Cloth Self Collision with Predictive Contacts

[Music] okay let's go going so hi everybody my name is Chris Liu I'm a physics engineer I work on the physics team frostbite which is EA's game engine so I've been asked to remind you not to video this and to fill in your evaluation forms at the end so thank you in advance okay so one thing I'd like to point out if we start is this is physics talk but there's no mathematics it feels sort of foolishly simple when I remove the maths from it so I would appreciate if you pretend that this is really difficult if you want to see that stuff then you can download the technical report that I've written on it right now which does contain all of the grisly details but this is only half an hour so I don't really have time to put those in here okay so what is self collision what is this all about so most people are familiar with cloth

and are familiar with the sort of attractive shapes that make on a body and in games we often want to capture these things in some way whether by you know just putting it in a in a normal map in a texture or by animating it or by simulating it more recently in games the more common way to do a lot of different types of clothing has been to simulate it because the clothing is likely to be attached to a character that the player has control over and in that case it's very difficult to capture all the defamations that the cloth can go through just with like traditional orphan means so self collision is the phenomenon where the cloth collides with itself and it can wrinkle and get into piles maybe you can knot it and you can have layers of cloth which slide over each other and the the layered clothing use-case in particular covers a lot of different types of clothing most of which you're probably wearing right now so I would hope you're familiar with that so let's talk very briefly about how you go about

simulating cloth like in a basic level most production cloth simulations that try to be real-time do some kind of non projected gauss-seidel solver which sounds kind of unpleasant but what it really means is that you have a series of constraints between particles and then you just go over those constraints and solve them so that they're satisfied so you might have length constraints which cause the cloth to maintain the same length and to solve that constraint would mean to go a for each constraint and say well is it longer than it should be if it is then we'll shorten it so that it's the correct length or if it's shorter than it should be well lengthen it so we use the length constraints to constrain the the stretching of the cloth and the shearing and the cloth and also the bending of the cloth and if you've got this on a run time character then you probably need a bunch of other constraints to keep the cloth in vaguely the right sort of place and we have a lot of different types of these but one of the most basic ones is that we just have an anchor constraint which is a

sphere that the cloth point can sort of live in where the center of the sphere is defined by the animation that you put into it and so in the absolute worth case where all of your other constraints have failed to keep the cloth in right place you can always be certain that it's never going to stray too far away from where it where your animation would have put it and then we also have contact constraints which is you've got some sort of collision representation of the body underneath the cloth like maybe a sphere for the head or a capsule for the arm and you need to make sure that the cloth stays on the outside of these colliders rather than going through them otherwise they will be very good colliders and for that we use contact constraints but wait a second why am i representing contact with something like a sphere or a or a capsule as just a plane so I'm going to talk now about discrete and continuous collision detection and what it actually means to use contacts and the relevance of this will become obvious later when I talk about how this concerns self collision

okay so sort of obvious way to do collision detection in a particle based simulator is to do it with discrete calculations so that basically means that you don't worry about the velocity of the point say you've got in this case we've got a like a capsule and there's a point which is inside the capsule and you can very easily work out the correct way to push it so you push it out by the shortest path and that is resolution of your collision and it's not too difficult to work out whether a point is inside a capsule or whether a point is inside almost any other shape but there are a lot of issues with this approach when you start considering velocities of the points and maybe the colliders have velocity as well maybe they have a translation and a rotation and in that case you start getting issue issues like this where if you're doing discrete time stepping where you have one time step and then 30 milliseconds later the point has a velocity which puts at the other side of the collider then when you say oh it's inside I would have pushed it out it gets pushed out the wrong way and this

will show up in your conten simulator as colliders very easily pushing their way through the cloth and that can be very distracting and there are other issues like if their velocities are high enough that it never even touches the collider then you won't notice that at all and and that will I mean that's the classic bullet through paper Effect 4 you see in a lot of old-style physics simulations but there are more pernicious issues like for instance even if you don't even have any velocities in your simulation at all every point is probably connected to some other constraints which are going to pull it around and so let's say in this case they've pulled it into this configuration and that's the other side of the collider from where it started the beginning of the frame and when we push it out it goes to the other side so you you can't just look at the velocities of the points because there's going to be some other movement generated by other constraints in your system so discrete collision detection has a bunch of issues with it which we

would like to fix so a classic way to try to deal with this is using some form of continuous collision detection and for the purposes of this I'm I'm using continuously in detection to mean collision detection that considers the velocities and trajectories of the things that are trying to stop them from interpenetrating kind of a most basic naughty way of doing this is just to subdivide your time step into as many time steps as is required you just run your simulation at like 4,000 Hertz or something and then as long as your velocities aren't too high you'll never get to a point where things move too much in one time step but this is obviously hilariously expensive so we don't do it so another thing is to do some sort of closed form calculation between your your objects and work out in this time interval from like zero to one between two different frames are they actually going to hit each other and even if even if they're not hitting like at the beginning state or the ending state there might be some state in between where they've barely

intersect and you can also work this out it can be very expensive for some kinds of primitives it can be reasonably cheap for others so it's not a good general solution to the problem and then the remedy for this that we use that I'm going to talk about now that we use in our cloth simulator and also most modern rigidbody simulators use we called predictive contacts some people call that speculative contacts but the idea is that you you kind of reject the idea of the idea the second thing where you're trying to find the time of impact between two objects and you say well actually I just want to know if they're going to be vaguely in the same sort of spaces each other I don't want to know exactly if they're really going to collide I just know that if they're near each other other constraints may push them around so that they will be going through each other so I just want to have a sort of fuzzy idea of when they're going to be in the same place as each other and if we think that one is going to go through the other then we can generate a simplified representation of the collision which is what we actually solve in our solver so in this

case we say oh it's probably going to go through the capsule so we create this plane and then when we solve this constraint we push it out of the plane instead of pushing it out of the capsule and even though it doesn't go to the same place that it would go to if we heard like solve a fully continuous problem the critical thing is that it stays on the right side of the capsule so your cloth is going to stay on the right side of your limb and that's very important for like the fidelity of your simulation so how does this deal in some of the cases that we were looking at just now so in this case where it was going to go all the way through we generate a contact and it stays on the right side of it in this case where was going to go partially if you're gonna get pushed out of the wrong way we do the same thing and in this case this third case illustrates that we need to use some kind of fuzzy logic like a radius that says if the things are going to be close together like within some epsilon defined by how how long our constraints are then we need to generate a contact even if we don't think they're going to hit each other due to their velocities

and in that case we we pull the particle through due to some other constraints and it gets pushed out again in the right direction and this really helps with issues where like for instance you've got some cloth that's rubbing over a Collider that's bearing a heavy weight that's going to be pulled down by the other constraints it needs to be pushed back up again in the right direction so what are the conditions for creating a contact well if the point starts inside a Collider and obviously we need a contact to push it out if it starts in the air to the collider then it might be pulled inside by other constraints so we need something to know what's going to stop that from happening and if the velocities mean that it's likely to be within that radius of the collider then we also need to generate a contact so what's the practical difference between two these two different types of collisions so here are two gifts which demonstrate the difference and it's quite like substantial we have this capsule which is going to move it's not like teleporting it's moving in one frame from one side of the picture to the other in the case of discrete collision detection where we only test at the beginning or the end of the frame it

doesn't even notice the cloth doesn't notice that the collider has done this but in the predictive context case we get the cloth reacting in a pretty nice way so there are a lot of artifacts associated with using predictive contacts like for instance you can get fake collisions the collisions that wouldn't really happen if you subdivided the time step but generally these are much easier to ignore than the problems associated with it it's doing discrete collision detection which is that your your cloth will just go through stuff so this is a nice improvement so now let's talk a little bit about self collision and then we'll unite these things together and talk about self collision with protective contacts so self collision is cloth against itself but we also use it to mean cloth against other bits of cloth so for instance in these two situations I've got two bits of cloth which don't collide with themselves they just collide with each other and at a local level in terms of generating and solving constraints these two problems are exactly equivalent to each other so there's the others no difference so here on the Left we have point point self collision you need to

choose which kind of creamy in your cloth you're actually going to like run these calculations on so you might say well it's a it's a triangle mesh there's points in the triangle mesh I'm just gonna put spheres around these points and make sure that the spheres don't go through each other and that is one way to do it but you can obviously see in this gift that there's a critical error with this which is that if the cloth stretches you might get gaps appearing between these points and that's not going to look nice when the cloth gets entangled or it slides through just because your tessellation isn't regular enough so one way you can deal with this is to run a full mesh self collision which is where you use the triangles rather than the points and as you can see on the right this enables you to make the cloth much thinner because there's a continuous surface and you don't need to worry about gaps appearing and generally this results in much higher quality so this is what we've mostly concentrated on doing so let's take a quick look at how you would implement point-point collision first so here's a sort of simple example of the sort of thing you can do with this so in

this case you've got two particles both of which have some sort of radius and we're trying to work out if they're going to be within a certain distance of each other within the frame and this is actually not too difficult to just solve exactly having spent some time slagging off time of impact calculations this is not a difficult problem to solve it's just finding their closest distance between two lines so this is not so bad and you can work out oh they're going to be quite near to each other so we need to generate a contact to stop them from going through so once we know that that's likely to happen we need some sort of representation that we're going to put in the solver and solve later and in this case you need to choose some sort of normal that you're going to push them away from each other along and what we do here is we just choose the normal at the beginning of the frame you could choose the normal like at this point the point at which they're touching but we found this doesn't result in great behavior in terms of like robustness so actually this works fine as just you

just choose the discreet separating direction of the beginning of the frame and make sure that they don't penetrate when they're pushed like a long van normal and that will keep them the same side of each other as they start at the frame on and you can encode this with just the the index of each point and the normal said that you know which line to project them long so okay let's look at full mesh collision now in order to make this robust you need to do two different types of queries so there's point triangle on the right-hand edge edge on the left and if you don't do both different types of constraint then there will be some configurations that you can slot your cloth together in that will cause it to be able to interpenetrate so there's actually two different types of constraints that we need to generate and solve here so let's look at the point triangle case first so what this is much harder to solve exactly than the point point case and the reason for that is that contrary to what people most people

are used to in games industry all the points here at deforming so there's no like rigidity that you can deal with and stuff like ggok isn't really going to help you here so what you can do is you can't write down the equation that describes the distance between these primitives so we've got a point on the left it's got a velocity and we've got a triangle on the right that's got some if each of its vertices have velocity and if you write it down you get a sixth order polynomial and then effectively what we're trying to find out is does this sick little polynomial intersect some some distance value at some point during the time interval between this time step and the next time step and if it goes below that dotted line then what we probably want to generate a contact because they're going to be near to each other but it is not nice trying to solve this equation and actually even if you ignore the part where we've got a radius on these things and you literally just try to find out if the point is going to touch the triangle itself that is still

a cubic polynomial that is very difficult to find the roots of and it's like a current current research problem in cigarette papers to try to find an efficient way of doing this so we really didn't want to do this but this is the games industry so of course we have unsupported hacks to deal with this so notionally what we are doing I call it a dynamic collision radius maybe that doesn't quite describe it very well what it is is we are looking at the discrete problem at the beginning of the frame and then we're making a bunch of assumptions that are not true but they help and then we're using those assumptions to work out if we should generate a contact and if and we have a parameter that we can we can tweak which enables things to be more or less conservative and the idea is that we should be really conservative if we want things to be if we want the behavior to be good well we will generate far too many contacts but that's ok and effectively what we're doing is we're just looking at the slope

of this thing at the beginning of the time step and we're saying oh well that's gonna go that's going to hit the green line so let's just generate a contact and we can make the green line higher and that'll make it more conservative will generate more contacts but that's okay so how do we go about this we've got these points for certain velocities we can look we can find with without too much difficulty the discrete separating direction between these things the bending at the time step so that's just finding the closest point between this point in the triangle that's not so bad and then we're just going to do all of the rest of the problem along this separating direction ignoring the fact that the separating direction changes as the time step goes on so we project all the velocities that we have of these points onto this direction and for the triangle we can look at this the closest points to being in the frame and we can use barycentric interpolation to find the velocity of that point to the beginning of the frame we say oh okay these things are going to be getting close to each other along this separating direction and in this case it looks like they're gonna touch so let's generate a contact and the nice

thing about the point triangle case is that you actually don't need any floating point data at all to solve a contact between these things because the the triangle has its own normal all you really need to encode is which side of the triangle the point started the frame app so that means like which side of the cloth did it start is the back face or the front face so that's all you need here so I talked about this dynamic collision radius business this is the approximation that we do like to to true to continuous collision detection here's a comparison that shows you that this is a useful thing to do actually so on the Left we have the dynamically generated turned on and on the right it's turned off and there's very obvious intersections in this tape when we run it so this allows you to generate contacts that you wouldn't have generated otherwise and one contact can be the difference between your tape getting inextricably tangled with it with itself and it being perfectly fine okay so the edge edge case we deal with

similarly to the point triangle case which is to say that we look at the discreet separating direction of the peeling of the frame and then interpolate and then at that point we have these two virtual points along each line which we can then apply the exact same constraint that we do in the point point case it's just that these points are like virtual points along each line rather than real points actually in the simulation and it it's just one extra level on the math so it doesn't make it much more complex in this case we do need to store a normal because edges in a mesh don't really have any global orientation that they don't have any intrinsic orientation you might be able to generate some orientation from the mesh neighborhood but we haven't looked at that yet and if you want details on this I have to exercise the details because this talk is short but you can see them in our technical report okay so if you've done physics then you know what's coming up next we talked about the broad phase so we don't do anything particularly special in this case

obviously you don't want to look at every combination of triangle and other triangle in the mesh so what we do is we just have a basic AABB tree we look at the trajectories of each primitive so if you're doing point versus point then it might be an ABB tree that contains the points as its leaves or it might be triangles and we expand them along their trajectory during the frame and then we just expand them by the radius of the things concerned so if your cloth it's quite thick then we expand it by that we also have this extra static collision radius on top which is like the epsilon of which if things are close enough then we want to generate a contact anyway so the takeaway for this is that we end up creating quite a fat AABB tree and that means that because because I'll method for getting things to be robust is to add radius to all of our primitives so our things are quite said of Cuba in fat and that actually means that stuff like a k-dog tree like more complex primitives probably not that useful for this algorithm that's nice

because this is nice and simple and yes I put Erickson real-time collision detection there that's the orange book that you should get if you're interested in this so we unite all these things together into a tree and then we can query the street to find pairs of things which may be intersecting and we can do our narrow phase collision detection or contact generation on those pairs okay so let's take a quick look at how things are offered here this is a very fast-paced video so I'm gonna have to talk quickly so we've got this Maya plugin here which allows you to real time simulate and tweak the cloth simulation so we've got a region system here which will allow you to set up different regions in the mesh so here I'm painting this with the blue region so there's two regions here and then you get this the bottom thing here which I'm about to edit you get a lower triangular matrix which lets you choose which kind of self collision you get on these so here I've chosen a point point so the these two regions are going to interact with each other via a point point collision detection they're not going to interact with themselves so here you can

see that oh it looks alright and you can change the radius in real time rather simulation is running however you can see that one piece of cloth is hovering over the other so there's obviously not great and when I decrease the radius one falls through the other so yeah we're not keen on that and it turns out that in order to make point point collision detection robust you need to make your points very thick which is not good so here I've changed it to use full mesh motion detection instead and when my mouse catches up to it that's gonna yet turn the debugger going back on and you can see that I can make it much thinner and like closer to the thickness of a real piece of cloth and you see that it flops down nicely and stays nice and stable and there's a less of a shadow between them so you can see it's a bit more believable and I can turn down the radius to quite small and it stays obviously you turn down the radius to 0 then our method fails but that you can make it fairly realistic yeah

so that is our basically our whole authoring pipeline so let's take a look at some results I when I started this I was kind of comparing it with methods from the academic literature from cigar papers so that's mostly what my test case as well and you'll see that the performance numbers are atrocious but this is just to show that we can do the same sort of stuff as you would do in a high quality simulation so here we've got a tape and it's uses triangle collision detection and it and you can wrap it around nicely and you don't get any nasty jittering or anything it's nice and stable and here is another classic test that you may have seen if you've seen cloth papers from Segura cloth which falls onto a sphere and it curls round and if your simulation is working badly then it'll generate a lot of self intersections at this point but ours remains intersection free however this is one second per frame so yeah you can't put this in again so okay what happens if we try to do something a little bit less ambitious

so here's something that's like just a couple of layers of clothing over each other maybe there next to it like the leg of a character something like like a tighten mark from destiny might look a lot like this if you simulated it with cloth so we can see that immediately they just get entangled and they never disentangle and the reason for this is that like I've put a very violent violent animation on this like leg collider but this is totally representative of the sort of stuff you might find in a game because game characters are super human in terms of the motion they can go through so this is a completely unacceptable situation and you can make this robust but it's really expensive for something for such a tiny piece of cloth it's really not worth it so what can we do about this well time for more tricks and hacks so in this case we have layers of clothing and actually we're being really dumb because we're looking at the beginning of every frame which side of this point locally is this triangle locally but actually we know that one layer should be above the other layer that's like

global information that we can just set up so in this case we say okay well I'm just going to hard-code which direction like which side of the triangle the points should be and when you generate the contacts you just override where was the beginning of the frame and you can see that this actually becomes completely robust as a result so if your points get into the the region where they would generate a contact even if it's on the wrong side of the triangle they'll end up popping up to the right side and this was pretty nice I'd like to point out here that the upper layer of cloth does not come by with the collider it only collides with the cloth so all of that motion from that is it comes out of the self collision and this is not 0.2 milliseconds per frame so they're still reasonably expensive but it shows you can get robustness with this kind of material and here is another situation which kind of exploit the the layered clothing idea as well you've got like sort of a like a model of a flamenco skirt I guess and there are some leg colliders underneath there that you can't quite see but it's just being

jostled around and you can see that the the two layers actually slide over each other quite convincingly you don't see them penetrating through each other and this is three milliseconds per frame so this is again even though it's still quite simple it's kind of outside the realm of of being put a bullet being able to put it in again okay so it's still expensive what are we going to do about this well in the case of layered clothing which is actually a really big like subset of the sort of cloth that you would want to simulate in a game most bits of cloth only stay within the same sort of region of other layers like all the time so why are we wasting a lot of time doing collision detection when we're just going to end up with us basically the same results every Frank so what you can do is you can just like do the collision detection once at the beginning or even in the pipeline and serialize out the results and then you can solve these contacts every frame and just see what see what the results look like I mean you may be solving contacts

which wouldn't have been generated if you had run the collision detection but that may not be a huge deal so in this case this actually works perfectly and you see no difference at all so we're now longer we're no longer doing any collision detection at run time we're only solving the contacts and it cuts the the total cost of the simulation by an order of magnitude so as long as your cloth looks like something there's isomorphic to this in some way you can do a very efficient emulation using this hack so I was asked to provide a game ready asset and much sweat and tears later here is Darth Maul from Star Wars Battlefront 2 and thank you to the battlefront 2 team for letting me have this so he's got this layered skirt on if you play the game you'll see that the cloth simulation on it looks good but it it doesn't have any sort of layering and here he's just running through some calisthenics animation I mean I did this the simulation myself so it's missing some

like art polish but what I want you to notice is that the layers may penetrate through each other like momentarily when he's going through some very violent animation but they always resolve to being the right side of each other and that's what's important is that the steady-state be not obviously broken game is a very resistant like very happy to be shown stuff which is broken as long as it doesn't stay on frame for too long but yeah so he can go through these unrealistically violent animations and it always ends up in the right place and it it matches like the art-directed pose so this is like a real time simulation and it turns out that you can make this not overly expensive so in this case the total cost on my PC is three hundred and eighty microseconds for the entire solve and of that 150 milli micro seconds is the self collision constraints being solved and I

should also point out that our cloth solver is not is not multi-threaded and most of it is Cindy but the the self collision stuff has notice Indian at all so you could potentially cut that cost by like three times so if you have the right kind of asset self collision is is totally something which you can have right now for not too much expense and I would like to point out that as I said I'm not an artist so probably other ways that you could make that stuff less expensive but I didn't have enough time to make that happen okay so what what sort of directions is this going to go in so as I said there's performance left on the table there's other things we could do especially with the rails of the board phase if we wanted to invest in actually running collision detection obviously if you're not running it then you don't need to optimize it another thing is that the contact caching which I talked about is very naive so we literally just generate the contacts as if we were doing it in in a regular simulation time step and

then serialize them but maybe you could have some kind of editor which will let the artist say well this triangle contacts with this point and not this one and that would probably allow you to deal with some edge cases which which wouldn't look good with this current system and of course I've shown you all these layered clothing examples and tried hard to convince you that this is a good kind of self relation but there's lots of other kinds like tying knots and scarves and like dropping tapes on the floor and we don't really have a performance solution for these right now because it's very difficult to predict which bits are going to contact which other bits in a given simulation so in that case you might have to do some genuine continuous collision detection with some sort of time of impact query all use the GPU of course that's always a big hammer that you can throw at problems so thank you very much for listening to my talk and I'd like to acknowledge these people and remember there's a technical report and frostbite physics is hiring so come and talk to me

after this and yes I think that's it so thank you very much [Applause]
