Lessons Learned Creating UI for The Division

[Music] hello just gonna start off with the basics please put your cell phones on quiet otherwise I'm gonna get very distracted and it'll be really funny and also don't forget to fill in your evaluations at the end of the session so that hopefully I can get invited back so my name is Chris savoir and I was the lead UI programmer on Tom Clancy's the division in my role I created the UI solution that we use in the game and I had the fortunate opportunity to help develop a lot of the core technologies used in the snowdrop engine today I'd like to share some of the hard lessons that we learned while building the UI system for snowdrop and the division for those who haven't played it Tom Clancy's the division is a third-person cover based shooter online RPG it's a Tom Clancy game where you play as a high tech government agent during the fall of New York due to a virus outbreak one of the

key pieces of technology is an AR system that links your character to the central AI system Isaac which will feed your character with information about your current situation and the world around you so it was very early on that we decided that we wanted to make a fully digest every UI element that went into the game was framed in the idea that this wasn't just for the player but also for the character that you play so here's the plan for today I'll start by covering a bit how our node graph and UI technology work then I want to talk about the importance of rapid iteration and the various things that we did to improve it after that I'll get into some of the gritty details of how we work and some of the performance issues that we faced and in the final part I just have some general lessons about what went well and what we would like to improve upon in the future so what makes no drop so special the

division was the first game to ship on the snowdrop engine that we developed at massive at the heart of our engine lies a powerful node graph visual scripting system the single system is used to create content for many parts of the engine from familiar shaders and scripting but also for particle systems graphical objects animations and behaviors and many more including of course UI as a quick example of how it all works I recorded myself doing a quick healthbar prototype first I output the health as text by concatenating the current and maximum health though you should try to avoid concatenated strings because it doesn't really work well with localization but in this example it's okay so I just do a quick test here to make sure that the values are responding I'm then just gonna add a bit of a background to the element that's going to change color based on your total health I also add a blurred background to it mostly out of habit but this really is what adds a lot of readability

to the UI elements in our game I use a gradient to transition the colors as you get damaged so green for good and red for red give it a test it's all working as designed now I'm just going to move it into 3d space so and then I attach it to the player unfortunately we move it into 3d it gets really really huge so I need to scale it down a bit and then I just move it above the players head since the player position is generally at the foot and then I basically just enable it and game hit save and then we have a new piece of UI running in the game so you might have noticed that at no point was there any direct manipulation of the UI this is one of the main differences in the snowdrop UI system is that we have no canvas to be honest this just started with a problem of time we focused on developing the node system first before the UI tools but every time the topic

came up to add direct canvas manipulation it didn't really feel worth the time investment another big difference is that we run in immediate mode instead of retained mode put simply this just means that we redraw the UI every frame instead of trying to pre generate everything on screen while this does come with a performance cost it also means that being dynamic and flexible are at the root of the system we'll get more into the performance cost of that later the system is also vector graphic driven we tend to prefer to build shapes with triangles instead of using texture masking this comes with a few key benefits first is that we can reduce the GPU load by only rendering the pixels that we use and the second is that our tech artists can really flex their creativity so this effect was made by one of our technical artists while just experimenting with various data processing and POI rendering techniques by using primarily vector graphics it

allow us to render all the UI at 4k on ps4 Pro without really having to change any of the data whatsoever finally our UI system is tightly integrated with our overall render pipeline and it uses the same shader backend this means that we can share shader techniques and have access to the same render resources as any other system in the game like the depth and the normal buffers any artist that has made a shader for 3d object or particle system can easily jump in and make you a ders for the UI since UI can just render overtop of everything it makes it very easy to add new post effects into the pipeline as well many of our skill post effects were done in the UI system here I built a small UI to test a few of them out I just enable it in game and hit save and then I can just test that all these effects are working well in the game to get information from the game a coder

just writes a new node to provide that information like the position or health of the entity that I used earlier to get more information we just add more nodes we had nearly 5,500 nodes when we shipped the recent survival DLC last Christmas these nodes may have been made for the UI but they can also be used in any other system like graphical objects to make them react to the player's presence here I have a turret object that I made out of made out of a few different meshes identify the head parts of it and I can use the player's position so that the turret will always face the player and then I just hit save and then it's updated in-game and tracking the players position nodes in snowdrop can do much more than just getting set data in the UI system they act as a visual scripting language so we have many nodes that affect the flow of execution with branching and looping most of our

systems share a high level of interconnectivity so from the UI we can add objects to the world run skills or spawn separate UI objects on the other side world objects and skills can also spawn UI the freedom of our nodes does come at a bit of a cost it can sometimes be difficult to understand who's doing what and where certain things are coming from for that we do have a very thorough dependency tracking system so you can always figure out who is owning wyden who's the responsibility of things the snow drop graph system is also very extensible it's very easy to add new data types to the system it's actually almost too easy when I made this slide we were up to 278 data types they range from basic types like int or float to very complex types that have custom behaviors and editors associated like the gradient that I showed earlier the numbers of types in the system doesn't really affect anything however since at runtime it all gets optimized away to

make life easier we have a system to enable automatic conversion between types which you can see by the yellow lines here it's also easy to make nodes that support multiple data types to either avoid conversion costs or to optimize for specific cases and if code doesn't provide enough data users can just make their own variables using almost any available data type and we also have global variables mainly store content creators can just shoot themselves in the foot all the time while it's a bit hacky to glue systems together using global variables they can't easily solve problems that would take much more time to code a system for we did ship with around 1,600 Global's actually our entire menu system was done using purely guild global variables which more or less worked the best thing to come out of having a single graph system is that in a lot of cases work done in one system would benefit all systems during the development of our UI system we added better variable support timeline based

animations and expanded on supporting arrays of data all of these features have benefitted and been used in many other graph systems in the engine we also have assets in snowdrop that we call compounds they're basically node graph snippets they're used in the UI to create reusable behaviors like buttons or common Styles like how many shadow layers to use however since they can be used in any system we also have a wealth of generic compounds that can be used just about anywhere we have about 3,000 of them in having everyone work with the same language just generally helps out around the office as well it means that level scripters artists coders and designers all speak the same base language so while each graph system might work in slightly different ways we at least have a common ground for communication so that's a little taste of the snowdrop engine but its biggest

secret lies in its iteration times iteration is one of our core pillars in the snowdrop engine in every system tool and piece of code we constantly think of ways to see our changes faster and faster this starts with our code base we're constantly keeping an eye on compile times in general compile times for coders is only around a minute and especially now that we've upgraded to the visuals - in Studio 2015 compiler with its improved link times and it's really worth upgrading to that if you if you haven't already it helps a lot we advocate both refactoring code to make it more efficient and removing code that isn't used anymore to keep our code blade base as small and clean as possible we also make sure startup times are very fast as well getting to the character select screen or to the start page of our editor is actually just a few seconds loading into Manhattan can take a minute or two since it is such a huge level but opening in our editor is actually quite quick

since were able to stream load everything much more aggressively in that case and our users can also hide large parts of the level so that they can work much more efficiently for the UI specifically it starts with being a what-you-see-is-what-you-get editor being connected to the game and seeing results immediately and it ends with only having to hit save to see your changes running in-game this has been absolutely key to developing things like our menu system and our mega map so not only do we build UI and see the results right away but we're always connected to live data so in our editor viewport we get a lot more flexibility to play around with ideas or even make some debug features like these debug UI graphs that show our input actions reacting in real-time it's not just the UI that updates live but nearly all data in our game we can save an object in the editor and it updates immediately world or change our input scripting or just

about any piece of data our goal is that the only time a developer needs to restart the editor is when getting a new version and even then they should be able to get back to where they were in very little time the less time they spend getting up and running the more time they have to make content as one last element to interation times is that we implement continuous integration with live deployment what this means is that as soon as a programmer submits their code our build machines will pick it up compile the various targets do some basic testing and once all of that passes the bill does Amy and Mail have made available to the development floor we found that overall the benefits of a coder being able to fix a bug or add a feature and have that change on the floor in under 30 minutes far outweigh any risk of a bad change causing problems in production our UI team all sit together so our artists and coders are only a few feet away from each other we're constantly working back and forth implementing nodes and features being able to react to them quickly enough so

that they're never really blocked from working on a future this connection to the artists is what really shaped our UI system to what it is today we use compounds which are those reusable groups of nodes for sharing functionality these are an important part of our workflow we can take any other graph or set of nodes and create a reusable component out of them these can then be used in any other graph that supports the nodes that it contains a great feature of them is that we can quickly replace them with code this allows artists to create complex systems that they need and we can easily replace them with an optimized cone system if the if the need arises writing code for a finished system is way faster than having a coder trying to guess what an artist might need iteration however does come with a bit of a cost that's best summed up by Uncle Ben with great power comes great responsibility when it becomes so easy to make tiny changes and then another and then another it also becomes easy to get lost

in your work usually this just results in having to kick people out of the office because they're having way too much fun working unfortunate other cases it might cause features to take a bit longer by losing track of time while trying to perfect them so it's good to make sure that you have clear goals and deadlines in place where people will just keep iterating forever towards the end of a project quicker or iteration can be really great for being able to squash those last-minute bugs but it also really helps to have someone in place that can also shut down the process those simple little changes at the end of a project can also easily lead to introducing new bugs so now it's time to get into some of the details of how the system works the actual UI system of snowdrop is deceptively simple the basic setup is that everything is split between widgets and graphics widgets take up space and are our primary source of mouse input graphics

are used to add flavor and are generally sized relative to the widget there on the funny thing is that we only really have five widgets instead of giving our designers buttons and combo boxes and very complex widgets we just gave them the very basics the very basics and let them build the functionality they need it turns out you don't need to have a very complex widget library to ship games especially on consoles so it all starts with a window this basically just tells the system where to start a new UI element when combined with coordinate frame that can be in either 2d or 3d it will automatically vertically stack all widgets given to it and it also is there to control how UI elements layer over top of each other text is our primary mode of communication all our fonts are generated on the fly to keep memory down to what we use the system has a rich formatting library to help customize text in additional ways by adding icons line breaks coloring and much more

images are the second mode of communication though most of the time we're just using flat colors or gradients instead of actual textures and it supports a bit more than just your basic import of DDS files we have sprite sheet systems and for improved performance or we can just support any loose image that you care to use the stack container is pretty much the only thing we have for sorting elements it just literally puts things on one on top of each other or there's an option on it you can put things beside each other as well so you can stack vertically or horizontally the scroll box is probably the only complicated widget that we have and it basically just moves the its internal con contents around and defines a clip area that's used to so that so that it won't render outside of a defined space so it's pretty much used for just scrolling content around and

clipping it off for graphics we get a whole seven types of graphics starting with more text because sometimes you want more text in the background not just in the foreground we found that there are a lot of cases where we wanted to define space with a widget but then use the text in the background to have a lot more flexibility with how its rendered and displayed in the graphics you get more than just your basic square images so we're able to cut some corners here or curve them lines are can be used for a lot of things like pointing things out in the world or framing other elements points are great for effects you can make a random mess or a more controlled effect with just a little bit of math and then we have arbitrary shapes because sometimes even artists don't know what they want sectors are a really cool

graphic that we have they're basically just circles or more parts of circles anything that you see that's a circle and the division was made with one of the sector nodes that we have and it really helped to sort of define that that graphic style of the division and then finally we have custom graphics which is basically everything else because something like drawing all of the streets of Manhattan through the regular line node was a little bit too much for that node to handle so making a quick custom node for that is was much better equipped to handle the amount of data in a much more efficient way we also have a node that allows us to draw almost any regular graphical object directly in the UI so it can be layered properly with the UI but that's pretty much it we have a few other minor bells and whistles but these twelve elements comprise the bulk of the work that's done every day in the UI system by keeping the basic usage of the system as simple as possible it allows to build up

complex behaviors in layers where the designers and artists have full control at each step so this might come as a surprise to some of you but the snowdrop engine does not currently have any form of reflection that is like there's no way to automatically expose the inner workings of the data to has two editors today almost all nodes are written by coders and but a bulk of the nodes however are quite trivial so for easy nodes we just declare the number of inputs and output pins the types and use this handy calculate method to do the processing this allows programmers to add simple functionality very quickly in other cases it gets a little more complex this is most of the code for this little node which goes through a lot of pain to output a matrix but it is a it's a really really good matrix like high-quality perfect matrix it might

seem like a lot of work to manually declare each node but it also means that we have nodes that do exactly what they need and no more we can craft each node to be as simple or as complex as we need to be and with short iteration times it's not nearly as bad as it sounds by coding each node in this way we have full control over how they execute do they need to run every frame can they be evaluated on startup or even having to bug nodes that remove themselves from the final game and in the editor we can customize nearly every aspect so complex nodes are easy to work with for example when selecting any UI node you see the element in the editor that's selected and our positional nodes provide elements in the viewport so you can interact with them directly unfortunately our UI is not a cheap system I'll break down a typical game frame so you can see what's going on I'm going to use this scene which is in the

middle of the fight that takes place while trying to establish your base of operations that happens fairly early on in the game here's a snapshot of our in-game profiler running on console there's a lot of one unused CPU time in this frame but that's actually to be expected since the fight isn't really that that heavy of a fight to the left we have the update of our game systems input agents and the player and a few other things to the right we have a big block that is the Colleen and the update of all our graphical objects and particle systems this generally will fill up as much CPU time as it can to try to offload the the GPU and then in the middle we have the UI which is all the orange bits it takes up a decent chunk but it is also very multi-threaded early in the frame we do a small bit of management to prepare for the updates to come next we do a few high-priority graphs that need to finish before the rest of the UI system can run this is mostly

preparing a bunch of matrices that will be used by other UI system so we don't have to constantly recalculate them then we get to the bulk of the work executing the node graphs with a little tail for preparing the render commands for the frame and this last area is the time we take on the CPU side of the render thread submitting data to the GPU I'd show the GPU cost but it's almost non-existent most of the time stain and budget while developing our rich complicated UI has been a major challenge since we're so CPU heavy the areas here represent about 12 milliseconds of total work updating nearly 100 root grafts per frame in total we run over 300 graphs per frame across all our various systems comprising of nearly 30,000 nodes multi-threading should now be basic knowledge for coders this is just the world we live in today my four year old phone had four cores current consoles have eight and these numbers are just going to keep increasing we no longer

have a simple 33 millisecond for 30 FPS on either console it's around 200 milliseconds across all available cores and all those cords need to be shared among so many complex and interconnected systems that it's no longer an option to just let one or two of the tech guys fix everything all coders need to be on board now even our freshest interns will run into a need to solve complex threading issues very quickly when starting a massive and to make things worse multi-threading is extremely complex for games at our high level we have a tasking system to sort dependencies between systems and allow major systems to run in parallel at the mid level we have a few different ways of processing work and multiple threads so our systems like the UI can go wide and then at the low level you just have to work diligently with different access patterns to ensure safe access to data so first off you need to make sure that every coder understands all the

threading primitives at hand and when to use them like only using spin locks for very tiny operations and always avoiding mutex as much as possible second is to make sure that every coder understands the various types of access patterns that are commonly used every game system has different requirements that need to be optimized for some systems can use deferred processing but others that need to stay frame synched might need to operate in designated safe areas during the frame for best for performance while some other non-critical systems are totally okay with just having mutexes to protect their data and multi-threading isn't just a challenge for coders anymore either I'm sure most games end up with loads of global variables to tie systems together when and when artists can interact with those in multiple threads they can run into the same issues that coders we had a lot of issues before shipping with our menu states because those were managed with global variables it took us a while to

figure out that it was actually a threading problem that was causing some of our last-minute bugs and when your script system is multi-threaded who controls what's threaded and what isn't trying to figure out how to run things efficiently it can be a challenge and it's usually where coders still need to step in the UI uses a simple high low priority system to split dependencies but our graph objects and particles have a much more rigorous set of options and constraints since there's just so many of them in the world on the other side our scripts don't do much threading at all but that's mainly because they're running on our servers which use a completely different threading model to our main game unfortunately I don't have a lot of answers here it's an area that we're still focusing a lot of effort on solving and it's a work in progress what does help is having more technical artists that is artists or designers that have a lot more technical expertise than you would normally expect often having experience with scripting languages or other node based tools so

life isn't always a rosy 30fps sometimes you just end up in a bad situation and need to figure out what's going on in this example we see a huge outlier in our thread times and we already see the graph name that's causing the issue so we can already start to take a look into what's what's going on here so we clearly see that as a mega map that's acting up but what's going on and it's no drop we have the tools to be able to see where the cost is going in a graph following the cost of the the mega map we find out that unfortunately in this case it's just trying to do too much at once so there's no easy fix unfortunately executing over 8,000 nodes and the single thread is still too much for the system to handle so the two choices we have are can we multi thread this or can we just do things more efficiently in this case the answer was to try to move work into multiple threads in general almost all of our performance issues our performance improvements fell into one of these two categories the easy one is just simply

simply identifying what work can be put in out of the threads so instead of rendering each enemy's health bar and name in a single loop we can split it up to run across threads the second category and the area where we saw the biggest gains by far was converting loops into data arrays so even better than looping over each enemy or even processing them in multiple threads is just do them all at the same time this was the most powerful part of our node graph system since any interpreted system has overhead and processing you need to be able to do more with less in our case it's about 300 to 500 instructions of setup to execute a single node plus a virtual function call we can either write complex nodes that try to do all the work for us or use arrays of data to do all the work in a single pass to support this we have a lot of fun ways to work with data like filtering based on complex conditions and this is in this example I can quickly filter a list of entities based on how close they are to the player an

interesting side effect of this is that as programmers start to become more familiar with the system they start to learn new and interesting ways to work with data I think that data driven development is an area that all programs can benefit from knowing a lot more intimately in addition to making low level systems data-driven we should also think of how to make our content more data-driven there's no point in having a super optimized render pipeline when a very basic scripts are taking up all your CPU this is an example graph I made when developing for loops in the UI system it does a brute-force collision between 100 squares as they try to get out of each other's way while at work the approach was very slow taking 20 milliseconds to run the graph compare this with the same approach using arrays I still need to loop over each bug but I don't need a second recursive loop this approach does the exact same work in only 0.6 milliseconds and not only is it faster it actually took about 100 or 30% fewer

nodes to do the same work sometimes though it's the small features that make a big difference one of the best little things we added was the ability to hold the control button and mouse over any UI element and show what file that's being drawn from when you have data from all over the place it's hard to keep track of so this became essential to being able to quickly track down bugs in the end especially when it's in graphs that may not be done by your team to ease the localization of burden burden we added a few small features that drastically reduced the implementation overhead like automatically trying to figure out what to show for a given game action on console or on PC or on PC with a console controller since we ship the the division in Arabic we also added support for right-to-left languages through various means and any list of UI elements you can quickly reverse the the order so for tech and for text we have

an auto justification mode that will be left to right depending on the current language we already had a system in place to input data into our strings so we simply extended it so that we can interpret numbers into language specific replacement rules it turns out there are very concrete rules for every language about what types of replacements to exist for different numbers I suggest you check out that link for more information another one was an in-game test for color blindness since the UI had a lot of render control and also has the final render pass it was really easy to just transform all the colors in a way that can be you to see where you might be having difficulty with certain colors we use this to figure out what colors we needed to change for our various colorblind options we simply enable it in our in-game debug menu which was also made with our UI system and then we can we used it to see what item colors worked

and didn't work in with various different colorblind so I hope you're able to take away a few things from our experience on the division like the importance of iteration threading and data I do have a few other things that we learned and or that we would like to do better in the future that I would like to share it's very easy for me to say that our UI system is just as equally developed by our artists as it was by our coders every feature was reviewed and approved by the team members we're always delivering code for someone else so the user should have a say and how it works in the end throughout the whole project we had a constant feedback loop with our tools and systems any request or complaint was considered and addressed if possible it's most important to do this during crunch when everyone is really really

stressed that we take time to listen and see if we can do even some small things to improve development sometimes it's just simple little things like trying to reduce the number of clicks required to do common operations or finally fixing that editor crash that's causing just one person to constantly restart by the end of the project I had a huge list of features and improvements that we didn't get a chance to implement we've been slowly tackling them so that we can just continue to improve the tools for our users to get the most out of your code I think threading and data need to be in the back of your minds at all time multi-threading was considered a lot for the internals of the UI system but not as much for the users we had a lot of hard to track issues towards the end that could have been prevented with some tools for users to manage their data better getting data models correct can be a challenge but it's well worth the effort it took us a while to fully

appreciate the power of a data driven approach but it made the single biggest difference in performance in the division while our UI system is very powerful the main complaint that we get over and over is that it's too complicated to use it does take a while for someone to really get into and most of our work is done by technical artists that usually have some scripting background the big reason for the difficulty is the lack of direct canvas manipulation I firmly believe now though that had we added it it would have actually limited the creativity even if it did make some things easier to do by removing the canvas the designer has to really work hard to understand the system and it was through this special connection that a lot of magic really started to happen with the division we're constantly trying to improve our workflow but in ways that doesn't dumb down the entire system I've been against adding direct

canvas manipulation because I believe it would just make our artists lazy and take a lot of creativity out of our design as is a usual case it's hard to find time to prepare documentation and it's and good examples during development we tried to make it a priority and we do have a bunch of wiki pages and video tutorials and things like that but there's always room for more I think the biggest problem that we had wasn't necessarily the lack of documentation but the organization of it you can have all the help pages in the world but if you can't find them it's not going to help and I find this is one of the most important left but often overlooked lessons that I can offer is just keep it simple it's very easy for programmers to fall in the trap of overthinking things more often than not the solution is much easier than it seems I find boring from test-driven development can help a lot

here you start by writing the what you need the code to do and then you fill in the code to do that and then you stop if you added any more code than you needed then you added too much code the same goes for tools it can often be a bit of a balancing act between what someone thinks they need and what they actually need but simple tools that work consistently and quickly without crashing are going to be far more useful than barely functioning complex tools that actually went a lot quicker than I thought so I hope you're able to get some ideas out of our experience on the division to improve your own games and engines at this point I'd just like to give a shout out to Anders Johansson and our lead UI designer and lars Vincent our lead UI artist on the division because I firmly believe that they were as much a part of making this UI system as any of our coders if anyone has any questions about

anything related to snowdrop or the division I'm more than happy to answer as best I can thank you for listening I enjoyed that thank you thanks you talked about how users still ask for the ability to directly manipulate the canvas but you reason that forcing them to understand the system resulted in a lot of magic can you describe that more I was really surprised to hear that so yeah all of our grab node graph systems are basically like scripting lines languages so you're basically you're building the logic to build your UI system and like every time we sit down and we evaluate and we're like what's gonna cause to to bring this sort of direct canvas manipulation and then we plug in the numbers and we're like okay it's gonna take like three months or four months or whatever and then at the end it's like what are really going to improve the situation for for people it's like okay we might get some things

to be able to just like stretch and move things but you can already do that with the nodes once you get a chance to learn them so it's just it's it's that level it's like when we when we think about the decoder investment to just add all of the work it just it never feels worth it hi oh sorry I worked on a similar system on a much smaller scale and I was wondering how did you handle merge conflicts putting all your code into Data not well it became a bit of an issue but post-launch when we had a lot of a lot of different branches and stuff like that we actually ended up implementing instead of well as sort of like a quick fix we basically set it up so that you can't modify data into branches and then we just have some processes in place so that like if you obviously you have to buy once you know that you're causing a

conflict between the branches then you can sort of take the steps necessary to resolve that ahead of time instead of having ending up in a situation where you have lots of data modified in multiple branches and then you end up in the merge hell so so by just adding a quick feature that basically said I'm about to cause a conflict it allowed us to sort of get of the problems it's awesome thank you hi I was wondering who your team handled like ownership of cross-disciplinary issues like for the main menu you had to frame the character and also put the UI up so how was like how were you able to communicate and make sure like the framing worked and showed the UI at the same time I'm not sure I kind of get the question I mean for the for the case in the main menu that's all controlled sort of an inner UI system so so the UI takes control the camera and frames it and I think we even add a couple lights in the world to make sure that the players lit at all times even at night but that was the UI team that handled that it was the UI team I

mean we also communicate very closely with all the other teams and stuff like that just to make sure that like like I said we added a bunch of lights in the world so that we're not busting their light budget and things like that so so most of most of the people on the division we all work fairly close together so there's actually a lot of cross-disciplinary like crossover and stuff like that thank you hey um could you talk a little bit about how you build in your graphs and execute them or how you optimize them well for that I guess one of the things I was going to suggest is is like hands up would anyone be interested in sort of a live demo of the UI system okay Wow all right in that case at one o'clock at the Ubisoft booth I'll I'll have the editor up and running and I can give a live demo and then sort of go over sort of the Det general process whew thank

you I just interested a little bit more information about the loops versus data arrays is that distinction as in you're then passing the full array to the node and handling that code side rather than knowing execution in loops or exactly so so the way our node system is built is that each piece of data it doesn't matter if it's one or more and so the code like so then we move that looping basically indirectly into code and then we remove all the overhead of the actual script processing and it made a huge like as as the example I showed it made one graph go from 20 milliseconds to 0.6 and so we got we got those gains pretty much anytime we did that it was games like that and if you looked at being our to write the nodes back down into coding and pile them into code to remove that over it one of the problems is is just since we have our node system that works in a whole bunch of different ways like we have the same

system that works in a whole bunch of different contexts it's just it's a huge amount of work to both write the code that does the work and then also make sure that it compiles down to proper code that's going to work in all situations however we do have some types of graphs like our shader graphs which effectively do that they're basically generating the shader code so it's definitely something that we've sort of talked to it talked about but it's it's I think it's a hard in our case it's a hard thing to do on such like a global scale just because all our graphs actually function in very different ways thank you you alluded to giving developers control over certain rendering aspects like the depth buffer things like that could you explain a little bit about how much flexibility there is in terms of where widgets and graphics can be rendered and how they interact with post effects and things like that sure so the UI system is like it's it's directly integrated into the renderer or so so we pretty much on a

feature by feature basis we can sort of add and remove whatever we want we just know we need to put the time and to do it so when we shift the division are you I actually had seven render passes and would make use of some of the data that's generated from the game so the game's depth buffer and things like that at various different points and then we could sort of use the different data during the different passes to achieve a whole bunch of different effects so we use them for things like highlighting enemies behind walls after we pulse and things like that that yeah help hi I was late so tell me if I asking about something that you talking about I have a rather simple question how you handle stuff like by outing what is centered topping cleft or something like this is this like anchoring uncovering it's so-so

when I explain so we have a window we have coordinate frames and our 2d coordinate frame basically supports all the anchoring for that and so you can anchor it to the left you can position things based on pixel or percentage positions and then we also have a built-in support for like safe areas on consoles and multi-screen support on on PC for different things like that low cost cutting kiss something like that right lock house Coleen scalene yeah yeah we have a I think we can do like automatic skin and a lot of the scaling we do on our own just because we found that especially with things in 3d versus 2d there like there's there isn't sort of a an automatic scaling that's applied to everything there's a few options for for different types of automatic scaling but we just found like different UI and different situations would have slightly different requirements so we sort of just kept those all as options that indeed manipulate in each situation and any errors in context of scaling if you

have any problems when move from one for example you know one sky pink for example and another from five two percent more and things like do you have gap between some elements and they look differently oh yes something like I mean I guess it's it's hard to I guess explain without an example maybe that's something at the live demo I can try to to sort of sort out how we do that but generally like if you within a an individual element if you scale it it's gonna scale uniformly so you're not going to introduce gaps or anything like that if you have multiple different

elements and you're trying to manage the scaling between them in a synchronous way then if you mess up the math then you can end up in a bad situation so now I had a question about clipping so when you when you can bring up the main menu you can do at any point in the game and you could be right close to a wall or you could be flipping the next to an object how did you deal it clipping and I had to follow another question about the mega map originally you had the the mega map kind of start off as part of the game world so I think it was in the first reveal that you guys showed the mega map was kind of like in the sea are you fading out the complete city to gray when you're doing the mega ramp now in the game was that just because of clipping issues and that kind of thing right so for the main menu clipping in general we just detect as soon as the camera hits something we found that it

was there were too many edge cases when trying to keep the camera in a safe space so we found in the end it was just better to as soon as we the camera just hit something and we're going to clip we sort of go into this mode where we kind of blank out the world using the turn remember the term but we basically just use sort of like the general colour of the world so so it's not like a fixed colour that we sort of like we don't grey out the world to a fixed color we do it to a color that sort of makes sense to the current state of the world for the Mega map we do a similar technique most cases when you bring up the mega map you're gonna still see the world a little bit and then we just we sort of fade it out for for like for clipping like you know because there's going to be things that and for readability because off we have found that towards the end like when you had the world and mega map at the same time it just became too noisy and was hard to to read and make use of it so you get it for a moment when you first open the mega map

but then we fade out the world so that you're focused on using the map all right I guess that's a that's about it so yeah one o'clock today at the Ubisoft booth I'll have a live demo of the the snowdrop engine up and running and if anyone wants to see how the UI system works feel free to stop by thank you you
