Tile-Based Map Generation using Wave Function Collapse in 'Caves of Qud'

[Music] why are we here uh caves of cud is a game that i develop i'm brian buckley i'm a co-founder at freehold games caves of cut has a ton of procedural generation we use a bunch of normal techniques that you've heard of perlin noise etc and we use a few novel techniques and today we're going to talk about a specific one wave function collapse which sounds scary but i hope by the end you'll realize it's not particularly terrifying so we're going to first start by looking at some final results that we get by utilizing this technique and then we'll go through some slides to talk about how we get there so here's a map in caves of cut if you're not familiar with it it's a tile-based game so each of the maps is 80 by 25 and it's very discreet so you can see walls and creatures and plants here and they're represented in a sort of abstract way so here we have a sort of rectilinear palace it has sort of an outer wall and inner buildings and they're

populated by various things blood splatters and centipedes and gardens and here we have an underground map where we have some very narrow corridors goalies full of water little rooms full of water this is very sort of maisy narrow map and here we have a circular tower embedded in some rock salt it's filled with bears i guess an asphalt and a little statuary on the right it's got sort of curvy labyrinthine halls and here we have a little town we've got maybe a big ruined civic structure up north and in the south we have a bunch of rectilinear village buildings adjacent laid out along a nice forested path so these are a wide variety of results but the result of a single algorithm so these each had a very different character you had little maisy corridors you had a fairly dispersed village with well-ordered buildings you had a

water filled goalies and instead of using an individual technique to generate each of these we use a powerful new texture synthesis technique called wave function collapse alongside a few other tools that we use to supplement its weaknesses when applied to maps so wave function collapse it was developed by a russian mathematician named maxim gooman released open source mit licensed and the repositories out here it's in 20 different languages you can go out there and download it now and use it hopefully after this talk you'll be able to go out there and build into your projects caves of code was its first commercial commercial use a bunch of others quickly followed because it's such a powerful technique wave function collapse has two primary modes it operates on tiles and operates on textures if you do procedural generation you've probably encountered wong tile maps which are based on edge colored adjacencies the tile map generation is sort of similar to that but the adjacency constraints are much more powerful than edge coloring you can get a much more powerful result so if you're

interested in tile-based map design this is great we're not going to talk about it instead we use texture mode texture mode uses small training inputs they can be big but it's most powerful when they're small maybe 8 by 8 or 16x16 training images and they can produce arbitrarily large outputs with the character of that input training image this is pretty amazing so on the left you have three separate inputs and the top you see a sort of rectilinear room hall and you can see seven sample outputs here just bigger you can see that each of them has a pretty different layout but shares structurally uh the same character as the input on the second row you see some caves these are caves that you would typically generate via cellular automata system or something or box filters something very different from that that first rectilinear room hall arrangement and then third you see an input texture that's five by five simple couple dots

in a line and you get some very complex uh quilted patterns and this would be some custom line drawing technique so instead of having to have three very different algorithms you're able to have one single algorithm that's fed different very simple training inputs this is something you can pop open ms paint right any training input and throw it through the algorithm very cool so i'm going to run quickly through this text slide don't feel like you have to load this into your brain we're going to walk through it more carefully i just want to prime your system for what we're going to talk about i'm actually not going to go way down to the nuts of bolts of this algorithm they're good papers to do that i want to give you a intuitive understanding of how this algorithm is making decisions when it's painting its output so first what it does is it chops it up into n by end tiles n is something you pick um three is a very typical size so it's going to operate on individual three by three tiles chop up your input image into those it's going to operate on those as its basic atom you can choose bigger or smaller atoms depending on the character you want out of your

output then we output the or we set up the output as a superposition of all those possible tiles so you can imagine each element of the output being superimposed of each of the tiles that are pulled out of the input and this is the character it shares with quantum wave function collapse it's it's sort of a snide relationship it's not anything complicated what it does then is it picks one at random to start with and says well of all these possible tiles we're going to select the lowest in by an entropy area and pick one at random and collapse it down to a single tile and then it's got some new information i know that this tile exists these adjacencies are removed from the list and then it continues until every output has only a single selection and that's pretty much it so didn't catch that we'll walk through that in a little more detail here so the first thing it does is it identifies all the in-by-end patterns so the example here i'm going to use is a very simple three color training input it's got red on the outside and a green box and a blue inside and so it's going to chop it up into all these three by

three patterns so i'm showing you five here but they're obviously a bunch in a nine by nine box without wrapping it's gonna be like 49 and uh if you allow wrapping it's like what a 81. if you allow symmetries and rotations it's much more then it goes through and for each tile it figures out where do the other tiles overlap and it's going to use this information in order to do the propagation and so here i'm just showing an example you've got two tiles and you can see that the first tile on the left it overlaps with the two tiles below it sharing those six red pixels so this is an example output of an wfc run so let's unpack what we're looking at here a little bit on the very left you see the training input what you're seeing is the first four steps of the wfc collapse in the very first frame the white outline box is the three by three tile it's decided to collapse it then steps through one three by three section at a time and selects an output tile that correctly overlaps the existing tiles that it knows about and it steps through

the image until all of them are collapsed from the existing input data so to give you a real idea what's going on if you look at the area in the box it's very clearly green blue that's a single non-superimposed result the rest of the blending pixels is a visualization of the output tiles that are remain for that available for that area superimposed on one another so pixels that have sort of a green blue box they can still be either green or blue depending on what tiles remain to be chosen so let's look very specifically at this first step and try to build an intuition for how it makes these decisions let's look at this strip of three pixels here unlike the pixels to the left you can see these blue pixels are a little green which means they still have some possibility to become green pixels so why is this well we look to the left of this pattern and we see to the left of this pattern in the input is a strip of blue blue

green and where can we find this in the input pattern we can essentially find it in these three places we can find it here each of these magenta boxes is what the output column we're thinking about might be in this case in the most leftmost case you can see left of that is blue blue green and the second case left of that is blue blue green and third case left of that is blue blue green so these are all these could all slot in there two of these outputs that column is blue blue green and the third possible output the column is green green green and so we can see here we go if if we look at two blue blue green inputs and one green green green input you can see that the probability is two blues and one green for each of those top two pixels and oh it's always going to be green in the output so you can see that we though we've selected that initial three by three box we know quite a bit about what possible adjacencies exist based on the input image and so again looking at this you should

have a better idea sort of intuitively what it's doing each of these white boxes is selecting for sure what these pixels are in each case it knows a little bit more about the possibilities that remain and it simply sort of flood fills around the area to make it work so let's watch this work it's fun so we have five training inputs on the left we have a little white box a little red box sort of more complex temple you can watch in real time as it decides usually from the edges what the possibilities are and then folds in those overlapping potentials until we've got a final image and you can obviously run this many times and get a different output each time pretty fun so you can get big complex outputs from little inputs

so that gives you an idea of how the technique works again you don't have to understand it when i started experimenting with it i had no clue what was going on so i i'm sort of a hands-on learner so i just tried to give it input and see what it see what happened and so this was my first experiment in texture mode in respect to building tile maps i wanted to build structured output so in this case i was like well can i make it build little square buildings for a village that would be neat i gave it a black box on a white background and i did not get a bunch of little square buildings and it turns out that's because what is the image telling it it tells it's telling it basically on the order of three by three pixels that a line can turn left or a line can turn right or a line can go straight you'll notice that there's no overlaps but there's also no training in that image that tells that there's an inside and out to side of the square there's no spatial spatial relationship between those turns and so you get the output there i said well what if i had a third color so now i've got white and

i've got black and i've got red inside this suddenly produces the kind of spatial coherence that i want across the map you've got little red filled boxes that's awesome because not only do you get the spatial coherence but you also get some structural hinting the red pixels tell me hey that's the inside of a place and when you're building a map that's a pretty interesting distinction to be able to pull out of a real simple texture okay well something i can put furniture inside and plants outside and that looks like a already a coherent village with almost nothing going on we've got a three color texture going into it here's another example as i get more comfortable playing with it hey what if i feed a bigger training image do i get noise or do i get something interesting i get something interesting that's cool another example i said well can i produce sort of naturalistic gardens sure i mean these are like eight second experiments in ms paint this is i'm not i'm not spending 20 hours learning to do high level math so maybe i'm in the wrong lecture also here's an introductory shape and keep this in mind because we're going to

return to the star shape i added an additional color here and you can see you get star-like shapes not identical stars but some variation and that's pretty interesting how to use this in your code probably the most interesting slide for people it's not complicated it's three lines of code you initialize the model you tell it to run and you get the output image and that's it and let's take a look at the inputs because sometimes the complexity is hidden in the in the parameterization for wfc it's not there's not even any complexity there you give it the training image you say what is the n i want i want it to be two or three or four how big do i want the output to be do i want the input to wrap across edges do i want the output direct cross edges and do i want it to sample with symmetry symmetry is a little bit interesting not very complicated if you're for instance putting in something where orientation matters and you've got ground at the bottom at sky at the top you probably don't want symmetry unless you want to end up with sky at the bottom if you've got buildings where you don't care about the orientation you want to probably crank that symmetry up to eight where

you've got full reflection and rotational symmetry so applied to map design these are not problems with the algorithm per se but only domain specific problems what problems did we run into when we tried to use this problem one was homogeny the outputs are as you get bigger and bigger just completely homogeneous in all directions they're interesting at the small scale but you don't really want to walk across an infinite homogeneous plane of these buildings problem two is overfitting and so we'll return to the star shape one of the things you want to do in maps is have more interesting details than walls you want to have doors and where the monsters are and where the furniture is etc etc and you might think that well let me add more colors to the wfc input and that of course was the first thing i tried the reality is as soon as you start adding more and more colors less of these tiles tend to overlap and so you tend to get very uh very non-varied outputs because the tiles can fit together only in one particular way and so instead you just reflect and rotate the shape across

space so how do we solve these the solution to homogeny was very simple we segmented the output space and then used wfc to fill in details so in this case this very simple example we've segmented this map into three high level chunks and each of them is filled with a wfc input with different character so this produces a high level graph that's more interesting than a homogeneous output and then the interiors that interior detailing which can be quite difficult to get with uh standard procedural techniques can be highly varied because you can pick from a big library of 500 templates you made in ms paint and get some really interesting complex output how do we deal with overfitting the solution to overfitting was pretty simple which was to use the output of wsc in order to generate high level wall structure and then use a post-processing pass to generate the more detailed uh more detailed things like doors and furniture you can imagine a bunch of ways to do this i'm going to show you one of the full run throughs that we did

we did to get a level in caves of cod so here's a real simple example first we pick some segmentation in this case we're going to pick a big circle in the middle middle of the map where they're going to run a wfc template to fill the whole map up in this case we're just going to run a set of buildings we're going to cookie cutter that circle out and our we are left with some walls you can see that this has created some disjoint rooms and so what we do is we simply segment this map we figure out which are the disconnected spaces and then we a star from segment to segment anywhere we pop through a wall we're going to place a door so you can see in this case we're a-starring here you've got a little red cross where the door is punched and we do it again and again and again and again and once that's done we are able to build a whole map which looks pretty complicated but you can see now that there's there's very little going on right we've we've done a top level segmentation we've filled in the

details with wfc and we've punched some doors with a pretty simple a-star and that's the output is pretty complex so let's revisit the initial maps which looked complex before but let's think about how we did these these are each accomplished through the exact same technique in this case we've got a couple square areas that were filled with rectilinear wfc output that's it you get this cool looking palace here we have a full map that's been allowed to run we had a tiny little corridor wfc it's maybe eight by eight we let it just run out across the whole map then we flood fill in some of the edges with with dirt so this looks like a buried buried set of goalies here we've just got a circle and a square output that been filled with real simple labyrinthine wfc and here we have a big square at the top that's been filled with wfc output and a big square at the bottom which has been filled with wfc output and that's it and you get this cool little village right pretty simple so

there are some really good papers in the wild isaac karth has written a good one called wfc is constraint solving the wild if you want to go really deep down into how the algorithm works you can go uh grab that the repository is a really excellent resource unlike a lot of reports repositories it's really excellently documented it's got source code in 30 different languages because as you can see it's like a super easy technique and a super powerful one and so it's very easy to plug into your project and go and that is it i'm brian buckler that was wfc do i have yeah if you have questions come to mike's happy to answer so how did you deal with communicating the algorithm to

like uh people who are more used to traditional level design tools uh or more traditional uh procedural generation uh approaches which tend to work on like kind of room chunks or things like that where there's discrete combat spaces or discrete uh spaces for different gameplay styles yeah the question is how would i how would i communicate that to them or how would you yeah how how did working with how did working with design people from that background work out for you yeah well our team is so the question is how did it work out working with people who are more interested in discrete level design and the answer is we have no none of those people on the team how did it go with you well i mean this this was a big uh challenge for counter spy because we ended up doing room by room chunking because that was easy to build out spaces and have combat ai work in it but yeah if i can take that question to an adjacent space i think there's a tendency to want to have a little bit more control ability from a designer's perspective these

in caves of code we let our generative systems run really wild and it's part of the aesthetic of the game and we can lean into it um and you can see we do things like we just smash outputs on top of each other but because our game is about runes that have been smashed out on top of each other that's great um i think that i think that the when you get into the design space where you want more control the tendencies to move more towards prefabs which designers have control over so you want to lean into like the tile based techniques in order to put fit those prefabs together and then allow the designators to design spaces that can work within a particular bound right so within this prefab this area can be filled in this knuckle so so if i'm following you you're suggesting maybe uh when you're doing the spatial partitioning uh step you can do some of that wfc step to do the kind of broad strokes and then chunk down uh prefabs into the appropriate size spaces yeah i would actually say probably the tile based uh portion of wfc which i didn't talk about is probably more interesting than those

teams that gets a little bit more controllability to that out thank you sure did you try building any constraints into the wave function collapse algorithm itself like no repeating tiles in this region or anything like that because i've experimented with that with some other implementations of this and ran into quite a few problems yeah the the question was did we build any additional constraints on top of wfc um the answer is no because i tried it and i ran into a bunch of problems max is is a cool guy and very knowledgeable obviously since he created and if you have a specific question about constraint building i would actually hit him up on twitter and and ask because he's helpful but i i didn't have time to push past those problems in this case and we were able to get really good output without any kind of complex constraint additions i would say there's a great c sharp library on github by guy boris the brave or whatever i think it's linked within that repository works great inside unity yeah awesome

great talk um i had a question did you ever try having like a more detailed uh training set to be able to have more permutations of different sort of adjacent materials yeah it's really tricky because the reality is that those bigger training sets like the temple really you can reduce those um quite a bit and still get similar output um those bigger bigger sets unless they're very complicated tend to just start repeating the same patterns and so a good train because as your training set gets bigger the memory impact and the cpu impact of the of the collapse gets bigger it tends to be best just to try to figure out exactly what the character is and pack it into as small as spaces as possible for actual production right um so i meant sort of when um when you have like so when you had multiple colors colors you got the repeating patterns right yeah so uh by having maybe a bigger training set maybe you could have more permutations of colors adjacent to each other to sort of still be able to get the detail but oh yeah could you work around overfitting by by having a

bunch of them with different colors yeah i think you probably could i haven't really experimented with it but i mean that would that would certainly be an effective use of it i think something to experiment with any other questions no okay well thank you
