Let's make a PICO-8 Game in 30 Minutes!

[Music] hi my name is matt lindsey i'm an independent game developer and i'd like to show you how pico 8 is useful for rapid development of prototypes or other small projects so what is picoway pika08 describes itself as a fantasy console essentially it's an all-in-one game creation suite that gives you a variety of simple rapid development tools each of which has useful constraints to help you make games faster it also runs on basically everything you can see it has a windows version and a raspberry pi version then a linux version and an osx version so chances are very good that you can probably work it into your workflow somehow so it gives you a very simple sprite editing tool uh wherein you can see right you can very quickly mock up these little sprites this here is a ninja and it has 16 colors when a fairly low resolution

which allows you to fairly quickly make easily differentiated sprites but not get too caught up in the details it has a very rapid tile map editor so you can go from having a blank screen to new platforms to jump around in and test on very quickly the map itself is large but not huge so you have some some constraints there too enough to give you space to test things or make something small but nothing too gigantic it has a very simple sound editing tool you can see here i select a sine wave and then increase pitch over time to make a sort of simple jumping blue sound right you can also select a variety of other different sound effects and a four tracker different uh music editing tool which allows you to import either these instruments that you've created or use some default ones and very quickly make

some music with different effects but nothing too complicated it uses a subset of lua as its scripting language so you get a rapid and human readable code base that also is kept fairly small it has a c a token limit on the bottom right side of the little pico 8 screen there you can't have more than about 8 200 tokens which keeps things from getting too bloated so pico 8 gives you a variety of simple low-level calls right an init function an update function draw function things to draw sprites to the screen or play sounds or show you the map so let's build on top of this and make a little platformer now you could at this point write a simple bespoke engine for whatever kind of game that you're trying to make and depending on your level of experience or the nature of your idea or

your time frame this might be the right idea for you but you don't actually need to work from truly nothing if you want to really get up and going faster any game that you load into a pico 8 console also gives you access to the full assets and source code of that game if you run the install demos command you get a variety of little sample games to learn from and build on like this little platformer here called gel pie or george lpl i'm not exactly sure and if your goal is just you know to build on top of something there like this demo platformer this might be all you need to do you might just install the demos load up the demo platformer and start adding some new stuff and i do want to note here that just because something is open source doesn't mean you have the right to modify it and publish it especially if this is somebody else's game that being said out of the way right

the original celeste which was a pico8 game its movement code has been released under an mit license so you are allowed to distribute it or publish it or even sell it as long as you also do so with an mit license now celeste and its sequel celeste ii another pico8 game use a very simple and similar foundation of collision input handling drawing things to the screen etc which works very well for a lot of different kinds of games of the two i think celeste two's code base is a little bit clearer and easier to work in so let's not go completely from scratch let's modify some of the basic structures in the celeste 2 code base into our game to give us something to build on now we're not going to be using the entire code base we're just going to be picking out the most useful portions of it the basic low-level stuff that we don't want to have to worry about when

our goal is to iterate on ideas and develop prototypes and a few places i'm going to be making some modifications for this purpose as well as for simplicity and i'll point those out when we get to them also uh before we move on i also want to note celeste 2 is not under an mit license it's under a creative commons license with all of these different attributes and you can't sell it if you make a version of this game and then put it on the internet just a little note here okay so we need some assets just to mess around with right so we can see here we've built up a few very simple assets we have a target we have a shuriken we have a little ninja we have a platform and i want to take a brief moment to point you at flags so you'll see here next to the target right there's all those little dots and one of the dots is red that means that that flag is currently turned on there are seven of the eight of them right zero through seven and we're going to be using that later the flags on them by themselves don't do

anything these are user defined this is just a way of us saying okay does this sprite have that flag great do something about it we can set these and check them in code as well but i'm set one here for a purpose that we're going to get into later just remember that the target and the ninja both have flag zero set so to start things off right at the top of our code we have a few different globals right we have our table of objects and a table of types in the table that's called lookup the table is the most useful and flexible data structure in lua you're going to be using it all the time your tables are going to be your arrays they're going to be just all of your structs are going to be tables right everything's tables and the lookup function for the lookup table here which is i think the most interesting of the three is something that we're using as a lua meta table to enable object-oriented style inheritance and if that sentence doesn't mean

anything to you that's okay don't worry about it it's all pretty simple to use you don't need to understand this to use it as well as that we've stretched up a few basic references to the buttons here right so we don't want to have to remember which button is left and which button is x and which button is o we can just set a few const here this is also uh adapted from the celeste one code base where this was present and is notably absent from these solus 2 code base so everything in our game is going to be an object and if you are familiar with object oriented game programming this is going to look very familiar to you i also want to note you don't have to make your game object oriented it's just very easy to work in and comfortable for many different game developers so our objects have a series of shared attributes they have a speed in the x and y direction they have a position they have an a unique identifier based on where on the map they spawned

as well as a few other little notable things here uh they have some collisions which are going to get into exactly how the collision engine of celeste ii and similarly how celeste works and why that may or may not be useful for your game but each object has access to those collision and movement functions they can see if they overlap or contain another thing they can see if they are solid right there's a helpful function called corner correct so if an object is moving and would just barely bump the edge of another tile you can sort of nudge it upwards or downwards slightly to give it a more natural movement path i also want to note here that each object has a user-defined hitbox which is an offset from that object's position and width and height this allows you to have certain objects have a hitbox which is differently sized than their sprite might imply so you can have a hazard be a little bit smaller than it looks on the screen you can have

a collectible pickup be a little bit bigger than it looks on the screen etc right here you can see i have drawn the hitboxes of uh celeste ii i booted up a level and i added a little bit of code to just draw all of the hitboxes and you can see some of them are larger than their sprites some of them are smaller you can see the spikes have very little little hit boxes right feel more fair and the player's hit box is just sort of this bottom rectangle now the way that the collision works in this little engine that we we're working on here that we've adapted from celeste 2 is pixel perfect so each object as it's moving moves one pixel at a time first in the x direction then the y direction and checks to see if it's hitting anything on the way this is going to give us extremely accurate pixel perfect collision and very very robust collision at that it's unlikely that two objects are going to out of happenstance be overlapping when they shouldn't be with this engine however

i do want to stress here that this is great for precise platforming and it's great for really precise collision detection but it's very expensive by which i mean it takes a lot of computation time so if your game doesn't rely on really precise collisions between objects you may want to use a cheaper collision model the platformer that you get when you install the demos for pico 8 has a much simpler version of this where instead of moving one pixel at a time it simply checks if your end position is somewhere you are allowed to be and if it is it moves you there and if it isn't it creates a bounce so that you would sort of bounce off the edge of whatever you were trying to move into and this is also you know robust enough this works fine for a lot of different kinds of games and if your prototype needs lots and lots of different objects on screen at the same time all moving around and detecting collisions you may want to consider this alternate collision version instead of the

more intensive but more accurate pixel perfect version oh also one other note before we leave this slide there's a flag here called remainder this allows you to make sure in this engine you're moving only an integer number of collisions per frame so if you're moving at a speed of 2.5 first you move at a speed of two the next frame you move at a speed of three it carries over a little bit of the non-integer portions of your movement speed to really make sure you have clean collisions because you don't want the player moving half a pixel and messing up all of your math inputs are handled fairly simply uh we have this large block here it looks kind of scary but really it's just saying if you push left you're moving left and you push right you're moving right even if you were already pushing another direction this works very cleanly uh also notably we have a quick check for your jump we want to make sure that

you're not jumping too frequently because that might feel strange so you can only jump every four frames basically if you're not already jumping you know if you haven't you haven't just jumped and you push the button great jump as to how and why you're allowed to jump that's handled later in the player code speaking of that the player code has been greatly simplified from the celeste ii original version we've essentially stripped away everything from it except a basic jump and move around and collision update i have chosen to keep the wall jump from celeste 2 because i think it's just sort of a fun flexible mechanic excuse me and it'll work well in the kind of games that we want to test out we may want to wall jump anyway and if you wanted to remove it it wouldn't be hard to remove the player notably has a state which is key to how its update function works so the player's default state is 0 which is

our standard moving around and jumping state if you want a different set of updates to happen on a different state let's say for example you wanted the player to be able to swim that is going to change how they update their movement over time it's going to change what happens when you get a jump input right these are things you can handle very easily and very quickly by adding a new state to the player that does what you want it to do and then adding a transition between the two states we're going to be getting into more of that later we also have a brief check here called hazard check so if any object in the world is flagged as a hazard we can know in what direction it should be a hazard and enable ourselves to be you know correctly hurt by it when that happens otherwise we have the same sort of move x move y and uh a simple flag called on ground which looks one pixel below the player's current hitbox to see if that is a solid object if it is you are on the ground you are allowed to jump and do grounded

things so at the very beginning of our game we need to spawn in some objects this is a very simple little code that looks at every tile on the map we're going all 127 across and all 60 you know 128 over 0 to 127 and all 64 down looking at every tile on the map and we're calling two different functions and get tells us what sprite is at the tile position x y and f get tells us if a sprite has a particular flag so this looks at every different tile location on the map and it sees if anything has flag zero if it does that means that that should spawn an object of the relevant type and shouldn't actually be a tile on the map so simply put if we find something which is a target and it has a little zero flag spawn a target in that location and then get rid of the background tile that

looks like a target right very simple very flexible again most of the code and structure of this code is useful for lots of different kinds of games besides platformers it's just generically this is a i think a helpful structure for you to adapt in your prototypes so putting it all together we've taken the celeste ii code base and stripped out everything from it that we don't need and put it into a new project you can see we've shrunk the number of tokens in our code from almost 8 000 to about 1700 give or take and we have some basic movement right we can run around we correctly uh enter do not intersect with the wall tiles we can wall jump this is all fairly stable feels pretty good to move around in and of course if we wanted to tweak the jump arcs or gravity or the movement speed or whatever we could do that very easily so now let's build on top of that right we're here to make a platformer so let's make a platformer let's iterate on this idea

so let's add some shurikens right our ninja has no way of actually interacting with the targets right now so let's add a simple type right we have a new type it's called shuriken and creating it is very easy you can see we just invoke the new type function and its initialization is very simple we just want it to get rid of itself if it hangs out in the world for too long right after you throw a shuriken one second later in a 30 frame per second game which is the default update if 30 frames have passed and this hurricane is still around it shouldn't be around anymore so all we have to do is move it in its directions in its little custom update and check to see if it overlapped a target right if it is overlapping with an object and that object's base is target which is another defined type that you can see below the jurican type then destroy the target and destroy yourself right or or more accurately set the destroyed flag to be true of the target and the

destroyed flag to be true of yourself to be later cleaned up in the update function otherwise we need to go update the player right similarly similarly to how we are updating jumping and detecting jumping input we add another function here that takes it a quick check to see if you're pushing another button right we have the button which isn't jumping which i called k other in this case which we're now going to use for a weapon so if you push the weapon button and i want you to be able to throw shurikens more rapidly than jump so you can do this every other frame then you know now you are considered to have your input weapon pressed and later we have a in the update we're to see if you're pushing that button and if you are we're going to throw a shuriken and throwing a shuriken is very simple if you are facing in the direction it spawns the shuriken in front of you and then gives it a speed related to your speed so if you're running forward throwing a shuriken it behaves how you

expect it to and uh and and so right so now we can throw shurikens right there's a little ninja he's hopping around and he's throwing shurikens isn't that great and uh those shurikens interact with targets and if you wanted to right we could also add sound effects to this pretty easily we could add a sound effect for throwing a shuriken and then sound effects for blowing up a target we could add sound effect for jumping these would all be very fast to do right this is very very rapid iteration at this point but throwing shurikens is great but that's not movement let's add some cool movement as well right so let's add uh ice skating right so think like frozone or iceman right they can they can hang out in the air and skate on a sheet of ice what does that actually look like well if they're moving downwards right if you're falling then you can convert that speed over 10 frames you can move your vertical speed into horizontal speed and that works pretty well

but it also doesn't really sell the illusion on itself so we're also adding one other set of small changes we're adding icicles icicles are not objects in this case they are simply points that we keep track of and with an age right so every icicle just has a point on the map and then it as it gets older it gets longer and it has a bit of randomness in there too to make the icicle path look a bit more like natural instead of a big sheet although again if you wanted to make it a big sheet you can make it a big sheet the only other note that we should uh track here for the icicles is if you just put one at each position if you're moving it faster than one pixel per frame then you'd have holes in your ice path so you need to make sure you iterate your ice path over the entirety of your movement right and there's a few other little changes to make right we have an ice skating state which uh if you're you know if you let go of the button then you uh then you stop skating if you uh hit the ground you stop skating right

all this all this stuff so now you can skate around right now you can hop off a wall and start skating and you can still throw shurikens right we've even moved the shuriken throwing code to outside of the zero update and into the generic player update right you can even skate backwards if you want to and this is pretty cool and now we can start iterating level designs off of this right what happens now that you can skate on ice well because you have this fairly controlled horizontal movement you can have this ladder-like structure right you can very easily sort of climb up objects if you have access to enough right you could theoretically you could do an infinite wall jump uh if you wanted to you could actually set a limit to this you know you could not have an infinite amount of ice skating but a limited amount of ice skating or increase that if you pick up an object or whatever right iterate just have fun with it have just mess around the idea at this point now that you have the basic structure i also want to take a note though right what we did is essentially go through the celeste ii codebase and take the

portions of it that we think are most useful for our game and strip it away and and port it into a new cart and make it from scratch you don't actually have to do that if you don't want to because remember if you load celeste 2 into pico 8 then you can just modify it so what if you want to do that right what if you want to just load celeste 2 right into your pico 8 console and start modifying it immediately uh there's a few small changes to make here you add a little flag at the top that says standalone equals one this is something that was already present in the code base and allows you to have better interactions with the map as opposed to the uh compressed tile data that it was originally ingesting so by doing this you can just modify the map and sort of the upper left corner and start drawing things out we also need to create the player because again we're no longer loading

our levels in the original kind of way so in the init just put the player somewhere i put them at 30 30. also you can remove all the grappling hook stuff because presumably you're not here to test out the celeste ii grappling hook you're here to test out your own new movement so you can just remove that stuff and the decompression i want to note here that the code you're seeing is not right taken right from the picoa console it's actually taken from visual studio or vsc visual studio code in the back end a pico8 file is just a long text file so you can edit it with whatever tools you usually like to edit your code and then simply reload the game in pico8 and it'll load in your changes right very simple to integrate into your workflow you don't actually have to use the text editor present in pico8 if you don't want to so you remove you remove the grappling hook stuff right you remove all this this stuff that you don't need now we can add some new stuff right let's modify it let's let's uh change things

up so let's add cling to ceilings that's kind of a fun idea i don't think i've seen that in a lot of games some games yeah sort of a ninja like move where you cling to a ceiling move around so what does that look like well if you're in the air and you're holding up then you should be clinging to a ceiling if you are next to a ceiling so we check two pixels above the player's hit box and then if that's solid and you're holding up great you're clinging to the ceiling we add a new state that says if you're still uh below a ceiling right if that ceiling hasn't stopped existing or if you haven't moved away from it you're still clinging to the ceiling and you can also move around left and right if you're on the ceiling if you let go of the button you shouldn't be clinging anymore right this is this is all it is a really small code change to make this new behavior and now we can just jump and cling to ceilings right pretty easy pretty pretty clean right didn't take very long at all to go from load up celeste 2 to add this new

different movement option but why stop at one right let's keep going let's add some more stuff let's add hang gliding so what does that look like well we have a hang gliding sprite which you can see has a little hang glider and the poles and lonnie's little hands holding onto the hang glider which we're going to just draw right on top of lonnie as long as he is hang glider so you can see that we just add a new state called you know we call it hang gliding and it has a very simple movement code it simply accelerates you in the x direction and ever so slightly dips you down over time right that's all it is this is all of the code that you need to add this new movement option now that you have the engine right and how does it look like well it looks like this right if you're in the air and you push the hang gliding button now you're hang gliding right and you can even use the two of them you can hang glide off of stuff and you can grab onto ceilings so what does it look like if you have both those things right what kinds of levels can you make with these two sets of mechanics well maybe you

could do something like this right we have a series of horizontally focused different areas for your platform through right you have some spikes around there and they're differently traversed with combinations of these two mechanics all right you can continue to modify this right maybe you need one upgrade first and then you go get the other one maybe uh you have enemies that you need to glide around right you just set those as hazards in the code and give them some movement you can even have them have access to the player if you want to to be able to track them right maybe you want moving platforms that's pretty easy too you just make sure that your platforms that can move are listed as solid and that's going to satisfy the constraints that we're using to check to see if you can grab onto a ceiling right very easy to iterate on from here so you've at this point let's say you've made your first pass your prototype right you have an idea and you've executed it in pico 8 in some form and you want to share it with either other team members or you want to get player feedback to see how it feels right

how do you do that how do you share your game it's it's quite easy so you can run a command that says save the names your game dot png this saves it in a cart right pico 8 cart is just a very very small png file that you can load into a pico 8 console you can see here all of the modified celeste 2 here that i didn't remove a lot of stuff from i removed the grappling hook from and i removed the compression tools from and i added some other stuff that's 36 kilobytes all together it's a very very very small file and this can be loaded into any picoa console by using the load command or just by clicking and dragging the file into the console and then hit control r that'll load it and then you can just you're off to the races now you can go right but if you want to share it with other people who are not internal or who don't have pico 8 or for whatever reason if you don't want the code that you're sharing around to be viewable right if you don't want people to have access to the source there are other ways of doing it too

you can export it as a web page right export your thing dot html it spits out an html file in a javascript file and now you can host this on itch.io for people to play you can hand this to anybody to open in a web browser if you have an internal company website you can host it on your internal company website and tell your fellow employees to go check out your uh your network website and then they can just go play it and give you feedback right and there's a full web integration player for pico 8 files but if you also don't want to do that right if you just want to give them executable you can just give them an executable you just export something dot bin and it generates an executable for any kind of platform you're likely to be running it on it's got a linux version and an osx version and a windows version you just give them the zip file and in there is your executable and then they can just play right it's just compiled code so i do want to note here that there are some kinds of games which are not especially fast the prototype in

picoa right 3d games like this is a version of doom called poom uh that somebody made in picoad is actually a small team of people over a long period of time a lot of work to make this very very cool thing and it works great but this is not their rapid development right this this took a lot of work to make happen so these kinds of 3d games uh you can see similarly we have a port of virtual racing right also perfectly possible very doable in pico8 ignore my terrible play here for a moment but you can see there are you know basic polygons and there's a really cool dithering effect and you have a little modeled car and he moves around right all very possible but a lot of work uh and probably not fast for your prototyping the other notable limitation is text based hey games or text heavy games this is a pico egg cart that has the first three chapters of a tale of two cities which works fine but requires

a bit of a bit of finagling so if you're planning to just write your strings right in the code as raw data and you need a lot of them like a lot a lot of them maybe consider additional or different tooling so to wrap things up i use pico8 pico8 gives you really useful constraints for making your prototypes making them really really quickly and making them in a way that's very easy to share and export with other people anybody can play your picoweight game once you've made it uh so thank you all so much for coming right click there uh my name is matt lindsey you can find me on twitter if you want to talk to me about picoac or anything else i'm at matt lindsey this talk was largely developed from a development blog i'm writing for a little pico 8 game i'm making called ball ninja and if you want to read about that or other pico 8 development things as i work on them um if you want to see this project as it goes on you can just go to ball.ninja which is also where i'm going to upload the carts i made specifically for this presentation if you want to play with

them yourselves thank you all so much for coming i've been matt lindsey i hope you all have a good gdc it's been an honor to be here thank you all so much bye
