Creating Complex AI Behavior in Stellaris Through Data-Driven Design

[Music] I'm a programmer at paradox development studio which is based in Stockholm we do strategy games Christian down here he told me that this is going to be the shortest paradox experience ever and I think that's true I've worked in the Solaris team the past two and a half years and I came in quite early into the team we were like five people at that time or something and I worked mostly on the AI and this talk is about how to break down like a massive universe of complex elements into manageable variables to create emergent NPC's in the game before I start I just want to ask how many of you are designers okay like a third or something

and programmers the rest okay right so the agenda or the background of this presentation is that we make really complex games in terms of the amount of input and the dependencies that the AI needs to process to create a human-like behavior so it's really about how we use data-driven design to solve this and make complex AI simple what I will be covering today is a presentation of the game why data-driven design is used in the AI some concrete examples of how we do this and a few things to keep in mind with it's this method method finally I will summarize it all and hopefully we'll have some time for questions so stellaris is a grand strategy game where you play an empire managing your resources economy politics or diplomacy

and military in order to survive in space and hopefully expand unlike our other games the Laureus is a non historical game so if the AI is quite different but it still follows the general theme of our games with high replayability depth and subject matter so here you see the galaxy map in stellaris every colored circle on this map is an empire with a different set of behaviors what's important to understand about our games is that the AI needs to do exactly the same thing as a human player so it needs to last throughout the game and this creates a very different challenge compared to other games where the AIS might be obstacles instead of opponents

I prepared a short trailer really to see Peggy 12 ever since the dawn of our civilization we've been reaching for the heavens our first man rocket was a crude device far more advanced vessels would follow but for two centuries we stared along the way at the vast ocean of stars beyond our solar system fearing them forever out of reach [Music] in one swift stroke the invention of the warp drive changed our world anew Frontierland and the start of an intense race to colonize the far reaches of space began we named her nemesis 9,000 brave souls heading toward an issue the star most likely to have an orbiting planet suitable for our first

colony two weeks and five days into the mission we received necess final message panicked voices broken why's that alien message in boss our first generation of warships would lead the rescue operations we arrived we soon located the remains of nemesis floating the darkness and approaching us a fleet of alien warships their technology and far beyond ours salvaged technology from ephesus these and managed to decipher our communications so they recounted the story a large unidentified ship had entered their system despite Romanian warning would not change course and a trigger was pulled it is a galaxy there are an untold number of species

border disputes tension and betrayal all right so now you should have a decent idea about the game so let's go into why we chose to use data-driven design some of the benefits of this method which you're probably familiar with is separating the data from the logic making the data accessible descriptors and designers it's also a good way of controlling state changes from the input data rather than in code as well as a modular way of building features this is these are general benefits but I want to go more into depth about why is the Laureus benefits from this model first of all we make content-heavy games to the left on the

picture you have a list of the current information that the AI needs to process to output certain behaviors as you can see our AI needs to handle a large set of data and it needs to process each of these elements differently depending on the dependencies that is that they have so for example a policy can be locked by a technology which you need to research and whether the AI wants to have that policy or not can depend on the Empire ethos or government type or something else if we will use the concept of state machines behavior trees or decision trees for the AI we would need to go through all the combinations that these elements in the list can create with each other and not only would that be time-consuming it will cause probably a massive performance issues and still result in a rather predictable AI which is the opposite of what we want so in

short there are multiple valid options for our AI to make it each decision point and we want to pick the one that is the ones that are most rings reasonable rather than the best one every single time it's also worth mentioning that the term utility AI has been thrown around a lot these days and this is probably something that falls on there that category all right so secondly our games should have high replayability this is one of our game pillars this is important because we want our players to be able to play the games for a long time one example of how we satisfy this condition in the game is by having randomly generated galaxies including random AIS we don't really know what qualities the AI will have until we've started that particular session so working with data-driven design in our way enables emergent behavior for the AI

and it can basically make decisions and situations that the designers or the programmers or anyone else for it matter in the team hasn't foreseen it also creates that sense of uniqueness and unpredictability that you want to have when playing against NPCs another thing is that our games have long lifetimes Crusader Kings was released in 2012 and we still make new content for it today and this is not only because we want to keep our fans happy is also to be able to release grow our player base sorry and I wanted to give you some numbers here but since our IPO we've been really secret with all the numbers so you just have to take my word for it but we've like massively increased our player base since we first released Crusader Kings

until now to be able to add content years after release we need to have a game that is easy to add new content with little support from programmers because we have really small teams at paradox and the teams are even smaller after release we also want to be able to rebalance and and scale the game worth mentioning is that Crusader Kings only has one programmer at the moment so just imagine if you would spend all this time on the AI finally we want our games to be moddable this is one of my favourite mods where you can determine the shape of our of the galaxy in this case the PDX logo by being not friendly we enable or enable ourselves to create a strong and a connection to our community and to

learn from people outside the studio it's part of our mission to make games where the players can create their own stories and this is one way of doing that so to sum it up the NPC's in stellaris need to be scalable for new content model be able to transform a large set of data to different behaviors and be unique in order to support game replayability now you know the why so let's go into how its implemented right so the tools for this is really really simple we have a trigger in this case we have and has ethic trigger that checks if a certain scope for example an empire is militarist or not which is an ethos or ethic and this trigger returns true

if that condition is satisfied else false that trigger we can then use to put a certain weight on one of our objects in the database and most of our elements are objects in a database like buildings traditions ascension perks policies edicts and so on so every building has an AI weight and there is a base say 10 in this case and then we add a modifier where we use that trigger to check if if this is militarist then we will add multiply it better by a factor of 2 and later than in code we use all these weights to randomize which of these we're going to use so say we have three

options a B and C and they have the different weights of five five and ten then we have a total weight of twenty and the chances for each of these being chosen is twenty five twenty five and fifty percent here are some other examples because we don't have to randomize the weights every single time we can for example just use the weight with the that is highest like we do with policies for example we can also have an allow trigger that we use from two to not even add that object to the list of weights so we basically just skip it the final way or example that I'm going to tell you about today is that we can use it as fractions so say you have unlocked the tech for cruisers and you

only want the AI to build cruisers from now then you just set the weights of Corvettes and destroyers to zero once that tech is unlocked and every time the AI will build a new ship it will just build a cruiser alright so all of these tools are great but if they're just used independently and randomly it's really hard to create that sense of good game balance and a human like AI so we want to be able to expect a certain behavior and similar to a human player it should have a certain style of playing but still have room for some unpredictability and for this we implemented personalities going back to this image that I showed you earlier every colored circle represents an empire in our game and each of the empires that are played by NPCs have

been assigned a personality and this will be like their backbone of their behavior the personalities are visualized in a game in the diplomacy screens and every interaction with the AIS will enhance that experience through the dialogues and it's really important here to actually connect the dialogues and the way of communicating with the personalities to get that realistic sense so a quick description of how we choose the personalities it's really really simple we just start off with say around 20 personalities and each personality is weighted differently depending on traits ethics government type whatever you add in script and once we have this we can then randomize which one first we actually will get like two

options maybe or more that will render like weights above zero and from those two we will randomize which one it will pick and the personality then has a set of behaviors that is connected to it so this is a way to make choices without having to randomize and calculate the behavior for the AI every single time and it's the part of the AI that is predictable in this case for example we have that hegemonic imperialists will enslave they will not purge they will build robots they will conquer planets they will vassal eyes etc it can also add that even the AI personalities are objects in the database that you can use for your triggers okay so one of the

benefits with this model is that it's really easy to keep your code simple and clean for the coming expansion we added two features of traditions and ascension perks to enable more customization and to add more interesting choices for the player and its two fairly big features in terms of content I'm sure our content designers will agree to that but in terms of code it was less than a day's work so basically what we do in this code is we go through the list of ascension perks we list all the weights store them and then we use a random weighted algorithm to choose which one of these we actually want and then finally post a command to do it exposing as much of the AI as possible in script does not only make the code easier when you separate the AI design from programming the programmer can focus on

what she does best and we'll also have more time to allocate to other other tasks you also empower your content designers and maybe I should add that content designers at paradox are scripters and designers by enabling them to script the AI behavior independently from us similarly it exposes the AI to the motors which means that they can do a lot of cool stuff as a side effect though they can easily introduce bugs or crashes into the game we can of course reduce this by having good tool descriptions and adapting the code so that we can handle scripters but the second part is easier said than done another benefit is that you will save a lot of time by being able to balance and

tune the game in tune the AI in game and I don't know about you but I spent quite some time compiling so I rather not do that one thing that you need to consider though when you do this is that by moving a lot of things to script you will also force the content designers or scripters and designers to actually be aware of stuff that they usually aren't so by setting a lot of the ai's behavior in script we also move the performance issues there so we need to make them aware of how to use the script efficiently and the code also needs to be designed for performance and this is

something that I wished we had focused more on early on finally debugging of the system need tools and I don't know how many of you saw this panel discussion on the Monday but it was a very good overview of the most common issues of debugging AI including stellaris but force the lor is specifically I think the AI is fairly easy to write in debug the part that is difficult is that the behavior is unexpected sometimes which we want in many cases but to be able to see when it is doing something the hey student we need to play the game a lot so we basically have to play the game I think one of the guys said it really well at that discussion like you have to try to make to break the AI yeah future

improvements for this would be to build better tools them than we what what we have today so to summarize our design will enable you to create unique NPCs with complex semi unpredictable behavior it's a good way of processing high amounts of input data on dependencies you can tune the game in the AI in-game and smart friendly its scalable is modular and the code will be kept simpler and cleaner which means that your programmers will be happier to finish off I would like to quote our game director it's a very robust system you could basically redesign almost the whole game without having to redesign all of the AI and that's something there

is really good I'm not open to any questions that you might have thanks no questions okay yeah you talked a lot about I guess my question basically is like if you're gonna do this system over again what is the one change that you would make like what is one area for improvement in this system that you see what was your name Andrea yeah I listen to Andrea yesterday and I think she said something that is really good like

sometimes when you do stuff you get blind and you think that that method is the only thing you should use and like what I would do differently is actually evaluate when we actually need to use the system and if there are parts where we can use something else I'm not saying we're using like data-driven design for everything we have like path finders we have nav meshes whatever but there are some places where I think maybe behavior trees would be better for example yeah hello I was hoping you could elaborate on on what kind of things would be good to automate an AI testing as opposed to not automating and possibly how to go forth with the quality assurance of an AI unit testing or any kind of strategies that you have found that work in your yes um the question was what kind of testing is

it that will help this style of game design or code design some of the tools that we use is all of our objects have IDs which we can see in game so when we debug we can easily break point with that ID and find stuff we have like console commands where we can just in game do stuff we can play as a as an AI in game we can add populations to our planets we can own a new planet so we can basically create those situations that we want to test but we've discussed unit tests at paradox a lot like there's probably somewhere like some way you can use it but I personally feel like this this

system requires you to play the game a lot and you you can't really get away from that I'm curious to know more about the scripting of your AI from what you showed it looked like it was very limited what the designers and cryptids could do they could just set parameters and flags I guess that influenced the decision making of the AI but how much can they directly force the AI to do something in the event of a trigger or maybe another question would be how many commands are there in the scripting language that they use there are much more stuff that they can use than what I showed you today like they have triggers they have effects that they can trigger they have on action events that you can put in code that's special like like say a planet is changing owner then you can trigger an action event for that there's lots of stuff you can do in script and basically

we we do as much as we can to support them because they have a really important job the paradox like I usually tell people that ask me like I personally believe that the content designers make our games like we're just there to help them make that thank you alright thanks for the talk I'm one of the few designers that put the hand up I think so probably following on from that question how do you feel that the content designers work with this process do they come to you with a lot of requests or do they find that this is very limiting for how they work or or they did they feel empowered and with this systems driven approach I think it's both like I know like that this system enables them to do much more than

if we would do a lot of stuff in code but at the same time of course they want better tools of course they want more be able to do more cool stuff and that is something that we are working on all the time but it's not like it's not like they want to do something and they can't and then we just ignore it then we try to figure out a way to do it so do you find that the almost the modularity that this provides is a good prototype process for the designers to come to you with new ideas for functionality within the code can you please like elaborate how do you mean like functionality so this could expert could quickly prototype with the modularity of the system to come up with a whole new thing that you might want to implement in the code is better suited

in the code rather than in script oh yeah so the question was if if there are stuff.if descriptors or content designers can come with ideas about how to implement stuff in code instead of in script yeah they can and they do that and when it's better to have it in code we do that sometimes for performance issues as well it's not optimal to have it in script that's probably more based on that the code is not optimized for performance but still we have to adapt thanks for the talk is great I have a I guess in a way two separate questions so you can choose to answer either or both I've dealt with a bunch of the problems that you described it several different times in my career where we've both developed AI and also scripting designer scripting based systems and

encountered some many of the same kinds of problems and I'm wondering how if you encountered some of them and also how you dealt with them one of the things that you didn't touch on was sometimes when you introduce the opportunity for designers to implement individual scripts such as that one of the things that doesn't show up unless you have a really extensive amount of testing is to have global interactions or combinatoric interactions between some of the entities that aren't visible within the scope of a given script you know he's he's scripting something for one entity and you don't really notice emergent behavior until you start playing it out in the entire system and so designers can code things that look saying from the standpoint of one entity's behavior but it turns out to be something that's exploitable in the global system or it can even break things or something like that I was learning if you encountered any situations like that and-and-and or if you found ways to prevent that so

that's kind of one category thing about behaviors on the AI testing I was learning if you had implemented anything in your system around it's partly tied into the question about unit tests but around being able to force behaviors in different directions such as always choose this weighted option or always choose the eccentric option of behavior you know either on a global level or on a personality by personality basis to be able to exercise sort of different vectors within the AI behavior yes so I'll start with the second question and the question was if we've used the script to actually have a set behavior for the AI so right sure something like that yeah yes and we do that like but that is like one of the places where I think maybe data-driven design isn't the best option like if you already know

that you're gonna pick the best option every single time then you might as well have a tree for example but yes we do we do that the first question was basically if the content designers have put in events or scripts where it breaks the AI without us really anticipating it one version of that is like you mentioned you can break from a performance perspective ya know in unreal somebody can write a blueprint that iterates through all actors of a class and if that's not used really carefully you know if you can have a terrible impact on performance but you can also break other things besides performance ya behavior I mean we do we do break the AI all the time like every single time we add something we'd probably break something because the challenge in a system like yours that

has as many separate entities and different interactions between all of them like technologies and policies and all that yeah is that anything you add can potentially have kind of a combinatoric interaction with the rest of the system you know it could have interactions with everything else and everything else can have you know some form of behavior that depends on that thing that you added usually we don't have that many dependencies but let me think that kind of depends on the touch points between the behaviors and the data I mean it's if I say it like that this it's really simple to break the AI so basically what we have to do at each point is to like go through what we work what we are planning to do and then actually thinking about how might this break the AI and is there anything we can do about it and sometimes we find those issues before we implement it and

most often there is always something that we missed so basically what we do then is to try to find a solution to it and I mean nicely I think it's the same in code really it's just that our games are super super complex like they're even complex for a human player like we've added now personality of high minds where you don't have to think so much about politics and don't have to think when you actually want to purge all the alien pulps and stuff and I'm I think marking implemented that for me because I got tired of thinking so much like there is so much like you can do in our games and that's that's one of the things that we want but it's also it's also one of the biggest challenges yeah thank you yeah hi thank you for the talk just I think

you mentioned the word unpredictable AI at one point yeah so and the objective is to have a more engaging experience for the human player so when it comes to unpredictable which methods do you employ to make it not predictable so just randomization of behaviors and traits based on the content that you add or is it there's any learning from the human player whether their aggressiveness or how they collect resources or how they build structure does the AI you learn and choose different paths of behaviors based on that so the question was if the AI learned from other players or if it just bases its unpredictability on randomization it it paces it mostly on randomization and it cheats a bit I mean the AI has the AI has access to all the data so you know is it they gathered of the users as they play or is it data that you've repop now if they'd wanted

yeah no it's not it's not it doesn't learn from the players but it can see stuff that the players can't see and it's not like I deliberately put in stuff so that the AI actually cheats but it can use that data like if it's gonna start a war there's no point of starting it if it has like one ship and the enemy has like a thousand and that would just seem dumb to any human player so we just avoid that by actually knowing that okay this you can actually see that in game human players well like the ratio towards an enemy but anyways we use that data in order to limit the aah behavior to make it seem more human-like yeah thank you okay yeah so we're out of time but come talk to me if you want to discuss this more [Applause]
