those live do those live in each AI or do they live in the objects that the AI runs into right so the question is where did the utility functions live so the utility

functions all live in just C++ code but each uh AI can run an action in their behavior tree that basically requests the outcome of that utility function so for example there's a node in the behavior tree called get combat position that talks to C++ code and runs the utility function there and then Returns the best position or the AI might run an action that says give me a a good cover nearby the co that action communicates with C++ code that calculates the best cover nearby and then returns them the entity handle of that best cover so the utility functions are calculated in code and the behavior tree can converse with that okay hi so just C3 is a open world game so probably so something like uh so micr Behavior tree is tged into some asset and load it into the so simultaneously or that kind of stuff can be available or sorry can you repeat the question uh so

can you load some asset with our other asset like animation or sound with uh micro Behavior tree so yeah it's the question that can you put Behavior trees on other assets like animations or sounds or objects or smart objects yeah yeah we're we didn't really do that that much in Just Cause 3 but we can do that you could for example potentially put a behavior Tree on a building and have it like kind of listen to the world and like play different lighting effects or dialogues BAS on if it detects like explosions or whatever and you could use a behavior tree for that we didn't end up investing in that too much but that is something that you can definitely do and that we want to try doing is using whether it's a behavior tree or some other type of script this type of scripting that can live on other animations or objects in the world okay thanks y cool and I'll be around in the hall afterwards if there are any other questions that people or want to come chat thanks
