Adaptive Virtual Texture Rendering in Far Cry 4

[Music] so my name is cotton I'm a technique architect at Ubisoft my job is to go to a different project and help them to build new technologies or improve the games last year I had the opportunity to work on far cry 4 and developed a technique called adaptive vortexes with this technique we are able to render thousands of details under a surface in less than one millisecond and achieves 10 pixels per centimeter resolution it gives our artists the freedom to place as many details that they want and achieve great result in Far Cry 4 so the content of the talk is divided into five parts first I will give an overview of

virtual textures technique then I'll talk about far cry 4 to wring rendering our first approach implementing a procedural virtua textures the problem with that will far cry 4 I know why we would like to develop a tab - in virtual textures after that I will talk about what this technique is how it works and why we call it adaptive virtual Texas then I will talk about the challenges we faced during the implementation of the virtual textures and how we solve them at last I will show some screenshot from the game talk about the performance memory and the give a summary vote for Texas is not a new technique it was first mentioned by John Carmack as mega textures from id Software mega textures Emily's a very large sniffing

of the textures this texture is too large to fit into a memory so it is divided into multiple equal sized pages for example the page size could be too 36 by 256 or 128 by 128 we allocate a smaller size physical texture cache in the video memory to cache the resident virtual texture pages we also use an interesting texture to map the relationship between the virtual capture page and the physical texture page the content of this interaction texture is used to translate the virtual textured UV address into physical texture address the virtual textures are used in some games for example mega textures in bridge and procedural virtual textures in battlefield 3 mega texture spray

bakes all the textures in used by the game into a very large virtual texture and it is stored on the disk the rendering engine that decides which page are needed depending on where the camera is looking at then loads the required page from the disk and update the page table this way the final socialists know the location of each virtual page inside the physical texture cache on GDC 2012 dice presented a new technique called procedural vote for textures it is bit different than the mega textures we talked about because it neither bakes the textures into the virtual texture in the tool not stream them from hard drive instead displays the Turing rendering into virtual textures at the runtime and

use this and a cache for future Fermi's rendering by doing that it can save expensive rendering cost of Turing material blending once they are cached in the physical texture and improve the Turing rendering performance since the missing virtual texture page are rendered by a graphics engine into virtual texture UV space the prime of the physical texture cache is much faster pairing to loading them from the disk so there is a much less vigil popping up comparing to standard for protectors our adaptive filter captures is actually based on based technique now I'll explain the basic fact I for Turing rendering pipeline and our visual target I also explain our first approach using procedural virtual textures for f4 is a cross-platform game with the bell on

both current and nourishing and the next generations it has a very large award as a ten by ten kilometer size the Turin is just divided into two parts fry distance Turin and the nearest ten stirring we render fattest anteroom by offline pegged geometry and the textures we call this vist artery the nearest entering is geometry is generated from the high res height map the rendering engine by blending for detailed material layers using a mask texture we also support road suppliers under decals to add unique details countering surfaces our visual target is as high as 1/10 taxes per centimeter so that the Turing surfaces are displayed with fine details when the camera is very close to the what mention that we would like to apply

our virtual touches on the edges transparent only to distinguish the next-generation platforms from the current generation we would like to add a massive number of details which will procedurally generated into the terrain to enrich the environment I'll show a difference between without and with procedural generated generated decals this is without and this in the web another example showing the different and indecent without this ill with the procedural decals we would like to achieve and unique and diversify the Turin looking by adding decals with the leaves pebbles sends cracks on the trees for example a simple deferred decals rendering would be too expensive to render details in this quantity and

quality so we are thinking about baking with decals interprocedural virtual textures as an optimization our our first approach is implementing a procedural work for textures we allocate a 512 K by 512 architecture and the page size in 256 by 256 we use an interesting texture to map from the vajra texture to physical texture the site is a 2k our physical temperature size is configurable and we set as 19 by 19 we have three of them they are arrow below normal map and a speculum the information for required virtual pages our computer are computed during the Jeep buffer rendering pass for every pixel on the screen without put on the

page index and am if enough level of the virtual texture into a full screen render target we call this page ID buffer we explain the format for this offer later in the talk we analyze this page ID buffer and CPU to see which pages are needed at which bitmap level with an allocated physical texture pages and the render both terrain material and the details into this page finally we update the interaction capture to be able to translate from the virtual address into a physical address these pages are cached in our physical texture texture cache according to a least recently used algorithm once in the cache the Terran sailor could just fetch from the virtual textures and we completely removed the rendering cost of tearing materials and details in the future and with

conventional virtual textures we used an interaction texture to map from the virtual UV into physical UV each entry of this interesting texture represents a mapping from the virtual address into physical address the content of this texture is used to generate the final physical memory location for the virtual texture page the format of this texture is 32 inches bit with the first sitting bit representing the final physical texture page offset and 8 bits representing the meta map level of this page the last bit is 40 Berg owning so procedural retro Texas works quite well to cache the rendering result of

the Turing and the decals as an optimization approach but there's a big problem for the far cry 4 since the standard the virtual textures applies the virtual texture onto the whole would uniformly with a 512 K by 512 K word protector on a 10 by 10 kilomettre would this means the texture revolution is only 0.5 texas per centimeter this is too low to achieve a 10 texas per centimeter resolution it will require 10 million by 10 million sized virtual textures this is definitely over the limit of the next generation platform so we need to find a better solution so allegory to develop a procedural vote

a Texas technique in a large award and achieve at high texture resolution of 10 Texas per centimeter this seems impossible when we applying the virtual Texas uniformly onto the wood but the one thing in our favor is that we only need that 10 Texas per centimeter resolution when the camera is very close to the terrain for terrain surface let a bit further away a v Texas per centimeter might be enough and into water require even less texture resolution when the pterence of this are very far away from the camera so G to find a way to apply the virtual temperature know uniformly unto the world based on the distance from the camera this is how our adaptive work for captures come into play now let's talk about adapting work for Texas it is

based on procedural virtual textures and it improve it by increase the texture resolution we divided our wood into multiple sectors each sector is 64 by 64 meter size for all need different sectors we will allocate a virtual image for each of them inside the virtual texture a virtual image is simply a square space inside the virtual texture and the size of this image increases for the sectors nearer the camera and vice-versa this is why we called adaptive moon for Texas we adapt the resolution of the virtual texture based on the distance from the camera to the sector nearest sectors are located at full resolution of 10 Texas per centimeter so we allocate 64 by 64 K virtual image for

the sector allocate less like 32 K by 32 ok or 16 K by 16 K the minimum size is 1k by 1k we display our adaptation of the virtual image inside the virtual texture as an overlay on it on the game screen mapped as the Red Square inside the virtual textures the colored square here represent the allocated virtual images for all innocent sectors every sector saves its virtual image UV offset and the size and that this information will be passed into terrain shader to determine the page ID and the map map level for every pixel on the screen now let's look at have a deeper

look at the allocation of the virtual images first we find two sectors nearest to the camera and we allocate to 64 by 64 sized virtual images then we found six sectors further away from the camera and we allocate 632 K by 32 key virtual images for multiple sectors that are even further way we allocate 16 K by 16 K virtual images we continue this process until all the additional sectors are allocated inside our virtual texture at runtime during each frame we calculate a target virtual image size for every sector based on its distance from the camera if this side is different than a curve the side of the sector we will allocate a new virtual

image as a tactic size and remove the old one now I will play a video demonstrating the readjustment of the virtual image for all the sectors during the team you will notice that when a player moves forward some sectors are becoming closer or further to the camera so that their virtual images are adjusted dynamically by allocating a new one and remove the old one let's look at some place here here you

will notice that there's a light blue virtual image is allocated with the bigger size when this sector is closer to the camera then later on it is removed from the virtual texture because this sector is behind the camera and it moves further away from the camera this two pictures show the obscuring of the virtual image when the camera moves closer to a sector the virtual image size is increased from 32k to 64k to provide higher display resolution and these two pictures shows the tongue skewing of the virtual image when a camera is the further away from a sector the size is decreased from 64 K to 32 okay as a higher resolution is not necessary now let's look at what happens

when we upscale a virtual image from 32 to 64 K our adaptive mode for textures need to be updated to reflect the changes of the virtual image under it make sure that rendering is correct a naive way would be render all the visible pages inside the new virtual image from scratch and update the interaction texture entries for these pages but this would be true slow in fact the read the rendering result of the terrine material blending with additional details is already cached in our physical temperature we don't want to render them all over again we could just shift them around by updating our interaction capture entries and reduce the content

since we're up skill scaling the image from 32k to 64k we realized that the mid map in the old image exactly the same as the mid map one low wouldn't even lower in the new image so we can accomplish most what do we need to do by remapping the virtual texture so that the old maps from 0 to 9 becomes the new mix from 1 to 10 now 32k by 32k virtual image contains 16,000 pages so we use a computer shader to rewrite the interaction texture note that the interaction texture contains the mid level so the modification need to be a little bit more complex than the simple copy of the interesting interaction entry we now demonstrate how to update the interaction capture entries to reduce

the mid 0 of the old image form it one of the new image for example we mark the map 0 fold virtual image as Red Square inside the virtual texture and it's related space in interaction texture we also mark the new virtual image map one inside the virtual texture and in architecture as yellow square what do we need to do is to remove the virtual texture so that we use the content of the Red Square in yellow square to yellow square so let's look at the specific interest in culture entries pointing to a page inside our physical texture as offset 3 2 and the middle 0 to reduce this

content we simply copy the page offset into the new place and a shift down the map by 1 we do this for all the pages inside the map one of the new virtual image for the pages in the new image from Neptune obtain the update are very similar as what we explained for the myth 1 so now we have updated all the interaction capture entries for maple one to be obtained in our new virtual image then what about the bit zero pages this page don't exist in the old virtual image because they have a higher capture resolution this pages need to be rendered in the next frame but in this frame we cannot live like that otherwise there will be some random color just played on the screen because these pages are not rendered yet into our virtual textures by the nature of the mid map we

know that form a personal pages correspond to one if one page so we will temporarily map them to corresponding lower page to prevent visual popping up they will be they will be correctly updated when the pages are rendered in the next frame as a result the terrine surface will look a bit blurred in this frame but in the next frame it will become sharp this happens very quickly during the fridge so it is generally not noticeable here we show how we up duplicate the interaction country to do a remapping we simply duplicate when mid one interruption entry into four corresponding map zero entry to remap the virtual texture we don't shift down

the mid level in this case and we will do for the when we'll do this for all the pages inside the module you'll notice that we set the mid level level as one only in Direction country instead of zero this will tell the rendering of terrain to display a lower mid level instead the pixel shader that handles the Turing rendering uses the interaction structure entry to calculate the final physical texture UV address it was shift to a scale that Buick on it by shifted nib level and I just play a lower lip level result I provide in the coolest limpid for your reference now let's look at an scaling a virtual image from 64k to 32k the process is actually the reverse of obscuring a virtual image again we

update the corresponding interaction touch entries to reuse the content of the old image in this case the maple won't return from the old image in the same as the mep zero to midnight in the new virtual image so we use a computer sheet to rewrite our interaction texture entries note that the mid ten pages don't exist in the old virtual images so we cannot remember on there but in fact that mix letter smaller than 64 by 64 shouldn't be utilized well our power by our word protection system because this page are very far away from the term from the camera and it is handled by a different rendering system which we explained before as far distance during rendering so in in reality we just

ignore these nips and they use a higher nib instead now as I'll explain some challenges we faced during developing virtual touches and how we solve them the first challenge is to reduce the memory footprint when we upkeep outputting the virtual texture page ID during the G before rendering pass our page ID buffer in 32 bits the first two bits represent the page ID and four bits for the mid level and the focus for the virtual image size we need to keep the data minimum to reduce the memory footprint and bandwidth we use 1/8 by 1/8 great

write a buffer instead of a full screen render target so that the actual memory is only one 64th of the full render target we have to set early steps of tensile attribute in the shader so that any pixels failing the depth test won't be outputted into the page ID buffer this is how our teams sing and page ID buffer look like caching of the virtual textures can take a long time when many new pages are requested in a single frame for example when a camera is moving fast we need to render a lot of pages this happens in fact cry for when the player is driving a vehicle or flying with the wind suit our solution to this problem is called distributed rendering we sought required pages by

their map map level from low to high lower milk map pages are rendered before higher web pages so if you're a rendering cost for the for the adaptive virtual textures is higher and the threshold for example one millisecond we will postpone the remaining Jaime pages into the next frames as a result we realize that transition from blood to shop for Turing surfaces in several friends but it happens very quickly so it is not generally not noticeable here I will show some two for continued frames when we do just stupid rendering you will see that the frame transition from blurred to sharp in four frames but it really happens very

quickly so you can't see it because our adaptive virtual textures can render so many details efficiently our artists would like to place a massive number of decals in the game but placing such amount of decals by hand is not a solution so in fact for with developed up procedural content generator to place these details automatically the artist can set rules to generate the decals like leaves sent stones on the trees and beside pushes with random shapes and the colors this really helps our artist director achieve our graphics benchmark here we show the road rendering with procedurally generated decals we mark the procedural details add as red

squares this has these are cracks thirds stones leaves for example an example with procedural details we place automatically the stones leaves sends and the trees and beside the bushes and we can we can have like thousand of them automatically attached using if we use a bilinear filtering for virtual textures the image will look like very blurred when you view the current surface from a very sharp new angle so we would like to support 8x and the tropic filtering for virtual textures but because of the nature of the virtual texture the neighbor physical texture pages are not necessary adjacent in the world space so there

will be a color bleeding when the textures are filtered across the page model to solve this problem we add a fourth Texas border to our physical texture page and our physical texture page size becomes to 64 by 264 we render the page with enlarged viewport so that the border pixels are rendered with color letter adjacent in the word space doing that we can support 8x electronic filtering nicely if we only do Ana stroke filtering with a bilinear filtering we could see a visible scenes altering surfaces when there's a map level changes in the area

so we need to do something better we support a software trilinear filtering for far cry 4 to fix the problem the solution is very simple we just fetch the rotary textures twice with two different mid-level and we do a line linear planning between these two colors to get the final color this works very well another solution introduced a hardware trilinear filtering you can do this by treat a quarter sized map one physical texture and you update this lip one physical texture cache whenever the mid-40s detection cache is updated so you basically keep two lips of the physical temperature in the memory now this would require 25% more memory for the physical texture cache our physical

culture is in Far Cry 4 used 200 megabytes in the video memory so we basically save about 50 megabytes by using software virtual type trilinear filtering under the performance difference between the software and hardware approach is very small in fact rifle here we can see with only bilinear filtering the image is very blurred and also you can still hear the seams because the image if you have the image that in front of that will for example a lower bitmap under the image below that is with the higher move now and anaerobic filtering makes the image quite sharp in this case but we can still see available scenes here during

trilinear filtering and anaesthetic filtering has a best result now I will show some screenshot from the game and talk about the performance and memory we only support adaptive virtual textures on the next-generation platforms rendered with procedurally generated decals on current generation platforms like ps3 and 360 we simply disable virtual textures and procedural details here we can see the difference between current generation platform and the next generation this is the current generation of this next generation

this is another example showing the difference between the current generation and the next generation okay under the example which I render and messing them up decals thanks to our adaptive virtual textures and they'll really enrich our environment by adding a lot more variety into the game we capture the rendering performance for adaptive virtual textures on ps4 the rendering cost are for adaptable for textures is less than 0.2 millisecond for Aesthetica C for dynamic scene where we need to cash a lot of work to attach of pages the rendering cost is a less

than one millisecond this is quite good because to render such amount of details with a traditional deferred decals rendering it would probably take more than 10 milliseconds so our deputy virtual textures is more than 10 times faster and achieve better result the memory usage for adaptive architectures around 220 megabytes here we have 16 sitting megabytes for in the ricean capture and 200 megabytes for our physical texture our physical texture is actually compressed into DHT and a PC format to save the memory and if this is done in the runtime using a computer shader so to summarize procedural virtual

textures is a good technique to improve the Turing rendering performance we use adaptive virtual textures to increase the resolution of virtual textures and then we can achieve a great visual result by drawing a massive number of details on fact for I would intend to right for rendering him and asked him for the support of a technique and also GDC advisory for the review of the slides I provided some reference for the virtual textures on the slide and thank you very much so if there's any question if you got free to ask us to send in front of the

microphone hiya great talk just wondering whether you you whether you considered using partially resident textures at all um whether you think that would fit with this technique yes we we evaluate the partial ability textures in working and we finally didn't use that because during the developing of the factory for the features is not completed on all platforms and the implementation is all different in ps4 and xboxone for example Xbox it's called a peyote resource and kiss voice and more like partially velvety textures using a virtual memory yeah so it is good to use a software approach because we can keep the same rendering API and uncross all the platforms and it's really a save a lot

of effort for us and it's actually the soft approach is quite fast it turns really slower than the hard way approach so quite good but in the future we might consider using that if because the I saw a small problem of the software software approach that you have to add for Texas border on the physical texture page like we explained for the futuring so we you might save some memory by using a hardware approach thanks one question do you use any kind of moral luck seclusion mapping or any kind of products mapping on a deep show on the terrain I think Paden do use any kind of parallax make a cake so you're asking any if I use any kind of parallax mapping for the Turing we have some kind of a parallax decals for a turian puncher for this detail so we don't render with virtual textures

because this depending on the view angle so we cannot really take them but in the future we are thinking about baking heightmap into virtual textures so you can have a kind of like facility you have achieved a hardware tessellations with votre textures so you save diffuse normal map and specular and also a 8-bit height map this will be compressed into PC format so in the if you use a hardware tessellation shader you can fetch this height map in the tessellation shader and you can get that directly from the virtual texture instead of rendering these decals with parallax so it's using a like tessellation shader instead or you can do whatever you want great well thanks I was wondering if you are allocating the

virtual texture pages dynamically to do AC correct that gets a two-time indirect fetch in the pixel shader thing repeated quick on the virtual texture UV coordinates of the try now video please but if you are allocating dynamic tight yeah it's so so I asking if I allocate to this virtual image dynamically yes yes I we do way like we said that we we have true talent Li and adjust the virtual image size depending on the existence from the camera so when when we need to change the size of the virtual image we have to remove the older virtual image and the create a new way so this is a really attendant Lee allocating so one thing I didn't talk

about that is that we have kind of the allocation system so you can just standing Lehrer move the other one and have the new one but it's a kind of like called tree style so there's not much fragmentation when you allocating a new and the rim the human soul it's always like a landing the power to so yes I had a question concerning your physical texture I was wondering if you had any issues with fragmentation on that texture and also if you had any issues with your with thrashing your your texture cache so yah steam if I have Fred imitation for the physical texture and if I have some trash you mean the fingertips show you the fool so in

the physical texture as you're allocating bigger and smaller textures into it uh-huh did you did you run into any issues where your fragmentation was filling it up bigger than you then then potentially it could hold we don't have a fragmentation issues because we allocated it's in size we every page is a to 64 PI to 64 so we don't have any fragmentation issues but we do have some kind of like yeah you the texture filtering cache could be full right because you are rendering in physics actually all the time so but we use like I said we use a least recently used algorithm so the least using physical texture pages will be swept out automatically and we render with a new physical with the new render into this physical texture so also we set the size of the our physical texture as a 95 90

so we we can just resize so we find a good spot for the correct size for our physical temperature so we don't see a lot of the swapping out and swapping of the of the rendering so otherwise you if you constantly swap out and you don't save much by using the virtual textures because you can only want to also achieve the result in the in the memory for for the terrain that in front of you for example but yet sometimes you face some problem and the way you grow very well you go forward and you turn the wrong there might be some issues with that but with all this computer rendering and the mid-level rendering you don't really see them so yes I see and the second part so did you did you do anything to minimize texture cache frog texture cache misses when you're

looking into your physical texture space do I do anything to make some eyes on my capture so your text your cache when you're when you're grabbing that texture to render your different decals sessions it could potentially look at all sorts of different spots on that physical texture and potentially your texture cache could get thrash and you need to pull in more textures did you run into any issues like that no we didn't see any issues for that the rendering of the Turing is very fast it takes less than one millisecond to run all the Turing on the details so I didn't really check check for that thank you so you mentioned that you rendered during the GBO pass deferred pass you ran the page AG's and then you said that

he use quarter-sized page at bar fire instead of full resolution does that mean that you actually shrink after the full screen different pass not a shrink the size to get it okay so the question of that if I render into full-screen run and tablet or if I run into a 1/8 size of the page ID so actually a rendering into a full-screen rental is our first approach then later on we change that approach so we do not render into a full-screen target anymore instead when we render into a 1/8 size so you know taking occlusion into into account if some tree for example or big stone or house occluding part of the terrain it still be in a page a deep buffer it still be like there's no no no

it's okay because I explained I didn't writing the you know slide but I have notes that I also talked that when you do a read write buffer you can set attribute in a shader you can set as only depth stencil so with that shader you any pixels that failing the depth test won't be writing into your result right offer so if it's occluded it we're going to be right and if you have true pixels which is behind that pixel and this won't be right again into your page no I don't I don't down that tongue size depth is it's it's cheaper for rendering pass it's ultimately timed by the shade attribute so it's like rendering to the render target the same as rendering to burn Connie but the difference that is if you don't at that attribute into your shader which without put all the pixels into your read write buffer but as soon

as add that shade which is attribute from shada from the sheet language and then it will do it same as the read the target but you can still render into the buffer so you don't render any pixel twice all you like that I've sort of two related questions first you mentioned that the budget for rendering new new pages was one millisecond right how many texels could you actually fill in one millisecond how many how many texts so I mean the the one millisecond hmm implies some kind of actual amount of texture you could actually fill for creating new MIPS so mm-hmm are you talking about - how many new virtual types of pages I can actually render well I guess

physical texture pages yeah physical texture pages I can actually render yeah maybe 10 20 i don't know me ten something okay because you don't really when you when you when the player walks in the team you they are not updated frequently right what so the related question is what about weird extreme cases like a player taking the helicopter and from when I get very close to the ground very very quickly like I'm hugging the ground so creating like a worst-case scenario where you're mmm zipping over the ground and you're sort of getting ahead of the cache yeah so I mean you mentioned that you fall back but are there cases where the the blurring of falling back can become actually obvious so yeah I mention I have a fallback to low res right virtru mid Maps right

yes actually you're right you could sometimes like when you really run a lot of pages in one frame and you could not finish and you have to postpone from the next frame right for example if you walk forward and know if you if you I can walk backward like like do this and you suddenly turn like 180 degree around you could see the pages like transition from blurred to sharp and sometimes it's quite obvious so we have a different algorithm for this so in this case we sort the pages according to that importance so I always render the important which is in front of me first then the page that are far away from me so you have a lot less visual popping up in this case that was quite quite well okay can I steal it here because it's

free frames of latency right your honor lies in CPU mean from GPU meaning it's gpiod back type of PC driver invokes free frames of latency so in that case exactly you mentioned you go you go in backwards then you turn around and although you can do that very fast when you realize what's happening but there will be free frames of reference chain you'll see blurred image we also have a like kind of like CPU page ID feedback so because the GPU page ID feedback will only feed back the pages that in your view first of right and the we increase that feel threatened a little bit larger so that some pages that beside you outside the view frustum

we are also included into the feedback of the page ID list but they are a bit like low res but still it helps because when you turn right like you said you have a free latency so it's already there so I think it will help and also usually you don't really see that much because a page is quite large so you always have the cash than you always referee's so most time it's okay I so um I just wanted to clarify from the question that was over there so you're actually you're rendering the scene again presumably with low resolution geometry at you know and 8/8 size is that right no no are we doing to render again we only render seeing one time I mean that cheap offer but we are put it into a low res range right buffer okay

right okay that was the bit that I okay so you're just selecting that based on some of the just yeah one of the one of the one oh yeah I should have said that right so you have like 16 pixels right and then you select one pixels because it doesn't matter because usually the page the new close pixels are sharing the same page ID right if we if we don't share the same page ID it doesn't really matter if you have all one level lower you move one X also only totally okay thanks different maps that used to pointing currently you talked about wanting to have eight maps later on mm-hmm but currently it's what the hues novels particular hmm what kind of thing are you managing with your virtual texture what kind of a map I manage with

the virtual temperatures so we have diffuse which is XYZ we have normal map which is X Y we have specular occlusion and we have roughness we have watch else I don't remember if I like that textures how much physical texture see you do the so maps normal map diffuse maybe you can utilize alpha channel yes that's right how many physical gestures and three yeah what are the Foreman's format diffuse is a TFT one normal map is bc v bc v yes and another way G actual one I think for

the normal map I have to use bc v otherwise the compression will be really bad and but this file is really great okay thank you very much [Applause] you
