Cold, Hard Cache Insomniacs Cache Simulator

[Music] all right welcome everyone i'm going to get going right on time here because it's 30 minutes and it's full of stuff so please turn off your cell phones and don't forget to fill in your surveys if you don't know me my name is andreas i head up the tools and infrastructure team and insomniac games and today i'm here to talk to you about our cache simulator called cache sim so this is a tool that we've developed for programmers to use to measure how well they're using the cache and i'm excited to announce today that we're going to open source this tech and that you can all well in fact you already have access to it if you had only known the url so the thing i want to show you first what we're going to talk about here just in case you you woke up frozen in a time machine or something memory sizes and cache sizes so i hadn't really seen a 2d breakdown of things so if you think about a big block of memory like this and then you put the

l2 from a jaguar next to it it's kind of tiny and then if you put the l1 next to it yeah but if you know you think about this why why are we making these caches so small well they're really fast right that's the thing that goes uh that goes along with this is that if you can hit the smaller thing it's a lot faster right we're talking about orders of magnitude and we forget this too much as programmers but it's really when we can hit these orders of magnitude improvements that we get the really big payoffs and i think it is true personally that most programming languages make it really easy to screw up right you can add memory operations that you didn't even realize were memory operations because programming languages like to abstract the stuff they make it easy for you to destroy performance so as programmers trying to fix performance problems uh typically with working on the cache we just need access pattern information and that's not something that is easily

gleanable from the code like you actually have to dig in so what are we going to do well if you're doing anything like this you're probably using a sampling profiler right because they basically won something happened 10 years ago and everything else just disappeared and it's easy to see why this is true like they're non-intrusive you can just run them and they tell you with a pretty good guess about what's going on um and they can also give you hardware statistics like yeah the number of cache misses and things and they use hardware statistics to do so so they're actually pretty accurate but and that's a big but they have a big limitation right they interrupt your program every so often and the instructions and that end is pretty big and even if you can try to make it smaller there's actually quite a big gap so now you have something that you're curious about finding out why is this taking half a millisecond right i suspect that there's something bad going on in the system but like it just pops in two or three samples in there and that's essentially useless

outside though of the sampling space there are tools like valgrind that take a completely different approach so this is a tool that sets up a synthetic cpu and then runs your program on that cpu and you can instrument and do stuff with the program and part of that stuff that they do is cache grind so that's a module that you can run on top of valgrind and what this does is it will break down your instructions reads and writes and simulate them on top of a cache and then you can get this awesome sort of super detailed output at the end so it's easy to see why that will give you a completely different picture because you're not looking at every end instructions or like that entire block you're actually pinpointing everything down to a particular instruction uh but it comes with a bunch of cons for us right that our games don't run on linux where this thing runs and it's all or nothing so if you know you can't decide to do this halfway through you're going to be navigating your menus and loading your level and doing all the things at like a hundred times slow down which needless to say is not particularly great if you're trying to

get to that particular gameplay thing you're looking at there is a tool that is near and dear to my heart from the previous generation of consoles that i won't mention by name and allowed you to do something similar for a short period of time and then run unimpeded again and i really felt that we could use a tool like this if you have a tool like this i'm going to show you just in case you haven't used this like this why you want them here's some high level rendering code from our push buffer so the purpose of this code is to say well i have a bunch of textures and i'm going to convert it to lower level data that's going to be fed into the gpu push buffers on the next string and the details aren't super important but what i'm calling out here is that this is relatively well-tuned code something that i wouldn't expect to be a disaster right and i found using tooling that this particular access of 16-bit flag was missing l2 2800 times in a frame which is a huge deal and sometimes it's just the small things

right why did it happen well it wasn't some sort of ominous bad guy putting this in right it happened accidentally because the object it was accessing had been organized into a hot part in a cold part and during maintenance because something grew or shrunk or someone added something without thinking it through again programming language abstracting things for you this little poor guy had dropped from the hot cash line into the cold cash line how do you fix it you swap two lines in the header file and you save up to a quarter millisecond depending on view right that's what i'm talking about and your time investment to do something like this is like half an hour and there are other reasons that you want tooling that help you along the right path so sometimes you have utility functions like i'm sure if you look at a profile for any random game you'll see things like mem compare standing out when it really shouldn't or you know just accessing a position will show up in the in the profile output so in this case uh what i'm showing here is our scene object class has a way to query for hey what's

the position of this thing and it's pretty easy to see what it's going to do it's just going to access a row from a matrix right and if you see this sort of thing showing up in the in the cache report you're going to be like i can't optimize this it's just a return statement what are we going to do well that's the wrong way to think about it what we need to optimize are the people who are giving this poor guy cold this pointers right they should be doing something else but in order to do that you have to figure out who is calling this guy with all these cold pointers and propagate the blame up the stack so i did that and our tool does this and uh i have found that one particular programmer was responsible for 12 000 out of the 14 000 l2 misses in get position so again i'm not going to bore you with all the details of the code here but like basically it was a loop like this that said i am going to go through and do a broad face is what the comment said to quickly get to the set of things that i need to look at the things that are around the camera

very prototypey very sort of first pass but like you know things like this happen okay so it's burning through 10 000 or so 12 000 in fact placed things by designers and then figuring out which ones are actually near the camera this thing 12 000 l2 misses in a frame from this one particular location right i mean to put things in perspective here this is like one millisecond this entire system was one millisecond per frame on pc so if you've done any console dev uh yeah it's not one millisecond so looking at this thing i'm like wait what's going on i need to fix this uh well it's good that these things that it's accessing over and over again with these super expensive l2 misses they always return the same result because these things never move so my fix for this particular problem then was to say well because they never move i only need to update this array when these things come and go which is super super rare and i can then get rid of this get position call entirely and that saves you 650 micros per frame

on an i7 it's a bigger project right it takes a couple of hours maybe to reorganize it but there are real wins so to do something like this to actually simulate what is going on in a program it seems so easy if we could just you know be super human because it's all there in the instruction stream like all we have to do is look at what the instructions are doing and looking at the addresses and the operands and saying you know if this was cached and if this was not cached and somehow count that up so to do that we would basically flip a switch when we have gotten at full speed to some point of interest and then start single stepping the instructions and seeing what are they doing update some cache simulation and then turn off the trace and report and we'd live happily ever after how do you even do this so and it sounds like we pitch things and we practice you know explaining the value of things and

it helps if your boss understands you uh this is my boss he doesn't understand me and so i said to him i think there's something here we should have our own caching layer that we can apply for all these things that there's no off-the-shelf tooling and i think my subject was i can see crazy town from here he said sure so i did that and my first approach which went nowhere really but we'll see why i started looking at binary instrumentation frameworks so if you're not familiar these are tools that will allow you to sort of muck with your executable as it's running right so you can say oh go find this function i'm going to rewrite to look like this and you can actually go way low labor too you can say oh let me patch up all these sse instructions to do something else or whatever there's dynamo rio is one popular one and intel has one pin but remember the scope of what we're trying to do here we're trying to look at every single instruction that touches memory let's just say that that's not really in the design wheelhouse of these frameworks like because the metadata that they need the track to like undo these patches and all the things it's hundreds and hundreds of megabytes

i don't know about you but our executable is kind of big right aaa games but i think you know i was interested in the space and if you're going to look at these frameworks i would encourage you to look at them for like how can i put sort of cheap d-trace style probes into the game that i can enable and there's zero cost when they're not there you know things like how often is this zero how often is this min max value between whatever like if you're doing your own custom stuff without having to recompile the game all right so that was a bust and so i said okay next next approach i'm going to write a function somehow it's going to be called trace function you give it a function pointer and then magically it's going to disassemble each instruction it's going to find the memory dereferences of that instruction and update the simulated cache and then because i don't want to emulate the entire cpu like i'm going to rely on the cpu to do the heavy lifting it's going to actually execute the instruction and to do that like isolate the instruction in a temporary buffer run it

and then return back to me so i can keep doing this that doesn't sound too bad yeah as soon as you hit a branch instruction like your party comes crashing down because oh yeah they're all relative offset coded so if you copy the thing elsewhere in branch it's going to just branch into garbage memory okay maybe we need to emulate them and then you've got the rip pointer so if you're not familiar with x64 assembly there are a lot of places in x64 assembly where you use implicit references to the instruction pointer with a 32-bit signed offset now removing the instruction let's just say that those deltas are no longer what you want them to be so you have to either patch them which you sometimes can't if you move it to a different four gigabyte range and okay but on top of this we're also violating the win64 api because in win64 every non-leaf function is associated with sort of a stack unwinding data block if you don't have that block and you take an exception your program dies like there's no trying to fix that

up like it just goes away and you might think well that's just if you divide by c or something which we wouldn't do but no if you've ever used output debug string or any other number of win32 internal things they use exceptions internally even if we fix all those problems it's still a pretty intrusive approach right because even if we had this magical trace function we would have to have everyone opt in to being traced they would have to start this frame saying oh are we tracing then let me run to this rube goldberg machine over here or otherwise i'm just going to do things normally so i was almost ready to give up but then it hit me e-flags is the flags register of x86 right and if you've done assembly programming you know that this is where the carry flag and the zero flag and all these things are but there's also this guy the trap flag intriguing this is how your debugger f11 steps right if you're looking at disassembly and you're hitting f11

it sets the trap bit and then the cpu continues running but after it's run the instruction it's before it runs the next one it will actually generate an exception so okay can we leverage this it turns out you can route this exception to the windows structured exception handling machinery and you can put a handler in for it which means that if you set this flag if you do it on your own thread you're going to have little problems but you'll basically get called back for every instruction you can choose when you want to do this or not but it still seems like you would have the the sort of opt-in problem that i just talked about where everyone who wanted to be traced would have to have a structured exception handler and jump through all this stuff but aha since windows xp there's this little known thing called vector exception handlers that allow you to set a crossbar handler for the entire app so with those crazy building blocks to do this we can install a vectored exception handler across the entire app

and it's going to listen for these trap exceptions then we'll go find the threads that we want to simulate and we set their trap bits we're now getting called for every instruction on all those threads into our handler it's trapping us so at this point we disassemble the instruction from the text segment we're not moving it anywhere we find the memory operands and we update our cache simulation and then if we want to keep tracing because this bit auto resets right we set it again so that we get called back for the next instruction and then to stop it's pretty easy all we need to do is basically stop setting these trace bits so i was excited to get two integer editions working with this approach there are some other problems first of all your debugger relies on this like this is its space like we just barged into its party saying hey what's going on and because the debugger gets the first chance of trapping all these exceptions and will right it gets super confused you'll have

everything from the debugger crashing to like doing all thing you know remember it will normally have set these single trace flags and so you can take your debugger down very easily just run outside of the debugger was my solution the more serious problem is that i had deadlocks in ntdll for actually running this on a full game executable so there's a lock inside of ntdl not to bore you too much that protects this vectored exception handler dispatch list and the idea is that while a handler is being run you have to protect this list with a lock so that you don't remove the handler while the list is being traversed and all these boring things and the thing is all the threads were blocked on this lock but no one held the lock so that's great i'm not really sure but if we step back and look at what we're doing here like we're running a full aaa game executable and for every thread for every instruction we're sandwiching in this cash simulation handler on using the structured exception handling machinery which is like it inverts you know the normal work of the program

with cash simulation by i don't know five orders of magnitude or something so let's just say that no one probably at microsoft anticipated anyone to use it this way and nothing was obviously wrong but what if i had to mentor a guest i think it is that critical sections that are in the process of being entered if you then take a trap and you go in and take another critical section in the trap handler i think that is bad news um anyway i wanted to get something done so my solution was this and you may or may not agree with my reasoning here vector exception handlers are exotic we are not shipping this feature outside of uh you know i used to say office but that's no longer true but i hope you're not shipping this to players because we certainly aren't so what i do is i go find this handler that takes a lock and will iterate the list of exactly one handler and call that handler which is always our handler with the jump door handler yes it is ugly but on the other hand it works and i also got rid of all the operating system dependencies from the cash stream module itself so it would never try to

do a syscall so at this point it works and beautifully instruction streams start trickling into these things and because we can now inspect them one by one the next step is to look at okay what memory addresses are they looking at and in terms of disassemblers i used one called udis86 which is nice and there's a fork of it made by the radar 2 project that is even better because it gives you the memory access operands so here's what i'm talking about you basically from the context record of the thing that interrupted you you get the instruction pointer and you disassemble straight from the text segment and then you just have to figure out what addresses are involved in computing this instruction should be easy you know here's a simple example there's a move clearly it's moving you know 32 bits from ebx into the pointer rex well that's the theory but if you've done x86 assembly you know that there's tons of stuff that touches memory but doesn't have a memory operand

and there are things that have memory operands but don't touch memory uh so string instructions uh a good example uses implicit registers you get your stack traffic which will also pollute your caches even calling and returning from functions will mutate the stack and there's lia which is super common your three operand swiss army knife for computing things which has memory operand but doesn't touch memory and so if you get this wrong you just have really bad results and they're also crazy things like they're long knobs that you can use to pad and that have memory operands which i found really interesting and there's floating pointer stores and prefetches and needless to say you can take all of this and you can put it in a somewhat awful switch but you can handle all of it in like 200 lines of code which is better than doing every instruction so once we've figured out what the memory accesses are we're ready to go poke our cache and so the first thing we can do is go post the cache to say well we know that we're going to execute the instructions so make sure that we do an i read

from this address and then we have our reads so we poke the cache again and we do a read simulation and then we do write simulation which then opens the question how do you simulate a cache well if you're familiar with anything about caches they have associativity set associativity and so you can basically break them down as a two-dimensional array of ways and sets so to see if something is in the cache or indeed entered into the cache uh you take the input address of whatever you're looking for and a certain number of bits depending on on the number of sets that you have and then you go look at those lines that are associated with that particular set those are called the ways and you know you run the comparison against all of them hardware thinks this is a really nice problem because all it needs to do is do a parallel comparison which we can't do in software so but anyway that's the theory i was interested in simulating a jaguar

core because that's the cpu that we know and love so um you have two modules they all have they both have a shared l2 and four cores and each chord then has its own d1 and i1 and a particular quirk is that it's inclusive so if you have a line that is in in for it's for something to be a hit it has to be in both l2 and i1 for example if you need an if you need an l1 hit so what's left to do is to figure out the associativities which are no secrets they're right here i want two-way associative d1 8-way for example l2 and 61 we have the sizes and with a bunch of helper glue that i'm not going to show you in this talk you can go look at it yourself we can declare these two-dimensional array type helpers and i set up this module thing that is okay four d ones four i wants a level two and a pointer to the other module right and this is important because if you're writing to something real hardware is going to do a line reservation of the thing you're writing which this

cache synchronization protocols can make sure that it's kicked out of the other guys l2 so we need to simulate that or we're just lying about things so for each cache line we're accessing depending generated from these reads and writes right if you are straddling a cache line boundary this will apply for both the cache lights you're reading if we're writing to that cache line we had better go kick it out of every other core on our module and the other modules l2 and then we can do a look at plus record so i'm treating the cpu here as an inorder cpu for the purposes of the cache so i'm going to pretend that whatever you asked for will be cached by this right but what we're also looking up is to see if it's already in the cache and that's how we can determine something as a hit or miss so we independently hit the l1 and the l2 and because it is an inclusive hierarchy it has to be in both to be considered an l1 hit if it's only in the l2 it's an l2 hit and otherwise it's a mess so it's reasonably simple all right

so with all this stuff i now have hooked up to a keyboard shortcut but i'm sure you can find other ways of doing it and then i run a frame on this in the game like this is a full aaa game i'm talking about here it takes a couple of minutes to do this which is still pretty awesome given what it's actually doing and how hacky it is and you know out falls 200 megs maybe 100 megs depending on exactly how much of data and i've you know i'm so happy to say that the goal is there like it achieved this goal of saying you know once it's done this slow thing it resumes running at full frame rate so if you want to do 15 of these you can like there's no problem so with the data we get out as i mentioned we capture call stacks too which is integral to this data that's why it's so big and we track l1 hits l2 hits l2 misses and we also put in a special thing to to track pre-fetches explicit prefetches put in by programmers and see if those prefetches hit things

that are in the cache so that's a pretty good detector to say yeah i saw you put these prefetches in but 95 of the time they're pre-fetching from cash so uh i'll just briefly show the gui tool that comes along with this this is a flat breakdown of things which you can use to scan for anomalies like this should not have this many l2 messages or something and because we track the call stacks we can turn this into a tree that shows you you know from all the way from the root symbol across all the threads like how the l2 misses and hits and everything break down and you can reverse the tree which is helpful when you're looking for who is to blame for this function missing cache and that's how you can find things that are similar to that gameplay example that i showed previously and finally there's a way to go from symbol to source and then see how the l2 misses and everything break down for those source lines that's it for the tooling really and um

a couple of things like we wanted to make it obvious in the source and you see that in a minute how like what what what bad looks like so we came up with this badness factor which is the number of l2 misses squared divided by the number of instructions to really make it obvious that this line be worn some attention and in general because it takes a little while to do the captures i just found that it's worthwhile to put a bunch of views in here so you can reuse and go back to the dumps after a while so you'll see that if you look at the tools that for example it resolves the symbols and then sticks them in the dump so it's independent from the program and things like this so just a real quick intro to how i found that first issue right if you look at the flat profile you see wait why is this relatively well optimized rendering code showing up here with 2 800 misses when you go to the source view that's the badness factor this line is doing nothing but missing cache this needs to be addressed and from there on you can relatively easily see what's going on

so to wrap up the pros of this approach is that you get every memory access of the of the program it doesn't cost you anything in terms of like you need to link with crazy things it's not encumbered in any way so you can just play with it and because it works on windows you can go all the way into graphics drivers and the os code if you want it's kind of scary in there but so that might be interesting interesting if you are a windows dev and you're trying to look at some particular problematic pc architecture cache and it's open source like i mentioned so you know if you need something that walks every instruction on every thread sort of slowly you can do this as i mentioned capture speed could be better i'm sure we can optimize it it only works on windows so yes but you can still pretend that you're simulating a jaguar cache which we do and it's not as bad as you might think because if you ignore dx11 stuff and the operating system stuff like it doesn't really matter if your high level rendering code or gameplay code has been compiled by

clang or msbc right the number of memory accesses and where they go is pretty much the same and of course it's not 100 hardware accurate right because we are treating the cpu as an inward cpu here it doesn't account for the out of order scheduling window which if you saw my talk from last year doesn't account for that much anyway like if you're seeing triple digits worth of l2 misses in a thing like it'll suck and out of water too like it's there's no magic fix but it's a caveat and they're a bunch of smaller issues like it has to use virtual addresses to simulate the caches the replacement line policy is not perfect array prefetches are not yet simulated so if you have very heavy sort of sim decode walking a race like you'll over report them pessimistically so yes some care is required and that's what i hope to address in the future some of those things right make it uh faster and fix some of the the pre-fetching stuff on the race and i would like to implement all of the special things like non-temporal stores

and loads and then whatever extensions you guys have so that's my prepared talk on this and you can get this right now at github and play with it and we have i think three minutes for questions [Music] [Applause] there's microphones hi great stuff um what's the chances of actually being able to put this on a console platform if for example you didn't actually have a windows build um can't comment all right i should i should talk to somebody you should know and i should know that we can't talk about that yeah i know i know we can talk about it

offline all right let's do that anyone else all right oh one more oh yeah do you support like multi-core interactions and like evictions from the different clusters that sort of thing so yeah in case not everyone heard it is multi-core interaction supported in here yes like all the threads are running independently because but because they're running through the windows exception handling machinery like the it won't be perfect but it'll be really kind of good like the win32 scheduler gets all aggressive about this because all the threads are sort of spin locking and interrupting each other so there's a good mix of things coming through and the way the simulator works is that you pin all the threads that you care about to a particular hardware core and then all the accesses that win32 thread runs regardless of physical core on the machine is going to be simulated as

if it came in always on for example core four on your jaguar cool would you see um statistics as well for full sharing on cache lines do you ever expose that in your gui um the question is do we expose false sharing no okay we don't cool thank you very much how do you think compares to linux cash grind which you mentioned early on sorry one more time you mentioned linux cache grind from valgrind yes and how does it compare this in terms of results or effectiveness it does basically the same thing but it does so in an opt-in way you could say okay so yes it is comparable i was just curious if you had a chance to look at the uh like intel like hardware counters or anything like that um i don't know like how well they're exposed than anything except like intel tools but there's some kind of hooks into like cache performance right and that's what sampling profiles use

right they're built on those hardware counters to to get cache metrics okay right so the question is how does this relate to hardware cache metrics you can get from the cpu yeah i mean i know like things like v2 and they don't i don't think it's presented very well but they do have like some information about like right that's what sampling profile is relying on is sampling those hardware counters i think there are four debug registers you can set and you can sample up to four there's 30 sensors or so there were things that you can read and then the sampling profiler lets you pick a few of them right but it doesn't really know what instructions cost the l2 misses but that's the problem i'm trying to solve here right but that will give you accurate numbers for a run of instructions on a particular cpu that is in your machine whereas this simulates that you're running it on a jaguar cpu regardless of what platform you're on hello one question i have is whether you track how many times each instruction is executed because this sometimes gives valuable insights of whether you have a lot of cache

misses and but also now many times that instruction was executed so you basically have a cache misrate so you can know if that there is a tiny loop which is executed many times and missing many times right so i think the question is do we count the number of times in instructions executed yeah kind of a destruction trace oh yes we do and that's but the badness factor is actually based on the number of ltmas squared divided by the number of instructions executed right okay okay that's pretty cool thank you cool all right that's it in case there are additional questions find me outside in the conference and thank you
