AI-driven Dynamic Dialog through Fuzzy Pattern Matching

[Music] all right everybody welcome to this the last talk in the last hour the last day of EDC we have deployed smooth jazz to keep your resolute in the face of almost certain boredom by the way if there's a seat like closer to the middle from where you are you can kind of squeeze in we can get more people in unfortunately there sure are a lot of you here today it's kind of hoping there wouldn't today we are going to talk about dialogue and game is a really simple way to do dialogue in games a really easy way to make writer is very awesome this game this talk is not really about code it is not really about programming it is about enabling writers and I don't mean like by handing them the Scotch although God knows I've had to do that often enough by the way if you are the sort of person who freaks out taking lots of notes in

every slides taking a picture feel free to take notes but the slides are all going to be up on the valve website probably by Monday so there's no need to take pictures of every slide unless you really want to this talk is about our system for tracking lots and lots of facts about the world and then picking one rule from a gigantic database full of lines based on criteria for all those facts it's a system that we've used in half-life 2 to import restore but for dead portal to dota 2 all of our games most of my examples are going to be from left 4 dead 2 just because it was easy for me to capture video but it's the same tech in all of these games and we realized after the fact you can use it to drive some things that are not speech like animation and sound you will see a particular scene that will tip you off as to what other games uses this for for animation but really this talk is not about code it is about writers it is about empowering writers it is about a way to approach tracking state in the world in a way that enables writers to

do what they do best which is making your characters say things that are interesting it is as much as possible a system that is simple general efficient and friendly that is three things not four I'm of the belief that's simple and friendly are the same thing because if a system is simple to use people will use it if it is simple to build you can maintain it if you can build a complicated system you can only do simple things with it you have to build a simple system to make complicated things and why stand up here and talk at you for an hour about talking well there have been a bunch of really cool games and the past couple years that had done cool and interesting things with dialogue dialogue States sitting or tracking the player tracking what you've done previously communicating character or just being really fun personally I really enjoyed each and every one of these games so if I can show you how to make similar games then hopefully you will and I will get to play them my ulterior motive when I mean contextual dialogue I am referring to any kind of like state or character

speech or behavior by character that seems to be aware of what the state the world is in and what the player has done previously in the early days when games were nothing but dialogue this was pretty easy but games got complicated and so did dialogue pretty quickly our PG said the notion of conversation trees but you know you may occasionally have a character who wants to remember things like the fact that you blew up his hometown three missions previously you know might respond to you differently based on that you have to start storing explicit flags and closing off branches of trees it gets really unwieldy if you have a bunch of stuff some games don't have conversation trees but they do have characters with bark to announce their state stealth games are a canonical example of this because it's an important part of the game mechanic the player needs to be aware of what the AI knows about the player what the AI is thinking where the AI is going to go next it's actually how you play the game a great example of this I think is is once again Batman I love this game there's so much good stuff in this game among the good stuff in this game is one particular kind of AI guard who is so

explicit so clear and what he is thinking that it's like he was tailor-made for doing presentations target deployed smoke to escape target is now moving smoke target was a negative just blew the crap out of an extinguisher okay so but you can see like it's this is how the AI tells Batman how to play the game right the game is all about manipulating where the guards are moving it really is a good game I played for like a hundred hours other games use it as an artistic or a narrative device Bastian has an

omniscient narrator who responds to everything the player does with some kind of specific speech this is not because the player needs to be told what he is doing but because that's what the game is about it's about storytelling it's about creating the world through your actions that's the game let's you know that it's paying attention sports games somehow create tens of thousands of possible utterances from I don't even know how many lines and a sports game is a really highly dynamic situation where I think that all these different teams and players in the field you can't just handle this by a gigantic cascade of if else your brain would probably melt and modern RPGs track an absurd amount of state think about all the stuff that's Chiron and NASA fact remember about what you've done not just to control character outcomes in mission outcomes and conversation trees but also so that townspeople can remember that you are the elf mage that saved the town from the demon horde just a few missions previously it's how they create the feeling of a living world it's how they create the feeling the world actually responds to your actions I have no clue how all those game oops PowerPoint fail well while I'm waiting

for PowerPoint to respond I have no clue how all those games did their stuff but I can tell you how we did our stuff and that's what I will be talking about assuming PowerPoint gets back to me nightmare I'll move on to the next slide that I haven't got up in screen our system as much as possible designed to be simple a uniform one way to track all the state of the game in one place one way to find the right line for every possible circumstance from a gigantic database of circumstances and as much as possible a way for writers to to be able to create the rules database themselves I'm going to reboot PowerPoint we start the program please do not recover my information and cancel so how's the fish

and we're back Team Fortress for example a multiplayer game where you can play one of nine different character classes we wanted to make a mechanism in this game where you could hit a button and speak in your character's voice if for example I am a soldier and injured need medical attention I can push the button and have the soldier save in his voice it's not just for role-playing purposes although that's kind of the largest purpose but it's also for international play if I'm in the United States and I push the button I will hear my soldiers being speaking medic in English but if you're in Spain you're going to hear them speaking in the localized voice it's a way for players to play it across international lines to communicate simple orders and ideas to each other and have a localization system take care of it for them needed to spread Zaheer there are other characters who have to automatically announce their state to the player that is so that if for

example I'm next to a medic character and the medic is ready to heal me I know that and I know it even if the player has failed to actually push the button or spoken over his headset to remind me sentry going up and we also have a contextual dialogue button where you put your cursor over an object in the world push a button game tries to figure out what it was that you wanted to say about that thing I'm a cop so this blogger thing we also use it to communicate rivalries between individual characters that's part of the sort of role playing in the in the story of the game the engineers is by the Scout is is fine the spy is a double agent so having finished the orange box and Team Fortress and all that Valve did something kind of valve we really were not ready to go on and make another huge game straight away we're a little bit a

little bit crispy and we figured okay how about we take everybody who rolled off the project put them on little teams of like four or six people apiece and each of them comes up with some interesting design ideas some piece of code some some feature that maybe we can put into our next game do something risky you know if it doesn't pan out you only spent a couple months in it yeah but if it is cool then it can become a feature that we use from then on one of the teams ask themselves what can we do to improve companion characters in our games what can we do to make up people like Alex Vance seem more real seem like they're aware of their environment seem like they have memory so we took a bunch of half-life 2 art assets Bank together a couple characters had a programmer and an artist record some voices and created a project called two BOTS one wrench for reasons I will not describe I was going to say by the way here seen for the first time ever outside of valve some internal video I am told that Jeff Keely and his a portal last our app has already shown this video so here for the second time ever outside valve two BOTS one wrench

starting up how can we make characters aware of the environment you can do all kinds of crazy code but we we only had a couple months for like what's the easiest simplest way we can do this and we thought about that system that we had in Team Fortress 2 or you can put your cursor over an object and say something contextual about that object what we said okay how about we just tag every single object in the world with a string name like its class name and then each of the characters in the game each of the robots that we made automatically pulls his field of vision every few seconds like you are pushing that vocalized button and if it finds an object there it pulls a string name off the object it goes through its database it tries to find a line matching the name of the object and if there is one it says the line super brain-dead simple you anyone want to see me break this in the clock with me ask anyone but you someone's gonna [ __ ] miss this

materials that does sound dangerous oh there's more not done yet so this is literally all the code that you need to do that it is not even code it's barely even the script it's a text file in notepad all right you've got these rules each of the rules has a list of criteria like why am I being polled oh I've seen an object am i being shot at no what am I looking at and there's the name of the object if the writer wanted to create a new rule for a particular kind of object had some funny thing that occurred to her to him about a shoe you would put in the shoe roll if not the rule would not play all it takes to add a new line to any object in the world is just like four pieces of text right there having characters babble whatever pops into their head is well and good but we have two of them and we would like them to talk to each other once again what is the easiest simplest laziest way that I could possibly implement that can have

all kinds of ways to handle conversation is you can have an entity that binds the two characters you can have a scripted sequence you can lock both of them down it sounds like a lot of programming to me you know it's a lot easier doing the exact same thing we did before every time one character says a line he creates an event dispatches it to the other character except this time the parameter instead of being the name of the object now what is the name of the line that has just been said second character looks in his database tries to find a line corresponding to the thing that was just sent to him and says that line when he's finished he may have a line of his own send it back to the first one back and forth implementing conversation in like three hours of code Oh PowerPoint and we've crashed right while powerpoints were starting I will send a video which either screen

sorry show some current slide danger crane overhead cursor you're an idiot one be so funny when you get Chris my booty Trey what kind of incidents a trafficker in prison it's uncomfortable it is leaving my sense is a Turkish test it's true I wouldn't blink they were trying to keep something in oh not the easy prison mates yesterday it's a rather shabby great new dance every day

ah accidentally looked at it again stimulated incidentally the red bought Richard Lord the same artist who did the original Wheatley voices may have heard on YouTube right so it's great to have characters babbling at each other but you know what conversation really needs it needs running gags we needed some way for characters to remember what they had said to each other to the said to themselves and what the player had done to them once again what is the easiest possible way that we can do this well we have this notion of every time a character says a line its evaluating all these criteria about the state of the world that we passed in from the function what if along with all the other state in this function we also pass in a table that is stored in the character's head we can just have the writer store arbitrary variables just a name and a number and it can update them so the first time this robot sees a barrel it's going to go through its database it's going to find that first line and then it's going to set that scene barrels parameter to one more than it was before so the next time it sees a barrel it's going to go through the same thing

except the scene barrels criterion will match for the second row I don't feel me now PowerPoint the second row it'll play the next line and that way you can get a whole series of lines about in about an event all right switching to emergency backup laptop

and we're back that is all the code it takes to do this kind of memory mechanism right you see that first rule there for no seen barrels the first time the character sees a barrel who's gonna play that role and then it'll set that scene barrels criteria into one more for the second role that one has the additional criterion there and then one more time and then a trigger back to the other robot the entire system must be down what is wrong with you after we

finish the project and kind of overcame our laughter left4dead was going into production and we realize that left 4 dead again I'm showing you examples from left 4 dead 2 but it's the same tech left 4 dead is a game that would really benefit from this the thing about why if you haven't played it it's about 4 human survivors you and your friends against a zombie apocalypse it is a game that is designed to have high replay value there are only about 5 campaigns that ship with them about 1 hour long apiece but every time you play the game it's different because an AI director throws different situations different characters different enemies at you each time but you can see why this means that we couldn't have pre-canned audio unlike environmental triggers for example Nick the gambler cannot say the same line about the hunter zombie every time he sets foot in the warehouse for the first time because the zombie may not be there may be a different zombie you may have

seen the zombie earlier Nick may be dead moreover because you're playing the same mission a bunch of times if he played the exact same line at the exact same location it would be rapidly very tiring and as I mentioned the game was about getting to safety but not everyone makes it we needed some kind of system that could cope with characters being dead at certain points in the game and try to figure out you know what can I say with whoever happens to be alive here's a little bit of what I mean about having variety in the game this is the exact same point in the exact same mission but two different playthroughs okay first we look for supplies then we start the Midnight Rider finale it's all kinds of fireworks smoke pots and lights and [ __ ] that chopper pilot cake misses so we gotta set up to rock and fi zombieland it's been a long time since I've seen the rise but if therefore now is the

same that'll signal the chopper pilot we just need to start coach that is the stupidest idea I have ever agreed with then let's do it everybody grab a weapon and let's go in addition to canned conversations we also needed a way for AI characters to call out things they saw in the world things like ammunition caches and weapon caches are in a different place in the world and on every plate that we put weapons differently it's part of the replayability and if you're playing with human friends your friends will tell you oh there's a new weapons cache over here this time but you may not always have three human co-players you may have robots in their place the game is designed to fill out your team if you're playing alone so the robot player is needed to call these pieces of information out in the same way and once we did it for the AI as we realized it's pretty fun to have the human controlled characters talk automatically as well it helps the role-playing we have guns here

[Music] and finally left4dead is a game that tells its story through in the environment there's not a lot of cutscenes or scripted sequences the story of the zombie apocalypse is told through the environments that you move through and the objects you come across so the best opportunity for characters to express themselves for us to have character moments was to have them interact with and talk about the environment as well hey can we stop make some cotton candy seriously holy [ __ ] guys I want to ride one just one just let me ride the screaming oak once hey what are we ever gonna be here again well looks like we're going through the tunnel of people no Hagee Peggy the air-duct of love one

man cheeseburger together this kind of scale it is imperative that your writers are the ones doing your writing you want to give your writers tools not homework assignments and a lot of games like this what happens is the AI programmer while making the AI asks himself hmm well at what moments with this character like to say something let me try to guess all the times a character would speak I'll put code hooks in for that and give the right or this big spreadsheet and tell her fill this out with Kings the character could say well this reduces your writer to filling out Madeline's which is not writing it also means your programmer is the one doing the writing and the intersection between good programmers and good writers while non zero is pretty small it's kind of Vernor Vinge II really so as much as possible you really want the writers to be the ones driving when lines get said what are the circumstances what are the specific cases that need specific lines

what are the general cases that need general lines so on here's how we did it I should warn you the system is incredibly simple it is brain dead facepalm why didn't I think of that simple that is the point the system evolved by accretion it wasn't designed from the ground up it was we had this one thing in half-life and then we added something and added something if we had designed it from the ground up there was no way we could have come up with something as simple here's the general idea the big database full of rules a rule is a list of criteria that have to be met about the world like which map I'm on how many players are nearby each rule associated has a response it's just the thing that happens when the rule matches like a line playing when you want to say a line you build up a query of all the state in the world you take all the state in the world you find the rule that best matches that state when you find one you send that response over to the character character says the line you have achieved dialogue a glossary for the words I'm about to throw at you and they say context or fact it is just a piece

of state about the world like my hit points query is a bunch of those all together all the state of the world criterion is a single thing that has to be true about the world like my hit points are 5 rule is a bunch of those together and the response is the thing that happens to think about the way that we assemble these queries programmers are used to thinking of the world as a pile of facts tune hither and yon right if I'm going to play a line about a character when he's in the cave and he's got a number of allies nearby I'm used to like calling all these member functions and looking at data things and knowing where to find these things it's a few problems of this approach one is it's not discoverable it's hard to know what information is available to you to pick a pick a piece of behavior from unless you kind of put it there yourself or you've read the docs or something secondly it's kind of a palavra to get in the individual piece of information if I want the name of my ally I have to know that I have the current player object from which I call the ally function I'm going to get the thing thoroughly kind of a mess right way easier to think of the world is a flat list of fact every time you want to do a

query you just pull all that information into one place it's always there makes it way more discoverable right you can just look at the query and see what information you have available to write a rule from you don't have to go thinking very hard about where you're going to get this information from you have to do a little bit of extra work to pull all the information together in the first place but I'll show you that's actually not that much more work but there's so much more useable it is absolutely worth it so let's think about how we build up these queries an individual fact is a piece of state might hit points 457 it is just a key value pair it's a name and the value the name is a string by the way when I say string in this talk I do not mean that you should use a Const CARSTAR like a newb I am assuming that you have some kind of in turn string or presentation some kind of symbol table I'm just using the word string to mean some kind of human and readable unique identifying number a query is a pile of those together it is not usually meaningful to have the same key appear twice in the query hitpoints cannot be both 50 and 80 so really it's a dictionary it's an

associative array we have typically queries that are hundreds of items long because you pull together all the possible state of the world every time we query the database that is so that if our writer wakes up in the middle of the night with this brilliant idea for line that can be said when the zombie is on the merry-go-round next to the ice-cream machine for the third time you can you can add this line without having to ask the programmer to inject any additional state into the query it's just always there for performance reasons we have a couple of key names that are in every query and every rule you'll see why in a sec we call them the concept the general idea of being said reloading I'm hit andwho which is the person speaking makes no sense to load to play a line if you don't know who's talking to build a query you start with the function that decides it wants to speak for example let's say we have our on hit event function this is the thing that starts the events in motion it creates this query object it starts filling out the first fields and the associative array based on the things the parameters to the event and then it calls into the base speak function starts to pull

together information about the world the first wad of information we get is about the player let's say it's Nick in this case there's a bunch of stuff that we can procedurally calculate about Nick that might be relevant for a line for example his hit points his ammunition who's nearby we simply go through all the member functions all the state on Nick pull it together at the array then we take any of the arbitrary memory numbers that may have missed organic the things that the writers may have give just given arbitrary names to and triggered from rolls these two are pulled from mixed memory and add it to the array we do the same thing pulling in data from the world both procedural information like what map are we on which allies are alive have we encountered the crazy hillbilly and so forth as well as once again writers can store arbitrary state in the world it's just a key and the value take all these sources information you merge them all together into one gigantic table this is your query it's also natural to think of dialog as a

pile of rules we're used to thinking of like well in general if the henchman sees Batman he says oh look Batman unless he can kind of barely see the Hat Batman unless he works at the penguin unless works with the penguin and the penguin is dead unless you know unless unless unless unless it's really natural to think in terms of general rules and specific exceptions and exceptions to the exceptions and exceptions to the exceptions to the exceptions kind of like a like a pyramid to this end we represent each of those exceptions as a criterion which is just a function that tests a fact like is the speaker bill our hit points between 30 and 60 in computer science 'yes that's a predicate function but in practice we don't really use function pointers for this kind of thing you could but it's not much call for it a rule is a pile of those together all the criteria in a rule must match for the rule to be considered a match if a criterion mentions a key name that isn't in the query like there's a killed 5 Bunny's criterion and the query doesn't even mention bunnies the criterion is considered a fail and

because multiple rules may match a given query like if you see a zombie on the merry-go-round you're gonna say oh look at all exams aam be in the merry-go-round but the oh look a zombie mine will also match so you have to have some way to take the specific rules over the more general ones we tried a bunch of different scoring functions as always the very simplest one imaginable was the one that worked best the more criteria a rule has the more specific it is the higher it scores let's walk with really fast through a simple example of how we might match a single rule to a query let's say this is our query Nik has been hit in the circus he's partially injured he has to friend he was hit by a zombie clone let's think about all the rules we might have in the seventh overall database first one has nickman hit yes passes the next one the concept criterion does not match fails next the health criterion doesn't match fails next was a more specific criterion does he have at least one ally he does passes next are we in the circus yes we

are was it a clown yes it was was it a clown in the circus yes it was so here are the rules that have passed to start with we've got this one which has only two criteria and this one has three so we can reject the first rule it's not specific it won't play up to this point each of these rules has a score of three they each have three criteria so to this point the engine would randomly pick from any of them to say a line here they're all equally specific and we get more variety that way but in this case we have one line that is more specific it has a higher score that is the one that will play the response is an arbitrary payload it's whatever happens there's not much to say about it other than that it's okay to have a bit of intelligence in your response what we have here are number of different minor variations in the same line that are all considered the same response the game will randomly pick between them saves us the effort of having 12 parallel rules for the same notion you can also have responses that disabled themselves that move sequentially through a series of lines it's totally cool to have

arbitrary logic in your response however you implement it let's think of a simple example of how we handle right back in conversations between characters one of those convos at the beginning of a mission every few seconds a character just ask themselves do I have a line to say that's what we call the idle talk this rule a match if that's happening and there are at least three living survivors and the person speaking is that is Nick the gambler and he hasn't said this line before and he's in the swamp and he's in the start area all these things match this rule will match before it says a line it's going to write some state back to Nick's memory in this particular case simply that this line has been said and then that Nick is speaking so that other characters don't talk over him you can set an expiry time on some contexts if you like that's how you can prevent successive lines of a running gag planning too close to each other then we will play the response there is three lines in this particular response we'll choose randomly between them if

the first one plays this one it's going to ruin my white suit after it's finished the venn clause there will send this concept over to Rochelle the TV producer she'll check her database to see if she has a reply to that and she does she'll say her reply and then after that it sends an event back to Nick the gambler and back and forth could have come out differently second line could have been played after he says these swamps don't agree with me the followup goes back to Nick it creates the illusion that he's saying one longer line rather than having a back and forth conversation that way we can bail out of the conversation if we need to after you said that second line once again there's two choices he happens to pick the first one then the reply at the end of that line goes over to the mechanic mechanic checks his database he's got a line and so on this is a brain-dead simple way to create branching conversations of as many different branches as you like with a minimum of effort because as you saw each of these individual branches is maybe five lines of text in addition to

sending a reply to a specific character we also have a way to ask all of the characters nearby and do any of you have something that you want to say for example let us say that Nick is badly injured and he's unhappy about that dead yet but not exactly healthy after he finishes saying this line it's going to dispatch that a lie dying concept to any character within earshot he's going to ask every character do you have a reply that you want to say Rochelle does not and this is kind of a general of applied but coach coach is different coach is a coach he coaches people for their difficult times he has a whole bunch of really specific lines for the particular case of there being an injured Ally and if coach happens to be alive and nearby he's going to be with the one with the highest matching response come on out put it behind you good you good in addition to those general replies he also has specific ones for specific characters hey Nick Alicia dress for funeral come on Alice

you got it in you so he could play those specific lines but he still has the general lines we play them one out of sixty times for the sake of variety but moreover if we had picked up an entirely new character and dropped her into left4dead if we had picked up Zoey from left her dead one and put her in left 4 dead 2 coach would still have something to say to her even though we never recorded Zoey's specific lines for Coach he would still just fall back to the general case and we would have created the illusion that they had known each other the whole time it's also important to remember that every time we do one of these fall queries it is de novo if coach mentions his favorite rock band and the reply goes over to Ellis Ellis is not going to look up his line until coaches finished speaking the reason for this is let us say that Coach mentions his favorite rock band but while he's saying this line is obvi interferes and starts chewing on Ellis in this case we do not want Ellis to reply with some banal line about a rock band we want him to say oh my god a zombie is chewing on me so there are ways that you could have like you know a scripted conversation object

and interrupt it and so on but it's way easier if Ellis doesn't even look up his reply until coach is finished speaking then the reply that he chooses will be contingent on the criteria of the world at that exact moment and at that exact moment the not in danger criterion is no longer true so the conversation simply self terminates by virtue of its criteria no longer being that that means there's no cutscene in to get the grabs both characters there's nothing to lock them down there's no kinds of cases where people get involved in this big speech and the dragon comes and sets someone afire halfway through but they can't do anything because they're talking to each other it is also helpful if you have long speeches to cut them up into little pieces where the character says something and then sends a follow-up to himself to himself that way if you have these long monologues they can automatically bail out if something happens it also means that you've blurred the line between code and content here usually a good thing and these writers can do work that otherwise they would have had to have wait for programmers to do for them thus dependencies less merge conflicts no compile time typically it's easier to

edit and continue script then right already let us think for a moment about the machine writer interface how do we make humans interact with this crazy system there is a bit of prior art here by the way a programming language called inform 7 designed expressly for the purpose of writing text adventures which I'm now supposed to call interactive fiction has this very mechanism of rule books of general rules being overridden by more specific ones by the way this is an actual source code this is what the source code for a text adventure looks like in form is designed to have a language that resembles natural English as much as possible it's kind of suggests as to how intuitive this concept is for the sake of writing stories a programming language that exists for the sole purpose of creating dialogue as this very idea moreover when

designing the mechanism for writers to get their dialogue into the system assume that your writers are smart right writers are smart people they were not smart people that would be vice presidents of marketing and smart people know perfectly well what works for them Mark Twain did not have to be told by his editor to either purchase or throw out a typewriter let's think about different ways that we can specify these rules just write the script directly our script language happens to be the recursive descent language it's kind of human readable ish I mean I guess I could write some lines that way but it would be really painful better to have more comfortable tools for example you can always have a more natural language representation of the rules and parse from those into your script this is pseudocode but you can see how each of these individual rules has a pretty mechanical representation in the corresponding script similarly in form 7 remember this is not English this is a parsable computer

grammar if you have a parsable grammar you can always do a syntax tree transformation turn English rules and descript rules or you could use excel on dota we have a bunch of characters who have Pacific rivalries when tidehunter gets kills kumki has a specific line to say the writer and dota happens to like excel you know what it's fine we have a script that exports from excel and to our in engine script and it's actually really convenient because then we can use the same Excel spreadsheet to export from the the same Excel spreadsheet exports not only the script that the engine loads but also the paper script that the actor takes down into the recording booth and reads from its one stop for all the data we also could build visual tools I've lost screenshots but one summer I spent a few weeks building this complicated visual system that had nodes and arrows and things see here I fell into the trap that I was mentioning earlier about thinking about your particular writers when I designed

this thing I was not thinking about my writers I was thinking about writers and ask myself what do writers like writers are creative people creative people are visual visual people like bubbles and arrows and things and I spent all these weeks building this thing and then I showed it to our writers and they're like what the heck is this fisher-price toy because our writers and I forgot this or DBAs in the previous life and for them the most comfortable interface was FoxPro you know works for them they built a relational database stored all their lines it actually worked fantastic this is how we handled like 10,000 pieces of dialogue and left for dead and it was great for them they were comfortable with it the point of this is do not design systems for arbitrary hypothetical biters design for your writer that you have in your studio she is just down the hallway ask her what she wants she's the only one that you have to make happy it's also possible if you have a scripting language in your engine like Lua or squirrel or whatnot you can always use the script files as a way of loading data into the engine I

don't mean to say that you're actually going to write the database itself in script but like it the whole you know you could have like a script add rule function that sends the data over to the C++ core which parses it and stuffs it away if you're designing a system like this you must have a way to debug it here are some tools that you would pretty clearly need some non-obvious ones you want a way to figure out where individual facts come from for example if a query comes into the system and it has a line about or one of the one of the facts in the query are the dragon has been slain and you're like but the dragon has not been slain why do you think it has been you want to figure out what's sitting that fact if you have a whole bunch of rules matching you're going to want to print out which ones match and what scores they had so you can figure out inversions you want to be able to put your cursor on any object in the world and say if you were to speak right now what would your context be that you add and it's really helpful to have a way of dynamically hot swapping your scripts so it really speeds up your iteration private reserve of urine

a long-standing fascination with funny robots all right that is all of this for how you can make your writers lives easier we will have a moment here to talk about the the programming the guts of the system Sam - Goffin - nerd time before we begin allow me to remind you this is not a relational database this is not the kind of thing that you can represent as an SQL query if it were relational every criterion would be its own column whether a rule actually cared about that criterion or not we'd have all these null fields and that is neither efficient nor convenient computer scientists would say what you have here is a monadic lookup database it's a bunch of rows each row has exactly one key and one value except the key is a complex predicate function it is a couple of predicates each of which

has to be true for the whole goal to match what does that mean it's a whole bunch of functions that all of them have to return true think about how we can implement this all right query is a list of strings and variants it's an associative array when you're go to query into the system you take all the sources of data you load them together you do the big copy the associative array merge and the one gigantic dictionary that's your query then for each role in the database and for each criterion in that rule you look at the corresponding fact in the query does it match Google survives if it does not match will rejects sort them sort the survivors return the highest-scoring rule that's your speech it works that works in cubic time also pronounced as you're fired so we can do better step 1 sort the criteria and your rules and the facts in the query alphabetically right now you don't have to search back and forth in the query it's really obvious if a fact is missing from the query that

the criteria needs you have to do all there's those half searches a little bit better give a quadratic time you're still fired all right let's let's do a little bit better we can skip the merge step you don't have to do that gigantic memory copy from when you're doing your query it's only important that theoretically it's as if you had all these arrays merge together so if you simply store pointers into your data sources in parallel when you're doing your search it has the exact same theoretical result but you don't need to actually like copy the arrays around these things up a little bit you can partition your rules hierarchically if for example you always know that every rule has a criterion on who is speaking you can chop up your big table of rules that when Nick talks Nick does not query every rule in the system no no Nick only query his own rules and then you can further subdivide that by what map are you in what concept is he trying to say and so on if you do not want to have like this set of hierarchical subdivisions you know each partition having multiple other

partitions you can also hash you can take speaker and concept and map and whatever else you like concatenate them into a string from the criteria hash that string and then use that string to pick a bucket so you will have like one bucket that contains both Rochelle saying I'm reloading and Nick sitting I'm hit that way you can divide your your speech up into however many buckets you want you can chop up your rules by region of the world let us say that you have built a globe-trotting European adventure well you're going to have quests that take place in England and in quests that take place in Spain I'm certain this being quests are fantastic but when you're in Spain you do not need to even query the dialogue that is pertinent only to England so while I load it into memory you can chop up all of your dialogue into multiple databases by region see super simple databases by region you're always going to have to have global ones like ouch I'm hit but if you're in the King Arthur map there's no reason to even test the Italy rules there is even no reason to load them into memory you only have to load the ones for the partition similarly when you are assembling the

query when you're pulling together the facts about the world you don't need to pull in the Italy facts when you're doing a query in England you can store your your sources of fact in separate separate regions of memory and once again you're only pulling in England when you're in England next optimization sort your rules by decreasing number of criteria by decreasing score if a six criterion rule matches there is no need to test the five four three two one criterion rules you know that you've already found your winner so by simply sorting them in descending order in each partition you can speed up your query significantly the next optimization you can speed up the individual comparison of each criterion all right like is named Bob or hit coins I have found that almost every single criterion in the game can be represented as an interval on a number line each one can be like a greater than less than comparison for example hitpoints is obvious our zombie's greater than five well it's still an interval it's just an interval between a number and infinity on the

other side you can even represent a string comparison as an interval on a number line if you do not use strings but symbols like I told you to then each string becomes a unique integer and integer can be compared instantaneously by the way you will notice that even though we're doing an equality test here I'm still doing it as greater than or equal to and less than or equal to that is so that each and every comparison can be represented with the exact same instruction stream you can store like the type of a comparison of each criterion and say okay this one is equals to this one is greater than this one is less than but now you've got all these additional branch penalties if you cook everything so that it is always greater than less than comparison it's always X between a and B and you can always do the exact same comparison but you're always doing the exact same assembly you dramatically reduce the branch penalties that you're paying on each criterion you can get each test down to less than a nanosecond moreover if you're on a discrete number system which any computer is especially with floating-point numbers you can

always turn a strict greater than comparison into a greater than or equal to comparison by adding epsilon Epsilon here is not like some vague ill-defined small number it has a very specific meaning the terms of floating-point numbers it's this number being exactly one bit higher than this number you can also compare floating point numbers on the integer unit to speed things up significantly if you know what you're doing Bruce Dawson knows what he is doing so if you go to follow that link to his blog you will learn all there is to know about comparing floating point numbers quickly next you can go off and do some crazy math in that science land right you've got all of these different number line intervals you've got and many of them defines an n-dimensional space Q is somewhere in your n-dimensional subspace how do you find Q in subspace or you know you can do it as a spatial search with the be SPE or an artery or sort your criteria or use principal component analysis to cluster your rules or I get in fact you know don't I've tried this this way lies madness it is not even any faster because all these data structures that I have tried involve chasing so many pointers across large regions of

memory that you actually just blend up blowing your cache if you use the hierarchical partitioning method you can get it down so that you have a constant time lookup into a into a bucket of about 12 or 24 rules even across like a ten thousand-volt database once you've done that it's like you know 100 nanoseconds that test 24 rules it's perfectly fast if you are Google and you have gigantic data sets you can always reimplemented is something faster but the interface will be the same anyway so start simple right simple is what works one other corollary of the system it is purely additive if you have mods if you have user-generated content you can add new contents simply by adding new rules you don't have to like go back and change the old code if you're always packing along all the worlds state in every query you don't have to actually write code that adds new states of the query if you want a new more specific rule so if a modder wanted to add a new character class to the game then all that would have to do is add new rules pertinent to that class and even to the other characters for how they respond to this class in summary all this is is a

pattern matching engine it's a big database of criteria about the world it's a big pile of data about the world you find which rule matches the criteria in the best it is super simple that's why it works you want to you want to when you're performing your query to build the context runtime from all the state that you can possibly gather the more state you can throw at the system whether you think of a rule that needs it or not the more specific your rules can be when you finally realize that you need them you need some kind of follow-up mechanism when one character finishes speaking triggers a query on another it's much easier if you do this without having to glue both characters feet to the ground it is helpful to have some kind of write back to the world that's how you quick conditional branches so the system becomes turing-complete say crate running gags memory gives you a lot more flexibility but most importantly it has to be something that your writer wants to use the person creating dialogue in your game is your writer and the whole point of the system is that it is convenient for writers the

more creative writers are the more easily they can iterate the more autonomous they can be the more writing they will do and the more writing they will do the better dialogue you will have special thanks to everybody who helped me rehearse my talks gave me slide everyone at valve except Doug and I actually brought it in on time so are there any questions all right let's go with this microphone first hi I'm one of the issues that I've heard a number of people raise for these kinds of dynamic dialogue sequencing systems is that writers want to see how dialogue might flow so they want to see all the ways that things might come before and come after the line I'm writing now to make sure it always presents the character the way I wanted to be presented do your writers express

that desire they did which is why I decided I was going to go build that visual tool it turns out what my particular writers wanted was actually an SQL query but it is absolutely possible to build a visual tool just ask your particular writer what she wants before you build something because it's not about writers it's about your writer okay stage right right so I'm trying to wrap my head around how you would implement it from an audio perspective what middleware do you guys use to or do you use middleware to and so I didn't hear what what we use do you use audio middleware to get this stuff implemented how do you oh yeah the voice files the voice files are like waves or mp3s and we have a custom tool that just glues them together with animations so that when a scripting sequence decides to play a character he plays the animation and says the line at the same moment there's really nothing special about it it's just a sound file so you just dynamically loading packages yes yeah when the level loads up we just loaded in the the web apps by the way if you

are petitioning up your rules by region you can use that as a hint for what lines you need to load into memory very cool Thanks Stage Left uh-huh good talk thanks I had two questions one did anybody ever ask for an or I mean I know you can do rules and simple is good but I was just wondering about that yes you can have an or the easiest way to implement or actually is just to have two different rules right two different rules that both match and they will play the same line even if you represent or in the interface and the friendly script specification I recommend it's the way that you implement it internally because it'll make the branching a lot faster and like the testing faster and then the other thing I was owning about is with write back did you ever get sort of official shortening of the number of criteria such that something else that had more would win out unintended then we as I mentioned we tried a bunch of different scoring functions and in our system actually it's possible to give different criteria different weight so that some of them score more of a particular rule in practice we used it very little it's at you can see it's

really obvious for how to implement it it's just we never actually needed it okay thanks um with that prototype we were showing with the robots running around the sewer it seemed like there is a lot more going on than just the audio because they were pointing at the object in question and they were playing specific animations and so forth so I was just wondering what was going on there yes can I just use my question-and-answer slides this is fantastic yes so you can trigger entire scripts rather than just animation in speech right rather than just playing a WAV file you can actually take the facts that were presented in the query and bind them to parameters of a script that plays so a Miss in those cases we had an actual little script for the robot it wasn't the sound file I was like turn play point animation bind to thing and the things that he was turning towards were the same parameters that were used for the voice query thank you what a great talk you explained that when there

cry tears are looked at you pull information from games objects or States I was wondering do you ever run into problems that like threat problems or that you have criterias that just flip in one frame like for instance when entity is shooting is that only like on for one frame but then when you evaluate the rules you know that that bit is not on your thread or yes so on your frame we have a single threaded dialogue system which solves a lot of those problems but for things that are transient like shooting you want a store not is he shooting this frame but when is the last time that he has shot right has he shot with in the last quarter second right then that can count as the same kind of thing it gives you sort of a history in your query okay thanks yeah trying to think how to phrase it but do all of the

key values evaluate to some boolean state each criterion evaluates to a boolean result that's what makes it a predicate function in the fact the key is any string and the value can be any kind of number string whatever variant type you want as long as the relevant predicate function takes that type as its parameter but the predicate has to return true or false okay was there ever any desire to add something with more waiting two or more individual state per key or would that defeat the purpose of kissable just add more keys left Doug says he's sorry but he was really sick that he missed your thing on Monday Mike left4dead is primarily a multiplayer game wondering is there a concept of a host that plays and then propagates like the song files what song finds to play across the network or do all the peers

play them individually it might be random or like different things are you asking like is all the logic one on the host yeah I do or kind of finds themselves like play different dialogue to what the host years in our implementation it is completely client-server there's a left-footed server the clients are all done they're just telling what the server tells them to do and the server is doing all the logic that you can see it's actually not hard to implement it in a peer-to-peer way to have the clients independently pick lines sudden now you have the problem like you know they may pick different minor variations in the line you have to find some way to resolve those things we didn't because we're client-server right so if you're doing the responses to someone else's line and you have a number of characters that can all respond to the same line and logic is per speaker how do you run them all from responding at once so when we do the then any query it's like querying all the nearby characters to ask you know which of you has a response it finds the

highest-scoring one be the all the characters are being tested simultaneously in that any query we only pick the highest-scoring one if they're equally scoring we'll pick one at random because it's really kind of the character who has just said the line it was querying the neighbors to make them speak Stage Left a great talk by the way thank you I with all this dynamic content some lines are going to get played a lot more than others I know valve does a lot of data tracking to see you know how much of the game gets completed and such do you have any kind of metrics for that for how some lines that are ultra specific get played more or less often than others and was feedback on do we have a database that stores how often each line gets said yes do I ever look at it no Stage Left hi I'm actually coming from the other side of the fencing that I am actually a writer so thank you so much for making this you know this code and this tool that makes people like mine job easier but I am wondering you know in that you've taken the time to sort of help the writers out with their job how can

writers help you out with your job how can writers you know go and meet the programmers midway to you know to make your job easier well for one thing simply thinking about dialogue in this way in terms of a series of general to more specific rules matching state about the world right it's a lot more convenient than having to think of a whole bunch of explicit code hooks that are all super specific moreover being clear about what is a useful workflow because at the point that I made smart writers you know what works for them if you're clear about what works for you then I can actually build the tool that works for you as opposed to simply guessing okay thank you if there are no further questions then I have the prerogative of playing the last slide of GDC I have been waiting for this for days smooth jazz will be deployed in three two you [Music] [Applause]
