Game Server Performance on Tom Clancy's The Division 2

[Music] hello everyone my name is david and i'm going to talk to you about game server performance on the division 2. a little bit of info about me i worked at massive for about 12 years now on a bunch of different games that you can see here from world in conflict to the division 2 most recently i've had a couple of different roles but mainly in game play and ai but the last couple years have really been focusing on server performance both the workflows that we employ on the team and the optimization parts themselves so the contents of today's presentation will be focused around how we maintain a large player base on our servers and i'll be going through this in three main parts one is the code architecture that's required to to maintain this and the second part will be about the tools and processes that we have to to be able to debug performance

problems and monitor performance over time and the third part will be some examples of problems that we ran into and the solutions that we found and then we'll round off with some conclusions and takeaways as well so let's start with a video to show you a little bit of the game and what it's basically see what you about find out [Music] so there you go the division 2 is a third-person shooter as you can see it has a typical client

server architecture and it has an authoritative server so we use the server to validate all kinds of player actions like shooting and movement using animations physics and amish the the servers are fairly large scale it's about 1000 players per server and on that kind of server we have around 20 000 npcs at any given time it runs at 20 fps except in some dedicated pvp modes where we run at 30 fps so we took a decision early on to maximize the number of players that we have on any given server and this helps us in a couple of ways one of them is that we wanted this kind of seamless transitions between your own personal part of the world into the more social spaces like the dark zone and the hubs where you can meet other players and having a lot of players in that case also helps us populate those areas in a good way so that whenever you go into a dark zone for example it's usually filled up with people or it should be most of the time

and lastly it also helps us on the hardware side because we don't really have to do any streaming from disk once we've started up the server so what does the game server really do if we're focusing specifically on the server well the server updates worlds and the worlds have a bunch of stuff in them like the all the ai and all the players and all the different kinds of systems like like the mission script system and the skill script systems which are used to implement things like player skills and so on so each world is updated once per frame and runs through the updates of all those systems and each single update is also single threaded so each world updates a single threaded and it doesn't have any cross references to other worlds during the updates and since we have at least one world per player this makes this means we have a thousand worlds or more at any given time so this makes it a really good candidate for sort of parallelizing process process

so let's take a look at the frame structure the way we structured the frame is that in the beginning of the frame we have these small non-parallelized segments and after that we have tried to parallelize world updates as much as we can basically and then at the end of the frame we have a small non-parallelized segment again so we have two types of tasks mainly what they were called short tasks and long tasks and the short tasks are what we use to update the worlds they run on high priority threats the long tasks are used to update more background kind of data like caching save game data to disk and instancing nav meshes and so on and also deleting worlds if a player leaves the server and creating new worlds when a player joins the server looking at this you can see here that in the middle we have short tasks doing all these world updates and we really want to parallelize this as much as possible to get the most performance out of the out of the system

so how do we distribute this work on a typical machine on a 40 core server we would use perhaps one or two cores reserved for the operating system and the remaining 38 cores would be available to all threads so we don't use any thread affinities to set any limitations here we just let the scheduler do the work for us and on such a forticore machine we would spawn 36 short task threads which take care of this world updates that i mentioned before and this leaves us with about two cores worth of cpu to run long tasks as well so that should give you a rough idea of how we do the cpu work basically so let's take a look at the actual tools and the pipeline we use for this so on a high level we want programmers to always have all kinds of performance data available to them for debugging server performance

issues the data generation however in collection can vary a little bit with context so for example if it's the live environment or if it's just if it's the production environment and this is something we're looking into fixing further so beyond turnquist is also going to do a talk here at gdc about unifying this we always have the same kind of environment both in development and and when we go live so this can be further improved but at least for for division 2 we made sure that all the data is always available for for debugging server performance issues so let's start with a tool we call grafana this is basically a graph viewer on top of a database and what we do on the game server is that we send data every frame from the game server to this database and due to its high level nature this becomes the point of entry for most investigations into performance issues we keep tracking this for all servers at

all times as well so this base this data is basically always available for programs to look at the second tool we're going to talk a bit about is the snowdrop profiler this nodal profiler basically has two parts and it has the runtime component which constantly records profiler events and performance data and it has a ui part so which you can see here in the picture and the ui part can be used either directly live as we are debugging a a running executable or debugging the process for performance or it can be used as a offline tool where you load up all the performance data that you've saved to disk in some previous run we use it for both cases but it's quite nice to have that sort of live debug ability if you want to tweak some values for example while you're running you can tweak tweak a little bit and look immediately and see if this had an effect on performance you don't have to restart or save something to disk and then load it up in an external viewer for example

and what you see here in the profiler ui is basically a single game frame in our internal profiler these colors represent the different game systems so you have the green for pathfinding for example and you have the blue for ai updates in general and you have the the pink heroes agent updates and just to break this down in terms of what we talked about before with the frame structure this this pink part here in the beginning the begin frame you can see that it's very small and needs to be very small so so that we because we can't run anything else in parallel with that at least not world updates and then you can see i've marked the hair as well the different worlds and how they are sort of updated one by one on each on each short task so how do we how do we use this in a day to day well every day we have automated blood tests running on the latest bills and the bots are very lightweight ai agents and they try to replicate behaviors that the players have as closely as possible

not necessarily from a functionality standpoint but at least from a performance standpoint so we really want to make sure that they are similar to to players in terms of the server load that they that they have and this is something we verify during production by having qc tests directed qc tests for example that that would we would test with 100 bots and then 100 qc players and make sure that the server load was roughly the same the bots themselves are part of the game solution and this really helps us implement additional functionality into the bots it's a small side note but having that make sure we can use server code and client code and data directly in the server button it's very quick to iterate over features using the bots the main point here is that we use the bots to fully load test our target hardware every day so we run a thousand of these spots on the actual hardware that we're shipping the server on every day each test

generates a report and we get links to grafana that i mentioned before there's also a link to some binary profiler data that was output during the test if there's any if there was any issues and we get links to crash reports and so on as well so some source code coming up it's been heavily modified just to make it readable and and understandable here so uh so but i hope it's the concept comes across anyway so the profiler data export that i mentioned the sort of binary profile data that's available we output that from the server from a couple of different cases one of them the most simple one is that when the frame time exceeds the target frame time in our case 50 milliseconds on a regular server the other one is that an individual system has actually gone over its own budget so each one that each system has its own cpu budget like ai system for example

and the the dark zone and and so on and if either of those go over their own budget we also save profiler data to disk the third one is when an individual scope actually takes longer than anticipated in this case we create first of all a regular profiler event but then we also create this timer object that you can see here which tracks if the scope actually took too long and doesn't save a profile or save it in that case the data export itself is nearly log free and it runs on a low priority thread in the background so it has almost no effect on frame rate whatsoever and can basically be running constantly during normal operation of the server it allocates memory on the first use which is not super relevant for the server but since this is available for the xbox and the ps4 as well for example we need to make sure that we don't use this memory if we don't allocate this memory we're not going to use it

and you can see here as well that in this task which is actually the code that is running on the low priority thread we recall into the runtime of the profiler to to save its state and the way we do that without interrupting the execution of the process or the threads is that the profiler at any given time has a number of used blocks that contain profiler data that has been recorded and it has the number of free blocks as well available for use and when a specific thread so this is organized per thread so each row here is per thread performance data basically profiler data when a thread needs uh fills up the current block it's going to the profiler grabs a free block and puts it in the front and starts filling up this block again and then once per frame at the end of the frame we do a sort of a cleanup where we go through all of the oldest memory blocks here in use by the profiler and move them to the free blocks pool and what happens when we do a save

is that we're going to lock this per thread data one by one and copy it basically and if that thread is currently recording events which is usually the case then we simply take a new block from the three blocks and put it in the front and continue to record data this way execution can continue on the thread without even though we're currently saving down the state as well there is one edge case here where we actually could run out the three blocks and in that case the current thread that is trying to record something actually has to grab the oldest memory block for that thread and move it to the front and if that happens during a save then we actually end up locking execution of that thread and that is something we really want to avoid so we need to make sure we keep the number three blocks available needs to be big enough to never run into that example okay so we store we save

the internal state of the profiler and we store it to disk we store it to disk based on the source trigger that that did the save in the code this makes it easy to find for the programmers looking for something in for example the dark zone in this example debugging performance issues in the dark zone the data will also always be there because we don't allow sort of these different game systems to overwrite each other's data they don't share a single disk budget for example they have individual disk budgets using grafana from code as a programmer is also very simple here you can see for example we have two couple of simple one-liners to report load factor and update rates and this is something we really encourage people to do as well for programmers who write a system if they can think of any any type of value in that system that they would like to track over time to be able to compare it with performance for example they should they are encouraged to do so and this

helps with an early stage of most investigations to narrow down what the problem could be here's an example for of that where we see for example we have all the different the numbers of ai in each each particular lot level for example and the number of raycasts we've done and the number of state sinkers for interactions which have this sort of runtime data runtime state of interactions in the world just briefly uh going into how it works on the live environment is very similar we still have grafana and we constantly monitor all of our live game servers and if we see an issue like the spike here in this case instead of going to windows explorer we just go to google bucket and it's structured in the same way so you'll find your dark zone data there for example if that was the problem you were having and then you simply download and open the profiler data and start debugging so that's it for the tools and process side of things

now i'm going to go into a couple of examples of things of issues we had during development and the solutions we found the first one was that at some point we were seeing that some short task threads were not running for the entire frame basically so this means that several cores are not really updating worlds for that entire frame and this is with the sort of performance model we have that means that we've lost cpu uh work that was supposed to go into updating worlds right so the first question is do they not have work is there anything to do but looking at what we do we we spawn a number of tasks equal to the number of threads and then what each of those does is to grab a world from a global list update that world and then grab the next one so there's and that global list like these different tasks that will do that until that global list is done and we've updated all the worlds so there's

definitely work to do you can also see here in the above section of the code that we list we sort the world models based on their estimated costs the estimated update costs and the reason we do that is to avoid frame time spikes so looking at this example here which you saw before as well we actually have one world that is taking very long time to update at the end of the frame and this delays the entire frame execution or the entire end of the frame and it also creates this pocket of low cpu utilization here at the end which is also really bad so this the solution here is to make sure that the system understands that this world will be expensive to update and then it will be sorted and be updated at the beginning of the frame instead but back to the issue so each task and thread is there's definitely work to do so next we enable the context switch data in the profiler and this uses the windows event

tracing api and we can see clearly that three threads are never switched in during the entire frame and then two of them were switched in after half the frame in this at the same time we have five long task threads running so long tasks are doing something at the same time as short tasks are not doing anything and the only conclusion here is that the low priority threads they get to run while the high priority threats are waiting and the explanation is that for windows server 2016 at least the highest priority guarantee is really only only valid within a single core group and core groups have up to four cores in them and each core group only has has its own ready queue of threads waiting to run so i've given here's an example in the picture where you can see that core 7 for example is running a is executing a low priority thread while there's a high priority thread waiting in another core group and core group 2 is not really going to

steal any work from core group 1 here until the ready queue for codeword 2 is empty so this can go on for quite some time and with 48 cores we're going to have 12 of these groups so we can expect this pattern to happen and we should you should expect that using this scheduler we made one attempt to sort of get around this using the function called set thread ideal processor we tried to map each short task thread onto its own core basically without using affinities and making it a hard requirement but this didn't have any any real effect and it mentions that in the documentation as well is that this is more of a hint to the to the scheduler than anything else so generally oversubscribing to the cpu is good for throughput you get a lot you get the most work done that way usually but in our case we could spot the five to ten percent perceived performance drop because the threads we want to run are not running but it made us rethink

the role of priorities a little bit because even if we manage to succeed and enforce that short tasks are the only ones running at this time or at least all short tasks are running then you would have long tasks that need to run you wouldn't be running anymore instead so it could lead to some sort of starvation in those systems and this is something we saw as well in the in development so i'm going to go into some examples on that um yeah so we spotted basically overnight this server was crashing we ran out of memory and looking in grafana we could see that this was connected probably connected to a list of pending deletions being built off built up over time so what this is is that when a player leaves the world we take their world when a player leaves the server we take their world and put it in a delete queue and then we have background tasks running to to delete that over time but they were unable to keep

up because they were they were starved for cpu so long tasks they are long test threads are low priority but it's crucial that they run within a given time remember that they're doing things like caching save game data and instancing nav mesh around the player and uh and deleting worlds in this case of course the window scheduler isn't really built to handle this and this is by design especially under high amounts of pressure and in fact the better cpu utilization means that we have a larger risk of running into this issue so the better we are at packing sort of the main part of the frame with world updates in a perfectly nice parallelized way we run into this issue instead the solution for us was to add a an internal wrapper around long tasks on the server and what it does is basically it adds an estimated cost to a global value whenever we start a new long task and as

soon as the long task is done we re remove that estimated cost from that global value again and this gives us a nice sort of yeah estimated cost of the total amount of work that is currently queued up to be done or being done on long tasks and the way we use this is that if it goes above a certain threshold we increase something called the starvation level and if it goes below another threshold we reduce the starvation level again and then when we spawn tasks to update the worlds we basically instead of just spawning a number of tasks equal to the number of threads we also subtract the starvation level we don't want to change the number of threads we're actually running we just spawn less tasks so those some of those short task threads are just going to be idle during the frame here you can see how that works in practice looking in grafana so you can see as as work here in the top graph estimated work for long tasks starts

building up in the middle graph you can see that we are starting to sort of yield short tasks in order to to allow more cpu to be used for the long tasks instead and eventually we can see that that the effect of that is that quite quickly the amount of long task work drops off again and in the bottom here you can see this is from a workstation so it has a slightly more exaggerated effect here but you can see that frame time is goes up a little bit when we yield short tasks to long tasks but this is expected and that's the sort of trade-off you want instead of complete starvation for some systems another example we had was with regards to memory allocation so overnight we were spotting a lot of contention in our graphs these graphs show aggregated execution time for every system per frame basically so during a single

frame here we had 306 milliseconds spent in contention which is which is an enormous amount of waste of course and again this data is available for basically all game servers all the time just a side note on this is that the data here is per frame but the resolution sample in grafana is one second and the reason i bring this up is that if you look into this kind of thing be very careful with data compression how it's handled in every step of the way so in the game server executable itself we have a report interval of one second and there are different ways to to deal with that and what we did was to make sure we preserve the maximum value through all of those steps so if there is any at any point on any frame there is a spike we will we made sure that it will reach grafana we will see it in the graphs but yeah if you use the wrong kind of averaging methods on any of those steps in the middle for example you can actually squeeze the data and miss a lot of important information

back to the issue contention here's what the profiler data looked when we when we looked like when we downloaded the file for it so this what we're looking at here is a full game frame of about 74 milliseconds in this case so too long and one of the short tasks is stocking contention for 42 milliseconds which is a very long time what's worse is that it's waiting for a long task to actually release the mutex and that's so so it's a priority inversion issue it's the worst we don't know when this mutex will actually be available again especially under heavy load and what it's hitting is a global mutex inside the allocation system so all allocations above 256 kilobyte hit that mutex so what um so here's how you can see sort of how the allocator looked um we have different heaps for different sizes of allocations and this heap system is used basically for all game systems

the smaller sized heaps also had some locks in them but they have we had less contention here but it was still a bit problematic but you can see here if i go back to in the page heap allocator here you can see that sort of the main global mutex that we were hitting so just to give an example of what kind of allocations we were having that were 256k when we create a new ai a new mpc in the world we give them an a behavior and these are generally pooled and reused so we don't create new ones but there is a small part of the runtime data that is actually reallocated on every on every new npc that is created and since behavior graphs are about 10 000 nodes and many of them have some small runtime component this actually ended up being a lot of data and the reason that we have to have to reallocate it is that we use these very highly compressed data structures inside the node graph system so so it was always even on it was always

reallocating the memory basically we managed to fix this eventually by optimizing just the size of the runtime data so we got below 256 kilobytes and then it was less of a contention problem another example we had that that ran into this large allocation was nav mesh sector deletion in some specific cases when we oops sorry uh in some specific cases when we were uh going to delete the number sector usually that's done on a background thread but in some specific cases when the player had run out of range before the sector was fully streamed in for example we would actually end up deleting ending up with the last reference to it and in the game code and we would delete it in the short tasks this was also fixed this was basically a bug so we just made sure that during the deletion we can detect that it's about to get orphaned and then we would spawn a

a a specific short a long task just to to do that deletion instead making sure that it runs on a background thread so both of these examples were fixed to avoid doing these big allocations in the world updates but we weren't able to fix all of these cases at the time this was a bit later in production we didn't have that much time left and some of the systems were quite complex to try to refactor so we had to take a look at the memory system so the first step was to refactor the heap to be lock free remove the mutex s make sure there was no locks left in there but we could still see that as you can see here in the picture as well the blue highlighted parts memory allocations were still taking a lot of time and there was some look still in effect because as you can see in the in the second frame there when everything when all the allocations are happening at the same time we would see this prolonged effect basically so some kind of lock was still in effect it turns out windows server 2016 had a

internal global lock in the soft page fault implementation and we were lucky to detect this at allocation time by having memory stamping in in our debug builds so we would see this as soon as you allocate memory but if we were running this on one of our release builds that don't stamp memory we would see this whenever a specific page was touched the first time by the application it would have been a bit trickier to to find it so the solution was to have the log free heap and combine it with a commit cache so what that means is once we commit memory from the operating systems we from the operating system we basically don't decommit it again we keep it in fixed size buckets and boxes based on the allocation size and these are global they are shared by all threads so we have a lock free access pattern to them and we still run into this windows lock the first time we touch a page but since we don't decommit the page again we basically

only do that on startup and at the begin just the very beginning of execution and then all those occurrences taper off very quickly so looking a bit at the new implementation the new page type allocation doesn't have a mutex anymore and each bucket entry commits just as many pages as it needs for that allocation it doesn't decommit them again here's a look as well as well at the bucket allocation implementation if you're interested in that i won't go through it in detail here it took took some time to find a good solution to this problem and the main reason was that the code here is shared between all snowdrop supported platforms so the ps4 the xbox one all the types of clients and and the pc server as well and this needs to run on all of them and we can't really introduce any regression on any of these uh other platforms when we do this rewrite there's not a lot of room for server-specific changes here and the second thing to note

really is that it may seem obvious that it's bad to have a mutex on a global level in in the allocator but if this was never visible on a 12-core workstation basically on the pcs it was only started appearing and actually quite significant on 40 cores or more next example is a crash that we had in open beta so basically on the first day of our open beta we had hundreds of crashes i think uh certainly games servers were crashing every few minutes it was affecting thousands of players and and we didn't get any crash dumps or any call stacks whatsoever there was no information machines just went down and then automatically restarted so we drew the conclusion that we have to catch this with a debugger attached so we had to go and talk to the infrastructure team to and sort of convince them to deploy a debugger wind dbg to a live game server machine and give

us remote access and we did that and we attached the debugger to the game server process and we immediately saw that every single player was was off the server so it turns out that wind dbg breaks by default when you attach to a process and goodbye to to those 1000 players basically so yeah we added the the g flag to wind dvd which makes it not break on attaching by default and we sat four programmers around the laptop remoting into this game server machine and waiting it took a couple of hours but we got the crash eventually turns out one of the udp channels was deleting a linked list by by recursion basically so it was the stack was running out of memory and the problem here was that the crash handler was dependent on stack allocation itself so there's a couple of solutions to this you can either use the set threats set thread stack guarantee call to make

sure that you have some space left when you get this problem and then use the crash handler to use that or you can just use static memory instead either thread local or or locked with some sort of mechanism okay time for some conclusions the first one is that we managed to reach our performance targets fully and this was due to the sort of heavy-duty testing that we did throughout the project always running on the target hardware and always testing with the full server every day in production we had very few performance issues actually slip past release this was and the ones that we actually had they were fixed easily found and fixed very easily thanks to all of this data being available like i said in in live as well you can just go in and look at any server and see if it has having any problems and then you can find the binary profile

data for that specific server if you need to look into something specific the third one is that the team and the management were always aware of the performance work that we had to do before shipping so this relieved a lot of stress i think from the team and made sure that we we knew the work that was coming up we still did most of the optimizations quite late but we knew exactly what we had to do the next one is that we this actually helped us find a lot of rare server crashes so just looking at an example if it takes a single dev tester about five hours to find a single bug or like a rare crash and using a full um a full server with bots we can find it usually within 20 seconds that's sort of the scale of how much faster we can find it one thing that we need to improve i think is our tools for regression testing so today what most programmers have to do if they make a change and they want to test if their change has any effect on performance they have to test with and

without their changes a couple of times i want to improve this so we have a more kind of deterministic test um and and should generally it should be available as some sort of pre-flight mechanism as well so just click a button somewhere and your change list gets sent off and it gets tested by bots in a good deterministic way and then you get a report back which is systems were affected by the change and how were they affected and so on so takeaways for you my primary tip is to make sure you test your absolute worst cases continuously in development this helped us find basically all of the examples that i've shown you before with the um the thread priority issue and the memory allocation issue we found them in development early on using bots because we were testing on target hardware with the max amount of players this is really key and the second one is

to have some people or at least one person dedicated solely to looking at performance this also helped because that means that that person will continuously also can improve the processes for the other programmers and how they work with this the third one is to plan implement and test your debugging pipeline for the live environment early on this is sort of self-explanatory why this is a good idea but it really helped us be very reactive once we went live and immediately analyze and fix some performance issues but again this is something that preferably you would want to have the same debugging pipeline in development and when after you go live and this again is something that that beyond will talk talk about here at gdc like i mentioned before and that's all i had for today thank you very much for listening everyone and if you have any questions or any any comments please don't hesitate to contact me on the email address you can see here thank you
