Designing the Bustling Soundscape of New York City in 'Marvel's Spider-Man'

[Music] we are going to talk about designing the bustling soundscape of marvel's new york city so i am alex previty i'm an audio designer at insomniac games and i am blake johnson also audio designer at insomniac games and yeah we're very excited to be here today to share how we um us and obviously a lot of talented people at insomniac games came to create the sound of marvel's manhattan in marvel's spider-man so before we get going just a little background on alex and i we met at the savannah college of art and design we were randomly placed as roommates and had a lot of ridiculous times together and we did graduate and swap that out that's us last night so we're here now living the dream at insomniac games

a little background on insomniac games it's a pretty great place to work with work for a lot of these places thought we were pretty cool to work with up until recently as well and we are looking to hire in a handful of positions and i want to highlight one specifically if you happen to be a audio programmer yeah come come find us after i'll be at the booth later today and you can find it on our website as well insomniac is been around 25 years we're celebrating our 25th anniversary this year and we got our you know big start with i think spyro and then ratchet and clank resistance sunset overdrive the unspoken and of course what we're here to talk about today is marvel's spiderman a little background on our team internally at insomniac we have one audio director

one audio lead four audio designers including alex and i one dialogue coordinator and then we extensively used sony product development services we just call them sony pd and from them we had 10 sound designers three which were working in-house for a bit of the end of the project one dialogue coordinator in-house four dialogue coordinators external three music editors externally and yeah that's the team specs on the project we used wise so you'll be seeing some screenshots from that we had 256 megabytes of ram for audio and that includes the 60 megabytes for wise and engine overhead and the remaining about 190 megabytes for sound banks and media today we're talking about marvel's

manhattan and alex will first be discussing the city ambient bed which includes the city room tone per se and then the fake 3d layers crowds and the crowd system the city perimeter spline emitter reverb and how that is created on a mass scale and dynamic ambient systems this being things like weather time of day stuff like that and then wrapping up with the performance and optimization for those areas i'll be talking about the ambient and scripted vehicle systems so traffic and the um like chase vehicles and things like that uh that entails the engines their horns uh brakes squeals and turn squeals and doppler buys and what i like to call the whiz by system

so before i pass it off to alex here's just an example of what the final version of marvel's manhattan sounds like from a handful of different perspectives three rows on that one [Music] hey hey so you know we had to make the

city sound great that was kind of our first major challenge we had to tackle on this game so as you know new york city is one of the busiest and loudest cities in the entire world i think on average in the midtown area in manhattan it averages about 75 db you know at any given time so basically we needed our sound to represent how crazy new york city was and how bustling it can be but we also needed the ambience to not be fatiguing you know because when you're out in new york city as a pedestrian you maybe you'll be walking for a couple ten minutes go down the subway station go home go to work but you know in our game you know you're going to be out in the city for maybe 10 12 hours of gameplay time so we kind of had to make sure that we were you know making this happen so we're kind of stuck being a rock on a hard place in this game trying to figure out that dichotomy between having a game be bustling and crazy sounding but also be in the background enough so it's not you know kind of reputation no well whatever anyways it was a tough reputation to kind of uphold for new york city so we kind of had a challenge in front of us like what do we do so we kind of had to find a way to

basically construct new york city's ambiance from the ground up so what we kind of had to do first is you know find some good source recordings that kind of were very characteristic of what new york city sounds like so what we did first is this first step into deconstruction was basically taking some good profile some good samples and kind of running that through izotope rx so i use the kind of room tone generator that's normally used for kind of filling dialogue and stuff but i use that for this system so basically we kind of took all these new york city ambiences ran it through isotope rx and kind of generated these very static tones that kind of had the energy and frequency spectrum of what new york city felt like but stripping you know every element out that would be considered distracting and then using that same edited sample you know bank i also ran it through gram evolution which kind of like smears things and kind of makes them like like cream cheese on a bagel kind of thing you know what i'm saying so basically we kind of layer that in with our more static isotope rx generated stuff to kind of get this like very

amorphous kind of moving feeling of new york city without having anything that sticks out like police whistles car horns people talking etc so this is really helpful for us because we kind of had to sell the energy of the city without really having anything that's recognizable and things that you would pick out with things loop um this is also really helpful for kind of stereo and quad imaging in our game you know if we were right on reliant on 3d elements only we would just have problems with it not really feeling full and i think just having things be 2d as just a foundation really helped fill out the stereo field unfortunately in this game for reasons we'll get into later we didn't have a lot of streaming bandwidth so a lot of our beds and loops were actually stereo we tossed some source reverb in our delay which were surround it kind of fell out the back speakers a little bit so the next element we have for our ambience is our kind of random 3d layers so you know while we stripped everything out that was interesting as the foundation we kind of had to add that stuff back in to kind of make the city interesting so you know new york city is a lot of cool sounds got like car horns sirens you know people yelling

at each other construction dogs barking car alarms whatever it is so we kind of edited those out and kind of created these banks of different ones so once we pulled all these interesting one shots of different categories we basically kind of separated them into different categories and different banks so we had three actor mixers and wise that were used to organize everything we had our close sounds we could hear basically when we were really close on street level had a not in the city available we also had a sky layer just for you know when you're up higher you can hear planes and helicopters and things of that nature and this was really helpful for us in the long run because we were able to take all these three different layers including the sky one so far and basically kind of mix them all differently depending on where you were with states and rtpcs which we'll get into later as well so here's kind of a video showing you

know the different layers being added one at a time to kind of create the full bed that we have in the game [Music] so [Music] [Music] so that's basically the bed only there's no actual like 3d diegetic sounds in that video at all so that's just like the faked bed so that worked really well for us you know for being inside of the city but you could also traverse outside of the city's boundaries kind of on that you

know outside road area by the seawall so we had to make sure that when you were outside in that area that the city sounds were being spatialized correctly to basically the center of the city so what i had to do basically to start off was draw a pathway kind of exactly detailing the outline of our road where all the buildings were and we had a path following emitter that would just follow the player you know along that rail that we drew and then we had our technical artist at the time who still worked with us david santiago he helped us basically kind of draw all these volumes that would create this network that whenever we would walk inside of it it would kind of turn off the 2d surround ambience and kind of activate this 3d point source emitter so look at this photo here all those blue volumes are what were automatically drawn and also hand authored so whenever you step into that area it turns off the surround reverb and everything kind of turns up the 3d stuff if you look really closely with the arrows pointing to that little magenta line and that's the line that i drew it took a while to set up but once it

was all working correctly it was great so another thing we had to do is make sure all the crowds had sounds so yeah like you know new york city is great lively but it's full of people that's what makes it so lively in the first place so we needed to make sure that they all have the proper wallet and stuff and 2d walla was not going to cut it at all so for scented overdrive we kind of developed this system called the crowd horde emitter system so in such a overdrive you can basically fight and you know battle up to 40 different you know bots at one time and so instead of hit them having all their individual emitters running at the same time it was kind of hard to manage performance and sound wise we kind of had a system where would take about five to ten people and it would basically find a center of mass and generate a 3d point source emitter and now basically every couple frames it would just follow it and when the crowd would dissipate it would play a stop event and go away so that's kind of how it worked for this game it was really helpful for us because we were able to basically find crowds place emitter on it it would follow it and we take it away so here's a video of it being soloed and if you

look at kind of the blue orbs and debug you can kind of see where that static emitter is being drawn so you saw it's kind of coarse and sometimes it can spawn in kind of weird unexpected places so instead of making you know the actual source that's playing on the emitter an actual mono sample we had it stereo is mostly mono when you're farther away but when you got closer it kind of spread to a more stereo quad image so that when you were kind of closer to it it kind of felt like it was enveloping you which really helped to not only sell the size of the city in the crowd but to kind of mask some of the imperfections in our system so our next thing we had to do is kind of come up with other diegetic 3d emitters so spider-man can be on the street level everything's lively down there but we kind of needed a way for

the upper levels of the city to sound lively as well because spider-man can swing crawl run wherever he wants to go basically so we kind of need more dynamics and also when you're swinging at mid to high levels we needed everything to kind of feel like it was moving we couldn't just sell that on our 3d ambience alone and our 2d stuff so basically our easiest way to do this was to take every single hvac in a window on a rooftop rooftop vents etc and place audio emitters on them um it was really helpful for us because our artists use houdini to kind of populate everything out so we're kind of able to open up all these art prefabs place our sounds in them close them back up and the game automatically updates them which was cool but there's a lot of these so we kind of needed a way to manage the voice count so basically our audio programmer at the time came up with a system where you know once we generate sound banks on these special emitters it actually recognizes its max attenuation settings so once you get outside of that range the engine actually shuts off and hibernates the emitter so wise isn't being pinged a lot and our engine has a much more manageable voice count as well so here's

a video of that in action again if you look at the blue orbs or the sound emitters you can kind of see them going in and out depending on how close or far away you are [Music] [Music] see that was really helpful because when that was not on we crashed the game everyone hated us so thanks audio programmers so you know that was all cool and stuff we kind of needed a way to balance our 2d and 3d elements not only our 3d fake elements but also our diegetic stuff it kind of took a while to strike that harmonious balance to make everything right basically took us from when i started basically almost two years to

really get that fine line between you know having our fake stuff and our real stuff together nicely and we kind of had issues with things sticking out too much so we just kind of made everything flat turned it down and it kind of made everything fit nicely so here's a video kind of showing the 3d elements that are diegetic only to kind of hear how the city sounds with all the real stuff and then halfway through i'll kind of unmute the 2d fake stuff to kind of hear how big it sounds [Music] [Music] so for the sound design and everything you know that was a good start but we also needed a way to kind of make everything sit well in the world so one

of the first things we needed to do was kind of fill out the space with reverb so no space is complete without his reverb and it kind of helped all our sounds feel world eyes and also helped our city kind of feel more grounded as well so here's some quick stats for you our open world in this game is six kilometers by three kilometers as its general size there's nine districts there's over 500 roads and over 1200 alleyways there's 8 300 buildings so we needed a way to kind of make sure all these alleys courtyards and other spaces were you know assigned the proper audio volumes so initially i did these by hand and it sucked really bad um it took me about two to three days per district and it was just time consuming stressful and did not make me very happy at all and anytime that any geometry was adjusted if buildings removed and stuff we basically had to redo everything from scratch and it was not a good time so we kind of needed to find another solution for this because this was not sustainable in the long term at all so what we did was turn again to our technical art team

who is great and we love them very much they already have all the data for how all the buildings are what the spaces are between them and their shape so they kind of use the space and measured it to kind of generate these volumes for us and every time you know something would change they'll just regenerate it would take a few minutes and all be good so we kind of gave them a few parameters for size for alleys and courtyard and stuff and every single you know type that we would generate in place they would have a different reverb and delay assignment from wise to kind of give a different space we also kind of use this to apply different y states as well so every volume type other than having reverb and delay settings that are different also have a different y state as well to kind of dynamically adjust the mix of the city and other sounds as well so here's a photo kind of of all of the streets and alleyways in our game from a bird's-eye view and then here are all the volumes that were generated um a few of these are hand-placed um kind of the ones on the edge and some of the more bespoke areas but most of what you're seeing here is what was automatically generated from our team which was super helpful

so that's all fine and dandy but we also needed a way to make our city kind of react to whatever is going on um you know the city can sound great but it also needs to be dynamic and living and breathing which makes new york city so special so one of the first and most important things we had to figure out was making sure that our city was changing appropriately based on player position so basically gameplay gave us this parameter of player height and we basically used that to kind of drive an rtpc and wise and that would drive a bunch of different things like blending between blend containers it would do eq volume reverb and delay adjustment and also change you know some various mixed assets we would bring up and down for why states as well we had over 10 different categories of environment types like parks different alley types and that was also further used to kind of push our mix in the game to bring elements up and down so here's an example of a wide screen shot of one of our layers and you can just see a few ways we're just taking our player height and doing some subtle things with the mix to kind of make it feel more realistic and it's not shown

here but also in the effects tab we're doing some high shelving and low shelving as well with this rtpc so here's a quick video just kind of showing how the city will sound a little bit different depending on how high up you are so that's all continuous too so there's no like on and off states that are happening like if you move up and down it's all dynamically happening in real time mostly via rtpc so we also kind of needed a way for our

districts to sound different you know we have our neighborhoods we have our different pockets in the city so we kind of needed those to sound different as well so we kind of talked with the art team in match notes to see kind of what's your art bible what's your goal in this space and how can we take that same idea and kind of apply it to our ambience and our different audio we have here so in our ambient bed we had certain sounds play a lot more or not at all in some cases and we would do some little mix changes to make sure that like how the space felt from a visual standpoint was reflected in a very subconscious and subjective way on the art side in the audio side as well so for example like in harlem you know it might be a little quieter because it's not as busy but in midtown we would mix up a lot of elements maybe in hell's kitchen there's more construction happening so it would kind of make sure that that was all being represented properly um and then we also had to make sure that our of beds were different as well basically we had our loot group actors come in and record in different languages to make sure that the wallog beds that happened in different areas like chinatown and in harlem and in hell's kitchen kind of had a different

sound and had different languages throughout we also made sure that our diegetic music that was playing on boomboxes storefronts and cars kind of had different genres as well depending on what district you were in so another feature we had that was kind of cool but also very subtle was making sure that our city ambience was mixing differently depending on our activity level so we kind of did was we had a programmer create the system for us that would basically draw this like radius around spider-man and inside it would count how many active pedestrians there were kind of what they were doing and also all the ambient and active traffic vehicles and we kind of used that to you know track this float value that they would give us and that float value be passed to us as a wise rtpc and then that would kind of help us lean into stuff more so if the area around it was really busy we could still rely on the diegetic sounds that were coming from those people in those cars but actually being able to like lean into it further and really push up our intensity layers and our bed to kind of help sell a fiction that this area is super populated but if you kind of go a couple blocks down it's emptier

would really change the mix of the city um and we could also adjust our thresholds our radius sizes and other things with a config in the engine that they set up for us as well so for our weather it was pretty simple in our game um we really only had like you know day night rain overcast so kind of figure out how rain was going to work in our game so of course you know we had a 2d rain bed but we also had some 3d assets as well so for our 2d rainbed you know most games your traversal is pretty limited so you can only kind of walk run drive etc but spiderman can go anywhere so we kind of make sure that our 2d rainbed reacted accordingly so we set up a raycast system for that which i'll show you soon we also had to make sure that all of our 3d objects in the game were tagged the correct surfaces so similar to earlier how we set up our static emitters on hvacs and rooftops and stuff we had to make sure that umbrellas trash cans and other things were tagged with 3d rain emitters that would turn on when it was raining and also we're tagged with the correct material type as well so for our 2d reign our audio

programmers set up the system to point to raycast from the hero to the ground and as soon as the input impact point happens we get an rtpc that measures that distance and basically we kind of drive the mix of the 2d rain with that as well so here's a video kind of showing that in action it's pretty simple you know it's just mostly volume and eq changes but once it's kind of sits in the rest of the city ambient it really feels pretty nice so another one that was a little more subtle just kind of time of day change so basically day and night was our biggest difference we kind of had to sell and this was a very subjective approach so basically daytime would be kind of

the default city ambience it would be very bright a lot of the more intense sizzly layers that were had a sharper q spectrum we would kind of mix those up during the day and at night time we would kind of re-cue a lot of the beds to kind of make sure that they were sounding more cold so we kind of introduced more like low mids into the mix to kind of make it feel emptier and we also changed our re-ribbon delay completely to kind of make sure that it kind of reflected how the city was a little bit empty or feeling we also turned certain things up like dogs barking and cars racing at night to kind of give the flavor a little bit more of a different kind of vibe so all that stuff was in game sounded great but we ran into a huge wall which was performance in optimization which is everyone's favorite subject so basically a lot of times in our game especially towards the end of the title development we were kind of over limit a lot um we only had you know 180 190 megabytes to spare for the whole entire game and since the open world was loaded most of the time we'd make sure that was fitting into memory so one of the first steps we did to kind of get in memory was switching from a-track nine to aug vorbis which was

really helpful because that kind of made our overall ram usage drop by about 10 megabytes which for us was huge however this caused us to rise our cpu usage by about 12 from what you know the engine having to decode the avorbus stuff so we kind of put a lot of ambient elements that were being streamed in a track nine so they wouldn't have to be decoded but they were being streamed anyways so they weren't taking up any memory at all um for our resident memory and distant layers were also more compressed so distant sirens that were more muffled we just used a really aggressive compression ratio on those if they were being low pass anyways you wouldn't be able to tell those nasty artifacts so that was a huge win for us as well but so how to kind of be you know smart with what was streaming what was resonant if everything was streaming at once we were also competing with quad music and a bunch of dialogue and everything that was happening in the world so we kind of had to make a lot of our things that we would normally be streaming we had to make those resonant so we kind of chopped up those longer loops into shorter segments and crossfaded between them so it's not only helped with variety but kind of gave us more bang for a buck when it came to

what was being loaded unfortunately to sacrifice a lot of our more dynamic layers and kind of sum things together before they went into y's just because we couldn't run everything at the same time and like i said before we couldn't do quad ambiences in our game because we had just too much streaming contention so we basically had to make sure that everything was stereo but using our surround sound reverb and delay to kind of fill out those rear speakers so that's kind of how the ambience fake and real stuff worked in our game i'll pass it off to blake to talk about the cars so as you saw alex uh when i came on alex was in the midst of putting together a really dynamic and layered ambient system but there was still one system especially in the three in in terms of the actual interactable objects that really needed to be taken care of and being new york of course that is cars there's a lot of cars in new york so cars became my first

like the vehicles the traffic became my number one priority and first big task on the project so just creating that bridge between what alex created in the 2d system and bringing that like matching that with the actual cars you interact with on the street just a quick overview of the traffic or ambient car system there can be up to 180 active cars at one time that's not including parked cars and i learned along did a really great talk yesterday and i think there's something in like four digits in terms of parked cars thankfully for sound we don't really need to do much for parked cars but 180 active vehicles i'll get to how we worked with that because 180 is too much for us to you know be actively doing things classified into five car types and vehi the traffic vehicles essentially

had four core sounds that they were make that they could make being engines the tire road noise their brake squeals and car horns the five car types we had were commercial which is like your box trucks delivery trucks that kind of like diesely engine sounding stuff compact and sedan were used pretty similarly and only had some variations in terms of the engines we used for them suv class we used for the sable kind of humvee vehicles in towards the end of the game and then electric were the taxis because marvel's manhattan is pretty eco-friendly and the taxis look like kind of electrical electric vehicles so engines was definitely the biggest hurdle to overcome if you've ever worked in audio and specifically with vehicles you know that

it's especially dynamic vehicles it's a challenge because an engine sound is a very complex sound and if it's a if it's static you know it does the same thing every time that's one thing you can kind of bake what you want to use but in the traffic system in sparta spider-man the vehicles can be interrupted and you know they stop and go anytime so i started experimenting with a plug-in you may know it's for wise and other middleware called rev by crankcase audio and it's a granular synthesis based engine simulator so i was playing around with that in using it with our traffic system and we all agreed that it sounded the best it was the best sounding option over using like loop-based audio but a it's really cpu intensive and obviously with the number of vehicles

that also throws another wrench in the system but i'll get to performance more later so we used nine rev models uh many which were created and provided by the audio guys in the uk but we did use a loop-based system for the electric taxis because uh pretty much any non-classic like like gas engine sound does not really work in rev it's really just meant for that and then we used loops for the police sedans because at the beginning of the game there's like a ton and to try to have rev in rev instances on those plus they're they pretty much do the same thing every time and they're not a focus so it works to make those loop based oh and just a note on rev it used about 1.5 to 2.5 percent of our

audio cpu thread per instance so it was a little expensive so what i ended up doing for the engines was essentially faking a rpm curve over speed so on the x-axis is the speed of the vehicle y-axis is rpm because these vehicles don't have any traditional physics you would expect in like a driving game or any any game where vehicles are actually being driven by physics i had to kind of fake things and in terms of you know programming support potentially you could get parameters that could fake the rpm accurately but to do that on a large scale and uh just in the amount of time we had on the project it just didn't make it in we weren't able to get something realistic so what i did was yeah fake this rpm curve

which ended up sounding pretty good you know most of the time you could never really tell and the only issue was when a vehicle would be constantly moving at a steady speed especially if it was at like a higher rpm because it just kind of sounded flat lining but thankfully new york there's a lot of traffic so they're constantly starting and going next i'm going to look a little bit at the break squeal skids and horn honks they really provided a nice level of immersion and just kind of personality to the city so first the horn honks so in this example a sedan spawns into the city and the vehicle type is set to sedan and this is done on the model level so on each type of model like the sedan compact etc the switch would automatically sign based on that and then we used what's

we called a random switch because we had this issue where you the player is spider-man you jump in front of this car and it would honk at you okay that's normal you'd move out of the way it'd stop honking you move back in front of it five seconds later [Music] we have a completely different horn you know and while we wanted the variety in amongst sedans and compacts especially because there are many different horn sounds in those car types we needed to be persistent amongst the life of the vehicle so we got some programming to sport programming support to essentially create a what we call a random switch it just randomly selects one switch out of a handful that you give it so sets it to number three so we can stay with a consistent sounding horn but it will still do like a variety of different types of hogs so at the heart just an overview

hong star event looks at the car type checks the random switch and place the honk just a side note they will honk anytime they're interrupted abruptly and a very very low probability if they're just stuck in normal new york traffic next we're going to look at brake squeals in this situation a delivery truck spawns in the vehicle type is set to commercial and the random switch would also be set but not relevant in this case for our break event the first thing we look at on the engine side is the distance of the object causing the brake to give some granularity we use this and speed which i'll also get to in a moment so if the distance of the object from the vehicle was greater than x i think it was around maybe like 10 meters

we would then play something much more subtle and slower like this [Music] however if the vehicle or if the object causing the brake was on a shorter distance then we would look at the speed of the vehicle if he was moving pretty fast we would give it something short but pretty intense and a little louder like that and if it was going slower then we would just get a subtle little brake squeal like that and to brent just in a cacophony of brake squeals we had to make sure there was kind of a threshold so we didn't play them for my new little movements so this guy's made me wondering hey what about the tire noise you know that's a big part of what we hear when cars are actually driving around it's not really the engine all the time so uh when a vehicle spawns in if it's

moving it will just automatically start playing the tire road noise and it's a pretty simple system this is the arc tpc graph of the sound on x-axis is the vehicle speed so we had an issue where sometimes the vehicle would stop but it would continue to play its sound and we didn't have a ton of time to you know thoroughly debug the issue so just as a fail-safe we just dropped the volume to zero when when the vehicle wasn't moving there's also some slight uh pitching up not a whole lot otherwise it sounds weird and the purple line is also just a priority playback so it doesn't prioritize it if it's not moving or moving very fast we also have kind of like a wetness system on the ground so um there's puddles in our game and on the road and uh when you would

drive over any object really we could send events so when you draw um drove over a puddle or not you but a vehicle would drive over a puddle it would send like a wetness value on an rtpc and you could do it with just like a switch system as well but i just found this to be a little more granular and give me a little more control so it would send like hey you know what you're driving over is wet and it would fade over to the right which is that kind of wet concrete wet asphalt kind of sound and then go back to dry once it got off the puddle so that's most of the aspects of the ambient traffic system but what about those crazy scripted vehicle moments where they're racing around the city flying around turns crashing and stuff we needed to you know do something extra for those vehicles

and the first aspect of that was the tire squeals now i wanted to create a dynamic system that kind of took care of itself amongst any situation that would that the designers would throw at it because they had the control of you know how fast the vehicle would go and you know the kind of angles they would go at and a lot of it was kind of auto-generated too so here's a look at a switch container or sorry the essentially the tire squeal sound and on the x-axis is the curve of or the angle of the curve of the vehicle so you can see if it's within plus or minus two degrees it's not playing the sound at all but as soon as it gets above that it will activate the tire squeal sound here's another view of the blend container which which it's in

and in the center there's a more subtle tire squeal sound and also some volume reduction and then on the outside you have a more intense tire squeal sound there were also different tire school sounds for different vehicles so like the bigger box trucks had a little different sound than say a sedan now the x-axis is showing vehicle speed and so the pitch would be a little higher when you're going when the vehicle is going at higher speeds and also to prevent cars sounding like they're going crazy fast when they're not uh this just prevented uh the chance if sometimes uh designers would script in a vehicle to not be going that first not be going that fast and this made it so we wouldn't have to go in and you know mute it manually or something or it would just be very

subtle so that's volume on the versus speed now here's an example video in a later part in the game where you can kind of get a sense for the tire squeals just doing their thing um you can kind of hear them in just the subtle turns and you know the bigger turns varying with speed and such [Music] next we're going to look at a classic sound that you expect to hear playing as spider-man swinging over manhattan and

that is you know that doppler buy when you swing or move past something really fast so we got some great programming support on this to create an event where when spider-man is at the peak or i guess no the bottom of his swing an event is sent to nearby vehicles or first it checks to see the closest vehicles to spider-man and it will choose i think about three or four vehicles to play to send the event on and it will play a baked doppler sound so to visualize again we would filter based on the vehicle type so if we have a sedan here and the event is fired on the sedan that spider-man is swinging over and it checks speed because we wanted to have when you're swinging a little faster to get more intense doppler buys and you know that are louder and also

the pitch change is stronger checks its sedan it'll play something like this then we also check kind of that middle speed and might play something a little more subdued like this a little slower and we learned we also definitely needed to make sure we weren't playing them when you were below a certain speed otherwise you could just hang hang there as spider-man and you would constantly be getting these doppler bi sounds as you're not moving at all similar to the doppler buy system i was working on the scripted chase and crime system and the engines were in there the tire squeals all that stuff but it just seemed to be missing something and i realized it's that feeling of motion as you're you know whizzing by cars you know parked and active

so i put together a really terribly cpu heavy system and wise just to get the idea across and to share it with a programmer to explain what i was going for and i just pitched that it was very similar to the doppler doppler buy event but we just needed it for the car chases so what we got was a system very similar where only when you're on a vehicle attached to a vehicle will this system activate and it looks at both parked and active cars that you're going to be passing and it'll just pick and this gets fired off maybe every second not too much because we were pretty tight on you know resource cpu and such at the time and it would pick about three vehicles to send the event on and we were able to reuse the doppler vi events and then for the

parked cars was more of just a clean whoosh not with like engine or um horn in it so here's an example video it's pretty short but in the beginning you'll hear there's none of that movement know that whiz by and a few seconds in it'll turn on and i don't think you'll hear in this round but it's extra great and surround just fyi [Applause] lastly to wrap things up on the vehicles performance and optimization was a big issue like i said rev was very heavy and we really had to make sure we limited the playback of rev this went back and forth a few times because we found if the number was too low and you were swinging over a very busy

area of manhattan you would hear the vehicle engine pop in and out as it switched from virtual to actually playing back in wise and i believe we settled on around seven instances for the traffic vehicles and it could potentially be more if it was descriptive vehicles activating and de-activating the sound component on a tight radius really helped us control this and similar to the static emitter system but on the you know moving cars we had a radius in which the sound component would turn on and off that way we didn't have 180 vehicles registered in wise at all times and yeah which really helped with cpu we also found though that if you're at a higher elevation you could be looking down at a street and seeing cars go by but you wouldn't hear them because it was below that threshold but the concern of the having too many

cars active at a time wasn't really an issue up there so the com the radius was essentially set on ground level so even if you were high up you would still have a few cars active which is really nice because it's quieter up above act 3 also produced some issues where it's much quieter there's far less cars on the street and you could see a car coming down the street and it would just all sudden turn on and then or turn off if it was moving away from you and once again because there's far less cars on the street cpu wasn't really an issue there so we were able to change the radius and make it bigger for act 3. not using rev for electric taxis was also very helpful and we just got a lot of memory savings from using rev because we didn't have to have a handful of loops saved for every type of engine we used

just to conclude this is an example video of just walking around and swinging around new york city with out the the traffic sounds and then with them plopton [Music] huh thank you

so all right okay so lastly we're going to kind of show a little video kind of you know showing all the elements in the game in a final product you know in full mix with everything activated just kind of showing different aspects we talked about with the vehicle sounds crowds and ambience this is a little you know end cap for this [Music] [Music] okay [Music]

[Music] [Music] [Music] i tried catching that a lot of times i suck at playing the game so it's a little sloppy sorry [Applause] so that kind of does it for us um just wanted to thank you know all these people so insomniac games obviously for making this game happen all these great teams programmers you know developers everyone on the team super helpful uh sony interactive entertainment for not only you know helping us make this game but was providing so many incredible sound services for us marvel for literally

inventing spider-man but also just being a great resource for us and you know being there for us in audio kinetic just for you know making wise which we all love uh here's our twitter's pretty easy to find us on there so be cool if we could you know chat all that stuff um yeah thanks for coming out everyone uh we have some time left like 10 minutes so if you have any questions we can do a q a hey great job guys uh i had a quick question about how you managed uh rev instances uh did you end up needing to have a fallback for if you you know wanted a car to make sound but didn't have enough instances did you need to fall back to a looping system or were you able to just be like no like it's not important like focus is is fine so don't play anything yeah that's a good question um i was talking

to someone yesterday yesterday about this with kind of like you know i think a lot of games might use like a lod system where at a distance it moves to loops kind of what you're saying new york is just so dang loud that it was never really an issue except for act 3 like i said i think if it was you know something that we did here more like like i said from above it was potentially an issue but then we fixed that by moving the radius to where they could be heard down below and with alex's system where you kind of hear tire squeals and this and that around the city it you i'm sure you could find moments where you're like oh yeah like i don't think i quite hear that engine but then again um you know i've spent a lot of time just listening to traffic on the street and whatnot and engines don't really make that much sound unless someone's really gunning it too so that um yeah that was kind of our solution there

good question kind of adding to that i just feel like a lot of games have a lower noise floor you know because of the location but for this game we were able to get away with a lot of stupid stuff just because like it was so loud all the time but also it's like you know we had to mix it down so it was never really like meant to be the main focus because it was just supposed to be in the background so even it sounds loud up here like in the game's mix is actually pretty low hi uh thank you for the talk it was awesome um i was curious if because you have a lot of stuff going on in wise like the rtpc stuff and then like just pulling out sounds and then putting them back in was there one specific thing whether for the vehicles or the ambience that was like really kind of kicked your butt and you were having trouble getting it to sound right and what did you do to go about fixing that or making it do what you wanted it to do engines were definitely [Laughter] like i said the biggest challenge was it's not it's not a racing game so i don't just readily have

the rpm value being passed to me or the throttle things like that i was able to get acceleration uh for just for the scripted vehicles which gave me some a little more control um trying to think what other oh we had a weird instance where squirrels actually were like crashing the game yeah so yeah i i just you know found these cute little squirrel cheeps or whatever sound they make and put them on and hey i realized there are a ton of squirrels in this game they're like everywhere so i had to really reduce how often you would hear them but there was a i think it was just kind of some old code that was the way it was deactivating or activating the sound source was like pinging-wise really hard oh yeah that was fun so there's a bug we had for a while where basically like whenever a sound instance would be generated on a crowd or a person it would just never go away ever so you would look behind you with all them activated you can just see this trail of

like all these emitters and like wives would crash after like a couple minutes so yeah i think for me personally the biggest challenge is kind of getting that dichotomy just working of like this city needs to sound huge and we got constant feedback it seems now it needs to be busier it needs to be louder but also making sure that like everything was just out of the way because this game is very busy there's a lot of swinging combat you know the music's very bombastic and cinematic as well um and also there's a lot of cinematics in the game we had to make sure that everything kind of like sounded like really huge but also was never fatiguing never in the way in a way that the player would never really like pick out you know you mixing these things so i think that was just kind of the biggest challenge for us at least in particular all right thank you very much i love the game thank you hey guys great job bringing the city to life it really feels well well done um i wanted to ask if you had any issues that you had to adjust everything that

you had set when the action would ramp up and be bigger and more bombastic like you were saying yeah so um we didn't talk about it very much in this because it's kind of a whole nother subject in this game but we had a ton of mixing systems um some of them were a little bit more like simple like states that would come on and off but we also had a lot of side chaining too so we didn't use hdr for this game because well by the time we had that idea it was too late it would have sucked so um we basically just use the wise meter plug-in and side-chaining to kind of manage all that stuff so the ambient city bed bus had so many people in from different you know buses and states and everything just taking it down for like impacts even the music too would take it down a little bit um and we also had these states that would come on in cinematics it would kind of neutralize the ambience in like really different ways and turn it down slightly so it doesn't get in the way also whenever you're in combat the city goes way down so you can just focus only on like you know the action excellent thanks you just answered the question i was going to ask about cinematics sorry yeah

is there anything else you would like to yeah like uh if you have like a really crazy busy like a city scene and then it's like a cinematics and you know maybe it's like an emotional uh beat that you just need to keep yeah so basically there's only three states for cinematics it was like default which we used 99 of the time we had our extra heavy state which is only used once in the entire game in our light state which is only used once the entire game so there's one state literally took care of it the entire game it was a very awesome kind of one-size-fits-all solution that was living in our kind of um global audio script that was always loaded and just had like a little relay so whenever we wanted to like call it we just go into our like you know cinematic script or go to our level script and just kind of add a call back to the state turning it on and off um and instead of just kind of simply turning down the bed which would have worked um there was a definite like obvious fade happening as soon as you get into a cinematic which was kind of jarring so it kind of worked on like a

bunch of different levels i think that state was like present on like over 20 different sounds you know in buses and actor mixers individually to kind of do this thing where like the actual like feeling of the bed is still there so there's really not an apparent dip in volume but it strips out a lot of the more distracting elements like all the close ones basically like the bustle layer kind of went away completely then all the things like horns and like the brake squeals and more aggressive distracting elements would come down quite a bit but you'd still hear it in the background the sirens and things were a little bit softer would still kind of be at the similar volume but then all the 3d objects that were diegetic like music would go all the way down for boomboxes cars would be a lot lower and kind of all that stuff would kind of be just like mixed in a way where it was just working and it would also be a little bit less so higher up so a lot of the high elements were naturally quieter would not be dipped as much so it kind of just felt like a natural like you know neutralization of the ambience nice thanks all right i think that does it so thank

you guys for coming out so early i appreciate it and have a good gdc
