Water Rendering in Far Cry 5

[Music] okay so my name is a branislav you jerk and a 3d team lead programmer from youths of Toronto and had the pleasure of working with a Christian on the Far Cry 5 yep hi guys I'm Christian Coto Charis I'm part of Fame DS developer Technology Group I work with developers to make sure that their games are running smooth on Radeon on PC awesome so just a little agenda what we'll cover today we did a little introduction but then we'll talk about the history of water and previous Parker games we'll talk about Montana as that's where far cry 5 is located we'll look at the engine tools and rendering goals and we'll actually look through a full render of frame of water and far cry 5 and then Christian will talk about how we optimized our compute shaders with 1/2 precision math and we'll close it off with problems how we actually debug these problems and the future so just to

get this started this is a screenshot of far cry 5 rendering wise there was the old Blin specular rendering model water was the same we had planar reflections I can see here so we moved on to Far Cry 3 Far Cry 3 was the first introduction of PBR and a far cry engine although water remained relatively non PBR they still looked quite good far cry 4 we did PBR version 2 also water starting to look quite nice although we were starting to struggle with waterfalls in our game and the reflections in the normal map it was China distort the image a little bit too much which we didn't like and then Far Cry primal is where we actually really started to consider redoing the water system as we were trying to hit the limits of what we wanted it to look like so this is a screenshot of our Chi 5 you can tell everything has gotten an overhaul including fully PBR water with

flow Maps reflections and refraction so before we get started how we actually render this our first approach is to look at some reference images of Montana we're far cry 5 is located we knew that we could technically do this with the old water shader but that's not what we wanted to do as when you go to Montana you'll see a lot of rivers that are really fast and there's no way you can get this kind of displacement from just a normal map then we get the rapids if we want to do rapids you're gonna struggle with flat water so we really need a system that will handle sloped water waterfalls surprisingly there are a lot of water waterfalls in Montana probably 50 or more and treating the previous Parker games we made all these manual and we had to deal with the connections between the river for example in the waterfall which was quite tedious and if we made any single change the terrain we'd have to go edit the

things we did before which was unacceptable Montana also has some exotic locations such as sulfur ponds at this point we already knew that a previous lighting model would not work so we wanted to tackle this so in terms of our game engine there's three sides that play together to get our awesome water system which is the engine side which deals with the data generation is streaming in all the textures and we have a very simple water crazed API we have an awesome tool which is artist-driven and procedural and the rendering I'll talk about this fully so from the engine side we had many functions to handle the water level before but once we started doing this I think I had about a 93 file change list which went through the entire engine and cleaned all of it up for it to be a single function that returned the water level and handled everything for you this deals with water quadtree for any water that is moving and all the baked water height maps that are streamed in such as lakes rivers and waterfalls and

one thing to note is we also support the ocean for things we'll see you soon flow in physics everything we do in the GPU we have to replicate on the CPU because we can have objects that are moving around in the world according to the flow map and last but not least it's the base material map we need to do underwater so we need to know exactly which material is where in the world so just for reference this is how this function looks like there's an engine level in the render a render thread function which returns you the water level and the get water flow directions and from an epi perspective our entire engine simply uses this and nothing more tools wise in the previous Far Cry games the Far Cry engine is a sector based engine which means we have 64 by 64 sectors in the world and if an artist wanted to place water they had to turn on the water per sector and if you want to get a lake you have to do this probably 20 30 times change the material

in each one and if you want to slow water you're kind of ha too lucky to have to tear from the terrain around the water surface to actually get this to work so for Far Cry Fire we went more of a procedural generation route and this is just a little video of how that works so an artist would simply placed a bunch of points on the terrain using our lake creation tool and then we could switch to the river tool which places a spline which allows us to modify the width and the depth of the spline and this actually modifies the terrain underneath it as well and then the artist simply clicks one button and he gets fully procedural water generated one thing to know what in this video is we're actually doing this in Houdini and this handles all the materials and textures underneath the water surface as well so you'll see here there's rocks moss and the dirt that connects to the rest of the terrain and we didn't have to do anything in terms of connecting the water bodies which was quite painful in the previous Parker games so this is kind of the bulk of the

work we did we wanted to experiment with a screen space distillation which is what's going to give us this awesome look per pixel material we're moving towards with each pixel containing data from the material buffers so we don't actually have to deal with reading things from world space and this allows us to do blending because now we have all the data per pixel and we can know what other materials are in this pixel we do everything to compute as much as we can - the depth test and rendering the depth out and we do floor maps with foam as previously in the parkour games we only had a scrolling UV texture so just a little bit of the things we achieved before we get into actual rendering algorithm this is a simple water plane that artists can just place can move up and down particles also interact with it fully this is a more exotic Lake

this is a wide river as you can see there's displacement at the bottom and it will fade out in the distance we have a nice LD transition between the height desolation and low distillation this is another example where we have a river that is modulated by its depth and its width which drives how the foam is generated in this specific location and phone will also follow around any rocks and the terrain started this tool we also have procedural waterfalls artists simply place a spline click that button and just play it again and they also get waterfalls with flow maps we talked about some exotic locations but this is one example of where there's a helicopter that's affecting the sulfur pond below it and you can see the helicopter spawning displacement particles on top of it which are disturbing the water surface and creating foam so on top of having to

support all of this in the engine we also have to support all these features in the world map as you will see once you play 405 and this is our Far Cry arcade in-game editor where we also support ocean rendering not only do we do all these things we also support a nice underwater effect and I really like this light because it really shows you how much water there is in our world this actually brings us to one point where we not only need to render water close to the player we actually need to do it in the distance as well and this has to go really fast on a GPU ok so we're going to talk about how we do all of this in screen space and how we achieve a screen space tessellation the general idea behind this algorithm is that an artist gives us a very low resolution mesh and they also give us a material which will guide how we actually tessellate and from this we will create a screen space test lay the mesh so from the artist point of view

all they give us is simple parameters such as amplitude roughness each scale and we bake this out into a structure buffer one problem with DirectX 11 is that we can't actually deal with textures if we're going towards a screen space approach so instead artists are simply using indices into texture arrays for any texture they want per pixel and that also gets baked out into a texture index in a structure buffer so if you can imagine when you're running around in an open world game there's materials constantly being loaded so what we actually do is have one fairly large structure buffer which runs a computer and takes the data out of that material into a structure buffer and then from this point on we handle everything using just an index per pixel and this at this point we actually link everything using per pixel so this is the actual overall

rendering algorithm we'll go through all the stages and how we actually do this so don't worry about this large graph so the first stage is always visibility how do you actually handle rendering water close by and in the distance for water near the player we actually use a conditional rendering approach with a clusion queries and we simply store the query permission since in the distance we actually do GPU pipeline where we have two cases which is flat water and a height map water both of this data is loaded from a quadtree on the GPU and we use this to do a secretary clusion and create the indirect draw arguments buffer and this part is fairly simple because the computer can just fetch from the height map and it can know whether it's a flat piece of water or if it's a waterfall or river and once it does this it will actually pass the data through through the indirect arguments buffer and give us a draw call now this is very

important it's a large open world game so in a typical scene you might have 80 to 90 draw calls but once you do occlusion you might end up only doing ten there are some really heavy scenes where you might actually end up having 600 water bodies and this is why we actually have to split the water into near rendering and far rendering where the far rendering is a single draw call but water bodies close fire actually multiple juggles so if we want to do everything in screen space we kind of need a mini G buffer which is a little bit lower resolution and a higher FV which defines the surface shape and as I mentioned before artists do not give us tessellated meshes we actually do screen space tessellation so in the past we call the position pass we write out three textures which is the data texture the mesh normal and deaf buff are only containing the water planes once you do this for all the water nearby and in the distance you get textures that look like

this now what do you actually store in these textures in the data texture we store the shader ID which is an 8-bit texture and that contains shader features which could be as a front face does the support lighting or not and is that a valid pixel or not we also store the material structure buffer index because from this point on everything is done per pixel and you'll notice also storing the map level of the algae and the phone because we are doing things in screen space we don't have access to D DX D UI so we kind of have to pack this out in the early stage water is a very interactive thing so we implement as something called vector displacement maps and this is a fairly simple particle editor extension where we render projected box decals for each particle and the way that works is when you render the box we sample the debt buffer that has water in it and we do position from depth to project that onto

the water surface we also have to invert two object space replying to you these otherwise you will notice this torsion in screen space at this point we also clip all the off-screen pixels sample the displacement textures and also do any sort of animation that the artist might want because if you're doing splashes it's probably multiple frames not a single frame the most important things from the slide is the fading of the displacement towards the edge edges of the box if you're applying a projected box decal on a for example a waterfall you will see displacement exploding as it gets to the edge of the box which you don't want to do and how do you actually blend all of these we do a max alpha blend where we cleared the texture to a negative told max and we do alpha blend max to get all these textures so at the end we get a texture that has all the displacement splashes in it we actually went away from giving control to artists to paint normal maps because we found that that creates a lot of repetitions so instead of that we create noise to get the

general surfer shape which is the high frequency noise and for that we use the fractional Brownian motion with nine iterations per pixel if you don't know how that works basically each iteration adds more frequency as you double the UV scale and this is one thing to remember is this is fairly expensive because it's nine texture fetches per pixel so we actually do an LED approach where in the distance we do three fetches and close by we do nine and we don't want to go to zero because otherwise the reflections look really bad in the distance and there's two errors on this diagram one is that this texture is not cleared because we have many passes and we have a valid mask on the screen which tells us where there is water there is no need to clear these textures so in every pass it will just simply check and check if there is water or not if there is ill sample the valid data otherwise it does not and the last thing is the second error is we combine the splashes with the high frequency surface shape so now that we know the surface shape and all

the displacement we actually need to do screen-space distillation but we don't want to do this for tiles that don't exist we need to do some sort of occlusion pass so the way this works is we divide the screen into 32 by 32 tiles we found 32 by 32 is the best for all hardware we first started with 8 went up until we found the one that works and the way this works is we simply get a purl tile pixel count and you have two cases like the tile might have a pixel that has water or does not have water if it has water we do an atomic add into a structure buffer but we also use the group shared memory to store this before we actually write it out into destructor buffer one thing to remember is if you're working on console or dx12 you could actually use the ballot instruction because we have a per pixel boolean we can test against to reduce this from 64 atomic still single atomic because we run this in a grid of 8x8 threads once all the threads are finished and the

group their ID is zero we actually write out the total pixel count into a structure buffer and then we do another pass where we simply iterate this list and get the pixel count if it's greater than zero we increase the indirect draw arguments buffer by 1 and the last line there is very important because we will write out the tile ID into a sector second structure buffer and you can see from a render capture this specific of you has 606 mesh instances on the screen with each one being 1536 indices so it's highly tessellated so now we know what water is visible which tiles are visible need to actually render this mesh so from the previous pass we know exactly which tiles will have water not have water and we will render a mesh that's tessellated per tile where it is visible how do you actually figure out the density we in this example I'm using a

512 by 512 buffer which will get up sample to the viewport and we just take the 512 divided by 32 which is our screen screen tile size and we get 16 by 16 quads and this actually gives us constant density tessellation and we use draw index instance indirect to actually draw each tile on the screen this is why we need to know which tile will have water or not so just to run you by how each tile is rendered you'll see a renders a highly tessellated mesh but how does it know what where to render this mesh from the previous pass we wrote out the instance IDs or the tile IDs into our structure buffer and that maps to draw call and then for each vertex we can figure out which instance it belongs to from each instance we can figure out how to create the UVs because our mesh is simply storing the a 16-bit position that's compressed and we can convert that into a UV once we have the UV we could

actually sample the depth and compute the worldspace position in a larger field of view and then sample the displacement texture which contains the FBM and splash and at this point we use we use an and to clip all of our vertices because there's no other way to clip in a vertex shader at that point we also project into screen space with a regular F of E and do depth test with the screen seeing the C buffer sorry and what you get is this so as you can tell there's no pixels that are black or there's the mesh because it's per pixel tessellation again with the depth buffer test and again it's screen space so we have to write out to you V's to match this discrepancy between the larger field of view and the lower field of view why are we doing this large field of view example if anybody has done any

ocean rendering you will know that when the camera gets close to the water it will clip and we actually want to fix this so when we do this in the larger field of view and do the tessellation we up sample and we get this there is some amount of distortion between the large field of view to the lower field of view but it's hardly noticeable with motion so that's kind of the deferred pass for a mini D buffer but as I mentioned before we don't actually give the artist the normal map so we need to generate a screen space normal map without D D X D Y which we use position from depth to do this and one thing to notice because we are a first-person game when you get close their water surface this will actually create artifacts so we increase the sampling radius as you get to the water surface and we do mesh we do blend with the mesh normal to remove any of the discontinuities because we do get a

low res mesh from the artist width which is blended with the high frequency displacement normal so this is probably my favorite slide because before doing this we actually found that we're getting a lot of specular aliasing and we actually do this for our offline textures as well but because we have a reference normal that we're storing in screen space we need to filter it so we're doing a variance based approach where you simply compute the gaussian normal per pixel and we solve for smoothness based on the reference munis and why is this important if you don't do this you'll notice that actually the the variance increases quite a lot so you will lose some of your specular but lucky for us we have a per pixel material map so we could actually use that to scale it back into the range we expect water to be with the variance we actually need to fix the specular aliasing and if you do this you'll see

your specular has come back so talk a little bit the foam foam is fairly straightforward it's just a noise texture modulated by a noise texture but the more complex portion of this is the flow map which is sample using a two different offset faces in order to avoid pulsing and where do we actually show this foam it's it's driven using a sine distance field based on the shorelines and rocks and at this point we also blend in the displacement foam with the shoreline foam so we are an open-world game so we can't actually afford to do with all this at runtime so we actually bake up the entire world's flow map and run the generation at runtime in an offline process this is how it looks some of you might think oh this is flood-fill which it is so we run a flat fill algorithm but a flat field is kind

of tricky because some pixels will arrive at the destination sooner than others so we actually use a signed distance field to guide the flood-fill around corners which also works for rocks and out of this we get a flow map texture atlas which we have two variations one is a high resolution texture and one is a world flow map the high-resolution close to player gets streamed in as the player is running around the world and the world flow map is baked out once the way the world flown up actually works is an old trick where we based on a sector idea we can figure out a UV remap table which is stored in the texture itself which can help us figure out which portion of the Atlas to read and this is a self-contained texture so any feature that means the flow map could actually read this simply based on the world position and this is also our world height map which we also baked the low resolution textures are eight meters per pixel okay so we generated all the

things that we need for a water surface but how do you actually like this because everything is in screen space so there is one important thing is that I mentioned earlier is our water right does the right depth so at this point we need to sample the the depth with and without water and also all the material IDs per pixel so you'll see in the screenshot on there on the right we get the materiality we also get the blend material ID this is very important because artists can place two rivers with having very different materials and we actually need to gradually blend from one River to the other without any discontinuities and we have a function that actually interpolates the material properties we don't actually want to blend all the material properties but only the specific ones that are required because it's kind of a waste of they'll used to do the rest so now that we've actually blended all of our data we need

to actually read all of this from the structure buffer and compute the lighting and the previous parker games the water simply supported the directional light but now we do fold full tiles even lighting on our water surface which is pretty much the most expensive part of the the lighting path and now we support GI reflections the directional point spotlights and we also support exposure lights so in terms of actually lighting the water surface the way we do light transport is we went away from giving control to artists to give a specific color but instead they actually deal with the scattering coefficients so we have a table of water types that the artists can pick from or they can create their own the way that works has just got RGB scattering coefficients with a turbidity value at the end which is based on the physical properties of the water so with this you can create oceans rivers that are quiet muddy or clear we also sampled the foam

from fractioning caustics buffer in order to compose the final image and this is just kind of gonna show you how these buffers might look like if you did this so this was the refraction this is the light transport this is the screen space local reflections this is a low res environment map 64 by 64 and once you combine all of these you get something that looks like this which handles everything physically based so you'll see we have the splashes we have the particles interacting with the water you have refraction there's foam and it works great with the rest of the terrain but I did mention that this is a very bgp are heavy pass so you have to be very careful how you actually handle this that's what actually christian is going to talk about alright so looks like we're doing very good on time i was planning to speak to my optimization is

pretty fast but thank you Bane for mentioning about the V GPR usage of this shader so what I'm here to talk about is about a way in which you can optimize your shaders by using half precision which is 16-bit precision by saving v GPRS and this relates to Ben's talk because the material the material blending done in the surface composite pass is well it's but it's V GPR heavy just like you mentioned you can see there are a lot of different attributes being sampled and these are very easy to optimize just with the change list you see here in this slide so if you look at the yellow font that was the only chain that was needed to be done in hlsl to actually save 9v GPRS of this path this resulted in an increase sort of occupancy the shader went up to three waves per Cindy from two weeks per same

D so the role world result was that this pass was running 25 percent faster when from this simple change now no actual change needs to be done c++ site so this is everything that really needs to be done and now I know you're all I know exactly what you're thinking seeing this what is min sixteen float right so luck we have a slide for that it's an SSL basic data type so there are no extensions needed for this optimization it just lets the compiler know that it can reduce the precision down to sixteen bits and this stands for integer as well so there's a min 16 and data type in there as well but then it's up to the software and the hardware stack to decide whether it can take advantage of the lower precision to actually speed up the performance of the shader right so this doesn't actually force the shader to use that precision like I just mentioned and it's it's very important to note that the this doesn't

specify the resource format in memory it actually just allows the GPU to use 16-bit precision when it stores the values to V GPRS and when it actually performs the math this is why no c++ changes are necessary it's just because this is like internal to the GPU execution not to the resource itself and please don't confuse this with the half key word in hlsl because it's that's like 32-bit and counterparts exist for GLSL so this is not an HLSL only thing you know you can implement this on different platforms as well and you know precision lowering cannot be automatic that's why we have the keyword in the first place it the software stack cannot possibly guess when it can lower precision without actually impacting quality so then it's up to the developer and actually the Quality Assurance department to make sure there are no quality issues and it's up to you to find those particular variables and those particular bits of math that can be safely lowered to down to 16 bit and

you see here listed few examples typical examples when this is not safe which I will not go over and I'm not trying to bore everybody but just trying to remind you you know register pressure is the common bottleneck and the way you optimize for it is that you're really trying to increase occupancy on the GPU and that occupancy increases these screed thresholds of vgp are usage so if you narrowly miss one of these thresholds it's not ideal right so you really want to spend that effort to get on the right side of the threshold and obviously if you target shaders that are particularly vgp are heavy you probably are targeting the right bottleneck there and you're you're likely to see higher percent gains on that and there are multiple sources of VG peer pressure one is I call the main source of VG peer pressure which is what everybody is thinking mostly when they talk about VG peer pressure is just how many maximum number

of live registers you have at the same time so basically how many temporary values need to be stored cash however you want to thank it during the actual execution of the shader and pertaining to this material blending example the reason why it's particularly VG PR heavy is because every material has a lot of attributes and to reduce each waves latency it's often optimal to have all the memory read in at the beginning of the shader execution and then all those values are cached basically in V GPRS until they're actually used and now think of having to sample multiple materials per pixel like in case of fire PI 5 they sample up to two materials per pixel so then those attributes need to be cached twice you've caching twice the number of attributes and even though a certain pixel is not using both the materials the shaders still needs to allocate the full VG PR in case it needs to allocate twice right so that's a real concern they're obviously packed map

hips helps the average VGA occupancy case because with pack math you can store two 16-bit values in the same space you require to store a single 32-bit value but there's a different dimension to VG PR pressure which is actually the focus of my talk today not a lot of people are actually familiar with the fact that there is allocation overhead for V GPRS and you can think of this is just like waist like v GPRS that are really used wastefully and that cannot be avoided and it's because of certain restrictions and these restrictions are related to the way memory operations work so if you look mid slide you can see in mah no space font an actual hardware instruction that loads four components from a buffer you can see buffer load format X Y Z W and the first parameter is the actual output it reads for these four components X Y Z and W into the registers one to four V

one to four and that's an actual registered range and that's a key concept so the the actual components need to be read in two consecutive registers you cannot spread them out over like arbitrary registers and the order of the components and the registers has to be exactly that order so V one will contain X and V four will contain W there is no way to Swizzle the components at the instruction level so these are significant constraints that that end up causing allocation overhead and in ways which we'll show next and this also would stand for texture dimensions so if you look at the I set example here you can see the texture coordinate is the second parameter is V zero this is because it's a buffer but if this would be a 3d texture the same sort of constraints would apply so how do you know if your shader is actually suffering from allocation overhead right for that you need to perform live register analysis and on PC we have the

Radeon GP analyzer which is our open source tool that allows you to do just that amongst many other things it basically takes in HLSL as input and it will generate a bunch of helpful outputs amongst which the live register analysis and you really need this to be able to optimize your shader and especially to detect the allocation overhead so I'll be showing two examples of I will be showing two shaders one shader which features an allocation overhead is on this slide and that the next slide will show a shader that actually suffers from one VTR allocation overhead and is a slight modification of this shader so at the bottom right and the red box you can see the HLSL listing for the shader with a bit of pseudocode added to make it easy to read and at the top you can see the RGA output which is the actual live live vgp analysis and if you look at the HLS a listing you can see this is a very simple shader that reads from an

input buffer it reads four components and it performs some math of the components and then the result is a three component vector of the initial four components so you can see in yellow font you can see that that is all the math that is performed on the input contained right there in pseudocode so at the top what is the live vgp analysis you can see the RG output the leftmost column it's just a line number which is still useful so I can refer to it the second column is the actual number of maximum V GPRS use that specific location in execution so it matches the particular instruction and then the third column actually contains a matrix and the matrix has its own lines and columns and it encodes the live vgp our state of each individual vgp are at each individual location and the instruction timeline so without this matrix the

lines correspond to the instructions of the columns they correspond to the actual V GPR so v GP r 0 would be the leftmost column and the VG p r4 with the rightmost column the characters encode the states so we have the carrots you can see for carrots at the top a carrot means that a particular V GPR is written into a third location by the instruction and the obviously is a valuable we have will have to be stored for later and then the V letter which you can see four V's at the bottom that means that value has just been read by that instruction and the value is no longer needed and then the X character the X letter there means it's a combination of the carrot and the V so it means that that particular instruction read a value from that register and it's over over brought that register with a new value and when you see a column character that just means the register is live so the particular instruction might be reading from it we're not doing anything with

that register but in any case it's value is needed for a later time and when you see a space character a blank space character that just means that the GPR is free for usage like it stores no value of consequence at that point so how does the shader get compiled into actual machine instructions you can see the first instruction is reading the four components it's exactly the instruction we looked at earlier and then the second instruction is just waiting for the memory operation to finish at which point we have the actual math and now if you look at the actual math that needs to be performed you will see that if the hardware is to be efficient about the way in which it goes and computes all the three components of the result as it actually can do this with only three additions if they are done in this order if the X plus y is at at first if the Zed component is at it afterwards and then if the W component is at at last to all these intermediate results so all these intermediary results will have to be stored in V GPRS for both

purposes of computing further math and also for the purpose of them actually being output now if we skip straight to bind 6 where the output is actually stored it's written out we can see again when it's written out it has to be written out in a range where again the V GPR is 1 2 3 are written out and they have to be consecutive and they have to be in that exact order so this creates constraints on the map for the math to be efficient so we see the first addition at line 3 that it has to add the x and y components and obviously it has to read V 1 and V 2 and you can see in yellow font you can see that the output is V 1 and the compiler only has a choice of V 1 or V 2 at that point because it just read those values so now those registers are available to store intermediary values so in this case it stores the value of V 1 and then it's a with the second addition that now the output in order to avoid any inefficient swaps it will actually have to be

allocated that value into v2 because remember it has to be all output in consecutive registers so it's actually able to compute to the math and the proper order and to store it in v1 v2 and v3 so everything is good here no allocation overhead 5v GPRS I've used five Ichi are V GPRS are allocated everything is good the math is done in place and now we're going to slightly modify the hlsl for our second example and these can see the hlsl has been modified just by changing the component order in which the math is done so now the math is done on the WN set components first and then it has to add Y and then it has to add X to be efficient so it's exactly backwards and this really affects the way the shader runs on the machine because the first addition now it has to read from W and Zed but those are stored at VG PR 3 and 4 because remember when they come in they have to come in and consecutive registers so now this means that the result of this addition can only be

stored in v3 or before because v1 is still busy with X and v2 is still busy with Y so once that's done once the compiler actually uses v3 to store an intermediate results to be able to actually now store the output and consecutive registers it's forced to go on to store the next results in v4 and v5 and when it actually allocates v5 we can see on the third column the one with the matrix with that encodes the VG PR register States we can see in red highlights VG p r2 and VG p r5 and we can see VG p r5 with a caret it just becomes allocated to store the intermediate value and then it quickly because the alligator is is written to output but we notice that throughout its lifetime we noticed that VG p r2 is completely empty right so this is what allocation overhead is it's the fact that the compiler has to allocate an additional bgp are even though one would have been free because of additional constraints and this can further degenerates in a

complex shader to cause further allocation fragmentation because once the actual ordering of the GPRS matter it can all cascade from there so how does half precision actually help allocation overhead well the answer is actually very simple to V GPRS only to V GPRS are needed consecutively so when and memory operation is loaded it it's only needs those two consecutive V GPRS that creates a lot less opportunity for fragmentation and that's the simple story of it so basically if you are able to identify the locations where you have significant allocation overhead you will be able to very effectively counter it by using half precision and that's it from optimization back to bein for further water discussions ok so

basically we spent a lot of time experimenting with this and we were shipping Fargo fives coming on next week so I thought it would be interesting to talk about a lot of the problems we had trying to do the screen space distillation and water writing depth so yeah first line is water right steps the moment you make this decision you're setting yourself up for a lot of bugs and I say it a lot I mean a lot this is kind of a a little bit of a curse because you essentially have to have two def buffers in your engine at this point and everything has to decide whether it's gonna sample the one with or without water and you really need to actually think about how to actually implement this because in some systems you can actually copy the DEP offer after you have the depth buffer with no water but on some of them you can't and what do you do with the stencil if you copy it without the stencil and all the passes that require the depth width stencil you can't actually do that or you might even have one pass that does

down res multisample which you could potentially fix this where you write out the depth read it back in and write it out through your chain of dead buffers we have a lot of small textures on console this is not really an issue because we do a lot of packing between passes so we'll know exactly the layout over structure we can pass one textures value from one to another and we do a lot of ping pong simply because this allows us to pack the textures and we do a frame allocator so you know and during the frame when de texture is gonna be free so we can release the texture and regain it when we actually need it so we don't use up a lot of memory screen space desolation there are two major issues with this the vertex shader is quite slow and on the current GPUs if you're actually launching a lot of large vertex shaders a very small pixel shaders you actually end up stalling the GPU so we did a lot of optimizations where the vertex buffer is actually just a 16-bit

integer which is encoded for UV s but it basically has to be the lightest possible vertex shader you can imagine but lucky for us in the future because we are doing per pixel to vertex tessellation we could do a compute pass which does all the ALU operations beforehand and then we simply do a fetch from a buffer instead of actually computing everything in the vertex buffer we also had a lot of edges I'll show you a picture of what this might look like so if you do things in screen space you could actually end up with two connecting water bodies which ends up stretching the mesh in the distance which is not really ideal but we actually did end up fixing this and the way we fixed it is we simply ran a computer that actually tracks where the two water bodies connect and lowers the displacement this is actually a result of the FBM displacement being in screen

space we do plan to actually move that into world space FBM generation into some sort of alice that we can fetch and fill a fixed decision issue later but for now this is what we did so we figure out the edges and then we blur using your computer the way you actually do this is it's very simple to do just like you would down sample a cube map okay the other really annoying thing we have to deal with is in Far Cry 5 we have a fishing mini-game which is quite nice but this creates a fishing rod which is actually a mere Z and far Z so it's partially UI and partially 3d and if you have spring space reflections you're gonna get this nasty line that's created by this line and this line also changes color so as you're fishing you'll see the water is constantly flickering and we did actually manage to fix that by running a post-processing pass after we

do the ray tracing for the screen space reflections just some little debugging tools we use to debug this when you're generating a lot of data you might want to create tools that help you debug this in this case we're showing the world flow map in a specific location along with the water level and this is how the two materials would blend in screen space you'll see also on the left side there's a there's a little map for artists to know which material is which and the colors essentially indicate the blending range in screen space and they have control over controlling this range so an artist can say I want these two water bodies to blend over three meters six meters twelve meters we typically use six meters and we also show the signed distance field which we used to debug all the water flow problems around rocks and shorelines so I know somebody's thinking

here how much is this take our budget was two milliseconds on the GPU these are all the passes listed and how long they take the things in green are actually running a scene compute in our game but if they're actually running on the main pipe this is what the performance would be like and if you look at the numbers the two most expensive things are the tessellation which is at point two two milliseconds and composite passes actually is 0.87 which is mostly done by the tiles even lighting so once we actually run this on a sink compute our time goes down to one point three three seven milliseconds however this assumes that you actually have gaps you're acing compute pipeline in our case we did because we have full control over when our acing passes run so we got that large win and this is just a little video to demonstrate all of this in

action [Music] [Music]

[Music] so just before we have two more slides just before we finish so there's actually a bunch of other farcry 4 farcry 5 talks happening at this week the first one is terrine rendering by jeremy moore the next one is the acid build system of far cry 5 by Remy and the last one is the procedural urgent world generation of far cry 5 these talks are all really good to attend because they are all kind of counterparts to our water system especially the procedural world generation because it feeds all the data into our system that we use to render and last but not least a big thank you to the far cry 5 team [Applause]
