Geometry Caching Optimizations in Halo 5: Guardians

[Music] hi my name is Ben and this is a beer we'll both be talking today we're here to talk about geometry caching that we did implement it in halo 5 Guardians so for those that are kind of new and don't know what geometry caching is it's the storage of vertex motion for quick playback it's like motion capture for character animation allows you to capsulate really complex motion and play it at runtime in the game engine for those Maya animators out there geometry caching will be familiar term as you do play blasting and your 3d animations when you're doing flip books but let me show you in game example from Halo 5

keep your head down and run I'm okay keep going [Applause] so beyond doing massive deals scale destruction which was our primary goal in Halo 5 we found out that geometry caching is pretty much good for any type of kinematic based motion as we developed a system we went from just purely a destruction team into a wider ranging thing using it throughout the

whole package and software we used it for character rigs effects environments and sky boxes the author of this team authoring teams for this type of technology can actually be any of your team you don't need to have a specific team for it you can use it based in any year system if you componentize this code so what we're really talking about is moving geometry really fast on the GPU we got off to over a million GPU transforms at 60fps and our engine which allowed us to fine tune and make this thing extremely fast and efficient in the gameplay me and Sabir didn't do this alone there was a large team of us that did it we so we want to give a quick call out to those guys Michael Bolton was the forefather he made the first homebrew geometry caching for us on Halo 5 Chris woods was our field art lead who kind of led our team Sabir was our white knight engineer that came in after Michael Bolton and fine-tuned that so he could go through all his technical details on that Alex Hogan was a tech art lead he helped

with the initial testing and implementation Mike LaFave was our content creator on the project who really put the thing through its paces my name's Ben I did the authoring story for Halo 5 pharrell this content that's now in actually Houdini 16 so you can actually get in there and actually access this technology right now but we also want to give a shout out to everybody else at 343 that we worked with there's the list is kind of long so they all helped in a lot of different ways so I want to give them a shout out to that so for the course of this talk we're kind of give a little outline to what we're gonna do just so you kind of understand the dataflow we're gonna talk about the initial concept how we actually kind of thought it up where we came from it we give you a little background story on why we're actually optimizing things because geometry caching has actually been implemented in a few engines now but these are optimizations to actually push it up to the next level then we're gonna break down the technology and its core architecture and then all the component ties systems that we have for it

and then we'll wrap up for a few questions so in the spring of 2015 we knew we're going to be in the e3 headliner so ever all eyes were on us for our talk that sequence was the main focus of the studio and our stuff started running a little bit over perf because we were trying to get the best we could out of it we're shoving as many things and sequences in there so one of the tasks that we were challenged was was making our system even more faster get more geometry in there optimize it so we had to share the load across to all the different teams like lighting animation effects those all had to share and coexist with our system so we had a little I of the production I saw are on fun as everybody was intently honest so it kicked us up to the next gear technology sort of those wondering why we needed to improve that was the primary reason so let me just kind of dive forward our very first implementation is the kind of a standard fluid approach this is topology that

changes every single frame that means the beacon described as vertex count agnostic that means from one frame to the next frame topology completely different you can go from a human to a man you're not using blend targets you can literally read to I put you to apologize anything like VD made rameshan and surfacing this is kind of like the Olympic file format where you can quickly load and reload anything in offline packages well Olympic is a good idea it's not actually a practical runtime solution and engine so one of the things that we this if we continued with fluid we were gonna actually have all of our assets cut so we moved to the next thing we found out Michael Bolton implemented us for us sorry Michael Bolton helped us implement a rigid pipeline so rigid is what we kind of deform to fine as multiple vertices that share a single transform this is the concept of object transforms bones particle animation character flock

swarms leave blowing in the wind this became our golden child this is pretty much what we ship almost all the assets with in Halo 5 however this method was not enough to ship we still needed to do soft information one night as a beer was working hard and he actually came up with the next implementation for us we called this soft it's a single transform per each vertex we could find out we could pass it around like tens and hundreds of thousands of transforms so in order to take those transforms that are per an object we put it per vertice allowing us to bend to form towers a lot of those actually towers are really soft deforming buildings that were had to over 32,000 transform so we're crushing down um but in order to take the technology further for us we developed a framework in order so we can further and continue to optimize this going into the future that's we got the full framework this is the core architecture on top this is the shared across all the heuristic values our base component we

actually introduced with static rigid skin soft and fluid static is something that we actually never focused on at first when he first implemented this but actually the static component is really kind of important that's when the geometry is not moving which is the biggest time-saver you don't have moving geometry hiding under a table or something like that you need to efficiently call and maintain this just normal end state's environment you are matauri but actually has to be built into the system and skinned is more of your standard character pipeline we didn't really focus on this because of the type of work we were doing but it is a core implementation strategy this is a multiple transform for multiple bones so as we go through the talk we kind of have this in a different little heuristic to we're gonna talk about the core architecture which I'm going to pass off to severe for a little while and he's got run through what the common optimizations and quantizations for the rest of the code they're not gonna come back to it and I'm going to talk about the fluid rigid static soft and skin more from the authoring side of handling

okay so let's talk about the engineering side of things mainly this slide is here for you to kind of refer back to roughly as a table of contents we'll go through the data structures involved the import pipeline and what the runtime involves so as Ben mentioned in order to actually pull off this geometry cache system you have two components to it you have transforms and you have geometry these are roughly the the components that are necessary for each type you know something like static you only require geometry just because it's actually not moving and something like soft implicit surfaces you only need transform since the implicit part kind of describes the geometry inherently we'll touch on these exactly as we go through this slides so let's talk about transforms first in order to represent and transform this is kind of the bare minimum that you need to represent rotation represented using

a quaternion translation and scale obviously completely unpacked this is 32 bytes which is quite heavy to be passing around but before we go further let's talk about some of the alternative representations that we considered when developing this technology one of the first things that came to mind is storing Delta position and Delta rotations of course because of the temporal coherency you get much better compression from this however we knew that halo 5 was going to have to support join in progress when you have joins in progress systems we didn't know exactly how long certain animations were going to be and that we would we wouldn't possibly not be able to support blast playing up to a particular frame when a joint in progress was actually happening in retrospect this was the right decision looking at the perf metrics and some of the lengths of animations we would not have been able to blast play everything up to when join in progress needed to actually occur the second representation we also

considered was storing velocity and acceleration this again has a lot of temporal coherency so there's there's quite a bit of compression you can get out of this however I was worried about the the physics simulation that we would essentially be writing in the stability of that right because again this is still some sort of like a delta compression format where where the previous frame describes your next frame this again doesn't solve the blast playing problem and join in progress was still a concern so the third representation you can think of is sort of like a video codec right where you have major frames where the full transforms are stored and then you Delta compress between them this is quite promising but of course the complexity was high throughout the project there was only one graphics engineer on this project first it was Michael Bolton and then I took over midway through so we knew we didn't have a whole lot of time to dedicate to this and and on top of that you know I had all their responsibilities as well also when we were moving from Halo 4 to

halo 5 we went from 512 megabytes to 5 gigabytes at the time we thought oh man 5 gigs we have so much memory we will we don't need to compress that much right we have plenty right we're just gonna have trouble filling the the 5 gigs from disk this turned out to be we were very wrong we ran out of memory like right away so to remind you again this is kind of the the transform which can fully describe what the transform is per frame we didn't want to have be dependent on previous or next frames the PAC transform that we end up coming up with is we relied mostly on quantization so we ended up packing the the quaternion translation and scale sort of as follows so let's go through each one of the the quantizations that we did for translation it's we generate a axis align bounding box per frame and we store that per frame bounding box off as constant data we quantize the translation between 0 & 1 within the axis line bounding box and it's a simple

operation to to reconstruct our original translation of course this is a lossy compression but this as long as your your content team is sort of aware when they're starting to lose precision they can where they can work with this and then we'll touch on exactly some of the techniques we use to try and mitigate this so quaternion compression this is an entirely novel I've seen in a few different places but I don't remember the exact source where I pulled some of the ideas from but we start with the quaternion identity given the paternity and identity we know that we can derive the force component from using only the three others however this leads to a precision loss if you if you always pick W as the oh sorry skipping ahead so we know that from the previous slide you can see that W will always result in a positive value of course using another quaternion identity we we extract the positive R at the inverse quaternion in case W ends up being so however that leads to precision loss if

you always drop the W component right so we can store off exactly which component we are going to drop and we drop the maximum value between X Y Z and W this allows us to again retain more precision since we also know that we've dropped the largest largest paternity and value we want to renormalize the remaining values the remaining values being renormalized we maps to 0 to 1 so essentially we're storing 3 components at 30 bits and we store which component we actually dropped in two bits scale was was very simple quantization and this was quantized between 0 & 1 what we did is during the import stage the entire scaling entire scale the maximum scale that we could see was renormalized between 0 & 1 and the geometry was expanded so that scaling was always between 0 & 1 this allowed us to only shrink the

geometry as necessary not actually grow it and and this was quite helpful also being able to scale by 0 is quite important as that's how we deleted parts out of our actual simulation and we'll touch on that later so let's talk about the geometry representation of what actual what that meant so we have to remember that this is going to involve two different geometry representations one pre vertex transform pre geometry cache transform and one post transform you want to integrate this into your existing rendering pipeline you probably don't want to build a whole new rendering system just to render this you kind of want to do the transforms and integrate it into exactly you're doing it and you want to try and look for the fastest way in which you render static geometry in your engine for us this is roughly kind of the vertex format that we had in the vertex target that we wanted to go to again so position we needed to transform UVs were kind of a pass-through normal and tangent of course we needed to transform since the the target is a world vertex

and the X form ID was again used as a lookup to to try and feed the color the reason this geometry format was picked is Halos engine didn't have a super flexible vertex format in that you could arbitrarily pick whatever we had a set of vertex formats we were choosing between and the world's vertex format was essentially the the fastest that we could render objects with dynamic lighting for your shadowing this was just as a we just rendered the geometry into a cascaded shadow map and the geometry again this was the fastest pipeline through our engine so this is the vertex format we chose so the vertex and index buffers I'll touch on this very quickly the vertex buffers we were able to limit to 65,000 parts and and therefore we were able to get away with 16-bit vertices the way we were packing the vertex buffers initially we stored them as 32-bit vertex vertex indices this is quite slow on the Xbox one so if you are considering doing this it's

really worth your time to chunk up your assets so they can be split into 16-bit indices we didn't end up being able to make this optimization just ran out of time but this is definitely something you should consider so I want to touch on implicit surfaces there were some types of surfaces that we used in the engine that were very uniform it was just like a flat plane so you can imagine like a flag which has a very uniform topology you don't actually need to store geometry data for this given a width and height you can actually derive where the vertices would be on this particular shape and you can use the vertex shader to and and the sv vertex ID attribute to derive where all the positions are of this actual shape so all you need to compute is the transforms this is particularly useful for soft bodies now I'll touch on how we used LDS later but in this case vertexes carrying that unique transform so the LDS memory where you would potentially share computations between waves are between threads wasn't

actually necessary so this turned out to be a good way to handle implicit soft surfaces we also had initially talked about the idea of additional vertex attributes the transforms are essentially what's driving the the dynamics of the whole simulation however there could be additional attributes like temperature and viscosity and things like that to drive the the color and and you know the shading of the object itself then we'll touch on the pros and cons of kind of this approach we ended up not making a whole lot of use for it but yeah he'll touch on exactly from the authoring story and why you would want to prefer one versus the other okay so let's move on to the import pipeline we were we used Olympic heavily and from our DCC we would go into Olympic however you do not want to use Olympic as your format that that your runtime is actually using you want to pre-process this into a specific engine optimized for Matt because Olympic generally represents full frame

geometry every frame you're getting essentially the entire stack the initial implementation that we had for this was a analytic part extraction where we were trying to find temporal coherence between a rigid part that appeared on one frame and then rediscovered that far but we discover that part in a later frame this was a complicated mathematical process to try and discover this coherency based on the tolerance levels used we could either get higher accuracy but it lets you a huge import time or if you reduce the tolerance we you would get either false positives so this ended up being very problematic especially how long it was taking us to to import so the next stage of it I realized after working with Ben for a little bit is a lot of this inter frame cracking that these rigid pieces were going through actually existed in

Olympic to are existed in Houdini are programmed to begin with if Ben was just able to export this additional attribute data we could speed things up immensely and and once we did we yeah we saw an incredible speed up we went from things that used to take over 30 minutes to 45 minutes down to maybe you know 30 seconds it was incredible speed up that that was very much worth it also this led to a really really high accuracy unless the artist actually made an error in in the park tracking so this was overall a win sometimes you know just a little bit of data helps eliminate a lot of processing power we didn't actually I'm fully implementing this in the production pipeline but after working with it for a little bit we realized the system can actually be split into two components you have the transform hierarchy and this transform cloud that your dynamics artists are working on and then you have a palette

of geometry that a separate set of artists could potentially work on so for instance if you wanted to do an interesting flock of birds one artist could actually work on the bird model itself and then the other artist can actually work on the the dynamics and the fly through and then during the import stage buying them together we ended up not quite having this this nice separation between the two teams but this is something that you guys should consider if you plan on implementing something like this just a quick note on meshing optimization we use the DX mesh optimizer and this saved about 3% GPU time all right yeah GPU time this would this added very little to the import stage so it's definitely worth adding in so let's talk about packing for the run time so so far we know that the import stage generated a palette of geometry pieces that we want to pack together and we have a set of transforms that are part per frame while the part is

actually alive so what's the optimal strategy the entire time we were bandwidth bound on the GPU so bandwidth is the key thing you want to minimize so the way you want to kind of pack this and we'll go through an example to kind of show you is you want to sort everything that's first born to the front of the list all the vertices and then all the parts within that frame you want to sort the thing that dies the first towards the front and what you end up with is essentially the right edge moving ahead as parts are born and the left edge moves ahead as parts die and you want to pack this into one big buffer we were specifically shipping just on the Xbox one so really wanted to optimize for the minimum number of allocations and pack the data together and offset into the buffer when when actually binding it and also null transforms are important here in order to eliminate some of these transforms so to give you an example if here we have

you know four parts one's born and on you know frame 0 the first one and dies on frame 3 right so the active range for this when you're rendering frame 1 is just this object here when we start rendering frame to the next part is born and we're still rendering the previous part that's alive in frame 3 obviously the first part dies in which case now weird active range shrinks again the left edge moves ahead when we render frame for another part is born in the act of rage expands and this is kind of the way you want to bind into the B onto the GPU the the active range of the vertex buffer now what on frame 7 you notice that a new part is born however a part that stuck in the middle has actually died in this case the way our pipeline was set up we shipped on dx11 halo 5 so we didn't quite have some of the more I guess advanced geometry vertex generation on the GPU that we're starting to see kind of like in

frostbite and also in Assassin's Creed but this is essentially the idea you you might be able to do some interesting things with there and not have to rely on the fact that you need to delete a part in the middle in this case now when it comes to transform packing you kind of want to do the same thing pack all the transforms into a single giant buffer and we want them packed right next to each other and we offset into the buffer to actually render it in this case you can kind of see that on frame 0 there's only one part that's action active and alive and therefore that gets packed first on the next frame again just only a single part so that's what gets packed in the next frame there's two parts and so on and so forth this ideal packing again tracks to what your actual active ranges and your binding the minimal set to the GPU and and essentially transferring the minimal amount of data to the actual GPU one thing yeah so pack into a single buffer

this ended up being much more efficient in terms of minimizing the number of allocations that d3d is going to do one thing to note is because of the packing structure that we talked about earlier if you use structured buffers this is going to lead to byte swapping that's going to occur between the CPU and GPU so you want to be aware of this we ended up using the byte address buffer which is quite handy not a lot of engines necessarily support it but this is something that you need to consider if you need to represent CPU okay so let's talk about the runtime down so the first thing that we implemented was interpolation and looping for everything even the quaternions we were able to drop something from most of their animations from 60 frames per second down to 30 frames per second this allowed us to obviously cut the bandwidth in half right away for far distance objects you can interpolate even more and kind of get away with it because they're obviously not so big in screen thing to note is deletion and creation rules can kind of get hairy

here when you're interpolating you need to come up with a defined set of rules that make sense of when does it when is a part actually born and when is a part actually die when you're in between frames we weren't super happy with the rules we came up with because it always led to some inconsistency in one animation or another so experiment with this and find something that you're happy with also interpolation is obviously not an option for fluid assets this is changing topology every frame there's no per there's no inner frame coherency between the vertices so the first approach that we had for the GPU pipeline was a series of compute shaders where we would decompress and blend transforms in one computer transform the vertices in another and then another computer to compact and to the render pipeline this obviously continually round tripped to the main memory and and completely killed our bandwidth so this approach was not going to work the second attempt was to have an uber computer where we perform all the stages in a single computer

we used group sinks to try and synchronize data caches and we utilized LDS to to synchronize between or within the wave itself this was about a 3x speed up and so we were pretty happy with this a note on the decompression obviously on you you have a limited amount of LDS memory when you're actually sharing your your blended and trended and uncompressed transforms so your active number of transforms that you can write to LVS has to we limited it to 64 in order to make sure we had enough occupancy on the GPU this was enforced in the importer when the importer detected that you are going to end up with more than 64 transforms per way or it limited the wave size to only a maximum of 64 transforms so when actually selecting the dispatch size this is essentially what you want to

keep in mind you want to select the largest dispatch size you can you can you can find but only up to 64 transforms per wave you don't want to if you schedule 2 if you schedule anymore than that onto the LDS you you will start to suffer occupancy issues for us this almost all the time we were still able to run the maximum 1024 lanes except for the last wave which usually was whatever leftover number of vertices need to be processed so the the next big optimization came is when we moved everything over to a synched async compute this is a fixed animation so you know what's gonna happen ahead of time you can prepare future frames in previous frames we had quite a few occasions in our pipeline where the GPU was idle and this is a great thing to pair with things that are ALU heavy essentially this is almost entirely bandwidth bound and

so if you have ALU heavy sections of the GPU this is when you want to layer this in also at the end of the project we started to play around with how to integrate physics more into this we were able to generate physics collision data just in time and especially on a shared memory system this works out pretty well you can feed this back in a havoc using we were experimenting with those two physics types to try and feed the geometry back into havoc and actually have collision responses on them there are several variants here you that you can play with for instance you can have on/off States which is obviously pretty easy so if the player can't get to a bridge you want to blow up the bridge and then so the on state is the bridges there and they off state the bridge is gone and then a more fine-grained approaches the player might be on the bridge while it's collapsing in which case a physics geometry needs to be generated every frame so both those are the two kind of approaches we started to look at and the last thing

I'll point out is the slides will be available offline so you can read through the shader exactly but the key thing to remember is you want to try and hoist as many of the processing into the scalar unit from vector units as you possibly can for the Xbox if this was make uniform call this is now available in shader model six as more of a cross-platform ability but it's definitely worth optimizing to move as much of the work from vector units into scalar units as you can the next thing is also be sparing with your groups inks they can be costly and if you have too many of them they will end up slowing down perfect it so we only ended up needing one and this is the rough structure and how we decompressed everything again just to remind you on some of the things you can do here's another

to advance on the constructors coordinates affirmative commander that Kraken reveals sequence from Halo 5 in the plateau section of the game was one of our first levels that we actually worked on so it's one of the first things that we learned a lot about the game and how geometry caching worked it's also the one that kind of carried us through the whole production as we had to optimize and change things um so I'm gonna I'm gonna jump into more of

the authoring side for the rest of the talk and kind of go and lessons we learned from like the artist side so you can use any content creation package you want one good thing about using a little because to intermediary we could use max maya any package and write to a limbic and then we could interpret import that import that data into the engine so that way we wouldn't be limited by whatever software our artists were but a few things to keep in mind though when you're authoring for these different types static needs a relative mesh for each frame so that's like camera culling on so you need to have components in that in your DCC rigid needs an identifier per part in Houdini we use name and my you can use the shape nodes or you can put an ID per each bone soft needs a wide range of deformers so whether you're doing in cloth so fluids lavash or rate projection skin needs the whole character pipeline so the more automating you can do of a character

pipeline it's a little bit better you try to avoid as much of that character author a character authoring when we're doing geometry caching and fluid needs to be able to allow the package to do anything so you can switch from bears to dogs two cats all in the same geometry sequence and pick any frame you want it's not just necessarily VDB remesh Inge you literally need to be artistically allowed to do whatever you want um one of the things to keep in mind is the lexicon for each software package is different we actually ran into this issue a lot limbic Houdini and Maya all use different terminologies and across the studio not every base really familiar where data is stored so you can look at this offline but like places where UVs are stored its vertex level and Houdini but in my it's like the face vertex level this actually becomes a big lingo issue when you're going back and forth with your software and these are the additional attributes

that we had a store for each level of the data I'm using the Houdini terms on the left cuz I'm more familiar with them with the point that's just your raw position data and you also need your DC asset DCC additional attributes that you don't really export and that's usually a rest position this is usually our T pose for on your geometry caches you use this to blend back and forth and to maintain the geometry as it goes through traditional stuff like your vertex as your normal TVs CDs and colors and skinning weights that's where you normally maintain them and then on the primitive level you have to maintain your part IDs and materials the other things to keep an account is a pointless and primitive list this might seem a little bit weird but as you have a geometry sequence over time it's very easy to manipulate the data and have points in the geometry get in a different array and as artists come and merge and blend geometry suik instance together you can get the data stack of all the different like point listings arbitrarily out of focus and it comes

really hard to track the data so we actually put a list at the very beginning of our content import so as soon as the geometry came in we assigned each point a list number so that one would go to export it it came out the same list as it goes through the whole sequence also the Olympic intermediate format we'll only reasons why we're using it is it supported in a host of DCC formats and it's also actually implemented in a lot of the engines and different varying levels one of the things we originally got this concept of geometry caching from the CryEngine so I we know and a lot of the derivatives of it that this geometry caching texts exist at a lower level State across a lot of the engines right now also the one thing we also want to talk about the Olympic versatility as you're using it as an authoring source the best thing about Olympic is it allows you to read any line of data at any frame without having to slurp up the whole thing if you use FBX and you have a 3,000 frame sequence you have to literally load up

the whole FBX sequence in order to pull lines of data out of it where's a limbic it's really easy in Python or in different seed bindings to be able to pull the one exact piece of data you need and when you're writing out big large sequences of 3,000 frames 100 frames in geometry you don't want to kind of like have to pull in and consume all your memory on your computer just to be read it the one other thing though to describe though is olimpic is not a universal seem description format like FBX and Colada and stuff like that so but what it does really well is handle geometry and that's all we really want the intermediate file format to do another thing that we kind of ran into a lot is integration and performance testing Jarmusch crashings could be really a small part of your pipeline so as you implement it you should take in these things as note building a kill switch we were working on like some of the biggest events throughout halo 5 and we got kind of the Eye of Sauron throughout the whole project just because they're the biggest things everybody has really focused on them so we in order to prove that our system

wasn't the culprit you can just easily kill it and then see the perf cost of other systems whether it's your effects your lighting yourself like that are actually a baseline for our system was under two microseconds whereas like the other effects systems and animation system usually have a higher-level need because they have to do a lot more CPU GPU bound work whereas ours if you just turn on the system as two microseconds the other things to keep in mind is it's a geometry sequence so when you actually want to put it into a sequencer or do testing have start/stop resets of go do frames and also make sure you do test for a little bit because it does different burying types of storage format so it's kind of the dynamically compressible so make sure that the when you have just like say a static piece of geometry the whole format will change itself to be the best optimized and then also with the Asthma Sabir mentioned earlier with a deletion and creation it can get really hairy so we listed out a list of tests to do

but these were very seems like silly tests but they became very unique and different for us and then depending on how you write the code they could actually cause some pretty interesting gaffes to say the least we actually lost our fluid caching pipeline because of deletion in creation at one point so now I'm gonna dive into the component system so for fluid to kind of give you a little better idea of what it is if you ever have seen a 3d zoetrope it's suggestive static models and as you spin this around and you look through this slit you'll see the birds in motion this was thought over 130 130 years ago but we use it a lot for DVD beer meshing nowadays we've kind of talked about the pros and cons of fluid some additional optimizing and some topology examples fluids were kind of like our first lub they we thought it's going to be the only thing that we needed and that's one of the reasons that actually almost got

the whole system cut from Halo 5 because it's not really a great experience it's really easy to author it's easy to get into the game you can rapidly prototype and you can do any art asset there's really no minimum bandwidth you can just pump geometry into the game however it becomes very expensive in there it's the same reason you don't want to put an Olympic file straight in there it comes really large data sizes but it's not really a reason to discount fluid there's a lot of times where you just need to do pure art and rapid prototype so fluid is really good test case for that as the beer was messaging the optimization that doesn't require transforms the geometry you know it's a constant load to the GPU so you can if you have a really good streaming system it makes the process a lot faster you can always balance for the constant memory load sorry yeah go on

so this is a quick topology example for those aren't familiar with the dynamically changing Poly's this is what fluid really is I'm gonna move on to region now this is used to really heavily at the very end state of our game we actually when you see this next sequence we actually had over like 10000 close to 20,000 swarms going for but at the end of the sequence we passed it on to an outsource vendor and they did the assumption that we could only have about 20 flaw 20 of these constructors in the swarm afterwards so we actually had a cut out over 75% of the swarm down in order to meet that source outsource vendors expectations [Music]

[Music] so rigid really was our golden child it was how we should ship the majority of our all of our assets across the whole game soft and fluid and skinned are really important but rigids really were you gonna use 90 percent of your assets when you can access tens of thousands hundreds thousands transform very cheaply and efficiently it's easy to make anything a rigid body so we're gonna kind of go over some of the different benefits and pros and cons of this aliasing issue subsidizing issues some of the reasons why we actually had

art defined limits on the asset types and then some more improvements with instancing lobs and sprites so with rigid it's really any kinematic motion it becomes really just a really transform cloud in the end and you can put on this transform cloud pretty much anything you want so since it is kinematic it means it's baked animation but the good thing is you still want to put lights of life in your engine and in your game so if you have all these interactive systems we're not trying to absorb them or replace them you can actually use those where it matters really up-close in your face so if you have a nice animation system or flocking system you can have that right up in your face whereas this geometry caching can be off to the side and cyclical cycles are in flags off to the side it's it's a trade-off and memory and stuff like that but you're reducing all the runtime costs associated with running a simulation or a whole character based animation pipeline and you can also

componentize this code so that you use it in your GPU in different sections of these systems like your flocking your particle your crowd system you can kind of spread it depending on how you cut up the code and share it in your system so one of the things that we actually found out we actually don't have anything with a million transforms in Halo 5 this was actually a system test that we did when you actually put a million things in the game at only 1080p you don't actually have enough pixels on the screen this kind creates a noise problem you actually get true aliasing because you don't have enough pixels on the screen only until you really get to 4k do you actually notice that you can actually have a million points flying around so we're not really trying to compete with Krakatoa we're trying to just do simple INF assets and usually when you're getting that complex it doesn't actually have the intended visual objective that you're trying to achieve just because you can morph

routing things on the screen doesn't necessarily mean you should but one of the things to do if you are trying to put that many points on screen use just a simple pixel shader you don't need to do any expensive textures or anything like that it causes a lot of aliasing and also sorry you don't even actually have to really do geometry or anything like that when you really get to a million points on most of the screens resolutions for the next couple of generations you can really just use a ribbon with points on it in a regular effects pipeline it's useful up to a point but what it really means when you can push a million transforms around is it's really efficient and that you can share the load across the whole system with your effects and the lighting teams and your footprint is generally extremely small one of the methods we actually used is called subsidizing it limits the amount of pieces that you actually have to author you don't have to author 100 different objects people have a hard time counting objects if you really want try to count all the stars real quickly it should take you only a second but

it's actually 10 stars in there but the way your brain processes is the same reason we cut the phone numbers down to about seven digits its mouth the max limit humans can perceive real quickly at a glance so when you're building a crowd system especially usually only do three to eight variations you don't really need to do more than that it simplifies the authoring story because you don't have to make hundreds and hundreds of unique objects the beauty really is in the motion not really in all the different unique geometry it's not really your environment in order to actually even make the system we even go further we didn't carry these out fully but since it is really just a true transform cloud you can actually just use instancing for a lot of this geometry if you're only using 3d objects you can actually just instance across the whole thing one of the things that we actually didn't do correctly was on those swarms we actually had at one point thirty thousand unique pieces geometry this created a bigger disk space if we literally just used one instance piece of geometry it would have cut down the disk load the render times

still the same in order to render that mini constructor swarm but uh the actually on disk footprint which kind of really fights you when you're actually doing downloadable content that's significantly reduced additionally using Lodz what you can do you can keep this completely in the GPU you don't have to do anything the same deletion and scaling method you can just do with the z-depth and just pick different models to scale and scale out on so I'm gonna actually leave you with a reference injured from Alfred Turk uh Alfred Hitchcock's the bird it was actually filmed not too far from here only a few of these birds are actually alive on this set most of them are just static so only need to animate what you want to see don't have to animate everything just because some of the art defined limits that we did is from our bigger towers we are they kind of became up to around 32 K and transforms you don't really need to have more than that we

actually found out half our assets actually worked at about half that rate this is kind of up to your studio and what your game is doing but we recommend anywhere between four K to 65 K for each asset since your artists are authoring this they know what the assets best you don't want to put more transforms in just because so if they know what the limit is it's easier to call the other one we had it was a three thousand frame limit per each animation this rascally depending on your frame rate equals anywhere from 25 seconds to over a hundred seconds of animation and you can even actually go down to five frames for a second if you want with these exports if you're just going slow motion across the screen what we found out is it doesn't really need to be a long sequence of geometry most of the time it's just calling something like a bird fly a bird flock flying across the whole level the issue wasn't really that the flock was flying for a minute and a half in the screen it was the the bounding volume across the whole object was

coming a problem so I call it the centipede thing where we just take the asset and then you cut it off you delete scale even though the author one animation asset you're just shrinking the bounding sphere for each section of it as the flock flies across the screen this actually significantly reduces the load time to because you don't always have to have a constant 3,000 frame geometry sequence in but in memory just because of the sheer scale of it when the whole Birds flocks are flying across that way it's easier if the player looks at it you can do it you can call and drop that from the memory really quick a few other random authoring notes when you're doing with rigid you pretty much need any particle rigid body motion graphics any mechanical motion methods you can use to author with rigid but you always have to do IDs on any object so that's the most important thing to maintain and then also when you're separating the parts we used to kick connectivity based dictionary so that we could identify which piece was associated with each

other and Houdini this is usually like the assemble stop or something like that but the one thing to do is once you've actually export the whole transform cloud if you have 20 pieces all doing the same motion to reduce them as being 20 different exports and just have a single export with a single transform this will reduce a lot of your overhead even though we have like simplified explosions or bird flocking 'z you can actually put like five Birds on the same transform when you have a hundred Birds you're not going to notice that five birds are all traveling together I'm going to move on to static this is actually something we didn't actually focus on enough and most of the unaccounted for time in the whole game was just cleaning up this static geometry to end States so it's really kind of a story of state changes in sequencers seems really city because jhanjhar caching is supposed to be moving geometry but this is where it actually hits you you don't want to have these expensive moving geometry being static that's why we have so many optimizations for environment geometry

one of the things there's also minimize duration on these geometry classes for the e3 headliner we had twelve towers all going off in different sequences when we initially exported those things they all went off and triggered at the same time this crazed a giant spike in memory that was pretty read astok but the only thing we had to do to clean it up was to the start of each beat in the sequencer is that's when we triggered the exact moment for each of those towers to collapse it came signed a silly but the fact that every single one of those towers were all drawing from the memory at the exact same moment create increased the spike time so dramatically that we had a lot of people like running around chasing us down so if you kind of think of like the 1812 overture for D from vendetta where it's explosions going off as soon as the explosion happens as soon as one of those towers happens if you just trigger it for just that amount of time you

juice the overhead so very dramatically the other thing is to it might seem a little bit weird but perspective culling and over in a game environment and camera culling doesn't seem like a native intuitive thing but if you have say like a small simple explosion pieces go flying the initial state you only want the outside shell you don't wanna see inside pieces but soon as something explodes you need to see that inside pieces as it twirls around as soon as that piece lands you don't want to see this side that it lands on you can call that side or if it goes off the side of a cliff you don't want that piece of geometry to continue and fall off the cliff so you want a camera call based on what the characters can see some of these assets depends on what you're kind of doing if you're doing a simple Jersey barrier and where the player can play everywhere this it might still seem kind of strange but it helps reduce the cost overhead of all the additional polygons because if you can't see it don't render it but when you're doing with geometry where you always see the inside of this it becomes a severe problem oh yeah the

other thing is it becomes also a handoff issue to when you're doing something as big as the towers the end states we actually just built into the actual environment geometry instead of actually loading that whole thing in the GPU process just for those geometry caches we just built in half the towers into the sequences even though we were simulating those towers we just picked a random point where it looked really good and then we pass that off to the environment team so it built it right into the environment pipeline all your environment geometries always gave you the most efficient that's kind of what you always focus on but with moving geometry you kind don't think about Oh the geometry static I should probably not have this in a moving geometry sequence because we actually have the whole base of the tower even though it's not moving just continuously stay there as soon as we cut that off all the assets for all those towers we've got reduced in half because awesome if it's not moving you don't have to play it as far as an additional collision method Sabir I was talking about just-in-time collision one of the things that we found out is like for the expecially for

that crack and reveal players were never supposed to go up and touch that geometry so we never bothered to even put collision there but an internal method is to actually do state machines or sequencers you just put the geometry either in the environment or in the state machine and you just trigger them and parallel this way you don't have to put collision into your geometry caching pipeline if you don't need to you can but we actually got away with a whole Halo 5 without actually needing to have this in there arbitrarily so soft is the cool invention Sabir was working on where it's just implicitly defined geometry and dlc left multiplayer book called Moulton that came out this past summer we got over to was 82,000 transformed playing in a multiplayer level where everybody was running around and shooting so we're gonna talk a little bit about the pros and cons of this a little bit about the topology and some lessons that we learned in extra vertex attributes soft

is relatively expensive if you have a character pipeline there's a reason why you built that character pipeline it's a lot more efficient means of transfer it for this but the offering for soft is extremely easy think of all the stuff you have to do for a character pipeline all the rigging and stuff like that you don't have to do that for soft you can use any type of deforming you want you can do rate projections it's really easy to export you don't need a whole team to build the character for you break it and I made it I can just do a fluid particle sim ray project on top of it and capture all the simulation data it's also really kind of nice because you don't actually add to worry about the geometry at runtime so it becomes actually extremely cheap the one thing we did learn though is vertex density even though we can put 80 mm transforms in there there's silly the texture density for UV space it's always gonna be a little bit bigger so even though we could put color in there it didn't actually express itself as best as it could if we could go back and redo those assets we would have just

done a render of the texture sim put that into a Tesla later and put it a little bit nicer shader I wouldn't have done it with actually a geometry caching method that we did we would have used the same sinned at a-- but have been a lot more optimized format and you could got higher detail so you kind of just want to use the geometry caching where it's could be best optimized and actually doing color transfer and showing that much detail wasn't really the best method for it additionally any other additional vertex attributes make it an option effects people will always be like I need that one extra Channel I need that one extra Channel but when you're starting to push around a lot of geometry it's not really as important you're really the beauties in the motion it's not really in whether that color goes off so when you build the pipeline up do the extra additional attributes as a secondary thing don't put it as the first thing that goes in there because it just could be a lot of dead overhead for you this is another topology example if you remember the fluid before this is a simple ray projection on top of it it kind of looks silly but all sudden this reduces a very expensive asset down to extremely simple asset go a little bit

faster now so one of the things you can also do is optimize the topology for it this is a simple grid but when you drape it on a cloth our table the way the triangles layout it actually folds really funny so if you just do the same thing like character topology and you put the edges where it matters these are the one on the right will actually accordion very appropriately whereas the one on the Left will just be a lot of wasted vertices on the top and in the middle finally we're getting too into skinned this is where like H I K carretera Tori this is when you're doing character rigs and motions so that's usually represents a very complex pipeline a very complex authoring story and up until this point all we did was basic sims to form our wrappers very simple something simple that one artist could create so we didn't even actually implement this we just theorized that this was it there's a good talk the

other day that we've been talking with delusion of motion by Mario Palmieri oh and norm Schafer they actually implemented the skinning method which was kind of cool it actually saves the most amount of memory if you actually need to do GPU runtime deformation it's an extremely efficient method you can get to like 166 minutes in to 4k textures which is cool but we never bothered to focus on that ship because the offering story for something say like a tower was very complex and there's no sense in proving a character rig on a giant building that's continuously sinned and changed every single authoring moment so this kind of led us to not even develop this things but on the alternative if you're doing something as simple as procedural ringing like a snake this can be actually authored extremely quick and easy this is something that we really didn't do a lot but we actually had a lot of assets like this in the game these would be like cables switching between buildings to buildings

cables vines we had so many vines that were put into random DLC content just because it was cheap overhead for us to put in so now wrapping into the conclusion so we talked about the core architecture Sabir went really in-depth on the engine side but we also got the static the rigid skin and it's soft and fluid when you build based on these kind of like base definitions and you had allowed off there for it it kind of separates out the technology for you and it comes easier to optimize now we know originally that everybody was just using fluid and then kind of moved on to rigid but if everybody kind of starts moving on to soft and skin and as you guys go out and develop these systems further you can further optimize them so the people that you should reference is actually a real-time caches for CryEngine this was done by axel netting in 2014 a cig graph used with

the forefather of our talk so that's how we actually originally based all of our technology off of then we further improved it after we learned all of our life lessons in Halo 5 but also do the illusion of motion it's kind of more of an intro to what we were doing they use textures where we use a different a little bit of different streaming of data but if you're just going off the shelf it's a really good method as opposed to going for the whole hardware engine that we need to do because you have to implement that directly into your engine well Houdini has also done some of the authoring side and unreal doing some more on the engine side there we used our own engine so not all these systems going to be available on all off-the-shelf packages at the current point in time if you have any questions feel free to step up to the mic if you don't want to step up to the mic and email me and the beer afterwards we'll be around for a little while in the wrap-up room too after this so thank you guys for all for coming and please fill out the survey we appreciate it very much [Applause] [Music]

[Applause] Hey is it something yeah so Ben can probably talk more about it but we did have some looping sequences right so essentially you you interpolate some of your ending frames back into your beginning frames and yeah you're able to do that for all the flags the bird flights and cyclical things we actually had a lot of those it actually became kind of a trick because depending on what you're doing like a flag or something like that it might become a staggered blend frame so just like tileable textures in order to get a table texture you overlay the two ends and then you kind of stamp between that

so you actually time warp the geometry sequence so that the two ends actually come back on to each other so that you got a pair better blending you can actually meet the geometry sequence at the end but that means your end state in your first state have to match and that's actually really hard to author but where does if you just drag the two pieces geometry around you can actually blend between them and it's pretty seamless every once in a while you'll notice a hitch but you can just put a little bit of noise into that blend sequence and it actually messes it up just enough where you don't even notice that's the blend point okay yeah we might be out of time all see you in the wrapper you
