Building an Expansive 'Star Wars' World in Mobile VR

[Music] thank you for joining us today my name is roma and i'm a senior gameplay engineer at ilmx lab which is lucasfilm's immersive entertainment studio our core mission at xlab is to pioneer a new era of interactive storytelling via connected stories that cross platforms the goal is to move from storytelling to story living where we invite you to step inside living worlds to meet beloved characters and become the hero of your own personal adventure we're excited to talk to you today about how we build an expansive star wars world in mobile vr with star wars tales from the galaxy's edge tales began in the fall of 2019 it was a continuation of our partnership with oculus studios which previously we released a very immortal the vr series for that experience delivered on the oculus rift which is desktop powered and the

oculus quest which was oculus first untethered mobile vr headset similar to vader tails is also a flagship title for the recently released oculus quest 2 which is a more powerful entry into the mobile vr market but even though our experience was to be featured for the quest 2 we still had to deliver a performant experience for quest 1 and that's what we're going to tell you about how we did it so now in mobile vr there are challenges that we've run into especially for a platform that is not as powerful as quest two which is quest one um some of those challenges include explorable world with long sidelines there are more characters more interactive cinematics lots of weapons inventory collectibles and of course lots of combat all of this challenges the device first what i want to tell you about uh is the game thread challenges we ran into so on this project i was the lead game thread performance engineer and we ran into a few issues some of

those i'm gonna mention here and how we went about addressing them some of those issues include moving complex component hierarchies spawning and despawning hitches ticks during combats that are not needed and stalls on the cpu so first component hierarchy so it's as a rule of thumb the bigger a component hierarchy is the longer it will take to move so there are a few tips to know and whenever we run into those kind of issues first is to try as much as you can to use actor components instead of scene components especially for things that don't need to have a transform all the time that is up to date things that are not visual for instance second is to use unrail's built-in scoped movement which allows you to do all the transform calculations ahead of time and only do the move once at the end which goes into the next point of making sure you only move heavy hierarchies once a frame at most if possible of course lastly we managed to build a system to

detach components that were not needed and to reattach them when needed and i'm talking about components like vfx or audio things are not present all the time but that might show up every once in a while now there's a special case sound address skeletal meshes so on top of the issues that i have detailed before skeletal meshes have to update their bones twice once when the character moves and the second time when the animation evaluation ends this is especially a problem if you have lots of bones if you have lots of things attached to your bones things that themselves have lots of subcomponents as well what we did for those is what i called the detachment optimization so for this we detached the skeletal mesh from its parent component and instead of moving the components we use the anim graph to move all the bones where they're supposed to be so basically we saved the transform that the component was supposed to have and put it on the root bone

this was great it helped us a lot especially during combat where we have lots of characters on screen we use it on the player pawn all that all enemies and some of the cinematic characters too there are obviously are some drawbacks you can't use the transform of the component anymore you have to use the root bone transform and uh some adding anim nodes don't know how to work with this so you have to go in and fix them thankfully we managed to keep that um a little it didn't take us too long to do that so another issue that comes about when moving upon the hierarchies is overlaps there are a lot of times where overlaps are turned on whether it's by default or it's people thinking they're doing the right thing entering them on there's a lot of cases where actually you don't need overlap so for instance when you're only going to be doing traces on a specific collision so it's great to educate people as to how collision and physics work what the settings are for and when to turn them on and definitely make sure you tell them

to leave things off by default unless needed and finally one thing that has helped us a couple times is to switch to a list of targets as opposed to collisions for instance if you have a sphere collision that only detects enemies you can maybe instead keep a list of the enemies and just do a distance check against them that will that will take a lot less time all right so moving on from components now we have hitches um there are hitches in unreal engine and especially when spawning and despawning actors and components so the best weapon we have to fight against those is to use a pooling system there isn't one built into unreal um so we had to roll out our own and it helped us a lot uh basically the concept is you spawn everything ahead of time you hide them and use them when needed and when they're done you re-hide them again make sure to turn off all the ticks collision everything it's great uh it helped us get rid of most of the hitches it also allowed us to use caps for all our enemies

and for also weapons and lots of items that could potentially balloon otherwise another thing it helps is with spawning and despawning of objects when they're far away so that's my next slide during combat and even when you're just exploring the world it's very common to see things ticking rendering or even updating their collision when they're really far away and you don't actually care about all this so what we did for that is to use a player distance system that we put on almost all of our objects interactive objects and enemies well not enemies the idea is to reduce the impact when you're not close to the items and we leverage our cooling system to spawn the items when you're close enough and despondent when you're far away so that was a great help all right finally and i want to say last but not least a game thread stalls on quest especially quest one we only have three cores that we can use the

rest are reserved and in heavy moments such as combat we are using all of those uh very intensely by rendering by audio gameplay everything is acting up all at once so it's really hard to address stalls sometimes they're just there because there's just too much work to do but there are some cases where you can solve some of them in order to do that we've used a tool called unreal insights that you may be familiar with this tool is aiming to replace uh the stats capture that we've been doing in the past um i think it's great personally i think it there's a little bit of work to do on it but um we've been using it with great success it's great for people who are more visual in understanding things it helps you see what things are happening in which order uh it also has a smaller impact on performance than the sas capture because it doesn't have to save everything to a file it just sends it over the network now it's a little bit hard to set up on quest um there are some resources online

that are not too hard to find and as of our version of unreal we didn't have any of the object names that were causing the the stats so it was a little bit tricky to interpret thankfully we're able to go in the engine and add some of that back so hopefully we can see that in the future version of the engine so with this tool we were able to to see uh one thing in particular and if you can see on this image there is a stall that i've circled and right after you can see a parallel animation evaluation that's completing thanks to this graph we were able to determine that one of our skeletal meshes had a prerequisite on it that was forcing it to complete in an earlier tick than what we were okay with by by fixing this we were able to let the animation uh complete in parallel and finish way later in the frame which saves us some of the stall uh so to unuse unreal insights the most effectively the way we did it's uh critical in my mind to understand the

task graph system so dive a little bit if you have to and uh definitely be careful of take prerequisites because those get added automatically when you parent components to each other uh so keep an eye out for those things all right i'm gonna close the game thread parts with some miscellaneous tips some of those are obvious but i just thought i'd mention it no blueprintix please keep everything in native because you will have to do it at some point i guarantee it uh you will have to move things to native except of course in some very trivial cases in the same same vein no blueprint implementable or blueprint native events on ticks because those incur the same kind of overhead as the regular blueprinting and even with blueprint native events that are not implemented in blueprints you will have to maybe remove that favorite non-dynamic delegates dynamic delegates actually use a similar tech under the hood as blueprint does so you will also have an overhead with that so try to keep

those to minimum finally beware of blueprint timers so the blueprint timers actually show up in a different area of the stats capture than the regular ticks so in our case it took us almost until the end of development to realize that we had three millisecond hitches happening very frequently in the timer and that were causing some of our issues that we just couldn't see happening in the regular tick section so definitely uh remember that and keep an eye out for those now game thread is not the only thing that we've had challenges with uh of course we've been trying to push our rendering and i'm gonna hand it over to jeff to talk about our rendering challenges on this project thanks roman hi i'm jeff gribby technical art director on tails from the galaxy's edge as tad it was my responsibility to oversee the render side performance and optimization approach as well as investigate techniques for visual enhancements this

was an exciting opportunity for us to partner both with disney theme parks lucasfilm storytelling to give our fans an opportunity to step well beyond blackspire outbooks explore the lands of otto we knew early on from our experiences with vader immortal thorough optimization was going to be essential to bringing about our rich environments and interactive storytelling content to life unreal engine has numerous built-in methods of optimization i'm going to share with you some of the methods we chose to use enhance as well as some of the features we implemented we want to achieve vast diverse regions for you to explore and to do so option conclusion was going to be vital to keeping our performance metrics down this was by far our best means of performance gains we wanted systems that were thorough automated and avoided human error and were also computationally efficient above all we want our rs teams to spend more time building our worlds and less time focused on optimizing them

for mesh occlusion we opted to use unreal's pre-computed visibility system it's a powerful tool in that it's uh it's simplicity is set up as well as its automated automation tied with lightweight generation it works by scattering cells over every single static mesh within a volume emitting rays from those cells to detect mesh boundaries unfortunately though most of the the default configurations lead to noticeable bumps and inaccurate occlusion queries to remedy this the sample settings need to be set extremely high for accurate results especially with long sight lines filled with various obstacles we also needed many cells to increase the occlusion effectiveness too large of a cell size and we ended up just drawing too much that said higher sample settings can lead to exponential computation times so it's critical for the effectiveness of this tool to limit the amount of cells and the only option to do that is to hand place individual volumes over each

location where you want these visibility cells placed in a large map this can be extremely difficult to maintain so instead to reduce the computation time and retain accuracy we modified the system to only place cells on specified meshes we also exposed a method to export the navigation measures geometry which we could then use for selective cell placement this approach dropped us from roughly forty thousand cells using individually hand placed volumes to only five thousand cells and another nice perk was that we only needed to place a single volume to encompass the entire map which made maintenance a breeze we also had a player jetpack to account for which tripled the potential player height but with our cell count nice and low we added some logic first to support cell stacking here we were able to add three layers of additional cells to cover uh each potential player height from the jetpack this way the cells

remain nice and small to maximize occlusion we also expose controls within the world settings to allow for performance configurations within each map as well as mesh quantity sampling thresholds to circumvent fluctuations in the amount of meshes that we needed to process early on our development those mesh quantities would shift drastically this helped to provide us predictable computation times for computed visibility one last bit that was troublesome was how each run the pre-computed visibility system would generate fresh occlusion ids with every static mesh and store those ids and then the levels containing those meshes that typically meant dirtying every level within a map unless those levels were available to be saved he ran the risk of a potential update and essentially an incorrect id even when all maps were saved the id structure deteriorates rapidly

with mesh additions and modifications and you're stuck with a flickering incorrect uh occlusion queries uh with an up-to-date editor session though uh within with a not up-to-date editor session it can be very difficult to determine what to optimize so we modified the system to store the mapping ids in the persistent level tying the static mesh ids to their footpaths this provided us a system that would not determine and uh remain uh valid with our uh hybrid pre-computed visibilities now in editor we set up syn cameras to run through our maps not only to optimize and visualize our pre-computer visibility but also to detect other objects not including even when uh optimized even with optimized pressure collision uh given our sight line detail we still had significant draw calls overdraw by memory consumption we were averaging roughly 600 draw calls and gpu well

within the 20s and we knew we had to perform some form of texture at the scene and mesh combining so once again we looked into unreal's built-in performance solutions for what two solutions that stood out to us the hierarchical lotting system which is a automated system of mesh combining and the merge actors texture atlas and generation system both uh provide automation of essential optimization tasks but we ran into some complications the systems degraded visual quality either by overriding some of the customizations we built into our source materials or by packing some of the tileable textures into too small of a unique texture the systems were also kind of cumbersome to implement by our artist teams and in some ways were destructive to their workflows plus we experienced numerous lighting and geometry led transition box killing our immersion so we wanted to see if there was a way we could leverage some of these systems with some enhancements textures and audio usually accounted for

the lion share of our memory allocation we found that we achieved higher detail with 4k towable textures as opposed to numerous unique textures at lower res to increase variation we blended multiple tiling textures through mass regions and offset the tie line by object size this way we could kit bash our environments with very small uh base set of meshes and still achieve a diverse looking terrain through the use of uh custom parameters we could we could drive unique mesh overrides through a common master material but for this to be effective at reducing draw calls we would need to utilize hierarchical lighting technique that would support our customizations unfortunately that's where we ran into some snacks with unreal's built-in h-slot system so we set about to see if we can make some modifications to simplify its implementation make it non-destructive for irish workflows support custom material systems and see if we could also utilize it to reduce overdraw first off we modified how each lies a

cluster opting for a very simplistic approach parenting source meshes under an overridden exposed led actor lot actors are the invisible age slide actors in your level this provider is not only a readable deterministic system for our artist teams to define how their h-lots are clustered but it was also non-destructive to their workflows and by exposing the lot actor we could control key specifics including the ability to create our own customized each line meshes [Music] utilizing houdini we built a tool that could ingest and export a set of h-line clusters not only combining those meshes preserving materials preserving our material systems but also utilizing the exported navigation mesh to scatter visibility rays to remove triangles not visible to the player region taking that a step further each a slot would be resampled and lot at varying view distances to further decimate

non-visible triangles as well as to incorporate the correct set of source mass lods from that distance and the whole process was automated and batched over our server farm that meant we could run the entire process in roughly 15 minutes for a full map which typically uh contains somewhere around seven sub levels and 50 to 100 each slots each automation meant we were achieving far better results than what we could manually achieve and this drastically reduced overdropped and because the system was now exposed within houdini we could further continue to modify its performance functionality in situations where the sight line was still too expensive we leveraged tiered eight slots to call additional triangles visible from specific vantages here in the mouth of the cavern player could see the entire region below which is far too expensive to draw using a tier 2h slot we trim the

triangles from that particular vantage reducing the gpu once the player drops down the sideline is contained and we restore ourselves back to our tier one set of h lines the transition is not perceivable given the uh h law's effectiveness of reducing overdraw we opted to set our age slots to always uh be visible and replace the source meshes entirely this had numerous benefits from removing e-slide transition pumps lighting lod-pops saving memory by eliminating source mesh light maps and it improved the pcv computation time because we had far less static meshes to compute for pre-computed visibility and unreal's internal h-log mechanics allow for us to leverage the source mesh collisions which were instanced keeping our memory footprint nice and low for our collisions with our memory gains we

could actually go back through and increase the light map resolution of all of our h-lots despite the effectiveness of our egg slots we still encountered occasions of gpu performance drops notably during intense combat nothing breaks immersion like a game stall uh one thing that we pursued early on was uh to implement dynamic resolution on the oculus plus which currently functions on oculus rift by dynamically modifying the the render target size modifying the render target size though on quest was out of the question as it requires a reallocation of memory that is far too expensive instead one of our rendered engineers looked into mimicking this behavior by simply adjusting the viewport size and this had no incurred expenses once functioning we were able to gradually apply and remove this offset during moments of gpu overage which was really helpful in just a pinch those render side optimizations open the

door to applying a few render size enhancements we integrated the use of stereo layers in our game game menus and subtitles since stereo layers have drawn independent uh to an independent render target they benefit from crystalx and and displays with aliasing disabled one of our challenges though by our engineers to overcome though was to bring the hands over the menu we couldn't use a depth test on the menu as the menu would then draw behind other objects within the scene but instead we found a solution contained within the oculus sdk for android that allows for the creation of a poke-hole material which essentially acts as a depth layer to composite against the stereo layer another feature we added for increased reflection detail and surfaces was uh mobile parallax reflections this allowed for a lighting team to place specific lighting objects and sources to capture accurately reflected uh reflections within our surfaces another solution our radar

engineering team provided us with was the inclusion of decals and forward rendering unreal only supports decals in deferred but we were able to mirror a technique from a previous gdc talk that allowed for up to two decals per primitive vertex animation proved to be an efficient means for storing and delivering large amounts of animation data whereas a joint driven animation roughly kept out at about 200 to 250 joints per animatable object we found with a mobile gpu we could handily support upwards of 4 000 objects utilizing vertex animation this allowed for us to use traditional film tools for destruction elements as opposed to storing animation data within individual vertices vertex animation rigid bodies can store their animation per component allow for greater quantities we cover this with positioning but turning and interpolation to reduce the data to exercises as well as procedural overrides to further maximize game performance

the real's hierarchical uh instancing system provides an efficient means that uh clustered uh uh draw call reduction led support and viewport frustum calling for instances we tapped into overriding a uh per instance random float to pass in individual instance arguments to drive unique characteristics and control our instances one example of this was our customized foliage system we combined several offset variations of each foliage type into a single mesh and then use a texture driven vertex deformation along with unique baked texture analysis to create variation with minimal draw and gpu impact scene lighting was then passed into the emissive materials by pre-sampling the nearest light probes to each instance and baking those values into a column lookup table which we could then reference in the uh in the material using uh baked ids that were sent through the for instance parameter this approach scaled our viewable foliage from the 20s up to the 200s

another use case for instance a couple with vertex animation were crowds here we would take our traditional film crowd simulations extract extract per component animations and store that within the uh data texture mapping ids to the source of suvs for unreal uh on the unreal side we set up a blueprint system to assign and those individual instance ids from data files right now from houdini further variation can be achieved through packing multiple assets together as well as texture at the same variants and here's a wonderful example of that process delivered by one of our effects team members that really helped to bring life to black spire outposts combining these processes together was how we're able to achieve the final

growth system in the jedi legend for the engaging conclusion of part one of our experience here we needed a system that would spawn and generate corruption growth over various surfaces within our final map supporting hundreds of growing instance vines we really wanted to engage all the senses and provide you a means to interact with the environment with a lightsaber this would not have been possible without utilizing some of the techniques we presented here today in summary we learned a great deal about core performance optimization methods in designing a vr project on using those practices is a core foundation will only further increase the quality and breadth of our work on higher-end processors [Music] we'd like to give special thanks today for the support teams at oculus unreal engine gdc for hosting this talk and the entire xlab team from production engineering qa and the artist teams

we're really privileged to be here to represent them today and thank you for joining in our talk today star wars tales from the galaxy's edge part two is launching later this year if you're interested in hearing more about that please follow us on social media at ilmexler thank you
