Math for Game Programmers: Predictable Projectiles

[Music] my name is Chris dark and I'm a program at robot entertainment I've been in the industry now for around 13 years at several different companies most recently robot entertainment for the last eight years I really worked on the Orcs Must Die franchise so for those of you not familiar familiar with orcs here's a quick rundown you have one warm agent friends versus hordes of orcs AI trolls ogres and worse and weapons and traps to hold them back from an in your IFFT there are tons of AI don't want to shoot you stab you and or blow you up I'm going to be talking today about is doing range day eyes and this franchise specifically is that fire projectiles I'll be talking about math code and design all three the design drives your math and your code keeping it fun is your former job so most action games have ranged AI like I mentioned I'm going to be talking about the ones that do projectiles some of this but not

motovan is relevant to hits can the projectiles need to be slow enough for the player to dodge this way the player has a chance to have some counter play against the eyes and it makes you a is more fun to play against however this means that by the time the put the projectile gets there the player won't be there if you're not aiming ahead this is what you're going to get looks pretty bad doesn't it you really want something more like this so the first class of projectiles we'll be talking about our linear projectiles and then the second or ballistic projectiles I'm going to be talking through how to aim debug and most importantly miss with bow types of projectiles and a few things I ran across while has implemented them so let's start off by talking about predicting player movement so first a few assumptions we're going to make we're typically working over a short enough timeframe that we don't need to worry about rotations and we also want to make sure we ignore the player's vertical velocity when they're jumping otherwise it's going to throw off our

aiming results we're gonna be pretending that we're operating in a vacuum it helps keep the math and ultimately the code quite a bit simpler so we need to know which way the player is going to be going the easiest thing to do is look at how fast the going right now and in what direction and just use that this works well as long as the players doing something like this however when your player starts doing things more like this it doesn't work quite as well is there something we can do better than just the instantaneous velocity there is we can use a history buffer which will give us a more accurate result you're gonna want to take that history buffer and tweak it until you're accurate but players still have a chance to dodge the projectiles so now that we've got a velocity let's walk through how to use that to predict to the players future position so the start with or mage here in a position in our first few games just as a side note the origin of the player is on the ground you want to make sure you're actually using the center of their bounding box and not shooting at the

ground we know from our history buffer that they're moving at some velocity and then they're going to be moving 40 seconds we don't know how long T is yet but we'll come back to that here in a little bit so when you put that all together that will give us our final predict position X prime which is the aboard ranges original position plus his velocity times the amount of time he's been traveling we'll see this again here in just a minute first though let's talk about linear projectiles a little bit this is a linear projectile there's no gravity on it it's going to go into straight line forever or until it hits something but before we go ahead and fire one of these off there's a few things we want to do we want to predict the player's position which we'll talk about how we're going to do then we want to make sure that we're not going to be firing this through a wall we may also want to check against friendly units between us and that predicted player position we wound up not however we did have the friendlies block shots because players were a little bit baffled where the shots were coming from since our range units tended to be in the back we

didn't do a line of sight check though just because we have a lot of works and it would have been pretty performance heavy to do so and then the other thing you want to think about is when you're actually going to do the math to do the intersection prediction you can do it before you fire off or you can do it at the actual launch point in your animation so now that we've got that out of the way let's talk about how we're looking at the projectile so like the word range it's going to start in a fixed position in this case it's going to be the end of the works crossbow it's gonna be moving at some fixed speed we let design to said what the speed was we also had a maximum speed or a maximum range sorry on our projectiles so that they would time out after a certain amount of time and we wouldn't have a lot of Indies cluttering up the world and then there's gonna be it's going to be moving for some amount of time T since launch and since the AI can actually fire in any direction SP your speed times the amount of time it spit out is actually going to form a circle around the eye that's expanding over time so the radius of that circle like I said is a speed times the time that's been out x prime which is going

to be our new projectile position live somewhere on that expanding circle this can also be written as the equation for a circle which I've done here I'm gonna be doing and showing all my math on my slides here in 2d I for some reason I'm not a very good artist when it comes to 3d so just just say you know this math actually does all work in 3d without any modification so when you take the players move in and the projectiles move in and you put them together you can see what we wind up with is a circle versus line intersection and so if we think about a circle versus line intersection we really have three cases we don't hit it all we have one potential hit or we have two potential hits so just keep that in mind as we go here so here are equations again for both the player movement at the projectile movement so you'll notice both of these have an X Prime this is actually going to be our intersection point where the projectile hits the player and you also notice we have a teen both of these for how long

it's been so we don't know T which is our intersection time so if you take these two equations and you solve them 30 you wind up with a quadratic equation which you can solve using the quadratic formula a B and C here are all scalars there's a vet bunch of vector multiplies in there that are just dot products for folks interested in how we got from the last side to this slide the online versions these slides which will be up shortly after GDC will actually have that whole derivation in the appendix so let's take our credit formula that we got from there it's pretty simple it's not too difficult to code this up and go however there's a couple edge cases you want to make sure you think about while you're working through solving this so first if you take a look at the bottom of this your intuition would be if a is zero you don't have a valid solution but remember we're actually solving a polynomial a T squared plus BT plus C equals zero so we actually do have a valid solution if a is zero same we want to do is when we want to take a look at the discriminant inside of the square root here if it's zero we wind up with one solution if

it's negative we don't have any solution at all otherwise we're going to get two solutions we want to take the smallest positive solution of the two because you want to hit as soon as you can if you have a negative solution its invalid in my experience you're almost always going to wind up with one invalid solution it's very rare to actually wind up with two valid solutions out of this so once you have your solution for time T you can circle back around and plug that into the warm Age movement equation and this will give us x prime the location we're aiming at you can take X prime and your initial firing point from the orc and that will give you the direction you're firing in and then if you multiply that by the speed the projectile is firing at you will have your final projectile velocity as you can see here so what happens if you don't come up with a valid solution because it can and will happen to you so if you did your math before you played your firing animation you can just not fire at all nobody will ever know anything happened however if you like us and you actually did your math at the time you hit the firing point in your animation the works already played a

firing animation it looks really bad in our experience if nothing comes out of the crossbow at that point so we wound up doing was actually just shooting a projectile at the players current position nobody ever really noticed it happened frequently enough it still looked fine and we have a lot of cases to where the player wasn't moving around so it still actually looked pretty decent so once you have your math all coding up and in your game you may want to actually visually double check it just to make sure it's working like it expected so we did that so the first thing we did is in under the orc here we drew the launch point you can't see it because he's standing on top of it the next one you do here in red was the actual predicted point of intersection between the warm age and the projectile then we drew the motion of the projectile every frame we just draw its position in white and then we draw the final endpoint impact point in blue so if you notice the impact point and the predicted point are actually slightly different here but that's expected since the players collision is an important space in our case it's actually a cylinder so that impact point is actually on the surface of the cylinder so those two points are close

enough that this is what we would expect to see and this lines up so now we've talked about hitting a little bit with linear projectiles let's talk about missing with them we're trying to write funny opponents here and not aimbots so we wound up giving to design two different accuracy settings one for horizontal and one for vertical we would then take that and do a random role between the negative value and the positive value so we defaulted to two degrees interestingly enough for both horizontal and vertical which gave us a total cone of four degrees we would then take those two rotations generate a rotation matrix and multiple multiply it by our initial direction vector to randomize the shots one thing we noted is specially on the vertical is that you want to avoid shooting too far up or too far down especially for shooting to the ground it made the eye look especially dumb they are orcs but at the end of the day you won't don't want them to look too dumb after all so this worked well we had this in our game for quite a while and then we added barricades which are obstructions have blocked the eyes paths

and that they can damage and we noticed that archers are really being rough on the barricades as you can see here pretty much all their shots are hitting the barricades it looks really bad players were complaining because all they're expensive traps are getting torn up so what we wound up doing is we added a new value into the equation we called tilt that we applied to the vertical value only so tilt automatically shrunk the cone by half so now we had a two degree cone instead of a four degree cone and then we had a range 0 to 1 where point 5 kept it centered 0 would remove the bottom and 1 would remove the top we wound up defaulting our tilt value to 3/4 which got the majority the shots clear of the barricades as you can see here we didn't want to remove all of the down because we do want to incent players to not fight around their barricades but we didn't want to be overly penalizing either as it turns out that actually still wasn't enough to fix all of our problems with barricades we had a number of short characters in the game as you can see here whose center point which is what we were aiming at was actually below the barricade height so what we did for those cases is we had the AI look at the height of the thing they were shooting at and if their Center was

below the top of the barricades we'd pull it up but not above the top of the player us collision cylinder we threw a warning if that point actually did need to go over the top of the cylinder fortunately it's never come up for us so here's everything all working on a layered projectile so in summary they have a fixed constant speed you want to take that speed and the player movement prediction to solve for the intersection time and location as far as missing we used a cone we used a different angle for both horizontal and vertical in that cone and we did need to do some additional game dependent tweaks and you may as well so next up let's talk about their cousins the ballistic projectiles so this is a ballistic projectile unlike a linear projectile it has an upwards initial velocity or some velocity to its initial velocity and it's affected by gravity so you get this nice arcing motion so you really want to do the same set of operations here as you did on the linear projectile before firing you want to

predict the player's position one slight difference here is you may actually want to predict on the ground which because a lot of times you'll have a group bouncy grenade and this will actually get you less bounciness and will land it closer to the player we want to do a line-of-sight check in theory you'd actually want to do a piecewise approximation of your arc to make sure you're not going to hit anything up in the air however our hallways in our game were pretty much square and didn't have any obstructions I've talked top so we actually just kept the straight line check it saved us some performance and was good enough for us but your mileage may vary on that point and then just like before we wanted to look at when we were doing our math either before the shot or at the time of the shot so this is your basic ballistic motion equation if you're interested in seeing how this is all derived out I'm gonna refer you to last year's excellent talk on building a better jump where it's talked through in some depth so after seeing how we solved for a linear projectile you'd probably assume we just take this and the one range movement equation and put them together and solve them except you wind up with this which

is a quartic equation and can be a little bit hairy to solve if you're curious how these are actually solved I've got some good references in the note graphics gems 1 is probably the best one we actually wound up doing some reproach mate approximations here in cheating so how did you cheat you might wonder well we started with an arc and we noted that you could actually break the motion of the arc into horizontal and vertical pieces so we solved the horizontal one first with actually our good old linear projectile code which he already had the one slight difference here is we actually had a maximum range on this which I'll talk about more here in a little bit we go ahead we solve that for t we'd get our intersection point and we're done so we take that intersection point with our vertical motion and say this is where we want it to land so let's solve for our throw so that will in fact land at our intersection point so we'll start with our projectile equation from a couple slides back and we'll break into x and y-components here which are going to we're just going to solve at the distance of the target so X

is going to be your horizontal distance and Y is going to be a vertical distance we want to solve these for theta once we can use to calculate our launch speeds so we have two equations and two unknowns and if you take these and you solve them you wind up with this which is actually the quadratic occasion again and once you solve that through for theta you're going to wind up with this and you can use this to get your launch angle so you may have one solution in which case you're good you know you're throwing the list you're done if you wind up with no solution we just threw it straight at the player but we kept gravity on the projectile we found it was important to keep gravity on there just for the feel of things sometimes it wouldn't land close enough but frequently it was good enough that nobody ever noticed and then sometimes you wind up with two solutions in which case we just picked this smaller of the two we felt that looked better the higher of the two frequently was a pretty large arc which I'll talk about again here in a minute so now that we have theta we can solve for our speeds which is a pretty simple

solve you just multiply by the cosine of the angle or the sine of the angle and we're driving that from just basic trig equations sohcahtoa in this case if anybody remembers back to high school algebra so now that we've got these we actually need a horizontal and vertical vector to throw along that way it all works when you have a case like this so for calculating throw vectors you're going to have R which is the vector between the launch point and the target and which may be non horizontal as it is here all you want to do is actually just project that down to the ground the math for that winds up being you're just removing the up component of your vector nice and simple then you take that component which I'm calling our prime multiplying it by your horizontal speed and then adding your vertical speed in and you are now in the grenade throwing business so one note here is that using the quadratic equation like we did is not a perfect solution to this problem you will hit where you want to but it may alter your impact time slightly we found that for us and for the ranges we

were fighting at it didn't matter and it still worked just fine and the fact rod Rene's area we didn't really hurt much either there so just something to be aware of if you use this solution so as far as actually calculating what our base throw speed was we change our approach between games here so at first we just had a constant speed that design would set for how fast these were thrown however it was kind of difficult to work with because they wouldn't know how much arc that would give them kind of what the feel was on that so we found actually giving them some values to play with it more just described how the bridgetta was gonna behave give us better looking results so instead of one value we actually gave them three so we gave them a gravity multiplier so a larger gravity multiplier would make the projectile heavier and feel a little bit weightier like a grenade making it smaller would give you more of an arc we gave them an ideal launch angle which we defaulted to 45 degrees that way you get since a 45 degree launch of the projectile will give you the maximum range for speed would actually give us the lowest possible speed there

I don't think design ever actually changes from 45 degrees but the option was there if they wanted it and then like I mentioned earlier we had a maximum range we had a little bit of a constraint on how far that could be which I'll talk about here again in a minute so solving out for our throat for a drive through a speed from that works just like before we're splitting into x and y components like we did and then we're actually gonna solve these for where the projectile comes back to the ground at the maximum range and this will wind up being the speed we used earlier just a friendly reminder all the derivations for all of these are gonna be on the online slides later if you're curious how the math actually all works kind of beneath the covers and then we're actually also going to use those trig identities again to calculate our horizontal through a speed specifically so maximum range which I've mentioned a couple of times so our designing our game agreed on a minimum ceiling height which is to say nothing will ever be lower than this don't forget to take into account when you're actually calculating how high that is that you want to calculate it from the throw

point of the character not from the ground so different characters might actually have a different height here so we would take that height we would plug it in the projectile equation and we'd solve it through and wind up with our possible maximum range for that height debugging this is actually pretty similar to debugging linear prevent projectiles we had the same colors did the same things one thing you might notice here though is we actually had a couple of impact points since their grenades will bounce around that's okay and that's expected so one problem we ran across with these grenades is when the players got really close so you got something like this which and it's not really so good you really wouldn't want to ship with this right so we wound up cheating a little bit to solve this we noticed it was really only when the player got close so we had a maximum angle of 70 degrees we used in our game and then we had a minimum distance that we set to about two to three meters and that actually seemed to work pretty well for us the players get close the eyes were just do a straight line throw again with gravity and it looked good later on in the game we actually wanted making an AI change so when players got close enough the eyes would just break off

doing range attacks it wound up making this a little bit better and it also end up looking better because an Oryx shooting you with a crossbow when he's right up in your face like this it it just looks a little bit silly it also gave players one other way to counter play against range AI since they could get up close to them and for ci to break off and continue running down the path there are some other ways you can possibly cheat physics here I've got some more information on these and the references if you're curious all of them have different trade-offs so ours is not the only way to solve it but we were we were happy of the results so as far as ballistic projectiles go you still want to be able to miss so the first project we did these we actually just picked a random point in a circle around the player and just or the predicted position of the player sorry and then we threw in there worked fine we shipped with it not a problem we actually went up changing a little bit on our latest game the thing we noticed was players were not always facing towards the grenade throwing units and so they would frequently miss the

fact that a grenade and just shown up and then they'd be like hey where did that damage come from that's not cool so what we went up doing was a handful of things so we added a few sound of the grenade there was a nice hissing sound as it flew through the air is 3d so as you'd hear getting closer closer closer closer then we beefed up the impact sounds so there's a nice solid clunk when I hate you or hit the ground nearby and then as you can see here we also hadn't a decal to show the danger zone to give the player notice it was there and give him a chance to run out of the way as a result we actually pulled off the missing in a circle code and just had the grenade throwing units always hit the player we actually were a lot happy the results of this and we were just trying to throw in a circle around the player so when you put it all together this is what you get for ballistic projectiles so we had a derived speed on these we threw them with an arc we came up with our approximate solution that we were happy with and then we solved it with a quadratic equation you may need to if you use that solution you may need to compensate for high arcs or some other edge cases as far as missing goes you

can either aim around the player or just make the grenades avoidable so wrapping up make sure you aim ahead of the player make sure it's fun fun is your priority here it's okay to cheat as long as it's fun and looks good at the end of the day make sure players have a chance to react AIS we're trying to write a fun opponent and not an aimbot and then make sure design can control your course ID with parameters and then derive your math code and fun from there any questions if you have questions by the way please step up to the mic you
