Inertialization: High-Performance Animation Transitions in Gears of War

[Music] hi I'm Dave oh I'm the lead engineer for core gameplay and animation on Gears of War in this talk it's a programming talk I'm going to present a new approach to animation transitions that we developed during Gears of War I'll describe first of all to start off with the high level intuitions and the motivations behind our approach and we're gonna dive down into some mathematics and and break it down in detail and then we'll come back up from that and I'll show a bit of how we integrated the technique into our existing game engine before we get into all that though let's let's take a quick look at what Gears of War is all about

so as you can see from the video there's there's a lot going on Gears Awards a fast paced game and our characters are frequently switching between different kind of actions shooting running chainsawing enemies in half all the good stuff of course when we switch to a new action we also need to naturally transition to a new animation state and so that's kind of what this talk is about so before we start here's were four we were doing these transitions kind of the traditional way which is with with a crossfade blend so let's take a look a little bit about that so traditionally when we're transitioning from one animation state to another we run a crossfade blend between the two poses from our two states so we run our kind of Source State and we start a new target state and then we for for the duration of the transition we run a crossfade between those two states so we

keep evaluating both the source and the target during the transition and we kind of ramp from the showing mostly the source to mostly target right where where we're blending the blending the actual joint angles and translations now when we think about optimizing this kind of thing often we're focusing on optimizing the blend step and there's lots of things we can do there you know we can do math optimizations we can do memory optimizations cache optimizations all sorts of good things but four gears at least the biggest cost is not actually the crossfade transition itself but rather the fact that we're evaluating both the source and target states during the transition and for us each of those states is much more expensive than you know then the simple plane cost it so for that simple crossfade cost itself so I've got a little kind of tiny snapshot of what one of our animate and one of the pieces of one of our animation graphs looks like in reality it's actually much bigger than that and we're doing lots of things where we'll be playing multiple animations we'll be layering things on

top we'll be applying a mean offsets for the gun which involves evaluating more animations and layering them on top will do procedural head look at a bunch of other procedural things so there's a lot going on in each of those states so all of that Dwarfs the cost of the actual cross fade transition now if we're lucky we only have a few active transitions at any one time so in this kind of picture I'm showing that there's you know four characters going and three of them are just doing their regular thing and then one of them is transitioning and so the cost really during that transition for this particular frame is equivalent to five characters worth of animation right for four normal characters and this one guy is transitioning so these cost is double because he has to evaluate both the source and target states but in the worst case everybody transitions at the same time and that effectively doubles your animation cost for the frame and for Gears this worst case happens all the time and in fact it happens in a bunch of really important times so for

example in a player versus player match at the start of the match everybody's kind of doing their their various loadout type animations getting getting themselves equipped and then as soon as the match starts everybody does this mad dash to strategic locations on the map and so we have and this is all running at 60 frames a second so we have five players on each side so ten players total and they all transition at once so at that moment we have ten players that are costing as much as twenty players because we have to evaluate all of their source animations and all of their are sort of source animation states and all of their target animation states so it gets quite expensive so we asked ourselves can we do better and there's an observation we made here which is that real humans don't do these crossfade plans right this is a construct we've made up for for video games and I guess filmed too so real humans don't crossfade but but they do have inner inner sin and an easy way of kind of picturing that is imagine that you know I'm waving to you and I want to go from this waving state to just having my my arm down if I do a crossfade

planned then kind of as I'm waving and I do this transition you know the wave kind of bleeds into the going down and real people don't do that right and in fact fun exercises if you try and do this try and keep the period of the wave down while you reduce its amplitude it's really hard so so what what would really happen right is you wave and then you kind of just bring your arm down and my arm doesn't come straight down in that case it kind of shot out because my way was you know when I chose to do this transition my wave was kind of heading that way so the inertia of my hand kind of down and then and then comes down so I guess the takeaway really here is that they're having a more exciting talk than Isaac the takeaway here is that that we don't blend right we do this we do this kind of momentum preserving transition and so the idea we came up with is hey let's just get rid of these transitions right they're expensive and then I've just kind of made this case that they don't quite match reality and so we'll do that great that solves our that solves our performance thing right now instead of during the transition we

value we're evaluating two things now we're just a value in one thing everything's great except of course we still have all these discontinuities so at the moment where we transition from the source to the target we're gonna have this big pose mismatch and that's obviously not acceptable but the idea then is can we fix these discontinuities as some kind of magical post process so that's that's what we're talking about it's transitions as a post process so let's make this a little bit more specific so on this in this picture and I'm gonna take a moment to kind of explain my notation here because we'll sort of work with this picture for a little bit but I'm showing the the blue pose which is kind of the pose you're coming from transitioning to this gold pose the blue pose there I've shown this is blue line and it ends at the dot when we start the transition and then the gold pose is starting it it's a dot and kind of continuing on and you can see there's a gap between the dots right so that's representing just this pose difference that we're trying to get rid of and if we just if we look at the guy on the right and we kind of look at it as an actual animation right if we have no transition and you just get a pop right and that's obviously not acceptable in

our game so this is a kind of a weapon mirror transition in our game these play actually much faster as all of these videos are showing it quarter speed negating right you can see this discontinuity and that's what we want that's what we want to solve so what we want to do is we want to find something that's going to fit from the old pose to the new pose and and be kind of smooth and continuous and pleasing and give us a result that looks kind of like the ghost image here right so we're going from the this discontinuous input and then the output is this nice smooth ghost image and we identified three primary goals while we were starting to think about how we could we could try to solve this things these are these are kind of important rules that we didn't want to we didn't want to break so the first one is to respect the original animation and what I mean by that is that during the transition obviously we need to change things up we know we're gonna you know do something to make the input be continuous but when we're not transitioning we need to leave the animation exactly as the animators offered it and that both to kind of respect their artistry but also for a

game like Gears there's important gameplay implications right the the muzzle of the gun needs to be in the right place when I'm firing otherwise if it's in the wrong place while I'm while I'm moving around then the bullets come out it might hit some some obstacle that I don't want it to hit obviously we want the result to be believable and pleasing and in some kind of way and and really we took that to mean that it should be kind of smooth and momentum preserving and this last one I call stay on model but what I really mean here is kind of don't get out of the space of poses that are your inputs so an important example here in kind of the one we focus on is to eliminate overshoot right so if I if I have a pose and another pose and I want to go between them I want the result of sort of in some intuitive sense to stay between those pose poses and not go beyond kind of that that range that they're defining because that could lead to you know unnatural hyperextension of arms or crashing through the body and other undesirable effects so our first idea

and I call this idea number zero both because we didn't actually implement it but also because I'm a programmer I come from starting from zero so this first idea is that we apply a filter to the output stream so you know you can imagine something like if you have a power drag doll in your game your power drag doll could be kind of driving towards all these poses during the moment of transition the poses will be discontinuous but because the power drag doll has limits to you know has a certain amount of inertia to it and has limits on the drive strength then the result of the power drag doll will still be kind of smooth but the problem is that introduces lag it's difficult to tune and that lag in particular is really important because then during a high speed movement for example that isn't during a transition so it's just animated that way the ragdoll might be lagging there and my deviate and then that kind of breaks the whole expect the animation principal that we had right so your gun might not be in the right place and it might not be matching what the artist intended so the first real idea we tried was this pretty

simple idea it's basically to blend from the organize be careful with they use a blend here but to fade out from the the pose difference between the source and the targets we want to take the difference between those two poses and ease that out over time going back to our picture that gives us a graph kind of like this and you can see that the poses are continuous now is the the blue line and the gold line are connected but you can see that there's a there's a sort of a kink in sort of near the where we start the transition where it's not continuous and stalled right there's this velocity discontinuity and if we look at the result of that in the actual character animation you can see the poses are themselves continuous so there's no frame where you see a jump but obviously you see this kind of unnatural slowing down and then speeding back up of the animation so that's no good so the second idea is kind of this natural extension of the first one which is to say all right well the problem with the first one is that we didn't have this velocity continuity so what if we remember as well as remembering the actual pose difference we remember the

velocity from the from the original pose and we can calculate that by just doing finite differences right we remember the previous previous pose and the previous pose into the difference between those two by the time that gives us our velocity and so then this curve we're gonna fit is gonna match that not only the difference but match this initial velocity so when we tried this we chose to use a fifth order polynomial as this curve we're gonna interpolate and that we kind of drew that from some biomedical literature where they basically observe that when people were moving they tended to move this way and that gets us something that smooth and it ends up where we want it to end up so that's great but as you can see it dips below that zero line there right and that's that's overshoot and when we look at the actual animated result we see that the gun dips way down for coming back up so again better than what we had but it has this overshoot and and we don't want to do that so then we took that idea a bit further and we said okay well can we do something to limit that

overshoot and the interesting thing about the fact that earlier we use this fifth order polynomial was that we have an extra degree of freedom to play with we've we've got this acceleration term now that we can we can pick to whatever to be whatever we want and then the previous idea we simply set the acceleration to be the initial acceleration to be zero and that's kind of gives us something like a smoother step right but we can make a different choice for that and what we experimented with was this idea of setting the initial acceleration so a zero there to kind of resist overshoot and basically by setting it to give a zero jerk at the end and jerk is the derivative of acceleration so that's the rate of change of acceleration so when we tried that we got a pretty good result and when we look at that in motion we get that so that that worked out pretty well and we made up a name for that so that's we call it inertial ization because it

preserves inertia of the incoming motion and because I like to make him new words for things my phone now when it auto corrects it it knows that word because I use it enough so let's look a bit more into the details of initialization and sort of start to build up this this curve kind of in a more formal mathematical sense so we want to construct this fifth-order curve that's going to kind of go between the blue dot and the yellow dot there we know that at the end of our curve because we're because we're adding this curve onto the target pose what we're doing to the curve itself is we're basically driving it to zero right so we want the final conditions of the curve to be that the actual curve itself is at zero its velocity zero and also it's acceleration to zero so that it's kind of this smooth settle at the beginning we know we want to capture our pose difference so kind of worried about my notation here but basically blue guy right is our old pose and our kind of showing in this blue guy minus one meaning he's the the first

previous vote pose and then sort of gold guys our initial target pose so we captured that pose difference as I said we also want to capture the velocity difference so we do that by taking the difference between the two poses and and through all of this I'm kind of in terms of sort of a single a single scalar value right a single floating-point value a bit later in the talk I'll get into how do we generalize this to vectors and quaternions because I've seen we want to use the song on character Jones so we complete compute our velocity there is with finite differences if I should mention too that for for here I'm always showing kind of x0 as being positive just to keep the explanation simple obviously if it was negative you could just flip everything over so you can make it all the inputs and make it all the outputs and you get the same result so to keep the explanation simple I'm gonna say from from here on out that x0 is we assumed to be positive for the

velocity so if the velocity coming in is negative great that's that's basically what I've shown here right it's heading towards zero if the velocity is positive it's heading away from the pose that we're trying to get to and that would cause over shooter actually would cause under shoot so we don't want that and so in that situation we just clamp the velocity to be zero now that obviously gives us a bit of a velocity discontinuity in that case but we prefer that over overshoot because we don't want to end up sort of crashing through the model or breaking joints or anything like that so if the velocities positive we said it's zero if it's negative we just use the expression that I've shown there we then compute our initial acceleration and this is basically the equation to give you your initial acceleration such that as I mentioned the jerk is zero at D at the end of the at the end there so this acceleration right is to is to resist the situation where the velocity is kind of heading down to aggressively too quickly towards the zero line so intuitively right that

means we want our acceleration to be positive right because it's fighting this incoming negative velocity if the acceleration ends up being negative then sort of the way to think about that is that the mass has worked out that we're kind of helping or velocity and we don't really need to do that right the whole idea is to kind of resist the motion so in that situation we just set the acceleration to be zero all right so velocity always negative acceleration always positive so once we have all these things now we basically have our initial conditions and are in our ending conditions and we're gonna kind of fit this to a to this fifth order polynomial spoke that into your favorite math package and you end up with this and so really the key thing here right is that the at the bottom right we see this kind of equation for XT right so that's gonna tell us what is the value of x over time and we're gonna add that on to our target pose as we're going and that'll kind of get us our continuity so so far

so good but I'm gonna come back to overshoot for a moment so for all the examples that I've used so far they're actually taken from real data from our game so the the animation that I that are showing there is sort of this mirror transition from a from a right handed weapon grip to a left handed weapon grip transitioning to our kinda our Idol stats and for the particular joint that I'm showing the the actual values are kind of this one point two and a velocity of negative twelve point six means playing point five and that gives the curve that I'm showing so those are all kind of real values but what happens if we push things further right what happens if we say let's let's make this velocity U ridiculous right let's play the the initial animation even faster and see what happens does it still hold up and unfortunately the answer is no so we get back to having overshoot now in practice this almost never happens for us so you know we could have stopped here and I think I think we would have been fine but we really wanted to enforce this guarantee of no overshoot just so that we knew we were always safe and then if we wanted to tune some

animations to play hyper-fast that we'd be okay not just hyper fast too if we have a really long blend time than to hit kind of that zero mark it's it's going to open it's going to go further right it's got kind of more time to kill so it's got to do something in between and so it's gonna dip below and and that idea actually thereof that it relates to time is important because that's actually how we fixed it is we say if if we're gonna get in one of these situations where it's still gonna overshoot even after all the other work we've done we're gonna take the time and we're just going to kind of nudge it to the point where that doesn't happen and so then that solves all of our cases and you can even kind of picture you know this limit case where if the if the incoming velocity is you know negative infinity well it's coming straight down but if you set your time to zero you know you sure you're gonna slam into your target but but you won't overshoot and so that's really important so how did I come up with that point three in this in this slide so I won't actually get too much into the mathil

just give you the answer which is basically that so we take the kind of the the original requested time and we're gonna take the lower of that or this negative 5 X 0 / v-0 just to give you bit of a quick hand wavy explanation so you sort of believe me I mean other than it does work but is really I'm setting the I'm setting all of the roots to kind of happen at that time so I'm figuring out what is the time where where they all come across 0 and then basically using that and then I kind of feed that back in so you actually do that step first and then you go back and you compute all of your like your initial acceleration so here's where you want to pull all your cameras take a picture this this is basically all of the math on one slide and really the the order of steps here is you're going to take your your X 0 in your v-0 you can even use that to figure out your adjusted time t1 plug that in to get your your a 0 obviously remembering all of the or zero parts right we want our

v-0 to be negative R a0 to be positive and then you're gonna evaluate it with the stuff on the right hand side so that's really the construction for a single floating-point value or single kind of scalar value now let's talk about vectors and quaternions right so we represent all of our joints with their translation as a vector and their rotation as quaternions we don't we don't currently actually initialize scale but if you if you were you could just kind of do it as a vector as well so the start was talking about vectors so the obvious choice with vectors right it's pretty easy you say okay I'm gonna I'm gonna take my x y&z and I'll just initialize each of them independently and there we go I'm done that turns out to actually not be very good and not give very good results and the reason for that is because we're we're potentially going to be messing with time and so if one of the axes is is kind of approaching very quickly in the other ones art then we're going to adjust time for one of these but not for the other and so you're going to get this case where one axis now completes before the other one and you kind of get this

unnatural motion and in different intuition about it too is that we don't really want to kind of have any preference for any particular set of axes right we that the choice of coordinate frame ideally shouldn't matter so the fact that it would show up in kind of this first formulation is not something we want so instead what we do is we we observe that what we're really trying to do right is eliminate this difference between poses and you can think of the difference in two parts there's there's a direction part to it and a magnitude part the direction is constant the magnitude is the part that we want to eliminate right once we once we get the magnitude to zero then and we're good so that's really what our approaches is we decompose our vector into the direction and magnitude and then we just initialize the magnitude away so let's let's dive into that in a bit more detail so we start off and again I'm kind of continue with my pictorial notation here we start off by taking the the x0 is kind of this initial pose difference so we capture that from our target pose versus the previous pose we

know we're going to want to compute our velocity so we're going to need kind of this this previous this X minus one so we're going to compute that that way where we look at the previous previous pose versus our target pose and then we're going to do is decomposition where we're going to take the that vector quantity and we're going to decompose it into its Direction sort of unit direction and and its magnitude so here I'm showing kind of x0 without the arrow is the magnitude right where I'm just just taking them back to the vector now an obvious choice for how to do that for X minus one would be to kind of repeat that same operation right just decompose X minus one into its its direction and magnitude but that's actually not quite right in a bit of a subtle way because what's important for X minus one and for our kind of our velocity calculation isn't the the velocity in kind of an absolute sense but it's the velocity along the same direction that I'm amortize away right that's that's the difference that I want to get so really what I want to do is a projection so I'm

going to take the X minus one vector and I'm going to project it onto this kind of unit vector in that same direction get the magnitude along the lines of that direction right so that means that if if X minus one we're not its realigned up sort of the difference of X minus one we're not lined up with a difference of X minus zero then I only care about the part that's in the same line because that's what I'm gonna be adding back to my pose we then compute the velocity from finite differences right which is pretty simple it's just take the difference between the two the two values and now we're dealing with scalars so this is really easy and of course divided by R Delta time and then every frame we're gonna add that back on to our target pose so we're gonna basically say that the vector result of this calculation is the the scalar XT projected back onto this direction vector that we that we remembered from the beginning and we do for us we do all of this in local space but really just like with a traditional blend you can

sort of choose your spaces to give you different kind of effects that you might want when we look at quaternions it's a pretty similar construction rather than decomposing on to kind of a direction and a magnitude we're going to decompose a quaternion onto the axis of rotation and its angle and then we can just initialize the angle that's a gain of scalar quantity right similar construction to before except now we're using quaternion math we're gonna take our quaternion and we're gonna extract its its axis and we're gonna kind of remember that as our that's sort of arrow x0 and we're gonna then take extract the angle and remember that as our actual initial x0 that we're gonna apply the initialisation math to and just like with vectors where i was saying we needed to project to be onto the same direction we want to do the same thing for quaternions too so in this case what we want is we want to find the angle around that same rotation

axis so the math behind that's tricky fortunately smarter people than me have figured it out this particular one comes from a paper from kimchi made from way back 94 if you're interested more kind of how to do these this is called swing twists of decomposition so you can just Google or Bing I guess for Swing twist decomposition and then now we're back in sort of working with scalars so we can compute our velocity from finite differences as before and then when we apply this back to our place back to our output pose we're going to take that kind of initialize scalar value and we're going to take the axis that we remembered construct a quaternion from certain axis and angle construction and then layer that on to the the sort of the original posts of the original unfiltered pose catch my breath after a bunch of math and then we can move on to

a comparison of blending versus inertial ization in some of the properties so when we look at this is kind of a recap of a bit of how I started the talk but when we compare blending a traditional kind of cross great blending versus initialization right with crossfade blending we're evaluating both the source and target during the transition and you know as I mentioned kind of making the case for this that's expensive right we have it gives us this variable frame cost and because we have working with these fixed budgets we need to kind of accommodate for that so we end up in the cases where we're not transitioning having all of this kind of wasted room because we had to accommodate the case where we are transitioning and that's really because the source and target are both expensive with initialization we're only evaluating the target during the transition as well as of course the the actual initialization math but that's pretty cheap so the cost of any given frame is is fixed it doesn't matter if we're transitioning or not and that's this huge advantage because now we can kind of use up our full buffer

without really you know our full budget I should say without really needing to to give us much Headroom to allow for transitions because during transitions that cost the same as when we're not transitioning there's some other advantages too when with a traditional blend during the actual arts or a traditional Crossley blend during the actual crossfade we are evaluating both of these states at once if those are parametric States so you know say we're driving a gun angle or ahead look at target we have to be driving that still for both the source and the target and sometimes that can get really tricky especially if the thing that we were using to drive the source is no longer meaningful so for example let's say I'm doing my head look at and the thing that I was looking at with my head ceases to exist or I no longer wish to look at it well I can't just stop driving that if if I'm if I'm feeding the source you know something has to go into therefore this if it's this parametric animation so you know I have to make me do tricks too to remember where it was and kind of

always have these last values and keep you know kind of plugging that in so it's a lot of complexity and bookkeeping within Ursula's ation I just don't worry about it I'd say okay well the thing you're looking at it's not there anymore so I'm gonna take you out of the looking at things State and I'm gonna transition you to this new state and and I don't worry about it because you're not you're not evaluating the source anymore and of course there's this qualitative difference and this was kind of what I was miming a little bit earlier in the talk and and that's not just me miming it actually ends up being true so you can see there that on the blend you see the wave kind of bleeding through during the transition and so you can kind of get some unnatural artifacts and any kind of periodic motion to something less periodic or with a different period you get some of these kind of artifacts with a conventional transition often what you do is you try to tune your transition time to be less than a period and then and then it doesn't matter as much but that means you got to do all of this kind of fiddly work whereas with an Ursula's ation it just kind of works so

let's talk a little bit about how we actually implemented this and gears gears Awards based on the Unreal Engine 4 sort of a customized version we we really broke down the work in kind of two three parts and the nice thing about this is each of these three is actually pretty easy so there's this this concept of an inertial ization node right this is going to be the thing or some kind of filter right there's gonna be the thing that's running near the end of your frame and a saying and basically doing the inertial ization math that I presented right it's getting this discontinuous input stream and it's going to apply the math to it and give you a continuous stream on the output we need to be able to actually tell that node when to when to trigger and initialization so we need some kind of hooks into the animation system so that when the animation actually wants to transition to a new state it can kind of notify and say hey you know please PLEASE inertia lies me now and then there's some code hooks we can do to that make life a little bit easier as well and I'll get to that in a moment so the inertial ization node itself in

our case I said we're using unreal so it's kind of this animgraph sort of data flow graph for poses so we basically add this node pretty late in our graph and we evaluated then and the input is this discontinuous poulos stream and then the output right is the inertial eyes post stream and if we dive into that a little bit deeper what we're doing right is when a new inertial ization is requested we remember the pose difference for across all of our joints in in both vectors and quaternions we remember the initial velocities as well we remember the requested initialization durations that's kind of the t1 and then we we start our timer at t0 and then every frame we're just going to update T with our delta time we're gonna evaluate that initialization curve right that X of T curve and we're gonna add that on to our joints and then this parts important we're gonna then remember the output pose and in a pose history buffer so that if someone were to request an

initialization again we're going to use that history of poses to do the actual x0 and v-0 calculations right so in my in my earlier slides that was the the blue poses is that kind of I remembered pose history and it's important that we captured the output pose and not the input pose because that way when we request another initialisation if one was already in progress we can kind of completely discard all of our knowledge about the the previous and memorization because it's already factored into that output pose so again we're just kind of saying okay we had this output pose don't know how we got there but we're getting to something different and there's a discontinuity I need to fix it no problem I just take that difference and carry on so output pose part is important as for the actual hooks for requesting an initialization or triggering an inertial ization with unreal it's pretty simple unreal has this notion for its regular blends and all of the notes are doing kind of blending in there animation system they tend to

expose this blend curve type so you know whether you're doing a the ease-in ease-out or you know some some linear blend or whatever we just made up a new blend curve type which we call an inertial ization and then when a blend is requested with this curve type we actually sort of request the actual initialization to the node that's kind of later in the system so we kind of pipe that message through and then we zero the blend time so not not the blend time that we're passing to the initialization but the blend time that would kind of carry through through this irregular node right so if it's an unreal blend node it's got this blend time but we sort of right then and there inject to zero and it says okay great I'm done my gland I don't need to do any work I'll just pass through the target pose unchanged so kind of we trick it and then I mentioned that there were some code hooks and we found it useful to expose this ability to request inertia lies ation to our actual code we don't use it in too many places but it's nice 'fl so it's nice to eliminate other types of discontinuities and that's kind

of my segue into a little sort of section on tips and tricks and I got a picture of duct tape up there because I kind of like to think of this as you know our animation duct tape every once in a while something's kind of not quite right now wait a minute I have got some duct tape I can just go kind of wrap it around and it's all fixed never been better so I'll give a few examples of that so this first example so in in Gears of War one of the things you can do is called a roadie run it's basically the sprint and it and when you sprint you always face your direction of movement and so if you are if you are sidestepping and then you hit the hit the roadie run button you trigger this sprint and what your character does is he kind of instantly pops to face your direction of movement so that the direction of movement is right and then he kind of does a sprinting thing after that so in Gears three that was basically the end of the story that the character would would have this sort of facing pop it wasn't too noticeable the camera tends to move around the same time but but it was there for years for we wanted to we wanted to eliminate that but we didn't want to affect any of the gameplay you

know so we want to keep basically everything else the same and so what we actually do is we still snap the character's rotation of the start of the sprint what we request this inertial ization and so what that does is even the characters doing something discontinuous the the pose itself is continuous so if you look at the images on the bottom there the kind of the first three images are of me just sort of side strafing normally and then the remainder are meaning this in a sprinting state that's unfortunate bit hard to see on this projector but there's a kind of a green circle underneath and the green circle shows the character's actual orientation and you can see for those first three frames you can't really see the arrow because it's pointing up and it's underneath the character but all those subsequent frames the arrows pointing to the right so that's actually the characters kind of moving capsule instantly rotating but you can see that the pose that you get is still continuous because we instantly rotate the capsule but then we request this inertial ization and says okay yeah there's a discontinuity here sure it's it's just a discontinuity in the route

the rest of the pose watch I mean I guess we're also changing poses but for these purposes kind of it's this discontinuity in the root and then initialisation just takes care of that so it was kind of this one line change once we have the system in place and the instant ducktape it makes things better another example that I find interesting is how we deal with our locomotion inputs so when you're driving your character around you're we don't actually directly feed your joystick or even your velocity inputs into the into kind of the blend space of motion because our game is really responsive so that velocity can actually be pretty twitchy so what we do is we just filter it a little bit and then that kind of gives you some nice nice sort of posing the output but of course because we're filtering that if you if you do a sudden change in direction then the filtered value can actually get a little bit further from a little bit too far from from where you want to be and you don't want to kind of stay in this you know sidestepping when you want to be going forward or something like that right it doesn't it doesn't affect the actual

movement of your character but it affects the posing and to give you a lot of foot slide so what we do in that situation is we just snap it to the to the new value when we detect that it's too far out of line and we initialize which takes care of the pose difference so that gives us kind of this fluid pose even with twitchy inputs and then lastly and there was a call-out to last year my colleague Steve Dickinson gave a talk at GDC about motion warping I won't get into his talk but one of the key things about that is that you had to remember these warping kind of landmarks that you're placing in the world so it's quite a bit of bookkeeping if we transition from one warped animation to another warped animation and we were doing this with a crossfade bland we have to keep track of both of those pieces of bookkeeping and that's a lot of bookkeeping so there's really nice way if you don't even support that in our engine because there's kind of no need we only have this once for each character we only have one set of work points these kind of these landmarks but it works because we only ever have one active work at a time if we're transitioning we just do the do the

initialization and so we don't we're not remembering the old day old state and that's kind of it there's a lot of other examples I won't I won't go into all those so I want to thank you very much for listening and I want to thank the people at the Coalition back home for working hard on all this stuff if you'd like to join the people of the Coalition back home we do have some positions open and give us a show thanks very much and there's nobody in the room after us so we have a couple minutes for questions before we get kicked out if you'd like and otherwise I'd be happy to chat with people outside as well yeah hello hi there interesting talk thank you um question about I might have glossed over this answer because there was a lot of stuff happening and you know I kind of lost track but you'll be able to clarify I'm sure a lot of this stuff seems to for me we have young and

equivalent of this and our engine which is essentially a a stop B stop transition and using whatever type of transition you decide to use between them there's a bunch of different algorithms right so one sounds like a pretty powerful one and I'm seeing a lot on what has been shown in terms of how to deal with stopping you're a clip and going to the be clipped your B clip seems to assume that you have no velocity do you guys store velocity to use for each one of your clip beforehand or I know this so that's a good question we don't actually factor in or we don't consider the velocity of sort of the B clip mainly because we don't want to have to kind of evaluate we don't have to kind of store all the velocities ahead of time and we don't want to have to evaluate two frames of the B clip to kind of know what the velocity would be it turns out in practice that doesn't actually matter and in the sort of visually and the reason for that is if the velocity of the B clip is very low

so the B clip is kind of fairly freely idle then then obviously it doesn't matter because it's close to zero anyways if the velocity is very high then it's a it's an animation with a lot of motion to it and so for gears especially you know that's typically the start of some kind of like pretty powerful action and we actually want to kind of give instant feedback of like hey you're starting to do something we wouldn't want to muddy that out too much so in those very dramatic changes people seem less sensitive to kind of problems around velocity because there's so much energy being expended anyways right so big I think what people visually pick up on is kind of these unnatural expenditures of energy but if you're already expending energy because it's this kind of high end you move then the fact that the that is not quite sort of perfect from an energy point of view you don't really notice okay so essentially you guys didn't feel like that was a problem yeah should be attacked because there was no right and one one thing that's kind of sort of a useful tip along with that is that we

tend to end our Eclipse I guess sort of the source states while they're in motion and I mean I think that's actually kind of good advice for regular crossfade transitions too but it means that then you get a case where sort of like in my gun example you know where the guns heading towards this target and then we stop and and it kind of just continues that momentum or is if we if we'd had that animation play all the way out to a settle and then it had to transition to another pose that's not quite matched then you get this kind of like I came to a stop and then I'm starting and stopping again and that looks a bit funny so it's always you know basically for us that just needs cut it early and that's great because it gives you control back soon or two right so just good practice thanks for the answer yeah thank you this is sort of related but uh when you calculate the X zero I'm assuming that's based on sort of your target blend time like that the initial T one and then you're recalculating T one later potentially which oh yeah I see so so X zero is just the difference between the poses right so so it doesn't

actually factor into time but what if you don't have a locked pose what if you're like it's a moving target so if you oh yeah so so we're calculating it at the moment of sort of the in the instantaneous frame of the transition oh I see and then and then from then on we're advertising that way but on top of the moving target so the movement of the target kind of shows up right away or contributes right away gotcha okay thank that most of your examples looked like they were for kind of game play action upper body sort of motion have you tried using this sort of thing for locomotion transitions or things like transitioning into a cinematic yeah we use it everywhere actually so it works really well I want to move with the feet yeah birth phase into it or yeah so we have a separate system that that kind of automatically matches phase for us it's it's not as fancy as some of the kind of emotion matching sure Athens but it does a really good job and and it's really cheap and fast

so we use that that kind of gets us in you know it's kind of true of any kind of transition the sure the closer you are to your you know between your poses the better result you're going to get so by doing the phase match we are always transitioning into into kind of match like phases and then right and then you apply this some time yeah and you can actually like when I mentioned about the animation node kind of being being at the end it doesn't have to be right at the very end so right for example run rik saw afterwards which sure we are in this in our k space yeah I was gonna ask about that as well do you one of the major issues with transitions in general right it's just the the linearity of all the joints moving at the same time and things like that I've do you feel like this starts to address that because each joint effectively has its own inertia and and and blends effectively different differently right offsets the the the blend for each joint you feel yeah yeah exactly yeah we are both sort of me personally but also our animators seem really happy with the quality they get out of it so that's that's always kind of the real test yeah yeah of course thank you thanks okay I think we got a we got a

wrap up but I'm happy to chat with you outside if you want thank you you
