Math for Game Programmers: Solving Nintendo's CodinGame Challenge

[Music] reminder to do all of your after talk survey stuff but let's get right into it so I'm like acting I'm the engine director at insomniac games and today I'm going to talk about solving the Nintendo's coding game challenge so if you don't know coding game is an online site where you did sort of a game it's sort of a programming competition site so they provide specific challenges people go on there and solve them it's good for practice there's lots of sites like it lots of hacker sites similar kinds of things but the fact that Nintendo sponsored a challenge is the thing that caught my eye specifically I'm like okay well this probably has some ability with games so it makes it interesting to me all of my steps all the things I'm about to show you

including this particular document are on github there's the link so you can you can pull that and follow along if you like so today's talk is about process not solution this I'm just walking through my personal process of solving this problem there are probably a million other ways of tackling this particular problem this was mine I'm a walk through the solution as part of talking about the process but that is not the point so I'm gonna walk through all basically all the test code or at least a significant portion of the test code and versions that I created while I solve the problem so from test zero zero to test one F and just sort of worked my way through it and tell you what I was thinking as I was going and why I was writing each thing so starting with ten zero two zero zero what's the question what am I trying to solve can I get any insight into that so going on to the site this

was the question that's presented the society program has received a series of messages from Alpha Centauri the most frequent message seems to be blah blah blah it is not known why any of these messages are encoded but there's a good chance that the the Centurions are trying to evaluate our cognitive abilities before establishing advanced cog contact our best engineers are working to code this messages etc etc so there's a lot of flour right a lot flour littling a language around the problem and at the bottoms presented some some pseudocode of the encoding program so I read this right get it try to get excited about the problem so what the first thing I need to do is I need to take away all the flour language I need to figure out what it is that I'm actually what it is this is actually describing so somewhat so to summarize the problem we have some function which given a returns B in

terms of the problem space here we're given B and F and we have to return all the a which satisfy that a and B can be 64 128 256 or 512 bits so it's pretty straightforward description problem description so in our case in my case I called F encode and so the universe of that is decode so B equals in code a and decode b return some set of a things that could that could have been encoded to create that B so taking the pseudocode and the c++ code that was provided here's the encode function as basically as delivered as part of the problem description and looking at it in my process i'm looking at it so it says there in comments magic centurion operation i can't really decipher what's happening just by looking at this bit of code so my goal here is really just to understand one code does before i get

deeper into trying to write a decode function so that's the most important thing to me first is what does encode do so first thing i do is i testing code with random ins and if you saw squirrels talk you know you know getting a good set of random values is important and so what I did and what I generally do is go to random not org which is an amazing set of actually properly random values that you can just download at any given time and use it essentially as a noise table so I wanted to be able to repeat all of my tests constantly over and over again so I have the same random table that I'm constantly using so I just downloaded a set of that created a random install H and now I know for the rest of time here all my tests are gonna be the same so for test zero zero I'm just sort of printing out what encode function this encode magic encode function does I just want to have a look at it and see if there's anything I can see so you can see I'm just looping through my test count which is my random ins I'm calling the encode function I'm just printing it out that's it

printing out the results I just wanna see what it looks like it looks like this so I spent a lot of time literally just staring at this the whole output I'm looking forward patterns things that appear anything that looks interesting and nothing really pops at me at this point so I have to dig in to actually dig in deeper okay I'll have to actually do some analysis there's nothing super obvious so that's what test oh one is is there any obvious connection between encode input and output so I'm testing a bunch of obvious stuff but the most obvious thing to look for is is there a is there a correlation between the bits of the output and the bits of the input so I'm testing here specifically what's the probability of the bit of B being on given at the same bit of a and that's just this simple function so in pseudocode all test one does is sort of loop through all a random tests and for each bit in each one of the results it counts up you're all here the bits here are the count for all the bits an a here all accounts for all the bits and B and just calculates the probability of B

given a for every single bit and so I looked at the results so from 0 to 63 all the bits if I look at the middle bits here so everything basically everything on middle super not interesting right basically they're all hovering around 0.5 so they're all essentially random given a whatever a is is sort of there's no correlation with B but first there's a sort of a chunk at the top and a chunk of the bottom that are much more interesting and I can see this sort of scaling up let's start with you know the you know given given a the probability of B being on is only 23% or 24% so is a sort of high correlation between those two bits and it sort of you know decreasing over the first few bits and sort of at the end - there's this sort of bunching up of a much higher correlation of bits so I thought okay well this is super interesting right so maybe there's something I can

do with this so this is where I went off on a super long tangent which I won't really get into but this is sort of the state machine generated this is totally a path that you can take to solve this problem but it is absolutely the long way around this problem so you just start with what's needed to get the first bit of B to be set so everything that I need to know in order to set definitely know that the first bit of B is set and then I move on to say given that I know what the first bit of B is and what I need to know in a what I need to know to get the second bit of B etc and I just sort of looped this in on itself you can basically build a state machine generator based on that on those facts and again like I said this is a this is possible it's totally solvable this way it was just a really really long way around solving this problem so as I'm deep into this this approach it occurs to me that I missed a super obvious test and that's test o2 here instead of just looking at random outputs I'm gonna recheck with order and outputs so now this is what I'm doing

here in test o2 testing encode with ordered values so for my input a I'm just setting a fixed upper 632 bits and the lower 32 base is just an incremented value so for however many tests I have it just starts with 0 1 2 3 and I could encode that I want to look at B so let's see what that looks like well thing that's a lot more interesting there's a lot more correlation going on here and if I'm looking at here right what's happening here at the top not the top value of each of these pairs is the input the bottom value of each of these pairs the output they're saying there's a lot of similarity between these two numbers so when I'm doing it in an incremental way it's a lot clearer that there's some correlation between the input in the output and my first impression when I'm looking at it some communities this is some kind of gray code maybe there's something going on here that's my first impression and just looking at this so my next step is okay maybe I just swapped the output and just display it a

little more little endian format to see if that changes anything from visually that's all I do is I just swapped the the I just swapped the two 32 bits just say maybe for me it's a little more natural maybe I see something different and so that's all this is it's just a more little endian format like okay well as I'm looking through these numbers I see something super interesting here as I'm pouring down through the numbers I see there's something is super interesting about each of the powers of two like there's there's there's something happening here Niq to just the powers of two in terms of the a in terms of the input so my next step is let's just print out the powers of two let's just look at that let's see what's happening with that so now I test test 404 so test Oh for I look at just all the powers of two now you can look at this and even without knowing what's going on here you can see that there's a visual pattern right you can see sort of this sort of left shifting going on of the of the inputs

and outputs so there's clearly something interesting happening in in the powers of two and in fact I look each individual one of these and I can see the same thing going on so I have a of a 0 and a 1 so remember little in against the right side here is a zero on the left side is a 1 and so we start with a zero looks like what's happening is B is just sort of that a zero shifted left and the amount it's shifted left by is the basically the trailing zero count of of a1 so I have some questions now like hey is it what's happening if a1 is not a power of two so what I do I pick any arbitrary number I just happen to pick oh F in this case I pick an arbitrary number and I just break it up into its into its constituent powers of two and in test oh five what I do is I say print out encoding of one two four and eight

and then the final value F and show me what that looks like so you can see sort of if what's the correlation between the final value and all the powers of two that it's made up out of and so this is what that print out looked like so here's a input here's the powers of here's one two four eight the powers of two that make up F and F at the bottom so I'm looking at this I stare at these values look at all the variations of these values I'm looking at it and I see something very interesting happening here and that's this I look at the value the final value F at the bottom and it's really just the XOR down the columns of all the power of two values there so the first bit zero bit at the right hand side is just really 1x or zero X or 0 X or 0 the second column similarly it's X 1 X or 1 X or 0 X or 0 is 0 at the bottom and so I see that all the way across so I find that very interesting so now I have kind of a theory of how

this is how this in code works so given where a and B are 64 bits and I can break up a into two 32-bit segments it's kind of looks like this so I loop through all the the bits of a0 if it's on then B X ORS with a1 shifted left by whatever the I did the current bit that I'm on there so this should duplicate the work that we saw that I saw there so now I have to test that but first I want to just help myself visualize so my next step is really just to Reese pace things this doesn't provide me any value other than visual value I sort of I want to look at the problem a different way which is a lot of what I do I just print it out in a different way just to look at it so with 10 7 the next thing I wanted to do was just validate across the simple sample a wide err sample set this isn't just what I'm seeing make sense because up to now I've test this very limited set write a zero just really small subset of values

and in fact with the last system which is literally just F right one single value and a1 is up to this point I just had fixed so does the theory I currently have in terms of what this loops supposed to do hold up across all the sample data and does it change if a zero is you know and anything other than this small subset values so I create this alternate version this encode 232 which is basically just the code version of the the pseudo code will you saw seen nothing unique or special about this and I run through so Tesla 7 runs through the same random inputs runs the original code runs this alternate version and just checks to see if the results are the same so this is a pure sanity checking does the thing work the way expected to work across all the sample data that I'm dealing with in fact it does works fine so I'm very confident now that the that this is essentially

the function so I want to play with some variations of the encode function at this point and so all test eight here is is just real the realization that I can do this if this branch here and check and shift of the I or I can just multiply by a 1 and so this is just me playing with variations I know these are two the same like I know these two things are identical but every test eight I want to rerun it anyway I create it I test it I rerun all my tests just for sanity sake and luckily all the tests pass I am still sane so test 9 so I want to go back and revisiting again with all with all the test inputs so with all the random values I want to see what it looks like again so test 9 is the same as test 7 but this is that encode 232 that I created just prints out all the steps as it going and so me

injecting a bunch of printf sin to the code that I write is pretty much how I do stuff and so you can this is a temp bit of the sample output from test Oh 9 which looks like this boom so I'm printing out at every step what's happening so at the top a one at the right hand side is a zero so all the bits in a zero and at the bottom here the result of B and as I said each one of these columns sort of X ORS down and so the results are as I expected but visually it's super interesting because now I look at this and I say well looking at this way and looking at a bigger case like this they're very specific you know these least test cases this looks suspiciously like some kind of longhand multiplication right but for each place there's something different going and going on right for instead of multiplication it's really just anding instead of an addition it's sort of an XOR so we you know we have this multiplication instead of multiplication right we have and so only 1 times 1 is 1

and for addition we have this truth table so this is what's going on so the question is what fits this model you know if this isn't really integer multiplication but it is some kind of longhand location what what fits this model in fact there is something that perfectly fits this model multiplication of polynomial over GF 2 fits this model perfectly if you don't happen to know that fact I don't know how you get from what I saw to this this is a massive leap and the problem is that you can't just search for those tables right it's very difficult so my suggestion is in the case where I where I happened to not know these kinds of things where I hid this kind of block and I know there must be something that's called this often what I'll do is I'll I'll write a bit of code that prints out a bunch of numbers in order and then I can search the integer database online for something that matches those numbers and I can see what things that fit that model so it's

generally my approach to those so GF 2 basically just means a finite field of two elements so and we can see here if I look up GF 2 in Wikipedia those tables look super super familiar those exact identical tables that we just created so most programmers when I'm gonna talk about finite fields that's programmers use finite fields all the time so if I were to say you have a youant 8a and we put FF in it and ask you what is a plus-two probably most of it you could tell me what the answer to that question is and we know because it just we know that it just wraps around a certain number of finite things we know they're just sort of just mod of eight bits here and in GF 2 really all that means is all the math is mod 2 so one bit right it's super simple super easy to understand really nice overview of of what's happening in finite fields is this particular paper which I totally recommend reading if this is something

that interests you what does it mean to represent a polynomial over GF 2 so the exponent is implicit in this place right and the coefficient is stored in coefficients here in GF 2 because we're ma everything is mod 2 can only be 1 or 0 so if we take a particular Jeff of 1 0 1 1 the exponent is implicit right so we're going from the right to the left X to the 0 x to the 1/x to the 2x 2 3 sort of as you would expect moving from the right to the left and so that's 1 0 1 1 which maps to X to the third plus X plus 1 you can see how sort of it maps so next test right I want now I kind of have them I have it I have a model online of a theory I have a theory that what encode is actually doing is multiplying polynomials over GF 2 everything so far in my model fits perfectly to this fact I don't care if this is the reality the model fits correctly so that's as far as I'm

concerned is the reality right the model fits it's correct so I want to create a new function called P GF to mole and just rework things in these terms knowing that I should get the same results so I create this GF 2 0 0 C and I start writing things in these terms at this point so I created GF 2 mold you have to add which is just X or and a GF 2 shift left shift left logical which kind of does as you'd expect and just shifts it shifts the whole value over so this is what multiply does which is very reminiscent of the other version of the encode that we saw it sort of test that goes through all the bits test a bit if the bit set then adds it in which is the same as X or and then this shifts over the a so we can continue moving along so as you can you can imagine it's sort of is that sort of kind of long hand multiply going on here wrecking not in a recognizable form I rerun this same from this function

against all the same tests and all its has passed so I'm getting exactly the same results it's just formulated in a different way so test OB it's another sanity test now I want to make sure that after I've sort of doing all this work and reformulating it do all the other expected bits work I've really just been focused on the 64-bit version right now but I want to make sure that all this other stuff works right so I need to verify its cases where B can be 128 or 256 or 512 bits so test OB is the same as the previous test this test so a that we just did but I've extended it to all the above all these cases I'm using the exact same random number tape tables they're same random values I'm just sort of casting them wider so instead of taking the first 32 bits of the the table and taking the second the first two in casting that as as 64 the first four in casting has 128 and so running off all the tests pass so I'm pretty convinced at this point that this is in fact the model this is in fact what encode does across all the bit

depths pretty good so with test OC now I think I know pretty sure what our wedding code means what could decode mean so this is what I get to the point where I'm actually trying to solve the actual problem here so if in code is GF 2 mol what does the code do well what's the reverse of multiplied and that's factor right so now I'm gonna take a look at the provided test cases so here's test case one that's provided and now with my this this with my insight into what what's happening in the encode function a lot of stuff really becomes a lot more obvious so I can look at the input and output and I can sort of interpret it so I see that the input is sums 60 polish 64 bit polynomial and sort of little endian format we're only this sort of bottom 16 bits have anything in them and I could say

what's factor well the first is that the st. that's a number the same number as a polynomial times one is it and that same number times one is the same value so that makes sense in terms of factoring and I can presume here that some polynomial represented by eighty-three times some polynomial represented by e5 multiplies to seven 3af and then can see the reverse immediately underneath it and so the thing is though as I'm looking through these other test cases and you can see the same pattern here with one time's the same number and these two numbers that are flipped and these two numbers of this you know there's two pairs here that are the same as but I'm looking through these test cases it really really should have been obvious to me when I was looking at test cases originally that this was sort of a multiply factor thing when I see this sort of pairs I'm looking at something times one and it really should have been a lot more obvious but it totally wasn't I totally missed this looking at the original cases I had to go through this process for me personally of visualizing all that data and going through it and walking through it and recreating in

code in order to then in hindsight see what's going on in those test cases so now with tests OSI moving on I want to just print all those tests take all the SEFs cases and print them out in polynomial format so this is just for me personally for visualization purposes so go through each of the test cases and prints it out like like you see here so instead of this value let's instead of these values up top is just printing out the same values in polynomial format so I look at this particular case and we said all right well 73f should be a three times E 5 in as polynomials which is interpreted as X to the seventh plus X plus one times X to the seventh plus X to the sixth plus X to the fifth plus X to the second plus 1 I promise I'm going to try not to read too many polynomials and the talk today so the first thing I do is say okay if this is true if this

makes sense then I should be able to verify this in like three seconds and mathematica so I just take the polynomial the input polynomial here and I cut and paste because I put it in a nice format that I can cut and paste into Mathematica I cut and paste it and I say factor this and luckily enough Mathematica can do modulus to factoring so I just say factor this modulus - boom those are the two values in fact those a same identical values as the show up there which are represented by 83 and ye5 so I'm super confident now that we're going down the right track that this makes sense if you have their lesson here is if you have a calculator use it and the very least to verify your what you're doing so I go through a night I cut and paste I checked all the other test cases as well I just paste those in do they make sense does it am I getting the same values and yes indeed they're all identical they all map to what I expect them to map to so test OD start figuring out what D code would mean to do what's the process like what are the steps and I want to I mean I

don't just want to put this in a Mathematica I want to actually do the thing so what does it look like so at this point I can restate the problem so I write it down so given a polynomial over GF 2 to the N where n can be one of these bit depths 64 128 256 or 512 display all the pairs of factors of degree and less than n / 2 that's sort of a specific constraint to the problem definition is you're just outputting these pairs of factors so what if there's more than two factors if you're given a polynomial it has a bunch of different factors well I think the answer here is you just recombine them until you get a pair that fits the constraint so the steps find all the irreducible factors of F so the smallest things that I can make that I can make up F with recombine those until I get pairs that fit format and sort the results in output seems fairly straightforward except that I don't know how to factor polynomials over GF 2 so this is my next step how do I figure what do i do how do I figure this out so

I asked myself what would Knuth do right so crack open the book I don't know about you but I find I find are to computer programming super handy for reference I find it super handy for when I already basically when I already know the answer looking it up I'm just reminding my I just want to know a finer point but I don't actually know the answer it's super hard for me to understand what's going on in there and this particular set of solutions is no exception to that so but to point you give you reference volume 2 section 4 6 2 factorization of polynomials which is perfectly what I'm looking for here and the finer point of that particular page is this this half of the page is pretty much the steps that we need to do but again in my first glance here in my first pass of the section in this page and this part of this page it's super terse because I didn't really understand what was going on I didn't it was very hard for me to read because I didn't

already know the answer but luckily we're given a hint I was given a hint anyway here which is the name of the thing that I need to Google in order to understand which is Berlin cans factoring algorithm all right so after a bunch of googling and reading and going I found this one paper right there's lots of papers on this particular thing but I found personally this particular paper the most useful the most straightforward description and I provide a link here if you're interested it's very short so 9 pages and it has a worked example which I always find it super useful like if you actually work through an example so to go back to this now ok let's look at step one so I know ok I kind of got a better idea of what what this means what Burley counts factoring out are the means because I've read this other paper now let's go back I'm gonna work on step one step one b1 ensure that UX is square-free all right what does that mean it means we have a fact we have a polynomial say a which and which is made

of the factors B squared CD we're pulling out the squared factors in this case B squared is the fact that we're pulling out so we end up with two things a 0 is B squared and a 1 is C D so those combine back together would be a right that's what we mean we're pulling out the stuff that is squared out of here so square-free factorization UX has a square factor if the GCD of UX and the derivative of UX is not 1 so just create that creat steps out of that the first is given some UX which we're going to call F which I call F get the derivative F get the GCD of F and the derivative of F call that G so f is made of G times some H which we don't know yet but since we know G we can just say F divided by G is that H right so a fairly straightforward process here except which I'll get to in a minute let's start with an example with a square in it so I just create an example any example fairly complicated one

enough to sort of know that things are going right or wrong in the middle of that circled at the bottom here is a squared factor just so I know what I'm dealing with so I'm gonna pull out that square factor manually so just by hand here I know what I want my a I know what I want my B so I know it's left might be so in test OD I'm just gonna multiply all these little things here left that are left and B together and print out with the results so what should I expect from me so I already know how to multiply we've already done it a bunch of times but again just a sort of sanity test and verify what I'm doing I keep doing it anyway so I multiply all these things back together and this is what I get for B I know this is what I wanna be I verify this by again throwing it back into Mathematica and making sure that all the factors are correct so after square-free factors a square-free factorization I know that these are the two values that I should be getting which is the a and B here the a is the squared value that's pulled out I know what I'm looking for but I have a

bunch of things that I need to figure out how to do so for instance how would you take the derivative of a polynomial over GF 2 I don't know I didn't know at this point so let's start there so let's just review the regular process Rick so we have the derivative of x squared plus X plus 1 with respect to X the mechanical process for that is really simple right we multiply each of exponent with its coefficient and subtract 1 from each exponent we're left with 2x plus 1 fairly straightforward mechanical process but over GF 2 it's the same mechanical steps but all the math and GF 2 is mod 2 so R 2 R 2 and 2x plus one the two there is two mod 0 which is 0 so our derivative of x squared plus X plus 1 over GF 2 with respect to X is in fact 1 because the two X becomes 0 to make a put a finer

point on it the process for taking the derivative in GF 2 is all coefficients are 0 that already everything is mod 0 everything is mod 2 all the even exponents will be multiplied by either 0 or 1 to get the coefficient right the result is that the coefficient of each one of those will either be even or 0 all even values are 0 so they're all going to be 0 so we can just mask out all the even exponents we don't need any of them all the exponent exponent will be multiplied by 0 or 1 to get a coefficient the resulting coefficient is either odd or 0 or all odd values mod 2 are 1 so we can reduce we can just reduce all the odd exponents by 1 which is the same as saying shift everything right one place so in terms of process this is what it looks like so we take this particular example 1 0 1 1 1 1 we zero out the even exponent because we know those don't matter because anything those even numbers all multiply but

whatever are gonna be even and all gonna be 0 so we just just mess those out we just shift everything else over one place and we're left with in this particular example X to the fourth plus X to the 2nd + 1 which is which as far as I'm concerned at this point is just is just witchcraft like that the fact that getting the derivative is so easy and socially forward is amazing so I just so in test OE I just printing out example derivatives just to check to see that what I'm doing is right and what would make sense and what's going on so I take this a value and I put the derivative of it and you know looks okay so the next step test OEF what do I need to find the greatest common divisor of the - of two polynomials because my next step here is G is the GCD of F and the so how do I get the GCD of polynomial /

/ GF - well in fact like most things and process is the same as the GCD of any two polynomials only the coefficient masses in GF 2 so everything is mod 2 so reviewing what how'd you get the GCD it's basically GCD of a and B is the GCD of B and a mod B so we just go through this process we do a mod B and we check to see if it's 0 and if it's not 0 we just keep going through the loop but a mod B presents a problem because implies that I need to do polynomial division over GF 2 because the mod is just the remainder of the division so how do I divide the polynomial over GF 2 again so the same as dividing regular polynomials only coefficient math is all in GF 2 so if we're gonna start with what's how does regular polynomial long division work right we can see here is this particular example I won't read all of it but starting with how many times is x + 1 go into X to the

third we just need that first bit here we just say it goes in x squared and so we multiple we multiply those out and then we go down the process there but I can visualize that another way and I know lots of people visualize it this way and you just deal with the the components and forget about the coefficients and forget about all the the variables in this particular case you're just dealing with the coefficients because much easier to read and reason about so you can see here 1 - 6 11 and -6 are the coefficients of the same as X to the third minus six x to the second plus 11x minus 6 right and one one there is X plus one so in terms of doing this process right how many times is one one go in how many times does it need to be multiplied in order to make one and just just needs to be multiplied well one we subtract those out we get negative 7 how many times does 1 1 need to go do x to make negative 7 is negative 7 so we multiply

those subtract those out we get 18 minus 6 how many times does that need to be multiplied by 1 18 and we subtract those and we have a remainder the same process right um but in GF 2 it's gonna be a little bit different right but if we're looking at the process of polynomial division we know that we basically need two operations when you're multiplication and subtraction multiplication we already have we already know how to do that it's just and subtraction though this is the first time I've had to deal with subtraction in this process but everything again is mod 2 so 0 minus 0 is 0 0 minus 1 is minus 1 Montu is 1 1 minus 0 is 1 in 1 minus 1 is 0 so this is our truth table for subtracting coefficients in fact that truth table is exactly the same as the one for addition which is just X or so subtraction and addition and GF 2 are exactly the same which is super super interesting and fascinating it also means that any code that I write in GF 2 will not work in any other finite field definition because I guaranteed to screw

that up and just use addition or subtraction everywhere so test Oh F now I just want to print out a working example so I create this p GF - div print this version of divide algorithm that prints out all the individual steps as it's dividing its as its dividing two values so I'm dividing a by B here and it's exactly the same format that I showed before and part of the reason that that format is is valuable to me is it's easier to printf honestly so you know how many times is that just the right hand side I need to go and it doesn't need to be multiplied to the left-hand side just one it's always gonna be 1 or 0 and we just go down and get our result but the fact that I can visualize it and look through all the steps and look through any particular example is super helpful part of my process and it seems like a lot of this step steps where I'm printing out a lot of extra things I'm printing out a lot of extra steps you know is it worth that is it worth me doing inevitably yes

inevitably it's always worth me going through the extra effort of printing out a formatted version of what I'm working on because eventually I'm going to hit some bug eventually I'm gonna be stuck on something and I'm gonna want to visualize all the steps and make sure that everything is right or wondering why this one case doesn't work it's almost always worth doing so in terms of division this is pretty much what it's doing which is as you'd expect as we described so we're going through the count we're shifting left the quotient by one bit we're checking to see if that top bit is set because we're only gonna be multiplying by zero or one and if it's set we're setting when we're adding setting that one quotient bit at the bottom and we're shifting the divisor left to the appropriate amount so that we can subtract and we're subtracting and as you can see here at number six in fact I call add instead of subtract so that whole guarantee where I would definitely get things wrong if we're doing anything in GF anything in not GF

2 is definitely true but add and subtract the same in GF 2 all right so now moving on test 1 0 so now I think I think I have enough parts here to actually get the GCD of two polynomials over GF 2 I have mod I have all the things right can I do this in fact so I build this function P GF to GCD which just does pretty much this loop right as you expect looping through I get 2 remainder I check to see if the rain or 0 if it's done if it is I'm done if the remainder is 1 I'm also done the vote if the if the greatest common divisor is 1 the relative with prime so I can bail out here and then I just loop it around this is a while loop so I just keep looping around with the until I fill I'm finished so this is we have all the pieces I can't test this now I want to make sure that in fact it's all good it's right so I get my example here I print it out and print out the GCD so everything's printed out and then I cut and paste again cut and paste my my my F

here into Mathematica I say polynomial GCD this value and this value modulus two and in fact the result is the same so I can test a bunch of values here be fairly confident that what I'm doing is correct now I think now that I have now I have division and multiplication and GCD and derivative I think I have all the parts to do square-free factorization this the steps four and five here just multiplication division so we're good there already how to do that so I jump right into creating gf2 SFF square free factorization and I just print out test eleven just prints out square free factors so I give it an input value and it prints out square free factors here in different formats different cut and paste able formats so starting with binary format and hex format and polynomial format and this last one here SFF a 0 and a 1 so to two versions and

hex is this what we expected if I go back this SD so now I'm reaching back to one of the previous tests and it's nice for me to have all these tests in a row so I keep them all together it's not just saying it's just not version like version controlled versions of the same file I keep them all in a big pile so I can refer back to them like this so back at SD I said this is what I want to have after square-free factorization in fact these two values are identical so I'm fairly confident that I'm getting the right answer here test twelve now I want to build the matrix q is described in step b2 so step b2 here says form the matrix Q is defined by eleven and twelve and this can be one of two ways depending on whether or not P is very large as explained below let me talk a little bit about the as explained below part of this I definitely felt dumb reading this and this is one of those examples where I'm reading and I just it's something just I didn't understand something I just missed something I just something is just obscuring my understanding of

this of this description and I just didn't get it right I'm reading in reading I'm just not getting it but again that's where I reached back to that other paper that I mentioned which sort of helped to to clarify what was going on but in fact I'll tell you the real answer here is I really really wasn't getting it to the degree where I went to a professor of mathematics at UCLA and I said can I just pay you money to tell me what's going on here and he said yes right before and I'll tell you often that times professor of mathematics at your local university will take money he just sat down with me and we sat down for for like four or five hours and just worked work through all the holes in my understanding and totally worth the money let me tell you and that's that's I think a legitimate way of approaching some problems where I don't know like I don't know what I'm missing I don't know why I don't understand this and just sort of helping me through but to summarize the

end results here I tell you how hard it was for me to this and I'm sure this is super clear to tons and tons of people from sure they're millions of people who this was super clear to for me this was this this moment where I could look at this and understand what it was saying was huge and worth hundreds of dollars so the building that key matrix looks like this which is for I equals 0 to the degree of P and the grape is sort of the largest exponent P where P czar polynomial each row of Q is X to the even power so I times to mod P that particular polynomial P that were that we're building a queue off of so this matrix is I understand what's happening here I understand what I'm building I understand mechanically but getting to this point was a huge long process of understanding but in this particular

paper again this reaches back to the other paper that I mentioned there's that worked example which is super nice this is really really tiny worked example because as often in papers is really hard to show a large working example but at least there's something so given this particular F this particular polynomial at the top here is the matrix Q in here and this is just print it that same matrix here printed out a different way more tightly but it's the same values above so that makes Q where f is X to the fifth plus X to the fourth plus one so in test 12 all I want to do is verify my understanding can I get the same results as that paper and I was really really happy because one I got the same results in two if that paper if there was a if there was a bug in that paper and they printed out something wrong I would have never ever understood this because I was the only the only example that I had to work from but luckily the data in the paper is correct I could

applicate it and understand what's happening here so the matrix fairly simple X to the 0 mod a right so which is just 1 even power so 1 mod a my a is X to the 5th plus X to the 4th plus 1 so just mod with that X to the 2nd mod a so that's just again even power so all the even powers of X mod are a and that's our result so test 13 I want to create a small but simple example to factor and solve so I start with two simple irreducible factors and I multiply them together and all I do in test 13 is actually just multiply them together and print them out so it starts with these two irreducible factors multiply them together I call my my PG f2 mall which I've now used a bunch of times but again I'm sanity checking and get that so for test 14 I want to start breaking down B 3 B 3 says triangular triangular I matrix Q minus 1 and a bunch of other

things but to summarize what step b3 says it says M is Q minus 1 and find the null basis vectors of M someone's start with that step 1 Q minus 1 I'm pretty sure I can do that so I'm in this case test 14 I'm printing out Q I and M Q is that matrix we just I just built printing out in this example all right is identity I definitely know how to do identity matrix and M is Q minus I so I print those out so I'm fairly comfortable for I'm printing here and I'm moving on test 15 all right bigger problem how do I find the null basis vectors of matrix M in fact super super excellent walkthrough on this particular link would totally recommend you reading if you're at all interested in this particular question because for me this really enlightened me this particular answer to this particular question on math stack exchange it's a process much like matrix matrix inverse so summarize the process

though you're augmenting m with the identity matrix of the same size you're transforming m to row reduced echelon form and the null basis vectors are whatever's left whatever's on the right when the left side of the Augmented form is zero it's a fairly straightforward mechanical process so to start with step a in that mechanical process augment em with identity of the same size so it looks like this w is just going through each row its Hickey am shifting it left by the degree of P and then inserting the appropriate vector of the identity at that point so in test 15 I'm just printing that out and I create a new print so I can print stuff an Augmented form which just means I just put a space in the middle so I can visualize a little bit better so it's just this it's the same M on the left and there's identity on the right but it's just of one matrix W with those so space in the middle for visualization purposes so now I need a function I need to get this into a row reduced echelon form which I

don't happen to have a handy function for but I can use I know I can use Gauss Jordan elimination super useful description here there's also calculator there's lots of online calculators online for reference this particular one I found useful because it sort of dumped all the steps out as well so as I'm debugging I have something to compare against which is nice again going back to worked examples are really nice and really helped for me in terms of understanding so I create this function pgf to our breadth and a function our F HTML which prints out all the steps and the output so I can visualize it make sure that what it's doing makes sense but to go over Gauss Jordan elimination gf2 how does that work it works exactly the same as if you weren't in GF 2 except for all the component math is mod 2 so in terms of mechanical process you mark first row as the next result next result row then you go through the loop so you find the first row with the leftmost bit set and

then you swap that in your next result row call that your pivot row and then you subtract that out from all the other rows so basically just that's the only one with that particular bit set and then you just go through that process sort of working away across the bits from left to the right and just remembering your add here is in GF 2 so it's just XOR so output of test 16 the thing about so in this particular case again printing out in terms of printing everything out putting everything out in HTML so that I can visualize what's happening here so I can printing it out as it goes marking the first row highlighting and again it's printing this out in color so I can see what's going on highlighting the first the pivot row it's highlighting the fact that they're swapping sort of highlighting what it's subtracting from here and then finding the next pivot row etc and so going through the whole process and you can see I can see it sort of work its way down here and in

fact this XI this was super fascinating to me because I don't think I've you know looking at this and looking at 64-bit versions and 128-bit versions and 512 bit versions I don't think I ever had seeing so gigantic actual worked examples step by step of Gauss Jordan elimination especially in GF 2 like I'd never seen it before and being able to visualize it and see it every single step of the way was I mean it was amazing and so I played with this quiet for quite a long time to be honest until you're done and you left with this matrix M here at the end so the result and remember is sort of an Augmented form so I just put the space in the middle here and I take this I also printed out the same matrix and it's sort of easy to paste into mathematic form which again just throws stuff into my pronounce and make it easier to paste in Mathematica so I verify this I can do a row reduce of that matrix modulus 2 and verify that the result is the same and it is so I'm

good with that the next step is sort of highlight what the null basis vectors are what will the point of doing all this so those are the where the left side of the Augmented form is 0 so I just added a dis is just an addition to the debug printing where I just highlighted those so here in red the left side you can see a zero so the right side are the null basis vectors which I then print out here in three different forms in binary and hacks and polynomial form so now I can sort of go through all the steps I can complete all the steps with b4 and apply to a simple example so b4 here so calculating GCD of U of X which is our F and that one of those null basis vectors and minus s where s is in the range of 0 and P now P again this is something that threw me reading this document P is the power of the of the the field to find that field that we're

working with so P is 2 in this case so it's from where s is from 0 to 2 so s is either 0 or 1 so we're calculating V minus 0 or V minus 1 so for each non-trivial vector V found in B 3 and the non-trivial vector is anything that's not 1 1 is the trivial version so we can find non-trivial factors of our original value with GCD of F so that the original F and V which is one of those those null basis vectors and GCD of F and V minus 1 so the multiplying those two things together will give us our F and that's pretty much what this says here it's a product of GCD U of X minus s and U of X where s is then the range of 0 and P where for our case P is 2 so this is just a sort of simpler way of saying that same thing so highlighting

our null basis vectors from test 17 again I'm just kind of highlighting the non-tree of the one non-trivial result the other one is 1 so we're just throwing that away so in test 18 all I'm doing I can already do GCD I can already get my null basis vectors now I can do all the things so I should just be able to calculate in print get the GCD of these two values and verify that Multan multiplying them together gives me my original volume back which it should and it does so I get that one be V which I'm calling be V that one basis vector I'm getting the GCD of a which is my original input I've been printed out there my original input and be V Plus 0 and G GCD of a might be me plus 1 which are those two polynomials there and now I can say are these what I'm looking for these two factors what I'm looking for and if I go back to creating a simple example with two reducible factors those are in fact the same exact two irreducible factor so I can compare and say yes those are correct it looks good I solved a really simple example yay so test 19 umm so test the process on a

larger square free example which is this one I created before so I had this B which was square free as I created before which I'm now calling hey so it's the same as the previous test same as tests 18 but with this particular value and I could so I can print it out I prints out everything you could see much bigger prints out the highlights and no basis vectors there I print out the non-trivial result the non-trivial results here so I'm just throwing out the one already I'm just in the function I don't have to I don't have to worry about it finding the factors based on those and so for each so I'm doing the pair of G CDs here with each one of those basis vectors that I found here so each one plus 0 and plus 1 or plus here and minus 1 it doesn't matter cuz they're both the same so each pair of these D CDs you see can be multiplied together to make the

original value so each one of those represents each pair of those represents a list of factors right potential factors I can multiply any given pair of them to back to the original one but can I get anything else out of there so I want to get factors that actually multiply together to get a so really all I'm gonna do is say ok I know each one of those two pairs each one of those pairs multiplies together but can I get more out of this so I'm just gonna loop through all of them and sort of just divide them out of of a until I can get a list may be it may be I get lucky and I can get some additional factors out of that right so I just divide them all out and see which I ever ones divide out evenly so from that and test one a I can now print out a list of non-trivial factors of a these are all the things that I could find so I'm comfortable printing that out at this point but now I realize that non-trivial factors are not the same as irreducible factors so I need to go from non-trivial factors to irreducible factors how do I do that well if I can find non-trivial factors I

can find any irreducible factors you're looking just recurse right I just get them non-trivial factors of each one of those until I can't find anymore and then I have an irreducible factor and so that's in fact what tests 1b does for each one of the non-trivial factors find the non-trivial factors of that until I can't find any more that's a pretty straightforward process so I'm left with at the end of one be spitting out a list of irreducible factors of F or of a and so I look at this this list here and I compared against B which I created before and is it what I expected and in fact this list is identical to this list this list I created here B is identical to list above here of irreducible factors that I found so I'm fairly comfortable that I can find that list yay just one scene but all these pieces together and test factor gets too large a polynomial with squares in it in the first place so if we reach all the way back to

creating an example with the square in it which is the thing that we verified here the head square in it test 1c really just says call GF 2 s FF first and then for each one of those square factors each one of the factors I get out of that do the same process 1b which is get all the reducible factors of that of those and then just combine everything into a final list so this is what I am left with here so I left with this list of irreducible factors which is the same as the one that we expected because we factored it in the first place so it's all looks good but now I need an expanded list of irreducible factors so remember one of those is squared because we pulled it out specifically because it was squared so it's this particular value that's squared but for my purposes I want to be able to recombine everything so I want to expand this so really I'm just going through anything that's squared anything that has a power that has a polynomial squared I'm just going to duplicate it

in as many times as it's called for so that's all that I'm doing in test one Ds I'm just printing out and duplicating all the expanded factors and so that's what this is f 0 you can see is the same as f 1 hex 67 and the rest of them are as you as there something happened to be be the section B of that of that original polynomial so going back to the original problem list of all the way back given a polynomial over GF 2 to the N where n is one of those bit depths display all the pairs of factors of degree less than n divided by 2 step 1 find all the reducible factors of F finally I feel comfortable that I can do step 1 at this point but luckily steps 2 3 & 4 are much more straightforward so taking all those irreducible factors and sort of recombining them and to fit into pairs that fit into the appropriate bit depth so that's all the test 1e does so it goes through those lists of irreducible factors and recombines them

into pairs that fit and that's what outputs here that's what it looks like so then I get to test one F test 1 F now I go back to the original test cases and I say all right am i even so I haven't even solved the problem and solving the correct problem you know have I done all those to all the things correctly so let's look let's run it against the original test cases to make sure so here's test case 3 we now know why there's a third now I now know why it says 32 instead of 64 even though the input an output is 64 because it's a multiplication to 230 different numbers but I run now factoring on that input there and I get my result here which is the same as the output in they provided test case so I'm good like I feel very good at this point and seems to be solving the right problem except sometimes in the original Texas is and only sometimes the results include this sort of what seems like in totally unnecessary factor with one like this the thing that made it so that

should have been obvious what multiply that it was a factoring problem in the first place but it seems totally unnecessary obviously it's gonna affect with one that why would you even bother to help with that so when do you include that one when do I include that one and the results I'll leave that particular part of the problem as a exercise to the reader and in here as I said all this stuff is available on Mike on this github page every single one of the tests is there this document is there you can walk through they all run there's a makefile you can do that so you can dig your way through it and I'm happy to take any comments on that even pull requests if you want to keep going with tests to zero so that's it thank you [Applause] you [Applause] you
