[Music] morning everybody thank you for being here very early this Thursday morning I hope everybody's kind of recovered from that party if you guys could make sure you turn off your cell phones or put them on silent or whatever doing the mics to pick them up I'm will Armstrong was Patrick I'm Patrick I was the lead programmer over on fire watch I was a tools and gameplay programmer on fire watch and we're here to tell you about the tools and systems that we wrote for sort of all the dialogue and fire watch and localization and just sort of how we built tools for a pretty ambitious game with a very small team so in a previous life I was at - Cameron worked on Bioshock 2 in the bureau these days I'm

over at Unity I was amazed sorry an early engineer at Twitter and an engineering manager mostly focusing on the web team and Firewatch is my first game so everything that we're gonna tell you about here is built off of previous work that we've learned about it other GDC s so kind of going all the way back to GDC 2012 Ilan Ruskin gave a very good talk about how valve used this sort of bark system to do all of their dialogue and left 4 dead 2 and our work is very heavily based off of that in what was it 2016 the valve gat 2016 yeah 2014 the valve guys gave a talk on how they used dynamic dialogue system to turn that sort of back and forth bark systems into big long conversations in and is it there is that a zombie one or the Nathan

Drake one and they didn't drink what I guess and then we took a lot of our design cues for the radio from the 2008 Prince of Persia reboot that game featured a dedicated button for an air there was just a button you can hit anytime and have your AI companions start to sort of chat with you about what had happened in the game or what you were looking at or where you were and then informed a lot of our early work on the radio so this is this all built on sort of the shoulders of giants here the initial prototype we were making was a little different than the game we shipped the way we first started thinking about fire watch was that Henry was going to be driving all of the conversations everything was going to be started by Henry interruptible at any time by Henry he could stop any conversation he had started to switch topics you could always talk about everything every conversation was started by him and that sounded does a lot like barks combat barks they could start at any time stop at any time come from anywhere

very very reactive very very dynamic so that's sort of how we landed on Valve's bark system as sort of the way to start for those of you who aren't familiar with fire watch it's sort of a game about wandering around the woods is a sort of sad middle-aged man having long conversations with your boss Delilah over a radio and the whole game is sort of built around these big conversations that you have while going on a hike through the woods so what we actually built when we were still you know having Henry be able to interrupt at any time talk about anything was a generic event system and generic event system meant that any system of the game could fire events and then we would have blackboards to store gameplay state and we would figure out how to respond to every event by that so what that really looked like was we have a bunch of events a bunch of requirements and a

bunch of responses you can think of this as like when something happens interrogate the current state of the game with the requirements and then use the responses to alter to a new game state relatively straightforward thing happens at some time change the game in some way what that really looked like for us was event name and then a bunch of boolean tests and then a whole bunch of responses ideally this would be just of you know the your boolean test could be anything and you can interrogate any kind of game state we were a small team we had to make some special cases we didn't bring strings into our blackboard system we kept it very simple and very very lean so we added a couple of special cases for what who triggered the event and then who was the target of the event the sort of context of the event and we let designer you string for those and everything else was just little Bleen tests on floating points so for a very concrete example if I say you know toss

the beer can then you would get the event on tossed who tossed it the player what was tossed the beer can if the context of the world is I haven't said this line then say the line [ __ ] it I'm not the maid when I talk about an event what that is is just a string it's a set by the designers and it can be very systemic like on tossed it can be extremely special case like you know quest seven-day 3-step to finished it really just is up to the designer to sort of decide what that concept is that they're trying to do and what sort of moment in the game they're trying to capture it's very open-ended and allows for a lot of flexibility when I talk about a target or a sender the target is context of the event so what did I throw what am I looking at Who am I talking to and the sender is what triggered the event the first place so often the player

sometimes Delilah and then a lot of times in level objects so you would have like on opened on a lock box or a door and then when I talk about facts facts are sort of arbitrarily designer created strings they end up being stored in blackboards blackboards are just dictionaries we use a bunch of different dictionaries to kind of scope the number of facts that we have at any one time down to a reasonable number this is for both designer sanity and performance you know as dictionaries get big they do get slow specifically we'd have blackboards for every individual game object so that you could track how many times I through this specific beer can without having to have a different fact name for every beer can in the game we would have a blackboard for the player which was going to be used to scope things that we only cared about in context of Henry we ended up not actually using this because performance ended up being a problem we

would have days specific blackboards and this ended up being extremely useful for designers we could track things like have you left the tower today without having to worry about leaving the tower on day one automatically triggering logic that should only happen outside on day two and then we had the global blackboard which is where almost everything in the game actually went the global blackboard was used for you know like I said very very designer specific things anything that we needed to remember from day to day today over the course of the game what you named your dog and systemic things like how long it has been since the last time you decided to have a conversation so I'm gonna walk through our workflow at our tool chain so these are all the tools we've built these are real screenshots taken just from right from our editor and so this is definitely gonna be a little bit of sausage being made here the example I'm

going to use is the first time you sort of run into the turtle in the game I don't know how many of you actually managed to find him he's kind of in whoa I found a turtle maybe it's a tortoise it's a thing with a shell actually pretty cute now what do I call it looks like a mmm so you'll see the first week after you're named after your dog bucket Junior it has sentimental value and then we changed the pickup text once that's ones that choice is the name so the first thing to know about how we did the turtle is it's a little bit of a lie there's actually six six turtles in the game is a six turts sprinkled around the world of Firewatch

and whichever one you see first that's the canonical Turk that's your Turk for the game plan we did this using kind of a big ugly playmaker we used playmaker and fire watch it's a unity plugin for visual scripting we used it for any sort of level design II thing that we need to do one-off content while this is a little bit ugly it was also made very late in the game it was a brand new feature it was a kind of a workaround for the problem of nobody never finding one perfect spot to put Turk and we wired it up the Nell's wired it up without really any help from the rest of the team so it was it was a pretty big win and the flexibility of the tools we had built to that point how this actually functions is we have the event system hooked into our various gameplay systems in this case it's the targetable component anything you can target anything that will display targeting text will have the ability to when you first start

seeing it or when you stop seeing it to fire events to the event system we then have the play maker listen for that event so not only was our event system talking to all the responses that I've already shown you the dialogue system it was also completely wired into all of our level scripting so you could tell a play maker to listen for events and then any event that get fired through the event system would be forwarded to play maker as though it were a play maker global event and that meant that any level designer any Content producer in the entire game could hook up any one-off custom content they needed to any other system that was triggering events whether it be the dialogue system or targetable or opening a door or the quest system or anything once that state got entered it would then interact with our blackboard so same thing we exposed all of our level designer tools to the event system to the blackboard system we had created special actions to read and write facts from any blackboard that you wanted

this is a screenshot of our actual event editor tool this was all made in M GUI that sort of built in unity UI system the and was plugged right into the runtime you can see we've got a big list of event lists an event list is kind of grouped by conversation or category concept topic of the game then there's a sort of top middle there's the big list of events inside of that list every event shows the event name the number of requirements it has the number of types of responses that's got and then underneath that is where we actually do all of the hard work of editing you've got a list of requirements and then a list of responses all of that's done with custom drawers this is all just a reflect basically just a 1:1 reflection of the actual public variables inside all of this data the we could have done this with the default unity inspector but because of the amount of data that we're trying to show here we needed it much more condensed so this is an

example of a dialog response all dialog in our game is an event that triggers a sound has a caption attached to it it pulls that information from a database and then fires an unfinished event that starts the next line it's all just chains of events event dialogue dialogue fires event event fires dialogue dialogue fires event until you're done talking dialogue tree works almost the same way dialogue tree is actually just three two to five different event responses that the user can choose we have a different system that knows you know how to display a dialogue choice and listen to input all the response does is store what are the possible events that could fire when we bring up the event when we bring up the dialogue we go take each event and basically fire it but don't trigger the responses just interrogate them and use that to figure out what response is going to be triggered and what line is going to be played and thus what caption to show as

your choice if we go the previous slide you can see one of the response types there's dialogue caption that's where we store that information no dialogue choice tree was compiled ahead of time it's all on-demand when you bring it up that's when we figure out what your choices are and what each of those choices is going to be so for example if you chose to name your dog mayhem in the beginning of the game there would be a requirement and says dog is mayhem a response type that brings up the caption name the turtle after your dog may have if we don't meet that requirement we didn't name your dog mayhem that doesn't we don't find that response we find the second response there that says name your dog bucket junior or named a turtle after your dog bucket responses we use responses for a lot of different things in this game we use them to trigger achievements sound effects particle effects all the play maker stuff that I've already mentioned

changing the icon on your save file and yeah firing off photos so we knew we were going to need to be able to make a lot of these and we were going to need to be able to make them quickly if you're making sort of this event response system you need to make your responses as light as possible this is all of the code for displaying triggering a dialogue tree from the event system and this is all of the code that actually does any real work all any response type does is grab information from the event system and pass it off to some other manager the event system knows about events the event system knows about senders and receivers and that sort of context around where the event was fired and nothing else in this case it calls the dialogue tree manager passes off the dialogue definition and who said who sent the event who were sending the to and where it can find any localized data it needs that all lives on the event system the rest this code here is debugging we're a small team we

were constantly building and changing this game as we went that meant lots of things were broken all the time for example we at one point changed the UI entirely we went from the old in GUI system to the new you GUI system so for a while we couldn't display like subtitles we can't let the level designers and the narrative stop working when that happens so you have to keep your systems usable even if nothing else is working so a big part of any event system is going to be logging everything that the event system does every event that fires every response that matches every requirement requirement the matches and why that all worked you should be able to go into your log and scroll back through it and see an exact playthrough of your game even if nothing is showing up on screen other than the debug output by building all of these tools on top of unity in our game engine integrate it tightly with our runtime we got a lot of big benefits for a small team these tools

were very cheap to make we didn't have to worry about you know setting up new input handlers or grabbing Windows contexts unity was handling at all for us we were you know sort of already showing pixels on screen immediately it was extremely flexible we had access to every system we had written we didn't have to write wrapper layers or in transport functions to move data from our big managers out to our tools and it was all just sort of automatically integrated with the runtime all narrative designers could sit there and tune out dialogue timing as the game was playing without having to stop restart save anything like that you could just go into the event data make changes add new requirements add new responses and then play through the segment again and again and again until it worked the downside of building all of your big sort of dialogue heavy data-driven tools in your editor is those tools were ugly I don't know if you noticed that they're

extremely complex like that was not easy to go over is a huge screen full of information that the event editor took over the entire editor most people just had it on an entire second monitor blown out full size and their ever changing like I said you're you know constantly building new systems constantly adding new response types and that means every time you go look at the event editor it's gonna be a little different so if your narrative designers are not you know sort of okay with the challenge of managing that you know maybe this isn't the right way to go yeah hmm so what we'll just laid out was the system we had for the entirety of Firewatch and he built it basically in that form that you saw very early on but this was just the beginning right we had a working proof of concept for our game for our vertical slice but we needed to fill this game with four to six hours of content like massively branching content and we also had a creative process at Campo Santo where we were constantly

revving constantly doing rewrites cutting dialogue rewriting it so we needed a content pipeline for that that's what I want to talk about so first one will look at the teens this is one of the earliest scenes we wrote or I'm fully implemented in the game and it's also one that never stopped growing we kept changing it we kept adding things to it every time we did a play test someone would want to interact with the teens in a new way and we always wanted to support that basically anything that people tried to do we tried to make work so complexity balloon as you can imagine let's take a look at one playthrough [Music] there are empties much I don't want to say that word again why cuz you're trying there's a yes

there are two naked ladies out here can you that come on I like naked ladies same as anyone but there's you know ya know be tough for you but try to make your tongue up off the ground and do your job I know you guys are setting up bottle rockets out here okay you don't know a damn thing about me we know you're a peeping tom standing

over there [Music] [ __ ] cool it with the fireworks bite another firework and it won't be your stereo Iraq yeah yo [ __ ] pay for this you can't just harass girls in the woods let's get out of here okay so that was only one of literally thousands of playthroughs you could see through here and I just want to like highlight how crazy this was from event an event-driven standpoint right when I approached those teens I was already talking to Delilah they overheard me

talking to Delilah they engaged with me Delilah hears them she engages with me then I'm going through dialogue trees the whole time I'm doing that they keep going they keep talking while I'm deciding what I'm gonna say next or if I'm not gonna say anything and I'm just gonna go throw their crap in the lake I could you know withdraw from this scene I could try to sneak past them this was a scene that kept growing and it really drove out all of our tools as we had to support this really really complex like ever-growing graph of events and to make the teens sort of react to whatever the player could possibly do this was only like a tiny set of what our event data looks like I didn't actually want to show the teens here because it looks like a bowl of spaghetti it's it gets really crazy really fast now there are benefits to this right the the system that will describe is so flexible that we really didn't have to write any new code when we needed to add anything to

the teen scene the cons though were that things were really brittle all those change we see a red box that's a node you have to hit for the game to essentially continue playing and if you if you interrupt any one of those chains if you fire an event that prevents the next one from firing game you're you're sort of broken at this point so we needed to find a way to manage this basically this creative content pipeline so the writers could reason about what they were writing feel confident making doing rewrites like this game is massively branching it's it's nonlinear right this is not a script everything every line is independent could be fired from any way anywhere it can trigger any other line based on context in the game you know are the teens aware of me yet have I been be nice to them have I thrown their boom box into the water yet all of these things change the entire shape of the

conversation interruptions make this even more complicated and the dirty secret with a lot of this sort of branching dialogue in the industry is that Excel is the tool that people are using I mean I've seen talks at GDC this year where people talk have shown their massive Excel databases and I I get it you know this is a way to give lines a unique ID and to sort of track content in a program istic way but it's not a creative tool it's very very hard to think like a writer using that so to that end I built a tool called magpie this was our dialogue CMS it's a web-based tool which meant that basically all writing would get wood would flow into this system where it could be tagged edited it could drive our voice recording pipeline and then the event system in unity would pull from a JSON API and keep the data there

fresh and local so magpies goals were that the the writers could use whatever creative tools they wanted to that it would be bulk imported into this database we could have checks on the validity of data basically no no no like incorrect lines and that changes could be made non destructively so we would never lose work and and and basically like eventually we hope this would grow to a localization tool which I'm going to talk about in a little bit I want to speak to how great web-based tools were are for something like this like this is a content management system and when it lives on the web that means any team member can access it from any anyplace in the world they can access it on their phone read through data make edits you can hand logins to other team members who aren't necessarily on unity maybe they're in another country and and plus

you can build these great dashboards so this shows this let us track our recording progress on the Left our progress towards wiring the game in on the right each of those event lists that you've seen purple down below has a localization tracker on it so it let us kind of reason about the progress we're making towards a complete game we also use this tool called status board that panic panic is like the the goddaddy of fire watch they publish the game with us and they make this create tool for iPads which gives you all these great widgets and I just wanted to show that we have the bus time so San Francisco Muni bus times in the left and the low upper left and the lower left we have the number of times every fire--which team member has been fired for making bad puns yeah well Williams at zero there I guess he was actually doing work the whole time well we were making bad puns in slack and but if you would enhance the photo you can see that we're also tracking our line data so basically every time you come in the morning you could see okay are we recording

are we wiring like are we did we just like write a whole bunch of new content that made our our lines move in the wrong direction we definitely saw that a few times okay so this is the process for getting written content into magpie first a writer delivers a plain text document Shawn vanaman the head writer and Firewatch uses Scrivener but this could be any tool you choose and basically it's a lightweight syntax for denoting like what's the name of this conversation what's a dialogue choice who's the speaker etc so they deliver that magpie has an import form it parses all those lines into individual basically grows in a my sequel database that's that lives in the cloud it's like a Heroku based app and and it adds the notes and adds the speaker and it puts them all into an organized list and oh and most importantly it gives every line a unique ID like this is what really was

is required for managing a pipeline is a single identifier that you can track a line from start to finish once it's in the system we got full-text search through lines and sections you can just go right in and edit a caption inline we also had a free-form tagging system so you could say this is a line that could happen on day two or day three you can also add a you know a separate tag for this is about Brian Goodwin or this is about relationships basically any ways that you could organize this content in an like it didn't all have to be in a single list as basically I'm trying to say then for recording you have one button on the upper right that downloads gives you a CSV export of your lines that could then be brought into Google sheets if anyone's doing voiceover on their games I cannot speak to how amazing this tool ended up being just because we'd have our - well basically you can see the line IDs on the left there right and then the session takes and chosen reads

what that basically means is rich summer and [ __ ] Jones our lead actors would be in their home Studios all recording in their own like voice setup right me Sean rich [ __ ] would all be on a Skype call together and we would they would be recording but this this you can't use Skype you can't use Skype for obvious like quality reasons right so what we need instead is all of us to be on our own setups but rich and sissy's little icons are sorry they're little like their colored boxes are moving around and we're all on the same shooting script they're recording they're keying off of each other's VOC vocal performances that reacting to each other's emotions and and then they're delivering separate wav files a intern is chopping those wav files up into using the chosen reads that Sean has identified you know he's like okay take three was great on line 21100 take 4 is great on 2200 and

then they're just delivering these wave files that could be imported into into magpie and into the system hello Henry are you there once we're hungry having a nice afternoon you can easily parse like listen to the lines as recorded updating the captions because this is a very common occurrence where the voice actor does their own interpretation changes the phrasing to make it read better so you need to go back in and collect the captions and this is something you could do from anywhere thanks to magpie you didn't have to have source control access you didn't have to have a unity install running so I want to speak a little bit before I move on to what we originally wanted to do with the system where it landed originally we want to have one unified content pipeline that would do all the event data that will shown with you know what triggers what every event response possible in the game along with all of the written content we ended up focusing on two tools one for content generation and

recording and localization which is magpie and one for wiring this really did help us focus although ultimately I think that's that's the dream ultimately a CMS that could manage all all of your data in one searchable place would be a would be the way to go it would just have taken the entirety of our development cycle so that wasn't going to happen so this next case study is the julia conversations this happens on day two this is Henry and Delilah starting to talk about relationships why is Henry out here is he married why isn't his wife here etc this is when we have the system more in place we had magpie we've done several revs on the event system and we had all the tools we needed to to create this so I want to show one quick example of one possible playthrough of this four part very context dependent conversation

trust me I know how it is so did you break any hearts back in Colorado when you took this job I myself has chosen to never get attached to anyone who would miss me but I know I'm a bit of an outlier I don't mean that the way it sounds I mean I care about people and I like companionship as much as the next person but why does it have to come from the same person for your whole life we don't really need to talk about this stuff right well what would you prefer literally anything do I know about the homeopathic remedy for yeast infections I came up with last summer okay never mind so this is an example of Henry kind of shutting Delilah down right he doesn't want to talk about relationships he just wants to do his job and wander out in the woods right let's compare that to how differently it can be if you've shared more earlier in the

earlier in the game and earlier in the day same conversation same game oh you know if it makes you feel any better you're a member of a diverse Club of lookouts that have come to the thoroughfare after a breakup there was Vernon whose wife got put away for running cocaine Becca who was widowed after her husband the jockey was trampled by his horse and Sharon whose boyfriend had his own boyfriend maybe he boned the neighbor maybe she boned the neighbor maybe he both did I don't judge if you ever want to talk breakups I'm here go it wasn't anyone's fault you know neither of us boned the neighbor so he doesn't real a part we just couldn't be together anymore how does that make you feel not very good sorry yeah what are you gonna do [Music]

so this moment has so much going on again it's a four-part conversation it's triggered by many areas in the world that you sort of walk through but each one of those doesn't necessarily trigger the same conversation it's dependent on how long has it been since the last time you spoke we wanted to space these out what have you shared with delilah so far have you kind of indicated to her that you like talking about this stuff or does Delilah sort of need to wheedle in on you this was also the conversation where we introduced the idea of a [ __ ] path conversation or a non interruptible conversation there's some of these chains which once they're started we just can't let them break because the game state depends on it we need Delilah to know the full truth about your wife once you've decided to change it we can't have Henry just going and saying oh hey I'm bird and interrupting that in these moments even though generally that was the case that was always possible in the in the game so this is not a lot

like to you know goons yelling at each other about needing more ammo while hiding behind crates anymore like we've kind of drifted of pretty far away from the origins of the system the you know this is more like a independent film or romantic comedy or something going on and the complexity started to balloon pretty quickly here this is all of those are on Delilah's calling you on day two that's the only event that's triggered there those are all different variants for that and this was one of them you know the big things we've learned from valve is that you can handle this complexity pretty simply by sorting your event lists if you just have your event list sorted by number of requirements you're going to go through them in order until you find one that matches every we're every requirement and that's going to be your best match that's going to be the most specific thing you could be

talking about the you know the best choice at that exact moment so you know here's an example of like the requirement list for a conversation where Delilah doesn't know much she doesn't know you've had a breakup she doesn't know about Julius she doesn't know that you had a wife she doesn't know that you're right too sick she knows almost nothing but you're still friendly and chit-chatting and so she's trying to still pull information out of you the absence of facts being said is still you know context that's still it that's still a valid match that's still something that you care about and delilah will assume things about you she'll just start making things up you haven't ever talked about having a breakup and here she is talking about you having a great plan to get back together with your ex because she's like why else would you have decided to come out here in the wilderness for a summer you've got to be lonely or sad or something she's projecting it makes her seem like a very real person and really the player hasn't done anything to earn that it's just a clever use of the lack

of context of being context in in itself the flip side of this is if Delilah knows almost everything about Julius she knows knows who Julia is know that she's sick knows you know that you had a breakup the whole nine yards now she can ask very targeted questions what does she have she's trying to pull information from the player she's trying to get you as the player to engage and you know kind of respond to this so that first requirement up there knows your partner has Alzheimer's that's like the most specific information you could have if that's set to true we know if he knows everything else because you've already gone through all of this conversation we know that she knows you have a partner that your partner is sick better name is Julia like the designer knows all of that so if we were to make one of these that set that required her to know that Delilah is sick then we would need that to be the most precise match even though it only had one

requirement so that's what that pad up there is for you know this the nice easy clean oh just sort by the number of requirements and you'll always get the most specific is only true as long as your black boards or black board facts are not dependent on each other once you get that you need to let your designers be able to cheat the priority of things because if you know you've got this bomb of a line you want that to hit in the right if if it's valid at all this long multi-part Frost day conversation also sort of taught us that we had a major problem in the system we had built kind of you know the conversation problem conversations are linear you know they say they seem linear they sound linear to the player but under the hood they're branching like crazy but if we want you to not be able to interrupt if we want to like pull in black bars or bring up a musical cue or have any other sort of like modal

game state go on we need to make sure that every possible way that you leave that conversation undoes all of that modal State this you know is fine when you only have a linear conversation the second you enter introduced branching though you can come in find content that was perfectly working add a nice little choice to it and you can no longer radio about anything ever again in the rest of the game until you load from a safe so it's not really ideal the yeah at the end of the day flexible tools are fragile if you can do anything you kind of have to do everything right so when you build these really really flexible really expressive tools for your designers you also need to make sure that you're supporting them with all of the debugging they could possibly need you need to make sure that they can continue to experiment even when things

have gone horribly wrong like it took me way too long to add a debug option to just turn back on the radio no matter what the hell it happened or bring down the black bars no matter what the hell it happened you if you're going to give designers and their designers and writers the power to break your game you have to give them the power to fix it in editor while playing with minimal minimal minimal friction and then as you're doing that you'll sort of learn best practices you'll figure out oh these are the tools I need to keep people working either to automate those tools so we had everything more or less working and we had a Vince going off we had conversations happening big long complicated ones and then about a week before we shipped the game we decided that we should probably localize it world out there so this is actually the first screen shot the screen shot I took of my desktop of the first time that our

Russian localization was not obviously broken we shipped February 9th the clock at the top February 8 8:00 p.m. so this was coming in hot to say the least yeah so here's our quick advice for how to do a like turn on a dime localization first before you ever start localizing your text or approach a localization house use a pseudo language so we had a script that would run through all our dialogue and make these two pseudo languages metal is English but more metal which tests UTF support unicode and wide is a wider version of english that tests languages like German which tend to be much longer and too like awkwardly break your slide in a weird spot so we had done that luckily so we knew pretty well that our UI could support other languages and then we need to get the content so this is where magpie came in handy again we quickly added a new

field and a new interface to let so basically we could give a login to Slava our amazing Russian translator and he delivered a full Russian localization of Firewatch within a week which was just so awesome and then the benefit of that is for later Lok's translators could go through and see other other translators work right so it kind of became this rosetta stone or if you weren't quite sure about the meaning of something you could you could look at the work of others so this is all localization tools were sort of built with the same mindset that we built our event tools on which is be flexible early build as fast as possible get things up and running as quickly as you possibly can we didn't have a ton programmers we did you know we had two programmers for most of the project actually in the editor so it needed to be really really trivial to add to localize any strings in the game we use

c-sharp reflection to just add a little string tat a little tag to any string in the game would dump it out to a JSON file and a little dictionary very very very simple we just used dumped everything to English key English value dictionary and then localized the English values this if you've ever localized a game you can probably figure out why this didn't go super well every time you fix a typo in your English you break every translation that has already been made we've handled this just by you know going in doing local dumps frequently every time that you built the game it actually dumped all of your localization out and then you could just pull for magpie and it would fix it so it really wasn't too bad just required you know kind of dotting your eyes the right way to do this is to do what's called a look lock I highly recommend the sort of English English key value pair translation scheme it's very simple

it lets you hand it off to other people very quickly originally we were actually going to do only fan loke so the idea was that we would generate these English English dictionaries put them make them available on the Internet people could translate you know the value side of it and upload it back up and it would all work once we were doing professional localization of course this became a little bit more of a problem we were getting dumps as we were still fixing bugs in our English the way that you handled that problem is do you do a local lock at some point you say nope English is a translated language too just like everything else we're translating from programmer English to actual English and that's fine we were originally going to do that and then turned it off during a pax demo because of performance problems and we never turned it back on so yeah do the right thing if you want to do the really really right thing every string in your game should get a unique ID those unique IDs should be persistent for forever or they should handle copy and pasting you

should never have a duplicate key you should not be able to break them with prefabs that's really hard you have to build that into your editor in a really fundamental way we didn't have that engineering support so we went with the English English dictionary if you find yourself with you know unlimited time or money locked string IDs the way to go so yeah clearly we had a localization success in with just about a one week to go more or less so again Lok Lak really really important I'm we're really proud that we managed to ship Russian and but yeah like there's a lot of stuff you can do early on to save yourself that pain oh so yeah just some closing thoughts just so we'll have some time for questions what do we learn we learned that a small team by investing in tools that are flexible and also writer friendly can deliver a triple-a production with an indie scope we were between 8 and 12 people most of the time

on the project so about right we learned that an iterative design process can deliver a game that feels much more cinematic and human not like a bunch of lines in a spreadsheet like actual two people talking back and forth and that a super flexible system can be very changed tolerant and can support this growing to organic complexity as the project goes along yeah make your tools general early you don't know the game you're making I mean unless you know you maybe you're awesome and you do but in general you you're gonna be exploring and finding out what game it is that you're really making as you're starting so make your tools general make them flexible make make them you know survive the sort of birthing pains of early production the biggest win for our event system is every single system in the

game that triggers a new event immediately gets the power to fire any response in the game whether it's something that was wired up in playmaker or any of those response nights any dialogue anything and vice-versa every time we add a new response type every single system that fires it then gets access to that power as well its multiplicative but in a good way you know normally you have that problem in design where oh we need to everything to work with everything so we've got to write a special case for everything in that grid this is the opposite you have no special cases you don't make any assumptions every one of your response types can happen at any time from anywhere any event can trigger from any system and any event can trigger any response type so you just get it all all that matrix for free however as you start to finalize your game you're gonna figure out what what specific problems you are trying to solve you can make tools for those specific problems usually customize your tools for the exact problem you're trying to solve the

tricky bit is scheduling time for that work up front like we knew about the conversation problem you know halfway through development and we just didn't ever have the time to bring me Patrick Shawn Jake Nels all in the room all sit down and all figure out what the right solution for the problem we had right in front of us really looked like we were all too busy making the game as fast as humanly possible yeah so just briefly - one more like a piece of further work if you were to pick up this system and keep going with something like it is we should structure we should have structured our data around conversations making them a first-class citizen we talked about the crib path conversation problem where you know we need to make dialogue not interrupted well that's a modal state that was turned on at the beginning of conversation and had to be turned off at the end of the conversation problem being conversations have multiple exit points multiple entry points and so for every one of those you had to be absolutely sure that you were

reaching a place where the right where the where the conversation was turned off this was just the kind of thing that we didn't need to change the event system in order to accommodate this all we really needed was a bubble a box around that long chain of conversations where we could say oh very nice well we're where we could say that guarantee lives on the conversation and is not dependent on any single line or single exit point of that that chain so that's that's our talk we'd love to take some questions don't forget to fill out your GC evaluations evaluation the web evaluation and here's our contact information if you ever need to send us an email or find us on Twitter questions along I really enjoyed your talk thank you

I'm thinking about the graph that you had of the conversation with the multiple red boxes of what you had to hit at least one for the game to not break how did you make sure that you ended up hitting at least one of them we had a tool for visualizing them which is what that screen shot came from so we could check it against that but other than that we had no like programmatic guarantees we had to play test right well we eventually put in a few safeties that get-out-of-jail-free card if you just want her to like win once you started any of the team conversations we spawned a volume around where we knew you had triggered like a larger volume that would trigger the oh you've walked away you have chosen not to have this conversation we're going to yell at you as you flee as sort of a yeah right get in jail yeah in that case we we used yeah smart like editor hacks to work around that fact right where you could create these guarantees yeah all right thank you hi my question is about the voice acting and again thank you so much

for having this is really amazing um how did you manage to or how would the designers able to pull together maybe different takes or readings of the voice acting so that it didn't sound like you know to AI is talking to each other so yeah it's it's all about recording oh sure sorry the question was how do you record voice actors so it doesn't sound like to AIS and how do you pull them together the best the it's all about getting to actors in real time who can play off of each other and then basically hand tuning the timings of them right so you like Shawn would pick the takes that sounded best but then after we sort of dehydrated those wav files rehydrate them back into unity we had to like specifically hand at it okay 200 milliseconds after this one 600 milliseconds after that one yeah thank you I'm curious it seemed like a lot of your

tools were kind of a linear list of events but you also had some sort of tree views how often when people were editing dialog did they work in a tree view and how often do they work in a flat State the question was how often did people use the list view or the tree previewer that we had shown the tree previewer was actually just read-only data so it would take the sort of full conversation system and parse it and figure out what the what the nodes looked like because the Aravind system was all interrupt-driven you could interrupt him anytime heavily branching very you know a context to where the tree graph ends up not being a very good visualization for it because it's not how the system works under the hood it really is sort of a linear list and they anything get interrupt and it just goes through the search and finds a match so it ended up working better to look at it look at the data in the format that it was that was

closer to the metaphor it was actually using the event editor there had full text search inside of any field you could search by a lot of different things so that you could scope down what you were looking for it lets you do multi select and let you head buttons to automatically follow up to what the next event was going to be so for conversations where is like play line wait play next line you could just jump to that follow-up and follow those chains manually very very quickly and that ended up being sort of more usable than a giant web thank you so if I understand the ways you're editing data you've got narrative designers or writers writing stuff in a like essentially a text document they there's no none of the tagging information is present there and then you have the separate you you add the tagging in the editor did you have any friction between these sources of information where maybe the writer goes back and changes something in the text document and maybe now it doesn't fit the context that's been prescribed by

the tags that have been added in the editor and now all of a sudden you know this this dialogue this plain doesn't seem to fit right so the question is did we have a problem with writers changing contents in its original text document before or a it no longer matching that way it had been tagged and built-in editor so the text document is sort of a throwaway as soon as we imported into magpie the text document is considered just history you know then we also had a tool where we could consider a line locked so basically you could freely edit content until we recorded it or until we recorded it and updated the caption and then there was a little lock icon you click and saying this is done because after that point if a writer were to change something they would be they should be aware that they're causing a lot of re of new work to be created so that was our solution around it is just having a pipeline where we just say after this point it's done we did also have some some real serious issues with this when we did things like major level redesigns or major rewrites

so at one point we changed the map around and we had a bunch of lines that were like go north where the North was no longer North so when you do major changes to your game you also have to make major changes to your text content and vice versa so we just provided good tools for tracking these things down you could as you edited a line in magpie you could find the take the ID search for it in the event system and find every line that referenced that very very quickly Thanks hi can you talk a little bit about your QA system was that mostly when you were making changes was that designer internal play test external play tests or automated testing the question was about our QA and what do we used internal external or automated testing we used internal testing until very very late in the project we would get people to come in and play the game we would record their playthroughs we had some my analytics data as well like heat maps and stuff like that though we didn't

make the best use of that and then as we got towards shipping we switched over to using Research Center and they would give us log fight like the editor would editor and standalone player would both dump out the log files to a place that they could track them down and then they would send those along with any bug that we got so we could just go through the event system you like oh okay that's nope that needs to play a Vince six not event seven yeah and rewind things pretty easily from that we oh another like thing I would I'd love to explore more in an another game as we we briefly had a debug data where the game would actually shoot lines that were played to magpie and so then it could keep track of lines that had never been played so we're in early steam beta we could actually see like oh crap there's like 20 lines that are unreachable and so we could track that down so that was helpful but yeah really was all about Reacher Research Center and internal testing yep thanks from hey guys great talk I was just thinking

about the the event system and how it's all string based and I was wondering if you did anything to kind of prevent like misspellings or fat fingering or things like that because I seem like it could break things we complained about it a lot oh sorry there the the question was did we do anything to prevent fat fingering or misspellings given how many strings were were used in our game again honestly the the answer to that question is mostly the search function by putting in quick string search into the end of the tool from the get-go if you were worried that you were misspelling something just start typing it in the search field and if it matches you spelled it right and if it doesn't you didn't we did have a fact browser so every blackboard fact that ever got created by any system that you know at data time so there were a few facts that were created at runtime but any any fact that got created at a time was in a big list also searchable so you could go find the one you meant we pretty quickly established some naming conventions

about what facts intimate names should be to try and minimize this problem and then we changed those I think three times during the course of development so yeah we mostly complain about it a lot um we wanted autocomplete and it ended up just being out of scope for the time we had but it was something we it was you know okay well if I have a week free I'll do that okay I'll have I have a leaf written yeah two years later we didn't have it also since it's all JSON you can always have a tools programmer you know basically write a big tree search function that says are there any requirements that are not found anywhere in the fact setting tables you know which we did a couple times basically that would feed like a bug burn down list yeah and that's actually a really good tip always make sure your data formats are human readable always for everything is ideally being able to go and just insert them and use regular expressions on them is it gets you out of jams like that very very quickly cool thank you all right um I think we are just about out of time for questions

we're gonna go to will be at the breakout room just around the corner here down the other hallway if anybody has any other questions I want to ask us we'll be there in two minutes [Applause]
