[Music] so mine so now's waiting so high welcome everyone first of all I'm supposed to tell you that you should turn off the song on your mobile phone my name is Mikkel I'm a graphics programmer this is Mikkel he's a very technical artist we work at play bed which is a Danish company that did a game ages ago this called limbo and neither must worked on that but we worked on the follow-up title called insight that's been in production for for some six years or so and that's what we will be talking about today more specifically we will be talk about are the rendering and we sort of selected some topics that we think would be relevant to other games that that you can steal and implement in your own games the same as we've stole all your

stuff so yeah before sort of diving into that I'll show the trailer from history a couple years ago so you sort of have an idea about the game that will be read [Music] [Music]

[Laughter] [Music] right so as you can see it's two and a half piece or side-scrolling game that means that we we have sort of full control over everything the player ever sees because now we're only ever moving right woods that means that our asses can sort of go in and tweak every pixel and turn that means that that our art style sort of heavily relies on these very subtle details of the earth that also means that they're from sort of a rendering point of view we can't have too many aspects that distract from from this these subtle details in the art and

that's that's kind of a point that that this fall will be revolving around so from some particular point of view just to get that out of the way we are releasing at 60 Hertz at 1080p on on current consoles and the engine we're using is a custom e custom unison pipe right now we have soft access for that so we made some modifications the rendering that we're doing is it's light like a light prepass renderer so that means that we have a base pass that the output Stefan normals we then have a light pass that that calculates light from those steps or normals and then we have a final pass that re-renders the entire frame and then applies the light and materials we then have a translucency pass and then we sort of wrap the whole thing up with a post effects pass all right so one of the things one of the effects I suppose that's really sort of central to our style and show to be central to our style

quite early on is it's the fog so actually initially we had a lot of scenes that were just geometry and farc so we had back since everything was comprised of silhouettes and then this like depth for so to sort of show you how much mileage we get out of that here's the scene without any fog and she could see that's that's quite bare and then adding just a like a linear a pep-talk we get actually quite a sort of moody scene from that the only thing that we're really doing with this is that we're capping the the farc at like a maximum level so if we have really intense lights in the background then those will still shine through but otherwise it's just like an OpenGL 1.0 linear that we use in the back in the depth then we have this this sort of light scattering post effect simulation paths and I kind of said that with a smile because really what we're doing is just blurring the entire scene and then

blending that bag on so really it's just I could blow past that our artists then used to sort of simulate this this misty atmosphere and that works surprisingly well and this is what we're using throughout the game so now that we're using glow for for this scattering effect then how do we do glow well we have a second path where we do these really narrow high-intensity glows so what we do is like many have done before us is that we write out a mask for wall for mists of objects in the scene and then remap the the intensity of that mask to like a Serie to 7 HDR value and calculate bling from there so this is so this is obvious in hindsight but it wasn't really when when we when we implemented it's so when you calculate bloom from a pixel with a certain intensity like if the bloom shows a certain intensities then of course we need to render the the sauce pixel with that intensity as well otherwise that's

like a difference between the two so it's really like you just need to if you use if the I'll you of course need calculate bloom from an HDR pixel of course need to actually show that pixel in with HDI value as well so the way we do the the actual eye bloom filtering is the same as Jimenez in the Call of Duty presentation and matza missing links from the Samaritan demo before before him in that we just found sample the image a number of times and blur while down sampling and then we up sample and blur as well off to us so the way himmat is this did this was that drink down sampling he had this 13 tab filter that that used to like that where every tab would sample for for Texas but as you can see like even though he's doing that he's still sampling some of the Texas multiple times so what we did then was to fit a nine tab or nine tabs

through this these 13 tabs and that actually works pretty well so we get an error of like 8 percent at most of the other polymnia weights but but in the end we can't really tell the difference of course one important thing about this is that this only works if you if you down sample to a size that it's exactly half your original size so but that's not really an issue because you get the most benefit during the first couple of down samples like from full resolution shaft resolution so what we did was just to detect whether or not that was case and then used to like the full 13 samples if it wasn't alright so that means that we have a post effect set up that looks like this so we have all our like prepares rendering and translucency we then run temporal anti-aliasing the top of of all of that we then run our to glow passes which are separate but into these for performance reasons and then in the end we do the like the HDR

resolve Cobra solve and apply the glow and some other effects all right so so back to the the fact that we talked about before so became apparent quite early on that we needed more control than just this this global linear fog that we were using so we implemented this this local local fog like local light scattering I'll talk about how about how long how that worked so in this scene we have this guy with a flashlight and that flashlight is calculated using using this effect so what we do is that for every pixel on screen we very much through the world and for every step we assemble our the light function so we say move the shadow map and the the projected texture and the fall-off and sort of thing and if you do like and they even limitation of this you end up with something that's really slow so this like if you don't want artifacts you need something of the lines of 128 samples and if you if you sort of try to

make that faster by reducing the number of samples you get these these horrific standing stepping artifacts and and still it's quite slow so what you can do then of course is you can add a little bit of noise into your array offsets but you yeah so now it's actually even slower than what's before when the reason for that of course is that we're now completely destroying texture cache because neighboring pixels are sampling at different points of the light textures but that's there's something interesting about this because the eye is actually quite forgiving to the noise so we can agree Nash's you know what what it's supposed to look like so that's that's an interesting property so so we should explore that further so this is the same scene except rather than using our 24-hour steps we're using just three and as you see that's that's a lot of noise that we get in the image where you still kind of make up what it's what it's supposed to be in but but

not really so what we can do instead is that we can use a piyo matrix and that has of course it has less noise because it's there's no random and this is an entirely homogeneous pattern and we also get better sampling because we now have like within a small week and we have all possible values so that means that especially before we like maybe we were sampling in everywhere from from each sample but but maybe we're not not we have certain they were always like within a small region we're always sampling at at all distances but but we get quite a lot of structure and listen and whereas the I is quite forgiving towards noise it definitely isn't as wards patterns so really what we want is something that it has this property of of changing changing at quite a high frequency while not not being a peasant so what we did then was that we used what's called blue noise which is high pass filtered high pass

filtered noise so obviously which is high frequency and that sort of has both of these properties so we get something that that doesn't have the the pattern and at the same time it changes quite rapidly especially so sort of stepping a little bit away from the noise and looking at how to best use these these samples the way we replace or define fog volumes in the game is that we replace boxes in the world so of course we there's no reason for us to sample outside those boxes and also there's no reason to sample outside of the of the light so what we do then is that we do a geometric intersection between the geometry of the box and the geometry of the light first and that essentially boils down to just its exact thing the the light frost one with all the planes of the box and then patching up the holes alright so that means we have like

a two pass algorithm where the first pass renders out the front faces and then the second pass does the actual array marching and the first pass renders four faces second pass renders back faces and same was the front face texture so we now have like the statement for array so this thing about using a bus to to define the the fog volume is something we actually use for effects so in this is a scene where above water we we have one volume that you just uses the the textures from the light and sort of prophesies that makes the books look like air and below water we use an animated projected texture to to simulate our caustics and then of course we've changed the the properties to look like both sense there so one thing you may have noticed and that that that many others have noticed before us is that of course we this is

quite a smooth effect we don't really need to calculate this per per pixel it we can at least get away with with sampling it at half resolution so we do that of course so now we have a three pass algorithm through passes all same as before but but at half resolution so we right off the front face depth we do the Ray marching and then we have like a third pass thus I resolve through full resolution at a later a later stage so while doing this this off sampling we add a little bit of blurring and we do like in under samples and under samples of noisy blur to break up the patterns that we we would otherwise get from the halfway solution same thing so one of the reasons why we do this is that we have temporal anti-aids and running afterwards so several anti aliasing at least in our implementations using neighborhood clipping and that means that if we have a lot of different values within a neighborhood we it will

will accept more more values and so it's it's easier for it to run to smooth out per pixel noise like a full resolution rather than and half resolution eyes so this is a sort of final image this is six samples at half resolution that's running at just below one millisecond if we sample every pixel on screen which of course we we don't actually most of the time we're usually just three samples per pixel so that means to be using just below one sample per full resolution pixel so one of the reasons why we've been obsessing about the number of samples here is because we like this this effect this is bandwidth bound like sampling the shadow maps and the projected textures really was was pollinating this so we of course also do all the other things to reduce bandwidth like we a lower-resolution shadow map which is low resolution objects and textures and

- yeah and then of course the shadow map can be low resolution then then then for the opaque lighting passes because it's such a smooth smooth effect so the way that fits into our render pipeline is like this so the lighting paths are during the lighting paths we save off the shadow maps that we'll meet later on we then do all true initial parcels and and end up with a volume light texture and then during the translucency pass we rerender the like the clips geometry and I solved that with other translucence ease so so this thing about sort of playing into the hand of temporal anti-aliasing is something we actually do in quite a lot of cases so this is this example is the depth of free will be doing we have sort of of planes that we can put into the world that will calculate depth of field and we do like an under sampled blur again and the temporal anti-aliasing will will come and pick up all the notes and smooth them on we also do that for for shadows

and and an interesting thing here is that even though this sort of jaded sampling entirely destroys the texture cache is still actually faster than doing just a single sample because we can render the shadow Maps at a lower resolution because the the soft penumbra is larger than then another wise which is why we can get away with it so just wants to show how like this is sort of our code through pattern for for doing this under sampled blurring and essentially just passed down to to having each sample or cover the the same area as well all samples cover the cover equal areas right so I'll talk about another effect that was really important to to get the look of the game which is dithering so this is a frame from the game and I've sort of adjusted the

luminous serene we can see what's going on a little bit better this is actually really good example of this sort of this sort of subtle detail of some that where we have a lot of really fine sort of gradients out in the background this this image actually contains quite a lot of noise you probably can't see that but if we if you turn it off it looks like this if that think that looks horrible that's good so so what we get here is quite a lot of banding really so we have these these really high frequency changes all these sharp lines during the image of throughout the image and we also have these sort of rainbow like effects where the color is completely destroyed and of course that happens because our red green and blue font sizes at different points and also it animates so it's really quite distracting not really something we can we can live with and or use with darts all the way whether we intend so the

reason why this happens is of course that we are writing into 8 bit per channel our render targets so as you can see in the on the line that means that we get this sort of stair-stepping artifact which which looks like banding the reason for that of course is that 8 bits are not enough like nearly the the human eye is able to perceive something along the lines of 16 bits so we could of course just used higher position in render targets but then for performance reasons on some platforms that that will be an issue there are other ways of sort of getting about this we could use sRGB color compression in instead but again on some platforms that that has interesting implementations and so we chose to explore doing a bit further so an example of how this works is that you you just add like one bit of noise so if we look at this we and look at the value 0.75 bits and add one bit of noise that

means that 75% of the time because it's an entirely uniform noise we end up at by quantizing to the the value above and 25% of the time we end up quantized into the value below so on average we actually get exactly the the signal that we that we put into it so just to sort of show how how to do this this is a fragment program or pixel shader and how to do the dithering is you just add a random number that is one bit big on output so just keep this in mind that this is actually spectacularly easy to thread and there's there's no real reason why our game should ship with with bending these days all right so let's look a little bit more about at what's going on so here are in the top we have the signal then we have the quantized bangy output and then the third row shows the arrow between the

signal enter and the output so if we that our noise through it we then see that it already we have something that's that's a lot smoother we see the errors is not very uniform and if we look at the variance at the bottom we can see that definitely we have these sort of weird humps if we animate the signal we can see you that we have these it becomes quite apparent that we have these areas of no noise which is which is interesting so what's going on there is something called noise modulation and that means that the the resolving noise is actually dependent on the signal it turns out that's a property of the type of noise were using so rather than using this this uniform white noise we can switch to a triangularly distributed noise that's a has a little bit like two bits worth of that and we get an output that that where the noise is independent of the theoretical Aboriginal signal so

if you go back and and apply that instead we can see that we now have on an error that is it's much more uniform and if we animate it we can see these sort of pants of less noise have disappeared all right but we've we've then added quite a lot of noise in signal so what can we do about that well we can go back and then to try different types of noise like the blue noise that we were using for the sampling and and that actually works out really well so again if we animated we can see that we we now still don't have these these these pants of no noise and also we have much less noise than just using the the triangularly distributed regular noise alright so so what we've done is that we've we've baked blue noise or high-pass filter noise into texture and we just sample that and and add that the same as the example before in the in the cases where we are bandwidth limited we

use an ALU based version instead which is essentially just adding two random numbers together alright so now that we know how the data we should look at at what to differ this is an example of a single spotlight shining very bandy light into the scene and so of course the first thing we do is that we did with the light path so that looks like this and that's that's actually that's already really good but we can see that we have these sort of like the noise is not inside uniform we have these sort of waves in the noise and the reason for this is not as you could expect because of the tabloids we're using it's just because we sampling the light buffer in the final path and then writing that out into an 8-bit buffer I can of trying to get buffer but if it's per channel so if we did that as well we we get this result which is which has entirely uniform noise which which is much better much better so of course we need to do

that the translucency pass as well may be even more important that than all the other parcels because during blending like we tend to write to each pixel quite a lot and then and then of course we quantify so it's quite important that we add on noise too to all those passes because each pixel will have I get recontact part of the one the the post effects passes tend to read and write from buffers quite a lot as well so of course we need to do those as well to sort of make sure that this really wide lights scattering light scattering glow was entirely bending free we actually ended up using ten bits and so power of two compressing the colors and also did ring and then that means that we are entirely bending free for those as well so so far we've been talking about bending in in colors but really this is an artifact of the quantization doesn't really have anything to do with colors so of course

this affects our normals as well so when writing out the normals in the in the first pass we write those out too to low precision purposes as well and we of course need to do that as well we don't actually do that everywhere we just do it in sort of the specific spots where we where we have really high intensity specular where that's actually an issue alright so now we know everything that writes in 2 to 8 bits per channel buffers there anything else well mm-hmm animating the noise is a really good idea because if you don't then you sort of get this sort of dusty lens effect that's static when you move around which looks weird another reason to animate the noises that we are running this temple anti using pass afterwards so so animating it means that the temporal anti-aliasing will actually go and soak up a lot of this noise because it's it's integrating it over time something else to think about this that your device when outputting to TV or other device

will will may convert the signal if if you're not using like the the right output so you should make sure to you know of match the expected output as closely as possible for example our limited range charge be if you know that that's what your device will be outputting then you know make sure that let you do that so you can probably divil the the signal yourself and also of course view iTunes to be transparent and have lots of layers and and fade in and out so it's quite important to do that as well right Allah oh and here and handover through the other Michael thanks hi so the first thing I want to show a little bit and talk about it is custom lighting or lights with custom light

functions and we do these and we can do these because we're using light prepass as our rendering loop from that we can then not just render our points or spots in our directs we can actually just render about any piece of geometry with any shader that we'd like as long as it's a you know contributes dividing in some way so we have a few of these I'm just gonna go into into depth of three of our types the first one is the bounce light so the bounce light is pretty much just something that we use for subtle lighting or global illumination in some cases as the name suggests and it's pretty much just a normal Lamborghini employed light but with a small twist and that small twist is we have a slider that can take that in the little product and wrap it all the way to the back making it a half Lambert at the half

point or side all the way behind and just made a fully sort of ambient term with just a fall-off which gives much smoother software results when you really don't want it to be obvious whether light is actually coming from in these cases they've used in in somewhat creative ways because they're not static so typically for for windows that open and let light in we put one there and faded in or spotlights that hit the ground and want to cast something off from there when when appropriate and one thing about putting these around is we could just put distribute them along a line if we had a corridor or range of Windows but creating this sort of sausage of point lights would be a little bit redundant both still applies and also overdraw wise so simple trick we actually just you know let's use skillet

non-uniformly using the scaling matrix that we have already been granted so far and yeah it's just it's just fit rooms fits rooms much better second of all and the more interesting is our AO decals so we cannot just render initiator you want here we can actually render with whatever blend mode we want as well so rather than using you know additive lights we actually have multiplicative lights if you will to draw other types of things and the reason we're doing imputing fusion with decals instead of screen space is because we would like local control we want to know which objects are casting these things and we want to control their intensity and we don't want any screen space artifacts like things being off out of bounds or occluded by something so it doesn't cast well so we end up with these and we have three types and let's dive in a little bit the first one is the point so point

is something we use mostly typically for characters to ground them to the ground and themselves in each other and in this particular screenshot I think they're about a hundred of numbers sir because we actually put one on each limb or each bone of the character and just stretch them to fit as well as possible and it gives these results and the implementation is really really simple if you have a bounce light you know 1/2 Lambert point light and you just make a most executive you're actually there so in this case we don't expose a wraparound parameter we just you know maybe the half Lambert and we have a fixed fall-off we really want to control it be simple we're placing hundreds of these so we don't really want to have too many sliders to worry about there's a really effective way of getting a beam infusion our characters for cheat C's

second of all we have a sphere so very similar to the point except with a little bit more added to it so we use this for larger occluders like this year Submarino and the difference is we want harder contact shadows as the light or as the submarine gets close to the ground so you can really see that contact happening there if you have a regular Lambert point the code will look something like this to get a end of the dot product and with this you just get the angle between the point on the surface and that's not really what we're interested in what we're interested in is getting the the solid angle between these things the coverage that the sphere has on our hemisphere in sort of a cone based coverage fashion the way we do that is if we have this normalization term that we will apply to our local position to make it a direction we just take that version and turn it into this

version actually and that accurately actually gives us what we need what we need to achieve this result assuming that we're we don't have any intersecting geometry assuming that that submarine doesn't clip through the world and when we do assume that that's not happening and finally boxes so we have a few boxes around the game that we drag around for puzzles and such and we needed a specific implementation for these guys sorry implementation for boxes quite empirical and it looks like this it's starts off with an unsigned distance function and we then get the angle around that distance to get the sides but the unsigned distance actually gives us too hard of an angle like there's a real hard cut there at the midpoint so what we instead do is get the squared distance instead which is

still unsigned but it has the first gradient just smooth right out giving a much better result and if you want to see was one of those sites looks like it's up there on the top kind of looks like an area light caster and composing all fours all six sides together gives us the result below and it just this is not this is not physically correct in any way it's empirically based by all means this kind of looks like a box occlusion you know finally shadow decals this is actually the synthesis of all these like types therein they don't have any light function really they're just a project texture that we project into the world here they're obviously not there but if we wanted to ground that it would look like this so the good thing about these is we can actually get some grounding on scenes that have no shadow casting lights and just have ambient lighting

and still get our objects you know looked not floaty they can be any any shape or form and they can be super soft without any sampling artifacts and we like to place a lot of them around and sometimes because of their non-static nest like it used in somewhat creative ways again so for putting on boxes together with a box AO or for anchoring to the feet of the boy to cast shadows off of a torch so we don't have to do point light shadows or to go off of a big platform of a big shield that fades in and out nicely when it moves up and down now like I said we do a lot of these so we also want to get away with them pretty cheaply the standard implementation for doing these would be something I could get a view ray in your vertex program and then in the fragment

program multiply that by a depth and then transform it using a matrix but that's the scan matrix in it I don't like it so luckily there's a solution to this one and it's real easy if you've done well spaced corner interpolation what you do to do that is in your vertex program you get your view ring or it's it is a world space the fragment program x definite an offset so now we're down to an FM a or a mad instruction for a world space position that's real nice but we want a decals base fissures so that would still require matrix this is all hard problem but you can probably guess where this is going so we have a view array then I wrote two things of object space which also includes scale and then we multiply that by the definite and offset and now we're answering it from a our math instruction which is pretty nice another thing thing

we would do with beacouse is screen space reflections so we have screen space reflections in the game and they're not a post effect we place them down locally just because we only need them in certain places no reason to the whole world chromey and we like them because they have quite a simple setup we don't need to we don't need to tag objects that we need to reflect we don't need to render a separate off-screen camera we don't need to bake any cube maps so for that reason we like them what you see is what's reflected that's a nice advantage and so wise that's like well we just have we just have a color and a backup color in case our array misses something we have a color that gets displayed in that case which sort of represent some fog in some cases and a texture for now power that's pretty much it for parameters but like I said what's what you see is what's reflected which means that the disadvantage is obviously what you don't see is not

reflected and in this case at the screen at the screen screen edges we fade out because we're not sure whether or not we're going to get that information on our screen so just to be sure we fade out and it looks horrible when when the puddle gets to the edge of the screen this is of course happening because we're not sure whether or not the rain might go in that direction and if it does we do need to fade to avoid repeating or clamping or whatever our screen texture might be set to luckily this is a side-scrolling game and the camera is pretty much pointing in towards the world at most times so we can just force our raise to always point of an inward and have no divergence from the x-axis which eliminates the need for fading on the x-axis altogether and the hack he works the other big problem of what you cannot see is not reflected is occluders and the worst excluder evolve is this guy as soon as you figure

out that you can make little ghosts in haystacks by jumping around in the puddle you're really going to do that if for no other reason to just piss me off and the way we once we we want to solve this just for him we don't want to solve Avery accuser but we can figure out a solution for this guy because you can control him so if we just stop him there well the way we're stopping me is that this is we first find bounding box in screen space where he is and we determined that array is behind the boy if it's within that bounding box and behind the depth buffer this is pretty safe case for raised behind boy and if array gets into this case all we do is tell the race to please go to the nearest exit of this bounding box and keep on tracing and since it's a very low detail game we actually get away with that all right so because of my

hatred for matrices in the in the pixel shader let's just talk about this again this time not with decal projection but with rate projection so in this case we want to take a view space ray and make it a screen space ray or put into frustum space the simple way to do this would be to take your your your view space Direction your view space position and put it through a matrix and subtract another position and you're there but it's got that matrix in it so we cheat a little bit and I'm the CPU will generate a so of the size of the bounding box of your screen and then in the pixel shader we can get away with something like this instead and it actually handles an edge case that the other one doesn't which is Ray's going behind the near plane we don't have issues with that in this case now

we don't like we don't like banning in our undersampled stochastic effects so obviously we add random numbers to this one as well the first step just gets multiplied by a random number and that takes care of ours there stair-stepping artifacts that you see on the left of course we don't use white noise or beta matrices we use blue noise and templates and either thing is really cool and finally there is the problem of wall thickness so we can't really tell whether or not we inside something we all just have a shell that's our depth buffer for colliding against with our rays so we need to have some sort of analogue for determining whether or not we're colliding with something we started with just a number that you would / the / decal but that's too much setup and it's it's not accurate enough

anyway the second iteration was we took the Delta that array travels instead and use that as our as our wall thickness like if if between the last step and the current we have moved behind a piece of wall that's as thick as that size we're pretty happy with it but it's got an edge case where if you hit a wall is 45 degrees three of you you'll be travelling an excellent wide space only and you have no tails and every wall is paper-thin that's no good if I unwrap that little little expression there it looks at something like this and the sinner is actually just the reflection ray itself so if we take that out of the equation and just get our by the way on the Skrull project is the thing that we generated on the CPU earlier couple slides ago divide that by the depth now we have one that's independent from the Rays direction and we are pretty sure at this point that we're going to hit something at least if it was visible it's real nice

another thing the users reflections are of course water we have a bunch of water that you can swim in and we render it out in three layers because that's how we about water we had think about it as being a layer of dirt or murk or fog that's inside the water medium it's dirty and a refraction and reflection of course and it's actually pretty nice to render them out as these you know layers of abstraction that we have as the actual render layers so we start with a fog that's our first one then we render any transparency that we've tagged as being under the water and we render these now because we want to refract those when we take a snapshot of the screen to distort it and now we reflect it and finally we add the reflection on top of this this is not a screen space reflection this is a camera based like an off-screen camera using a bleed clipping plane reflection because there's just way too much they can go

wrong in water and the case for when the camera is unto or underwater is similar but shuffled around a little bit because the order of which you see things has now been changed so the first thing we render now is reflection then fog then refraction and then the transparencies to keep them crisp now for each of these there's we actually render out three pieces of geometry and the first one is an itch that's from the near plane of the camera and six to twelve meters into the scene this is to avoid pancake water when the camera passes through it's just a tessellated mesh that's stuck right at your nose and follows you around wherever you wherever you go and creates this is just a look at the depth to this to the water next up we render the outside of a box because this water is a

box volume and by the outside of a box I mean the the front faces of a box so something like this we're not rendering on top of the displacement edge we've already rendered and the way we avoid that is just by using a single stay a little bit for rejecting any layers that come after the ones we've already rendered then we render the inside faces of that same box the back faces which looks like this and again we're not rendering on top of anything because of that stencil bit that we that we've been using so far and yeah we just kill that have something that looks like a full volume but in reality was three palaces now for some visual effects canister with smoke particles right so let's use a few effects that has try to break them down

get some emotions me like them there even though I've frozen it you might be able to see that the particles are still moving a little bit we have some sub particle motion just to try and make it non obvious where one particle starts and another where one particle ends and other stuff starts and we get some lighting coming from the floor and any gradient just to the ground a little bit if I remove all the effects it looks like this again the light from the floor which is the most obvious of the effects looks like this now I want to have each particle be lighter at the top than at the bottom I don't have any diffuse detail in any of these sprites because I want me to blend well together so if we add that gradient it's very subtle it looks like this and finally make them wobble and we want all them around with a texture it looks like this it's basically just a UV gradient in Photoshop in Photoshop with

a twirl effect applied to it and then paste that around as a stamp a few times it makes it kind of look like wind swirls essentially and then we take that texture map in world space to the particles and scroll them downwards in this case and we chose downwards for this example because well the the spoke is kind of getting shut up from above and down below so that works for this one so next up some fire turn up Thanks sorry I'm just throwing around the box showing how it looks in that dynamic setting yeah so it's using some of the

techniques from the smoke it's using UV distortion again but the most most important here is the color is actually because we don't want to have any bright blues or any bright purples we don't want to have any dark White's especially by any means we want to have a consistent luminance to the color ratio so the way we do that is by rendering fire into a fire buffer of sorts so this is just a this is just the Alpha Channel on what we're rendering into actually which is now the deferred fire buffer for this for this scene we just render each Friday in here to accumulate additively and then we apply a lookup table to it and now we'll be sure that any you know value of luminance of the fire becomes a specific color and never gets the wrong color of fire than a given point and first any

given sprite it might look like this other than UV Distortion we're also using flipbooks here because we need more more motion than we did with the smoke so for most of these sprites we have three by three different different textures we can go with we started with just select them in sequentially one through nine but that takes about a second and which means the animation will repeat once a second and that becomes real jarring to look at the second thing we tried was just pick a random one but there's a really high chance that you'll pick the same one twice in a row actually higher than 10% so that would happen once in every 10 seconds and it will look like a lag as awful what we chose to do was both so we go sequentially on the x-axis and randomly on the y-axis so we just choose just go through columns ABC and then a random row one through three at any given frame so we don't give any

lag and repetition becomes more unlikely now between these different different of course don't just snap between layers with fate between them no we fade on the vertical gradient in the direction of the fire no we don't do that either we do it noise and a gradient because we might as well insistence of looking more fiery in the end now some Lindsey flares so then stairs are just points that you put up around in the scenes for us that are not the post effect is just I want to have this flashlight be SuperDuper bright so you put a lens there and there and of course we needed to be occluded by things so it's nuts you know set over there it's you know it doesn't depth test or anything like that and for fading it out we didn't want to collide against the scenes geometry

colliders because we don't want to you know the characters not gonna bump into any of these trees so I would we set up close for them that's urban expensive so instead for each of the vertices we sampled the depth buffer in the vertex shader a bunch of times in a Poisson disk we only have four vertices so doing 30 samples per vertex is very little to get away with of course we don't sample from the corners we sample from the center instead from the pivots but just to get a little bit of a gradient going on because it's free we sample somewhere in between together like a horizontal gradient going across them as they pass behind and get this occluded and now some water effects [Applause]

[Music] all right so this this column here of foam is using the exact same techniques and shader as the assessment before is basically our particle Cooper shader just to demonstrate quickly here if I remove the motion it looked like this and if I kick back the motion and remove providing which is just making it lighter at the top and darker at the bottom it looks like this super flat [Music] so over here the most important thing to look at this is spotlight here if the boy swims into it he he gon die so we want to emphasis that as much as possible we have three main effects to remind you of this spotlight and the first one is some rain so the rain we have we've gone through three different versions one that was just generating

lots and lots of particles but you know once you get to about 10,000 raindrops it's pretty heavy and then we tried some scrolling billboards but the overdraw was also terrific so and other ended up actually using a mesh that we put in there with a vertex C shader so the wireframe of that rain looks like this and the animation is literally just for every whole number of time we reposition the particle at some place or reposition the sprites somewhere else and for the fractional part of the time we either scale it up or faded out or roll it down depending on which particle it is except they get some volume lights above here it's not using any textures but look up below and finally we have some specular light so underwater stuff is really simple just to you know reflect that off

and down below we use a similar but different effects than the ring for dust particles so same thing here we just have like that one of these little dots there that just float around and fade out and move somewhere else and fade in and then move somewhere else that paid out again down here the down here the volume light uses a animated texture to simulate caustics or simulate being messed up by the water waves and it's of course or each of these volume lights are sorted differently you know the one that's about the water is being refracted and the one that's below is not the other way you're up there and finally the specular reflection has now turned into a specular refraction which just makes it super bright from the point of you know casting now as we swarm up the boy also

generates some wave particles that we use to distort the surface the shaping of them is just resampling the resampling the refraction and the reflection again but with a different normal this time and normals we regenerate come from the shape of these particles so each particle is just a ring and we use the local the local like particle position of these rings as the normals just normalizing them and then we multiply that by a sign that goes from 0 to PI from the center to the outer rim of it which would mean that the inside of the of the wave becomes negative and the outside becomes positive and and Sur in between now a different shape of water

[Music] so this is not a square this is not great shaped piece of wire it is a cylindrical water and it's it's it's quite high poly because we want to have some very specific texture coordinates here we're not we're not just you know putting this texture down flat we actually mapping it radially around around the water like so and then we're scrolling it on the y-axis and the reason we're doing this is we don't want to fade out expanding foam textures because that would be obvious yeah we're doing this scrolling instead to have a really consistent motion and the texture looks something like this we needed something that tiles but in not such an obvious way so the inspiration we got here was from European fan couple stone would look something like this they tile perfectly well but in a more

non obvious way and they just happen to look like waves so if you kind of draw some lines and stuff of that and then put some wave some of those lines and remove the lines you can get some tiling waves that's great and finally [Music] so this is using pretty much the effect that we've talked about up until now water particles providing and screen-space perfections and stupid phone sex charges the first one and most important is the water volume itself which without any other effects looks like this it's got the same scrolling a couple stone foam texture on top of it and of course it animates this time but otherwise it's using our standard water

shading code the way we animated this using just three blend shapes one from before the crash and one half when it's crashing and then one when it's one is finishing and below that of course is the puddle the puddle looks like this you can see the foam stretching a lot in the beginning and then becoming more more easy as it goes out and also we're using screen space reflections than that and the way we gain that stretching then is very simple we you know we want to make it look like it's really pushing the foam out in the beginning and then easing out as it gets to the end and the simple way to do this was just you know add power to the to the y/y gradient of this of this UV map and then take it from the power of four or eight or something and then down to just linear when the effect is done and finally a most apparent are is this foam carpet of

particles on top which is using the same particles smoke foam shader that we've been using so far gets this from the light from behind and to blend in the decal on the ground and the wave itself we've got these impacts here and just to make the effect a little bit more powerful in the beginning we've got these just foam sprays coming out the sides in the beginning that quickly fade off [Music] so in conclusion and the rules to live your life by we really like blue noise and so should you we like Tim Pawlenty using it really gives a stable image and makes all kinds

of nice effects possible that's it and you should did all your things and you should do it with a triangular PDF if you can afford it and your lights if your if at all possible should have custom light functions and get your tech artists to do something it's really cool and we like screen space reflections and we don't like screen space ambient occlusion and thanks to all these wonderful people who helped make this tool possible and thanks to the unity team and thanks to double eleven for putting our stuffs and things from it to the Twitterverse for improving our slides and thanks to you guys for listening and we're hiring [Music] [Applause] also we're taking questions you can go up to the mics if you have some if we

can oh yeah so if you'd rather like that if you don't have questions or yeah you can just come off ask those are the questions that you don't have all right cool that's for coming [Applause] you
