The Rendering of Below

[Music] hello uh my name is Colin white uh I worked at cppy bar games working on a game called below and this is the rendering of below low complexity high density detail so what what is below below is a procedurally generated action adventure game um it is ired by Rog likes uh of old and it's mixed in with handcrafted content um here's some pictures that I find to be pretty cool to demonstrate the world of below uh the visual makeup of below is low geometric complexity art in the form of these uh 3D geometry um highres handdrawn backgrounds and an intricate display of moving Det details so this is

a short outline of what we're going to talk about today uh um we're talking about a making a dark game uh Dynamic lighting and the layering transform or skewing method that we used uh in the game and there are zero below related puns in this presentation uh let's see things get dark Into Darkness uh this was uh below is an intentionally dark game uh we really wanted to have negative space as a prominent uh visual feature in the game and the the thing that we're going to talk about today is the difficulties with uh making such a dark game um some of the things that we encountered were contouring uh banding and uh being unable to distinguish from uh darkness and the fact that users will adjust

their gamma um however they see fit when you eventually release the game so uh this is an example of uh contouring you can see that there's uh spaces of uh like um very clear areas where there's banding or segmenting of the uh the visual space which is bad we don't want that um here is a screenshot which is very very dark but we want it to be very very dark so we want to make sure that uh it it is intentional and the first thing you need to assume is that the end result will be on a poorly calibrated monitor or a viewing condition uh users will destroy the white balance and Gamma by cranking the gamma either on their television or within the game therefore you want to deliver the best quality image uh uh up

till that point uh so the one of the first things that we did at the studio uh to try and um level the playing field and make things better for uh um I guess uh development of the art uh was monitor calibration and it is hugely important it pro it promotes consistent art creation and it helped uh in our case uh reducing false positive bugs because we knew um that everyone was going to have a similarly calibrated monitor however it doesn't fix uh time of day bias which is uh the difference between uh your lighting conditions with outdoor light the the color temperature of outdoor light um trans U transforming to uh the indoor light later in the day so like indoor outdoor lighting um so what we proposed was a gamma correct pipeline um

through development of the game it it was kind of difficult to figure out exactly how you make a gamma correct pipeline because there aren't very many examples of exactly how you do it um so I just wanted to sort of summarize how we did it and uh hopefully other people can use that to do the same um so the first thing was uh bringing in gamma textures to your linear space rendering where you do lighting your postprocessing your color grading uh your your user gamma modification and noise and then you compose that to the back buffer um and on top of that you render you your UI and the back buffer uh will be in gamma space the same with the UI um so srgb is a color space uh which is perceptually uniform it's what most uh image editing uh tools uh Photoshop um other image editing programs use to

encode their color information you're going to want to make sure to use your albo textures which or your base color textures for your 3D meshes for your backgrounds you want all of that to be in srg srgb gamma space um also of note uh the graphics apis like directex and uh opengl cheaply convert between srgb and linear um and and that's something that you're going to want to use and then finally uh the back buffers will also be in this srgb gamma space uh linear space so linear space the reason that it's important is because gamma space is only valid uh between the values of zero and one if you want to do any lighting outside of that range uh you're going to be clamped to it and it it's not going to go it's not going to end well um so you want to make sure that you maintain your

intermediate results in your whole entire rendering pipeline up to the point where you put it to your back buffer in linear space and the types of uh render targets or Texture buffers that you're going to be using to do that are rgba uh well yeah rgba 16f R11 G11 B10 F or RG r10 G10 B10 uh A2 uh the one that we used primarily and Below was r 11 g111 B10 F uh cuz we found that that had the the the best um it had the best uh performance uh per cost ratio um so linear space the thing that's important is uh if you're going to do any effects uh post-processing effects or lighting effects uh that are physically simulated you definitely need to be working in linear space uh so anything such as depth of field Bloom

motion blur color grading uh tone mapping all of those you're going to need to to be doing in uh linear space uh so one of the problems that we had in gamma space was we realized that our color grading was introducing artifacts um and that was the contouring that I showed you before so we decided that we needed to move our color grading into linear space uh and what this did is it preserved the Precision of your your data in your render Target to the final transformation so uh one of the ways that you can do uh color grading is by creating a lookup table in the form of a uh 32x 32x 32 color Cube which we see right here which you can thenay into a 1024x 32 strip which we see here um which you can put on on

top of a uh a render from your game in Photoshop do your color grading export that and then import it to your engine and use that Cube to basically the the XY Z AIS of the cube corresponds to your input color and what's in the actual pixel is your output color and that's what what you can use for your color grading we found was that if you do this in Photoshop and you uh export it with uh 32-bit color or or 24-bit color 8 bit per channel uh your input texture misses a lot of precision and will introduce a number of artifacts so what we decided to do was create an in-game uh color grading tool instead which you see right here and it has all of the necessary function ality that we needed for uh

doing the color grading from Photoshop and it automatically uh converts the color values from linear to or from gamma space to linear space on top of that this allowed us to create the uh to create animations for interpolating between color grading scripts which we use in gameplay to uh Express a number of different in-game events and we're still using the the color Cube internally uh we just create the color tube and generate the transformation based on the color grading uh values that we have from our in-game editor and this helps a lot with the filmlook look of below um and it it became a a pretty important feature uh for the development of below so this is a picture of uh the color grading before

the in-game editor and the the better use of precision and this is after which honestly with these projectors is probably hard to tell but that's a pretty good example of why you want to make sure that you're doing the best that you can before you actually release your game so another thing that was a pretty prominent or important effect that we use in the game was a noise or film grain which we tried initially in the form of a Shader which has uh Burns scratches and pearlin noise but we found it to be extremely expensive and sometimes every every once in a while when the seed got to exactly the right spot you would see a repeating pattern which definitely didn't want uh we tried dithering um and that also it was just too video gamey it makes it feel like it's an older uh I mean we're trying to make a game that is uh inspired by old Rog life likes but not not that

much um so what we ended up uh landing on was a uh a noise generation generator um called the Wang has which uses binary operators uh you can see the code right here I'm not going to explain all of it but it uses binary operators um which makes it extremely fast um the disassembly on it is is is actually pretty pretty good um and it had much higher quality than the other uh noise generation and there was no uh distinguishable repeating pattern so this was before the noise and after which probably can't see too well um and uh yeah the the noise just a second before we move on the noise was really really important uh for breaking down that contouring even further to the point where uh it was really really hard to tell any of it at all and uh I think we're we're feeling pretty good about

the way that the the image quality is currently looking in the game so uh the final conversion to gamma space um you combine your lighting your color grading your user gamma and your noise to the srgb back buffer and then you render your UI on top uh which uh the the reason you want to render your UI on top is to make sure that you're keeping your UI and srgb space and if it's outputed directly to something that's in srgb space doesn't require any lighting doesn't require your linear space it it's going to skip the conversion uh from srgb to linear to srgb um and it it's the best way to go so moving on uh we it's part two uh let there be light or making a lighting system from scratch uh in the beginning with below we started out with a pseudo lighting system where there was a circle of light around

the player and it was very very rudimentary this was back when the game was heavily 2D um and the game was always EnV envisioned to be dark and Moody uh the requirements that we would need for creating this lighting system was uh well the reason that we needed to to do it was that our our game engine only supported a perspective projection and what we'll talk about later with uh uh the game is there's a uh orthographic camera that's required for the skewing method that we use to render the 3D meshes and there are handdrawn backgrounds and the combination of both of those things require us to use an ortho camera um basically it's to make sure that the 3D meshes are rooted directly onto the uh handdrawn backgrounds and if there are any Sprites there is no perspective Distortion around

them so what if we added Dynamic lighting to the game uh we we started with a deferred lighting system implemented that whole thing we found it to be pretty good but then uh it it was really slow on Xbox because it's really hard to fit um your render targets into your esram so we decided to try and create a tiled forward lighting system that would Leverage the power of uh the the Xbox um so it starts with a compute Shader that reduces the lights to a spatial subdivision of tiles uh in our game it's uh 16x 16 World units which corresponds to approximately 16 x 16 uh screen space units um and we divide it into those tiles and then for each of those tiles we call a list of lights ahead of time before rendering the GE geometry we then packed the lights uh

using a bit mask and we were able to use ASN compute to do the light culling uh operation at the same time as we're doing other things which I believe were the uh the shadow rendering and uh a few other physics based uh simulations so yeah and ended up being a big win um so yes when you're lighting when you're when you're actually evaluating the lighting is when you render your 3D meshes and at the time of the pixel Shader of your 3D mesh you unpack the tiles Cold Light list uh and the way that we we we did that um and and I'm always looking for uh neat optimizations and the best way to to use uh to leverage uh Shader code or or Shader optimizations and and what functionality

is is out there to best optimize stuff cuz that's what Graphics programmers do often um and the the interesting thing that we were able to do uh was use a count bits function and a first bit High to scan through the bit mask really really quickly and unpack the the lights and you can see that that code right there but I I I should add that uh the the binary arithmetic for uh doing these things um it is really really fast on on gpus and it's something that uh was really really helpful in optimizing the game uh the other thing of note is that uh the tile for lighting system works really really well with msaa uh originally we were trying to use a deferred lighting system that deferred all of your uh your geometry information such as the normals the bo uh the any

glow that you're going to do any world space information to uh texture buffers render targets um and if you're using msaa it's going to have as many samples as actual memory and that is extremely it's disproportionately uh slow for msaa whereas tiled forward lighting your lighting evaluation only happens once per pixel and with uh the tille forward lighting system you're not required to defer as much information and it ended up working out really well with msaa and msaa we ended up kind of needing to use because uh postprocess anti-aliasing uh we didn't find that FXAA was pretty was very good um and temporal anti-aliasing would become really really difficult to do if you were doing any type of um or it it become very difficult to do if your

geometry is really small and you need to and and the temporal aliasing of whether pixels render or don't between frames is going to be ex extraordinarily high so yeah it helps with small geometry um so Point Light Shadows one of the interesting things that we tried was uh dual paraboloid Shadow Maps um you can see one of the hemispheres of that right here uh we tried doing that and there were difficult steam issues because you actually have two hemispheres that you are sampling between when you're trying to check for your shadows and anytime the geometry goes through the center of the light it would warp the the vertices and create a lot of interesting artifacts um so we decided to use Cube Maps um Cube Maps the the downsides are you've got six faces to render and in below typical scene is hundreds of meshes and that's a

lot of geometry geometry to render therefore uh your your CPU time is extrem extremely valuable and Gathering lists of geometry is is something that you don't want to spend a whole lot of time doing um so here's a little animated gif of uh what one of those lights uh shadowcast would look like and what we did to optimize this process was create a conservative volume of your lights and your camera and we multi-threaded the calling of the lists of that geometry to run simultaneously across many cores on the Xbox and it ended up working out really really well and uh it was a good performance win as well um so one of the other interesting point light shadow optimizations that we had was we used a geometry Shader to replicate the geometry to all of the different faces of the cube map and we

were able to do that in a single draw call um so what was the impact of creating this lighting system in below uh one of the things was um as a result light became a resource in our game that it's craftable it's something that you can create it's something you get from defeating enemies which allowed us to make really dark areas that as you can see here it's almost Pitch Black back so it also allowed us to think about what happens if the player has this control over light can we allow them to light up a room essentially creating a bread crumb path for them to follow um and it gave us the confidence to make the game even darker than we initially anticipated so uh um and

then sorry I'm running a little late so another issue uh or another thing that we found um by creating this lighting system was it allowed us to um interact with have enemies interact with light it allowed us to do things like create light volumes which we then use to activate switches and we even created this thing where lights will reveal hidden objects and that whole thing piggybacks on the lighting system and it extends all the way to lights that are actually hidden by other lights so you can use a light to reveal this hidden world that's filled with lights that will then for example in these uh these videos illuminate the character whereas it would otherwise not be uh visible so so the the moral of the story is that if you're going to add uh the

ability to create light uh in your game for Game playay you better make sure that it scales as well as possible so here is uh part three uh things get skewed uh we're going to talk about the skewing method of how we uh rendered the 3D meshes in the game um and how it gives or sorry if you want to know how how it gives the authentic and original perspective of the game from an artistic perspective uh go see Dan my cooworker Dan Cox's talk uh on Thursday uh March 2nd uh room 2011 in this building I believe at 3 p.m. um and uh this is a picture of a a very very Shameless pug um so the origin for our skewing in the game is that every time you die you come back as a new character so we

wanted to demonstrate that with uh randomized uh outfits and in order to do that uh originally we had Sprites 2D Sprites and if you were to try and do all of those uh outfits in Sprites it would be an immense amount of data it would just not work out it wasn't possible um therefore we tried to figure out how we could render 3D meshes with the ortho camera because of the uh the handdrawn backgrounds and the first thing we tried was rotating everything along an axis uh the one parallel or uh tangent to the camera um which was okay at first however the Shadows that we added uh which came later uh didn't match and that was a problem the other problem was that when geometry interacted with other geometry um it it it it created a lot of issues uh and

um yeah and then finally uh there were issues with attachment where if you attach an object to another 3D object with the rotation it became really difficult to make sure that that worked properly so uh in our game the skewing method that we used is uh uh the camera is top down on the Y AIS and uh the screen space coordinates are x and z so what we do is we move the vertex position in the Z axis based on the Y position and then we push the vertex position uh in the Y AIS towards the camera based on the ZW World position and we do this for all 3D geometry that's been rendered um and this is a demo of of how it works this is that was the regular game view now this is our 3D world view this is what it looks like like without any of the the skewing and

then when we press the magic button to do the skew you can see that it pushes it all towards the camera and aligns it in a way so that it it works almost as if it was uh rendering towards the camera um but it allows us to create a depth buffer uh which has all of the important information that we need to do effects such as uh um screen space ambient occlusion depth of the field volumetric fog of War um all of these things require a world space position and with a depth buffer that contained all of this information we were able to uh do all of these things and here is a example of the uh game before the fog of war and then once it's been uh composited in you can see the uh U pillars are rising out of the fog it

looks pretty cool and then uh we're able to with the world space information uh deduce uh or create the ssao effect in conclusion uh indie game development is sometimes crazy um and a lot of the things that we talked about today weren't necessarily the fastest most optimal way of creating something but sometimes you take the the easy route because uh you're small teams you don't have the most time in the world and you're just trying to to do the best that you can and lastly with respect to the uh layering transform uh sometimes you get stuck with weird systems and uh sometimes uh Reinventing it would uh take too much time or or take too much risk um but sometimes these weird things give your game its charm and I think uh below is a pretty Charming game thanks for [Music]

coming so we have some time for questions uh does anyone have any cool um well I will go over oh hi hello uh so I noticed you do most of your lighting computation on the GPU but then you use that for gameplay mechanics did that cause any challenges because all of the final computations like the volume were on the GPU correct yeah and so did you have to uh move that data from the GPU to the CPU to uh do the game play based on yeah yeah sorry um so to answer your question uh we did all of the gameplay based uh light Li in computations uh on the CPU uh all of the

the lighting information was coming in from our uh Lua uh light scripting system um we we brought all of that light information in we put it uh through to C++ and then from there sent the the light information to the GPU but basically in between when you do the light coling the the coling is doing a bunch of those checks uh on CPU so it seemed like a pretty good place to figure out those results uh most of the time when we were uh referencing the uh gameplay based uh light checks those were happening uh multi-threaded while we were doing the the calling of the lights on CPU [Music] thanks any more questions um I'm probably going to go

over to the the other area so if you have questions and you don't want to ask uh here I can answer them there thank you again
